QMS-VG100VoIP Telephone Adaptor

1-1 VG-100 VOIP TA User Manual V1.0 August 1, 2002 Yoda Communications, Inc. 1-2 TABLE OF CONTENTS 1. Introductions ............................................................ 2. Features .................................................................. 3. Standard Compliances .......................................... 4. Packing Contents ...................................................... 5. Installations ............................................................ 6. Configurations and Operations ................................. 1-3 1. Introduction The VG-100 is a single port Telephone Adaptor for Voice over IP (VoIP), and it support H.323, SIP, and MGCP Protocols. Connecting to the Internet with an analog telephone set, the VG-100 can make a voice call over the Internet from anywhere to anyone. With portable and user friendly design, the VG-100 is very suitable for ITSP (Internet Telephony Service Providers) customers and SOHO users to make a voice call on the Internet, especially during traveling. Note that each VG-100 will need an IP address for its own use. Sometimes, the Media Access Control (MAC) address (indicated at the bottom of VG100) is needed for your local ISP/ITSP to configure your subscription. You may provide this MAC address to your local ITSP. 2. Features The VG-100 VoIP TA is equipped with one RJ11 connector for POTS, and one RJ45 connector for Ethernet Connection. Three LED indicators; POWERLANand PHONE provide the status to the user. 3. Standard Compliance The VG-100 VoIP TA supports the following standard specifications for the function of VoIP; IETF RFC 2543 [SIP: Session Initiation Protocol] 1999 ITU-T G.711 ITU-T G.723.1 ITU-T G.729A/B 4. Packing Contents Inside the package you should find: (1) One VG-100 VoIP TA (2) One DC Power Adaptor (3) One Phone cable (4) One LAN cable Please check if the packing is damaged before unpacking or any component is missing. If so, please contact the manufacturer. 1-4 5. Installation 1. Connect VG-100 LAN port to Ethernet using the Category 3 or Category 5 LAN cable. 2. Connect VG-100 PHONE port to a regular POTS using the phone cable . 3. Connect the Power Adaptor to the POWER outlet. 4. All the LED indicators will be flashing twice, then turning off except the POWER LED will remain constantly on, and the VG-100 will enter into the Normal mode operation. Note that if the LED indicators are not function properly, please check if the power adaptor is connected properly. 6. Configurations and Operations There are two operation modes for VG-100; one is for Configuration mode and the other for Normal mode. You need to configure VG-100 first before making a VoIP call. The configuration of VG-100 can be made from the telephone set and will be stored internally and remain the same until next configuration update. Once VG-100 is properly configured, you may make VoIP call anytime when VG-100 is in Normal mode. 6.1 Configuration Mode 1) Connect an analog telephone set to VG-100, and turn on the VG-100. Pick up the phone cradle, the PHONE LED will be constantly ON and you should hear the dial tone. 2) You need to enter the VG-100 IP address, subnet mask, and default gateway IP address as the following, for example, Press #7211020102004 if the VG-100 IP address is 211.20.102.4 Press #8255255255000 for the subnet mask (normally 255.255.255.0) Press #9201020102001 if the Gateway(Router) IP address is 201.20.102.1 3) After entering each item, you will hear the voice prompt for confirmation. You may also replay the voice confirmations as the following; Press #7# for the stored VG-100 IP address Press #8# for the stored subnet mask Press #9# for the stored Gateway IP address 1-5 6.2 Operation Mode After the configurations, you may now start making VOIP call by the IP address directly from the telephone set. 6.2.1 To Make Regular IP calls to another Internet Phones 1) Pick up the phone cradle, and you should hear the dial tone. 2) Press the IP address of the party you want to call as the following, for example, Press 201023005014 if IP address of the called party is 201.23.5.14 In a moment, you should hear the call progress tone (CPT), and wait for the called party to answer. 6.2.2 Redial the last IP call Pick up the phone cradle, and press *0 for redialing the last IP call. In a moment, you should hear the call progress tone(CPT), and wait for the called party to answer. 6.2.3 Memory Dial for IP call There are 6 stored IP memories can be used for IP calls. To make Memory Dial, simply Press *N for memory dialing the IP address stored in the Nth memory set. ( N=1~6 ) For example, you may press *1 for dialing the IP stored in the 1 st memory set. 6.2.4 Store the IP address for Memory Dialing To store the Nth memory set ( N=1~6 ) for IP address, for example, Press #N061219023102 if the VG-100 IP address is 61.219.23.102 To replay the voice confirmations for the Nth memory stored IP address ( N=1~6 ), simply Press #N# for the Nth memory stored IP address 1-6 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is co…

Text truncated - open the document above for the full version.

YODA COMMUNICATIONS , INC Confidentiality Request Company：YODA COMMUNICATIONS, INC. FCC ID：QMS-VG100 Product：VoIP Model：VG100 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Block Diagram The above material contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application And all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature:

Company : YODA COMMUNICATIONS, INC.Page: 1 of 68 Product : VoIPModel : VG100 <Color 1> Company : YODA COMMUNICATIONS, INC.Page: 2 of 6 Product : VoIPModel : VG100 <Color 1> Company : YODA COMMUNICATIONS, INC.Page: 3 of 6 Product : VoIPModel : VG100 <Color 2> Company : YODA COMMUNICATIONS, INC.Page: 4 of 6 Product : VoIPModel : VG100 <Color 2> Company : YODA COMMUNICATIONS, INC.Page: 5 of 6 Product : VoIPModel : VG100 <Color 3> Company : YODA COMMUNICATIONS, INC.Page: 6 of 6 Product : VoIPModel : VG100 <Color 3>

Product : Adapter for the VoIPPage: 1 of 3 Model: SP48-50700R

Company : YODA COMMUNICATIONS, INC.Page: 1 of 1 Product : VoIPModel : VG100 VoIP Model No: VG100 FCC ID： ：： ：QMS-VG100 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: [1] this device may not cause harmful interference and [2] this device must accept any interference received, including interference that may cause undesired operation. S/N： ：： ： Made in Taiwan

Company : YODA COMMUNICATIONS, INC.Page: 1 of 2 Product : VoIPModel : VG100 Company : YODA COMMUNICATIONS, INC.Page: 2 of 2 Product : VoIPModel : VG100

Product : Adapter for the VoIPPage: 2 of 3 Model: SP48-50700R Product : Adapter for the VoIPPage: 3 of 3 Model: SP48-50700R Product : Adapter for the VoIPPage: 1 of 3 Model: SP41-50350R Product : Adapter for the VoIPPage: 2 of 3 Model: SP41-50350R Product : Adapter for the VoIPPage: 3 of 3 Model: SP41-50350R

Report No.：510-9107-021F Page 1 of 14 Industrial Technology Research Institute Electronics Research & Service Organization Bldg. 17, 195-4 Sec. 4, Chung Hsing Rd., Chutung,Hsinchu, 310 Taiwan,Republic Of China TEL : 886-3-5917069 FAX : 886-3-5825720 ELECTROMAGNETIC COMPATIBILITY TEST REPORT Company ： YODA COMMUNICATIONS, INC. Address ： 2F, No. 3-1, Industry East Road IX, Hsinchu Science Based Industrial Park, Taiwan, R.O.C. Sample Name ： VoIP Model ： VG100 Date Received ： JUL. 17, 2002 Date Tested ： JUL. 25 & AUG. 08, 2002 MEASUREMENT REQUIREMENT USED ： FCC RULES AND REGULATION PART 15 SUBPART B CLASS B OCTOBER 1998 AND ANSI C63.4 MAY 1992 CISPR 22, CLASS B, 1997 WE HEREBY CERTIFY THAT: The measurements shown in the attachment were made in accordance with the procedures indicated, and the energy emitted by the equipment was found to be within the limits applicable. We assume full responsibility for the accuracy and completeness of these measurements and vouch for the qualifications of all persons taking them. NameSignatureDate Testing EngineerS. B. Lu/NVLAP Approving Manager C. F. Wu /NVLAP Notes ： 1. This report will be invalid if duplicated or photocopied in part. 2. This report refers only to the specimen(s) submitted to test, and is invalid as seperately used. 3. This report is invalid without examination stamp and signature of this institute. 4. The tested specimen(s) will be preserved for thirty days from the data issued. 5. The report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Report No.：510-9107-021F Page 2 of 14 Industrial Technology Research Institute Electronics Research & Service Organization Bldg. 17, 195-4 Sec. 4, Chung Hsing Rd., Chutung,Hsinchu, 310 Taiwan,Republic Of China TEL : 886-3-5917069 FAX : 886-3-5825720 TITLEPAGE NO. 1. GENERAL INFORMATION ...................................................................................................... 3 1.1 GENERAL STATEMENT ................................................................................................ 3 1.2 DESCRIPTION OF EUT................................................................................................... 3 1.3 DESCRIPTION OF PERIPHERALS ................................................................................ 4 1.4 EUT & PERIPHERALS SETUP DIAGRAM ................................................................... 4 1.5 EUT OPERATING CONDITION ..................................................................................... 5 1.6 DESCRIPTION OF OPEN SITE....................................................................................... 5 2. CONDUCTED EMISSION TEST............................................................................................... 6 2.1 TEST EQUIPMENTS........................................................................................................ 6 2.2 TEST SETUP ..................................................................................................................... 6 2.3 CONDUCTED POWER LINE EMISSION LIMIT .......................................................... 7 2.4 TEST PROCEDURE ......................................................................................................... 7 2.5 UNCERTAINTY OF CONDUCTED EMISSION............................................................ 7 2.6 CONDUCTED RF VOLTAGE MEASUREMENT.......................................................... 8 2.7 PHOTOS OF CONDUCTION TEST ................................................................................ 9 3. RADIATED EMISSION TEST................................................................................................... 10 3.1 TEST EQUIPMENTS........................................................................................................ 10 3.2 TEST SETUP ..................................................................................................................... 10 3.3 RADIATION LIMIT ......................................................................................................... 11 3.4 TEST PROCEDURE ......................................................................................................... 11 3.5 UNCERTAINTY OF RADIATED EMISSION................................................................ 11 3.6 RADIATED RF NOISE MEASUREMENT ..................................................................... 12 3.7 PHOTOS OF OPEN SITE ................................................................................................. 13-14 Report No.：510-9107-021F Page 3 of 14 Industrial Technology Research Institute Electronics Research & Service Organization Bldg. 17, 195-4 Sec. 4, Chung Hsing Rd., Chutung,Hsinchu, 310 Taiwan,Republic Of China TEL : 886-3-5917069 FAX : 886-3-5825720 1. GENERAL INFORMATION 1.1 GENERAL STATEMENT MEASUREMENT DEVIATION：Comply with standard in full TRACEABILITY：This test result is traceable to national or international std. 1.2 DESCRIPTION OF EUT MANUFACTURER：YODA COMMUNICATIONS, INC. SAMPLE NAME：VoIP MODEL NUMBER：VG100 SERIAL NUMBER：Not applicable POWER SOURCE：5VDC (From Power Adapter) POWER CORD：Unshielded cable, 1.8m POWER ADAPTER Manufacturer：Sincho International Inc. Model number：SP41-50350R Input：110VAC / 60Hz Output：5VDC / 350mA  Engineering Sample ， Product Sample ， Mass Product Sample. Report No.：510-9107-021F Page 4 of 14 Industrial Technology Research Institute Electronics Research & Service Organization Bldg. 17, 195-4 Sec. 4, Chung Hsing Rd., Chutung,Hsinchu, 310 Taiwan,Republic Of China TEL : 886-3-5917069 FAX : 886-3-5825720 1.3 DESCRIPTION OF PERIPHERALS （ 1 ） VoIP MODEL NUMBER ： VG100 SERIAL NUMBER ： -------------- MANUFACTURER ： YODA COMMUNICATIONS, INC. FCC ： -------------- POWER CORD ： Unshielded , Detachable , 1.8m （ 2 ） Telephone MODEL NUMBER ： K-903S SERIAL NUMBER ： 14N0000708 MANUFACTURER ： TENTEL CORP FCC ： -------------- SIGNAL CABLE ： Shielded, Undetachable…

Text truncated - open the document above for the full version.
