QO4-ISAVISH100Satellite Terminal, iSavi

Page 1 of 49 Page 2 of 49 SAFETY INSTRUCTIONS For safety and protection, please read the user guide before using the Satellite Terminal, iSavi TM Model: SH-100. In particular, do read this safety section carefully. Keep this safety information where you can refer to it, if necessary. The following general safety precautions must be observed during all phases of operation, service and repair of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this user guide violates safety standards of design, manufacture and intended use of the equipment. Addvalue Innovation Pte Ltd assumes no liability for the customer’s failure to comply with these requirements. Hazard Symbols Avoid touching the metal plate of the Transceiver (bottom/rear) during continuous operation that are marked with this symbol, otherwise it may result in injury. Evitez de toucher la plaque métallique de l'émetteur-récepteur (bas / arrière) pendant le fonctionnement continu qui sont marqués par ce symbole, sinon il peut causer des blessures. “HOT” Antenna Radiation Warning During transmission the embedded antenna in the radiates high power levels of radio frequency energy. This radiation is considered a health hazard to any personnel that come close to the antenna. It is important to maintain a distance of at least 1 metre between the transmitting antenna and any personnel. Service Users should not attempt to access the interior of the transceiver. Only qualified personnel authorized by its manufacturer may service the device. Failure to comply with this rule will result in the warranty being void. Page 3 of 49 Battery Safety Use only Addvalue-supplied or approved AC adapters with the terminal and for recharging the batteries. The use of batteries that are not Addvalue-supplied or approved may pose increased safety risks. Do not dispose of batteries in a fire, as they may explode. Batteries may burn or explode if damaged. Do not dismantle, open, bend or cut cells or batteries. Do not attempt to modify or remanufacture the battery. Do not immerse or expose the battery to water or other liquids. In the event of a battery leak, avoid the contents coming into contact with the skin or the eyes. If this does happen, flush the affected areas with water and seek medical help as appropriate. CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS ATTENTION IL Y A DANGER D’EXPLOSION S’IL Y A REMPLACEMENT INCORRECT DE LA BATTERIE, REMPLACER UNIQUEMENT AVEC UNE BATTERIE DU MEME TYPE OU D’UN TYPE ÉQUIVALENT RECOMMANDÉ PAR LE CONSTRUCTEUR. METTRE AU REBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS DU FABRICANT. Page 4 of 49 COPYRIGHT © Copyright 2014 Addvalue Innovation Pte Ltd. All rights reserved. This publication and its contents are proprietary to Addvalue Innovation Pte Ltd. No part of this publication may be reproduced in any form or by any means without the written permission of Addvalue Innovation Pte Ltd., 8, Tai Seng Link, Level 5 (Wing 2), Singapore 534158. WARRANTY Addvalue Innovation Pte Ltd has made every effort to ensure the correctness and completeness of the material in this document. Addvalue Innovation Pte Ltd shall not be liable for errors contained herein. The information in this document is subject to change without notice. Addvalue Innovation Pte Ltd makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. TRADEMARKS All trademarks, marks, names, or product names referenced in this publication are the property of their respective owners, and Addvalue Innovation Pte Ltd neither endorses nor otherwise sponsors any such products or services referred to herein. Wideye, the Wideye logo, iSavi and iSavi logo are either trademarks or registered trademarks of Addvalue Technologies Ltd and/or its affiliates in Singapore and/or other countries. Microsoft, Windows and Internet Explorer are registered trademarks of Microsoft Corporation in the U.S.A. and/or other countries INMARSAT is a trademark of the International Mobile Satellite Organization. The Inmarsat LOGO and the trademark IsatHub are trademarks of Inmarsat (IP) Company Limited. All trademarks are licensed to Inmarsat Limited. IOS is a trademark or registered trademark of Cisco in the U.S. and other countries. Android and Google Chrome are either trademarks or registered trademarks of Google Inc. Macintosh, Mac OS, iPhone, iPad and Safari are trademarks or registered trademarks of Apple Inc., registered in the U.S. and other countries. Java is registered trademark of Oracle and/or its affiliates. Firefox is registered trademark of Mozilla Foundation All other company and product names may be the registered trademarks or trademarks of their respective owners. iSavi TM Model : SH-100 User’s Guide Page 5 of 49 REGULATORY INFORMATION Federal Communication Commission Notice FCC Identifier: QO4-ISAVISH100 USE CONDITIONS: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and radiates radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equi…

Text truncated - open the document above for the full version.

FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 External Photographs Front View Rear View FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Front View Rear View

FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Label and Location Label Physical Location of Label on EUT

FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Internal Photographs Internal View1 FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Internal View2 FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 EUT Internal View 3 FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 SatelliteRF PCBA Component Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 RF PCBA Trace Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Base-Band PCBA Component Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Crystal Board Component Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Base-Band PCBA Trace Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 AntennaPCBA Component Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Antenna PCB Trace Side Satellite Antenna FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Power Switch & Pointing Mode Switch PCBA Component Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Power Switch & Pointing Mode Switch PCBA Trace Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Battery Contact PCBA Component Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Battery Contact PCBA Trace Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Battery Pack PCBA Component Side FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 Battery Pack FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 RF Module Circuit with RF Shield Removed Base-Band & WiFi Module Circuit with RF Shield Removed Wifi Module Wifi Antenna GPS Module FCC ID: QO4-ISAVISH100 IC ID: 5023B-SH100ISAVI Model Number: SH-100 WiFi Module Circuit with RF Shield Removed

Test Report No. 7191086396-EEC14/05 dated 03 Jul 2014 Note: This report is issued subject to the Testing and Certification Regulations of the TÜV SÜDGroup and the General Terms and Conditions of Business of TÜV SÜD PSB Pte Ltd. In addition, this report is governed by the terms set out within this report. LA-2007-0380-A LA-2007-0381-F LA-2007-0382-B LA-2007-0382-B-1 LA-2007-0383-G LA-2007-0383-G-1 LA-2007-0384-G LA-2007-0385-E LA-2007-0386-C LA-2010-0464-D FFT-2013-0002-A The results reported herein have been performed in accordance with the laboratory’s terms of accreditation under the Singapore Accreditation Council - Singapore Laboratory Accreditation Scheme. Tests/Calibrations marked "Not SAC-SINGLAS Accredited" in this Report are not included in the SAC- SINGLAS Accreditation Schedule for our laboratory. Laboratory: TÜV SÜD PSB Pte. Ltd. No.1 Science Park Drive Singapore 118221 Phone : +65-6885 1333 Fax : +65-6776 8670 E-mail: [email protected] www.tuv-sud-psb.sg Co. Reg : 199002667R Regional Head Office: TÜV SÜD Asia Pacific Pte. Ltd. 3 Science Park Drive, #04-01/05 The Franklin, Singapore 118223 Page 1 of 127 FORMAL REPORT ON TESTING IN ACCORDANCE WITH 47 CFR FCC Parts 2, 15, and 25 : 2012 OF A SATELLITE TERMINAL, iSavi [ Model : SH-100 ] [ FCC ID : QO4-ISAVISH100 ] TESTFACILITY TÜV SÜD PSB Pte Ltd Electrical & Electronics Centre (EEC), Product Services, No. 1 Science Park Drive, Singapore 118221 TÜV SÜD PSB Pte Ltd Electrical & Electronics Centre (EEC), Product Services, 13 International Business Park #01-01, Singapore 609932 FCC REG. NO. 99142 (3m and 10m Semi-Anechoic Chamber, Science Park) IND. CANADA REG. NO. 2932I-1 (3m and 10m Semi-Anechoic Chamber, Science Park) PREPARED FOR Addvalue Innovation Pte Ltd 8 Tai Seng Link, Level 5 (WING 2), Singapore 534158 Tel : (65) 6509 5700Fax : (65) 6509 5701 QUOTATION NUMBER 219192247 JOB NUMBER 7191086396 TEST PERIOD 06 May 2014 – 30 Jun 2014 PREPARED BYAPPROVED BY ____________________ Quek Keng Huat Higher Associate Engineer ____________________ Lim Cher Hwee Assistant Vice President Addvalue Innovation Pte LtdPage 2 of 127 Satellite Terminal, iSavi [ Model : SH-100 ] [ FCC ID : QO4-ISAVISH100 ] Test Report No. 7191086396-EEC14/05 dated 03 Jul 2014 TABLE OF CONTENTS TEST SUMMARY ........................................................................................................................................ 3 PRODUCT DESCRIPTION .......................................................................................................................... 4 SUPPORTING EQUIPMENT DESCRIPTION ............................................................................................... 6 EUT OPERATING CONDITIONS ................................................................................................................. 7 CONDUCTED EMISSION TEST .................................................................................................................. 8 RADIATED EMISSION TEST ..................................................................................................................... 11 RF OUTPUT POWER TEST ...................................................................................................................... 14 UNWANTED EMISSIONS AT ANTENNA TERMINAL TEST ...................................................................... 34 RADIATED SPURIOUS EMISSION TEST.................................................................................................. 79 PROTECTION OF AERONAUTICAL RADIO NAVIGATION SATELLITE SERVICE TEST .......................... 84 FREQUENCY STABILITY (TEMPERATURE VARIATION) TEST ............................................................... 91 FREQUENCY STABILITY (VOLTAGE VARIATION) TEST ......................................................................... 95 MAXIMUM PERMISSIBLE EXPOSURE (MPE) TEST ................................................................................ 98 ANNEX A TEST SETUP / EUT PHOTOGRAPHS / DIAGRAMS ............................................................... 100 ANNEX B USER MANUALTECHNICAL DESCRIPTION BLOCK & CIRCUIT DIAGRAMS ........................ 125 ANNEX C FCC LABEL & POSITION ........................................................................................................ 126 Addvalue Innovation Pte LtdPage 3 of 127 Satellite Terminal, iSavi [ Model : SH-100 ] [ FCC ID : QO4-ISAVISH100 ] Test Report No. 7191086396-EEC14/05 dated 03 Jul 2014 TEST SUMMARY The product was tested in accordance with the customer's specifications. Test Results Summary Test StandardDescriptionPass / Fail 47 CFR FCC Parts 2, 15 and 25: 2012 15.107(a), 15.207Conducted EmissionsPass 15.109Radiated Emissions (Class B)Pass 2.1046(a), 25.204RF Output PowerPass 2.1051, 25.202(f)Unwanted Emissions at Antenna TerminalPass 2.1053, 25.202(f)Radiated Spurious EmissionsPass 25.216(h)(i)(j)Protection of Aeronautical Radio Navigation Satellite Service Pass 2.1055, 25.202(d)Frequency Stability (Temperature Variation)Pass 2.1055, 25.202(d)Frequency Stability (Voltage Variation)Pass 1.1310Maximum Permissible ExposureRefer to page 98 for details Notes 1. Three channels as listed below, which respectively represent the lower, middle and upper channels (transmit and receive) of the Equipment Under Test (EUT) when it was configured to operate under test mode condition. Transmit Channel Frequency (GHz)Receive ChannelFrequency (GHz) Lower Channel1.6266Lower Channel1.5251 Middle Channel1.6435Middle Channel1.5420 Upper Channel1.6604Upper Channel1.5589 2. The following tests were based on conducted measurement method: a. RF Output Power b. Unwanted Emissions at Antenna Terminal c. Frequency Stability (Temperature Variation) d. Frequency Stability (Voltage Variation) 3. All test measurement procedures are according to ANSI/TIA-603-B-2002. 4. The EUT is a Class B device when in non-transmitting state and meets the FCC Part15B Class B requirements. Modifications No modifications…

Text truncated - open the document above for the full version.
