QM6DEXA0918S06Self-Ballasted Fluorescent Lamp

User’s Manual This device complies with part 18 of the FCC rules. 1 Use only on 120V/60HZ. 2 Never disassemble or modify - any changes could void the user's authority to operate this device. 3 Not for use in totally enclosed fixtures. 4 Risk of electric shock-do not use with where directly exposed to water.. 5 This device is not intended for use with emergency exit lights. 6 This product could produce interference when used near a TV, radio, wireless remote control or maritime safety communications or other critical navigation or communication equipment operating between0.45-30MHZ. If interference should occur, move the lamp away from the appliance a distance of three feet of more. Or, plug the lamp or the appliance into a different outlet. 7 To prevent burns, do not touch the bulb during operation or immediately after switching off 8 Not for use with dimmers, electronic timer or photocell devices or occupancy sensor. 9 It dose not start up when placed below -15°C. 10 “Added weight any cause instability of free –standing portable lamps. Use only with portable lamps in which the distance from the bottom of the base to the top of the lamp holder does not exceed three (3) times minimum base width. Use only with portable table lamps which are provided with lamp shades.”

F IGURE 1 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-91) G ENERAL A PPEARANCE FIGURE 2 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-111) GENERAL APPEARANCE F IGURE 3 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-141) G ENERAL A PPEARANCE FIGURE 4 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-171) GENERAL APPEARANCE F IGURE 5 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-71) G ENERAL A PPEARANCE FIGURE 6 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-91) GENERAL APPEARANCE F IGURE 7 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-111) G ENERAL A PPEARANCE FIGURE 8 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-131) GENERAL APPEARANCE

Label Drawing Reference: One of the two labels above will be the mark of the product, while they refer to a same product. SHERRYTECH FCC ID: QM6DEXA0918S06 ANHUA FCC ID: QM6DEXA0918S06

Label Location Information Refer to the below red arrow: (for example) DEX/A3 S ERIES DSG/G0 SERIES SHERRYTECH FCC ID: QM6DEXA0918S06 SHERRYTECH FCC ID: QM6DEXA0918S06

F IGURE 1 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-91) C OVER R EMOVED F IGURE 2 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-91) PCB B OARD (C OMPONENT S IDE ) F IGURE 3 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-91) PCB B OARD (S OLDERED S IDE ) F IGURE 4 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-111) C OVER R EMOVED F IGURE 5 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-111) PCB B OARD (C OMPONENT S IDE ) F IGURE 6 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-111) PCB B OARD (S OLDERED S IDE ) F IGURE 7 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-141) C OVER R EMOVED F IGURE 8 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-141) PCB B OARD (C OMPONENT S IDE ) F IGURE 9 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-141) PCB B OARD (S OLDERED S IDE ) F IGURE 10 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-171) C OVER R EMOVED F IGURE 11 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-171) PCB B OARD (C OMPONENT S IDE ) F IGURE 12 SELF-BALLASTED FLUORESCENT LAMP (M/N: DEX/A3-171) PCB B OARD (S OLDERED S IDE ) F IGURE 13 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-71) C OVER R EMOVED F IGURE 14 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-71) PCB B OARD (C OMPONENT S IDE ) F IGURE 15 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-71) PCB B OARD (S OLDERED S IDE ) F IGURE 16 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-91) C OVER R EMOVED F IGURE 17 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-91) PCB B OARD (C OMPONENT S IDE ) F IGURE 18 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-91) PCB B OARD (S OLDERED S IDE ) F IGURE 19 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-111) C OVER R EMOVED F IGURE 20 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-111) PCB B OARD (C OMPONENT S IDE ) F IGURE 21 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-111) PCB B OARD (S OLDERED S IDE ) F IGURE 22 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-131) C OVER R EMOVED F IGURE 23 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-131) PCB B OARD (C OMPONENT S IDE ) F IGURE 24 SELF-BALLASTED FLUORESCENT LAMP (M/N: DSG/G0-131) PCB B OARD (S OLDERED S IDE )

Schematics

SHERRYTECH HK LIMITED TAIWAN BRANCH FCC ID: QM6DEXA0918S06 Page 1 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02096 Application for FCC Certificate On Behalf of SHERRYTECH HK LIMITED TAIWAN BRANCH SELF-BALLASTED FLUORESCENT LAMP Model No.: SHERRYTECH Brand: 2409S, 2411S, 2414S, 2417S, 2507S, 2509S, 2511S, 2513S ANHUA Brand: DEX/A3-91, DEX/A3-111, DEX/A3-141, DEX/A3-171, DSG/G0-71, DSG/G0-91, DSG/G0-111, DSG/G0-131 FCC ID: QM6DEXA0918S06 Prepared For : SHERRYTECH HK LIMITED TAIWAN BRANCH 3/FL NO.94 Chung chen Road. SEC 2 Taipei, Taiwan Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd., Caohejing Hi-Tech Park, Shanghai, China 200233 Tel : +86-21-64955500 Fax : +86-21-64955491 Report No. : ACI-F02096 Date of Test : Sep 18-19, 2002 Date of Report : Sep 23, 2002 SHERRYTECH HK LIMITED TAIWAN BRANCH FCC ID: QM6DEXA0918S06 Page 2 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02096 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 Test Configuration...................................................................................................................... 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures .......................................................................................................................... 7 2.7 Test Results ................................................................................................................................ 8 3 FIELD STRENGTH TEST ........................................................................................................... 16 3.1 Test Equipment......................................................................................................................... 16 3.2 Block Diagram of Test Setup ................................................................................................... 16 3.3 Test Configuration.................................................................................................................... 16 3.4 Operating Condition of EUT .................................................................................................... 16 3.5 Test Procedure .......................................................................................................................... 17 3.6 Test Result ................................................................................................................................ 17 SHERRYTECH HK LIMITED TAIWAN BRANCH FCC ID: QM6DEXA0918S06 Page 3 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02096 TEST REPORT FOR FCC CERTIFICATE Applicant : SHERRYTECH HK LIMITED TAIWAN BRANCH Manufacturer : SHANGHAI ANHUA ELECTRIC APPLIANCES CO., LTD EUT Description : SELF-BALLASTED FLUORESCENT LAMP (A) Model No.: SHERRYTECH Brand: 2409S, 2411S, 2414S, 2417S, 2507S, 2509S, 2511S, 2513S ANHUA Brand: DEX/A3-91, DEX/A3-111, DEX/A3-141, DEX/A3-171, DSG/G0-71, DSG/G0-91, DSG/G0-111, DSG/G0-131 (B) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Sep 18-19, 2002 Prepared by : Test Engineer : JEAN LIU (Assistant) LORENZO CHEN (Engineer) Reviewer : Approved Signatory : BYRON KWO (Supervisor) ALEX CHIU (Assistant Manager) SHERRYTECH HK LIMITED TAIWAN BRANCH FCC ID: QM6DEXA0918S06 Page 4 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02096 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : SELF-BALLASTED FLUORESCENT LAMP Type of EUT : ; Production … Pre-product … Pro-type Model Number : SHERRYTECH Brand: 2409S, 2411S, 2414S, 2417S, 2507S, 2509S, 2511S, 2513S ANHUA Brand: DEX/A3-91, DEX/A3-111, DEX/A3-141, DEX/A3-171, DSG/G0-71, DSG/G0-91, DSG/G0-111, DSG/G0-131 Note: Except the name, 2409S is the same as DEX/A3-91, 2411S as DEX/A3-111, 2414S as DEX/A3-141, 2417S as DEX/A3-171, 2507S as DSG/G0-71, 2509S as DSG/G0-91, 2511S as DSG/G0-111, 2513S as DSG/G0-131. In this test report, Only ANHUA Brand is noted. Applicant : SHERRYTECH HK LI…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test (M/N: DEX/A3 SERIES) (M/N: DSG/G0 S ERIES) 2. Field strength Test (M/N: DEX/A3 SERIES) (M/N: DSG/G0 SERIES)
