QOW-S106Studio Light

Interfit Photographic Ltd
Studio Light - FCC ID QOW-S106 - Interfit Photographic Ltd
Click to zoom

Application Details

Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Date of Grant
Nov 12, 2012
Application Purpose
Original Equipment
Date of Application
Nov 12, 2012
Equipment Note
Studio Light
Frequency Range
315.00000000 - 315.00000000
Company
Interfit Photographic Ltd
Country
United Kingdom

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Dear customer: Thank you very much for purchasing S106 remote control. The output for it are 315MHz .So you can take photos by 360°omnidirectional.Effect long-distance control speed light. One of the classical products, wear well, with long life, steadily working, multi-channels to satisfy different environment requires. In order to get more information for this product. Please read the user instruction. S106 REMOTE CONTROL INSTRUCTIONS 1.Indicator for LED test 2.Channels change 3.Modeling lamp 4.Test 5.Up/downe output adjustable 6.PC trigger 7.On/Off 8.Hot shoe connect 9.Battery Hatch Operation: a.Put the battery 23A 12V into (9),open the power (7),choose “ON” option; b.After turn on the remote control, press (2),choose the corresponding channel for light from the remote control 1-8 channels. Then you can use long-distance control, and adjust the modeling lamp, choose the output and flash. If the remote control channel not corresponding for the light channel, press TEST (4) the light will be flash; c.When the remote control channel corresponding for the light channel, long-distance control the modeling lamp (3).press one time open the modeling lamp, press second the modeling lamp will be full light, press third the modeling lamp will be close. When you press the “Mode” button (3),it will shows that the LED light corresponding the current channels will be close within 3sec; d.When the remote control channel corresponding for the light channel, press the “+”on function adjustable button (5).You can adjust the output for the flash light and make it the biggest. When you press “+”,it will shows the LED light corresponding the current channels will be close within 3sec. press the “-”on function adjustable button, you can adjust the output for the flash light and make it the smallest. When you press “-”,it will shows the LED light corresponding the current channels will be close within 3sec; e.Press the Test button one time, the flash light will be flash one time; f.SYNC (6),it can connect the camera's PC cord, trigger voltage is DC5V,3.5mm standard connect jack; h.Camera can connect with the hot shoe, then it can be remote control the flash; 1 2 3 4 6 5 7 8 9 Output 315MHz Voltage 12V/23A Sync speed 1/200S ■Function Attention: 1.Please replacement the battery when the LED shows dark, and the flash sometimes missing, also the short-distance; 2.The battery life will be influence if you always press on the buttons; 3.If you don't use for long time please choose the power button to “OFF”, or please take off the battery. It can be delay the battery life; 4.When you replacement the battery please pay attention the anode and cathode, please fix the battery correctly。 Distance ≤20m Channel 8 FCC STATEMENT: 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsiblefor compliance could void the user’s authority to operate the equipment

Cover Letter(s)

Interfit Photographic Ltd October 30, 2012 To: SIEMIC, INC. 775 Montague Expressway Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______ Interfit Photographic Ltd ___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: studio light Model name: S106, S107 FCC ID: QOW-S106 We affirm that between SIEMIC and _ Interfit Photographic Ltd __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities.

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Interfit Photographic Ltd October 30, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: QOW-S106 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application.

Cover Letter(s)

Interfit Photographic Ltd Date: October 30, 2012 To SIEMIC Inc 775 Montague Expressway Milpitas, CA 95035 Statement Model number:S106, S107 We hereby state that these models are identical in interior structure, electrical circuits and components, and just model names are different for the marketing requirement. Your assistance on this matter is highly appreciated.

ID Label/Location Info

FCC ID: QOW-S106 This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: 1.this device may not cause harmful interference received, 2.this device must accapt any interference received, including interference that may cause undesired operation. Studio light: S106 PDF created with pdfFactory Pro trial version www.pdffactory.com

Internal Photos

Antenna

Test Report

Page 1 of 28 FCC ID: QOW-S06 ACCURATE TECHNOLOGY CO., LTD REPORT NO. ATE20122314 APPLICATION CERTIFICATION On Behalf of Interfit Photographic Ltd Studio light Model No.: S106, S107 FCC ID: QOW-S106 Prepared for : Interfit Photographic Ltd Address : Unit 4 cleton Business Park, Cleton Street, Tipton, West Midlands, DY4 7TR, United Kingdom Prepared by : ACCURATE TECHNOLOGY CO., LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20122314 Date of Test : Se 29-Nov 1, 2012 Date of Report : Nov 1, 2012 Page 2 of 28 FCC ID: QOW-S06 ACCURATE TECHNOLOGY CO., LTD REPORT NO. ATE20122314 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 4 1.1. Description of Device (EUT)....................................................................................................................4 1.2. Description of Test Facility ......................................................................................................................5 1.3. Measurement Uncertainty.........................................................................................................................5 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 6 3. SUMMARY OF TEST RESULTS................................................................................................... 7 4. THE FIELD STRENGTH OF RADIATION EMISSION ............................................................ 8 4.1. Block Diagram of Test Setup....................................................................................................................8 4.2. The Field Strength of Radiation Emission Measurement Limits..............................................................9 4.3. Configuration of EUT on Measurement ...................................................................................................9 4.4. Operating Condition of EUT ....................................................................................................................9 4.5. Test Procedure ........................................................................................................................................10 4.6. The Field Strength of Radiation Emission Measurement Results ..........................................................11 5. 20DB OCCUPIED BANDWIDTH ................................................................................................ 13 5.1. Block Diagram of Test Setup..................................................................................................................13 5.2. The Bandwidth of Emission Limit According To FCC Part 15 Section 15.231(c) ................................13 5.3. EUT Configuration on Measurement .....................................................................................................14 5.4. Operating Condition of EUT ..................................................................................................................14 5.5. Test Procedure ........................................................................................................................................14 5.6. Measurement Result ...............................................................................................................................15 6. RELEASE TIME MEASUREMENT............................................................................................ 16 6.1. Block Diagram of Test Setup..................................................................................................................16 6.2. Release Time Measurement According To FCC Part 15 Section 15.231(a) ..........................................16 6.3. EUT Configuration on Measurement .....................................................................................................17 6.4. Operating Condition of EUT ..................................................................................................................17 6.5. Test Procedure ........................................................................................................................................17 6.6. Measurement Result ...............................................................................................................................18 7. ANTENNA REQUIREMENT........................................................................................................ 19 7.1. The Requirement ....................................................................................................................................19 7.2. Antenna Construction .............................................................................................................................19 APPENDIX I ( TEST CURVES) (10 pages) Page 3 of 28 FCC ID: QOW-S06 ACCURATE TECHNOLOGY CO., LTD REPORT NO. ATE20122314 Test Report Certification Applicant : Interfit Photographic Ltd Manufacturer : Ningbo Jinhui Photographic Equipment Co., Ltd EUT Description : studio light (A) MODEL NO.: S106, S107 (B) Trade Name.: Interfit (C) POWER SUPPLY: DC 1.5V (“AAA battery” 1×) Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart C Section 15.231 ANSI 63.10: 2009 The device described above is tested by ACCURATE TECHNOLOGY CO., LTD to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C Section 15.231. The measurement results are contained in this test report and ACCURATE TECHNOLOGY CO., LTD is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. Th…

Text truncated - open the document above for the full version.

Test Setup Photos

Radiated spurious emission (up to 1G): Radiated spurious emission (above 1G):

Contact Information

Applicant

Richard Harris(CEO)
[email protected]00441215224800Fax: 00441215572221

Test Firm

Accurate Technology Co., Ltd.Sean Liu
[email protected]86-755-26503291Fax: 86-755-26503396

Technical Specifications

#Rule PartsFrequency RangePower Output
115.231315 MHz - 315 MHz-
Confidentiality
Long Term
