__________________________________________________________________________________ ETSHandelsregister:Bankverbindung: Electronic Technology Systems Dr. Genz GmbHAmtsgericht Frankfurt/Oder HRB 5151Sparkasse Oder-Spree Storkower Strasse 38cGeschäftsführung: Dr. Dietmar GenzBLZ 170 550 50 D-15526 Reichenwalde b. Berlin Norbert KasparKto. Nr. 3105165974 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH - ETS - STORKOWER STRASSE 38c, D-15526 REICHENWALDE B. BERLIN Tel: 033631 888 000 FAX: 033631 888660 BZT ETS Certification GmbH Storkower Str. 38c 15526 Reichenwalde b. Berlin GERMANY IHR ZEICHEN / YOUR REF.IHR SCHREIBEN / YOUR INFORM.UNSER ZEICHEN / OUR REF. DATUM / DATE 09.22.2003 Subject:Application for Certification Grandway Toys Limited. FCC ID: QK5GY220027 Dear Sirs, Submitted herewith, on behalf of Grandway Toys Limited. is an application for certification of the following R/C HELICOPTER(27MHz): FCC ID: QK5GY220027 Attached are the 731 form, technical description, test report (TestRp 1 = test data and TestRpt 2 = test plots, FCC ID label and label location information, test setup photographs, internal and external photographs, operational description, part’s list, block diagram, schematics and the user manual. Should you have any questions or comments concerning the above, please contact the undersigned. Best Regards Jenifer Täubert Electronic Technology Systems Dr. Genz GmbH Storkower Strasse 38c 15526 Reichenwalde bei Berlin Germany e-mail: [email protected]

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 1 of 13 Appendix A. Pictures ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 2 of 13 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 3 of 13 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 6 of 13 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 9 of 13

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 4 of 13 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 5 of 13 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 7 of 13 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 8 of 13 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 10 of 13 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATIONNUMBER: H1M20306012256-P-15 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 11 of 13

ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH TEST - REPORT FCC RULES PART 15 / SUBPART C Test report no.: H1M20306012256-P-15 FCC ID: QK5GY220027 FCC ELECTRONIC TECHNOLOGY SYSTEMSSTORKOWER STRASSE 38C, D-15526 REICHENWALDE B. BERLIN DR. GENZ GMBHPHONE +49-33631-888 00 FAX +49-33631-888 66 ETS Dr. Genz GmbH, GermanyRegistration number: H1M20306012256-P-15Page 1 of 26 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH TABLE OF CONTENTS 1General information 1.1Notes 1.2Testing laboratory 1.3Details of approval holder 1.4Application details 1.5Test item 1.6Test standards 2Technical test 2.1Summary of test results 2.2Test environment 2.3Test equipment utilized 2.4Test Procedure 3Test Results ETS Dr. Genz GmbH, GermanyRegistration number: H1M20306012256-P-15Page 2 of 26 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1General Information 1.1Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has Passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH. Tester: 18.09.2003N. Kaspar DateETS-Lab.NameSignature Technical responsibility for area of testing: 18.09.2003Dr. Genz DateETSNameSignature ETS Dr. Genz GmbH, GermanyRegistration number: H1M20306012256-P-15Page 3 of 26 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.2 Testing laboratory 1.2.1Location ELECTRONIC TECHNOLOGY SYSTEM DR. GENZ GMBH (ETS) Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telephone : +49 33631 888 00 Telefax: +49 33631 888 660 1.2.2Details of accreditation status A CCREDITED TESTING LABORATORY Accredited by: Bundesamt für Post und Telekommunikation (BAPT) DAR-REGISTRATION NUMBER: TTI-P-G 126/96-30 ACCREDITED COMPETENT BODY Accredited by: Bundesamt für Post und Telekommunikation (BAPT) DAR-REGISTRATION NUMBER: BPT-ZE-026/96-00 FCC FILED TEST LABORATORY REG. NO. 96970 A2LA Accredited Certification No.1983-01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) Accredited by Bluetooth Qualification Review Board INDUSTRY CANADA FILED TEST LABORATORY REG. NO. IC 3470 1.3Details of approval holder Name: Grandway Toys Ltd. Street: Rm 1201-3 & 5, Fullerton Centre, No. 19 Hung to Road Town: Kwun Tong, Kowloon Country: Hong Kong Telephone: +852 2851 6789 Fax: +852 2851 6278 Contact: Mr. Honson Chow Telephone: +852 2851 6789 ETS Dr. Genz GmbH, GermanyRegistration number: H1M20306012256-P-15Page 4 of 26 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.4 Application details Date of receipt of application :02.07.2003 Date of receipt of test item:02.07.2003 Date of test:03.07.2003 1.5 Test item Description of test item:R/C Helicopter Type identification:GY2200 Serial number:Test sample without serial number. Transmitting frequency:27.17 MHz Operation mode:simplex Transmitting mode:L1D Voltage supply9 V DC (battery) Official AC adapter for charging station Antennaintegral antenna Photos:see Annex Manufacturer: (if applicable) Name: Street: Town: Country: Additional information: ETS Dr. Genz GmbH, GermanyRegistration number: H1M20306012256-P-15Page 5 of 26 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.6Test standards Technical standard : FCC RULES PART 15 / SUBPART B §15.109/ SUBPART C § 15.203, §15.209, §15.227 2Technical test 2.1Summary of test results No deviations from the technical specification(s) were ascertained in the course
of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests performed. 2.2Test environment Temperature: 22 o C Relative humidity content: 20 ...75 % Air pressure: 86 ...103 kPa Details of power supply:: 9 V DC (battery) ETS Dr. Genz GmbH, GermanyRegistration number: H1M20306012256-P-15Page 6 of 26 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 2.3Test equipment utilized No.Test equipmentTypeManufacturer ETS 0001 Test receiverESHS 10Rohde & Schwarz ETS 0002 Test receiverESVPRohde & Schwarz ETS 0003 Test receiverESVS 10Rohde & Schwarz ETS 0004 Spectrum- and Network-AnalyzerFSMS 26Rohde & Schwarz ETS 0005 Test receiverSMV 11MEB ETS 0006 Test receiver systemSME 12MEB ETS 0008 AntennaLoop antennaSiemens ETS 0009 AntennaARA 2MEB ETS 0010 AntennaLoop antennaMEB ETS 0011 Antennavan Veen/ FrameRohde & Schwarz ETS 0012 AntennaHK 116Rohde & Schwarz ETS 0013 AntennaHL 223Rohde & Schwarz ETS 0014 AntennaHL 025Rohde & Schwarz ETS 0015 AntennaHL 025Rohde & Schwarz ETS 0016 Precision antenna kitVHAPSchwarzbeck ETS 0017 Precision antenna kitUHAPSchwarzbeck ETS 0020 AntennaDP 21MEB ETS 0021 AntennaDP 3MEB ETS 0022 AntennaSAS-200/ 521A.H. Systeme+D65 ETS 0023 AntennaDP 1MEB ETS 0024 Antenna mastAF 2MEB ETS 0025 Antenna mastAF 2MEB ETS 0026 TripodHeinrich Deisel ETS 0027 TripodHeinrich Deisel ETS 0028 TripodSTA 2C. Lorenz AG ETS 0029 TripodBerlebach ETS 0031 Turn tableDS 412Heinrich Deisel ETS 0032 ControllerHD 050Heinrich Deisel ETS 0033 RF generatorSMGRohde & Schwarz ETS 0034 RF generator/ AmplifierSMLRRohde & Schwarz ETS 0035 RF generator/ AmplifierSMLMRohde & Schwarz ETS 0038 RF amplifier150LAmplifier Research ETS 0039 Absorbing clampMDS 21Rohde & Schwarz ETS 0040 Artificial mainsESH3-Z5Rohde & Schwarz ETS Dr. Genz GmbH, GermanyRegistration number: H1M20306012256-P-15Page…
