COMPAL COMMUNICATIONS, INC. 7F, No. 319, Sec. 4, Pa-Te Rd., Taipei, Taiwan Date: May 25, 2006 Attestation We , COMPAL COMMUNICATIONS, INC., hereby declare that Pocket LOOX T830 / Pocket LOOX T810 (FCC ID: QQXUPX001) can not be used for simultaneous operation of WLAN and GSM/GPRS transmitters by software control. When the device is in WLAN mode and then receive the phone call of GSM, the software of this device will shut down the transmitting of WLAN immediately. On the contrary, as the device is in the phone mode and users would like to use WLAN function, the software will block the WLAN usage. Should you have any questions, please have my best attention. Sincerely yours, Kevin Chou COMPAL COMMUNICATION, INC. Tel: 886-2-2528-8198 ext: 18592 Fax: 886-2-8797-3771 E-mail: [email protected]

Compal Communications, Inc. 1/1 Date: 06/ 05 / 2006 Attestation We, Compal Communications, Inc., hereby declare that the device, Pocket LOOX T830 / Pocket LOOX T810, can only be operated at temperature -10 ~ 55. This device will not operate at colder temperatures by design. Sincerely, Contact Person: Kevin Chou Company: COMPAL COMMUNICATION, INC. Address: 7F, No. 319, Sec. 4, Pa-Te Rd., Taipei, Taiwan TEL: 886-2-2528-8198 ext: 18592 FAX: 886-2-8797-3771 e-mail: [email protected]

Compal Communications, Inc. 1/1 Date: 05/ 08 / 2006 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality Request for FCC IDQQXUPX001 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant hereby requests confidential treatment of information accomparrting this application As outlined below: 1. Block diagram 2. Schematics 3. Operation Description 4. Parts List 5. Tune-up Procedure (for phone) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Contact Person: Kevin Chou Company: COMPAL COMMUNICATION, INC. Address: 7F, No. 319, Sec. 4, Pa-Te Rd., Taipei, Taiwan TEL: 886-2-2528-8198 ext: 18592 FAX: 886-2-8797-3771 e-mail: [email protected]

Compal Communications, Inc. 1/1 Date: 05/ 17 / 2006 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality Request for FCC IDQQXUPX001 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents containd in this certification application be temporarily withheld from public disclosure for an initial period of 45 days: 1. External Photos 2. Internal Photos 3. Test Setup Photos 4. User’s Manual NOTE: Only exhibits not previously covered by permanent confidentiality should be listed Sincerely, Contact Person: Kevin Chou Company: COMPAL COMMUNICATION, INC. Address: 7F, No. 319, Sec. 4, Pa-Te Rd., Taipei, Taiwan TEL: 886-2-2528-8198 ext: 18592 FAX: 886-2-8797-3771 e-mail: [email protected]

COMPAL COMMUNICATIONS, INC. 7F, No. 319, Sec. 4, Pa-Te Rd., Taipei, Taiwan Tel: +886-2-2528-8198, Fax: +886-2-8797-3771 Date: Jun. 02, 2006 Power of Attorney To whom it may concern, Please be notified that we, COMPAL COMMUNICATIONS, INC. have assigned Sporton International Inc., located at No. 52, Hwa Ya 1 st Rd ., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C., as our agent. Any and all acts carried out by Sporton International Inc., on the matters of relating to all processes required in the FCC Part 24E, Part 15C and IC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. This authorization is limited to the product of as following: FCC ID: QQXUPX001 Any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Kevin Chou COMPAL COMMUNICATIONS, INC. Tel: +886-2-2528-8198 Fax: +886-2-8797-3771 E-Mail: [email protected]

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 2, 2006 RE: Compal Communications, Inc FCC ID: QQXUPX001 I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) Kindly provide separate block diagram Exhibits for both the Bluetooth and WLAN portions of this device. 2.) Please review the Internal Photos. Are pages 3&4 duplicates? 3.) Kindly provide separate photos for the WLAN and Bluetooth devices. As an alternative, please indicate where the BT and WLAN devices are located in the existing Internal Photographs. 4.) What accounts for the differences in SAR values between the models T830 and T810? Why are they so different? What is meant by the term “serial model”? If necessary kindly indicate the construction differences in the Internal Photographs. Are there any changes to antenna gain for any of these transmitters between the two models? 5.) Kindly note the SAR report has photos which are requested to be held in confidence under Short Term Confidentiality rules. FCC will permit SAR test setup photos to be moved to the Test Setup photograph section of the Application. The SAR report by itself cannot be kept Confidential. 6.) Kindly explain how this device will not be able to utilize WiFi channels 12 and 13 in North America. 7.) Please provide for me some guidance in locating the Bluetooth device in the Schematics. 8.) Kindly explain in a specific, separate attestation letter how and under what circumstances different radio sections will transmit under simultaneous conditions. 9.) A Part 15B report was included with this filing. Will DofC or Certification apply to this device as an Unintentional Radiator? 10.) I am unable to be assured of compliance with the radiated 15.205 Restricted Band edge at 2483.5 MHz. All 802.11b/g modes need to be tested across all data rates. I suggest a set of radiated plots of no more than 60 MHz span, and centered directly on 2483.5MHz, with both peak [1MHz RBW / 1MHz VBW] and average [1MHz RBW / 10Hz VBW] measurements would be helpful. These plots should be taken as radiated measurement on a 3M OATS, and not a conducted measurement at the antenna terminals. FYI: According to my estimates, a device with about +17dBm output on a 0dBi gain antenna should have a radiated field strength in excess of +110dBuV. This means that to show compliance with the limits, I should expect to see emissions offset from the fundamental at 2483.5MHz down over 54dBc. This is not able to be demonstrated with the data presented. 11.) Please identify the plot page 20 of the GSM test report. I am unable to correlate the RF power displayed to anything. What are you trying to demonstrate? 12.) Your GSM Test Report temperature data shows that the device did not turn on at any temperatures between -20C and -30C. Is this by design or are we looking at a fault with the specific sample tested? Please provide a letter from applicant attesting that this device will not operate at colder temperatures by design. 13.) The tune-up procedure states that a tolerance of +/- 2dB is allowed for RF power. FCC requires that all devices for both SAR and EMC test be tuned to the upper range of this allowance. For this case, this would translate to possibly a ~40% increase in RF power and reported SAR. Please review. z Page 2 June 2, 2006 14.) Is the manufacturers supplied holster necessary to meet SAR requirements? Is the spring clip for this holster made of metal? 15.) The contact person on Form 731 does not match the FCC database. Please confirm the contact information at FCC database and update as necessary. 16.) Kindly provide an Agent Authorization letter allowing Sporton International to act as agent for Compal Communications. William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Sent: 06/16/2006 5:52 AM To: Dward ATCB; [email protected] Cc: 陳鴻達 [major]; [email protected] Subject: RE: Project Status of FCC ID: QQXUPX001 Dear Bill, Dennis, Please find the re-tested bandedge data with smaller span. If it is OK, would you mind issuing the grant in advance? For the remaining issue, we can get them done on next Monday. Compal is pushing the grant urgently. Thanks for the consideration. BR Daniel -----Original Message----- From: Dward ATCB [mailto:[email protected]] Sent: Thursday, June 15, 2006 4:46 AM To: Daniel Lee (琄㎝) Cc: '朝翬笷[major]'; [email protected]; [email protected] Subject: RE: Project Status of FCC ID: QQXUPX001 HI Daniel / Major I thought sending an email for clarification would be better than another RT. A couple issues: 1 the response states that “Compal will disable channel 12 and 13 for the NA market products” – What evidence is there to this statement? Please provide some evidence that this is done – either an attestation etc. Please make this evidence from the manufacturer (i.e. on their letter head etc). Please remember that the device tested according to the FCC rules must be a representative market sample not an engineering or prototype sample. As such the disabling of these channels is to be as sold in the US. 2 Please note that as Bill mentioned in his comments (item 10) wide spans (i.e. in this case greater than 2 and 3GHZ) is not an appropriate span to measure field strengths in the restricted bands – especially when the margins are as close (i.e. less than 1dB) to the limit. The reason is simple – the analyzer does not provide sufficient resolution to the signal in such a wide span mode. For signals that are within 1dB in the restricted bands it is very important not to miss any possible portion of the signal that would be over the limit. In extremely wide spans this is not possible. The FCC accepted procedure states that the analyzer res bw is to be 1MHz and the span is to be in autospan. It is unlikely that the auto span for this would be 3GHz. Please show some evidence that the signals within 1dB of the limit in the restricted bands clearly meet compliance requirements using a span that insures maximum emissions have not been missed. Please provide the data Bill requested using a span sufficient to assure compliance data accuracy (i.e. less than 60MHz, res BW 1MHz etc) 3 Your response to item 10 is confusing. You state that the data tables and plots on pages 34 to 36 are radiated spurious emissions. This is not supported by the report. Please note that the page 34 (Band Edge) clearly states that the device output was connected to the input of the analyzer and not tested on a 3 meter site. Please provide radiated test data to support proper compliance in the restricted bands. 4 the op description states W-CDMA is selectable by a switch. Please confirm and verify that this W- CDMA is not an option (disabled) in the US or alternately provide test data to support W-CDMA. 5 Please note that you have requested short term confidentiality. However, please also note that the device external photos are clearly visible in the setup photos that are contained in the revised SAR report. Unless these are removed and provided in a separate exhibit the exterior of the device will 06/20/06 be public knowledge. Please remove the EUt photos from the revised SAR report and provide these setup photos in a separate exhibit. 6 FYI – since the SAR setup photos show only the provided belt clip and since no evidence that other accessories can be used with the device, only the provided accessories will be allowed on the grant. IF a condition for accessories with no metal are provided please point to the specific test data. Thanks Dennis Ward Evaluation Engineer American TCB Certification Resource for the Wireless Industry www.atcb.com 703‐847‐4700 fax 703‐847‐6888 direct ‐ 703‐880‐4841 cell ‐ 209‐769‐8316 NOTICE: This E‐Mail message and any attachment may contain privileged or company proprietary information. If you received this message in error, please return to the sender. 06/20/06

FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A1 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 APPENDIX A. External Photographs of EUT APPENDIX A. External Photographs of EUT T830 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A2 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 T810 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A3 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A4 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A5 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A6 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A7 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A8 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A9 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A10 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A11 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A12 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A13 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A14 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A15 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A16 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A17 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A18 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : A19 OF A19 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev.01

FCC ID : QQXUPX001 IMEI: 35889800100001 M/N:10600622946 S/N:YEXXxxxxxxxxxx P/N:S26391-K182-V835 Made in Taiwan Pocket LOOX T830 Agency Series PLT800MD IC : 4626A-UPX001 2006.04 REV.01 xxxxxx xxxx 0889 1.0A 43.4 +/- 0.1 mm 19.5 FCC ID : QQXUPX001 IMEI: 35889800100001 M/N:10600622946 S/N:YEXXxxxxxxxxxx P/N:S26391-K182-V835 Made in Taiwan Pocket LOOX T830 Agency Series PLT800MD IC : 4626A-UPX001 2.5 9.0 10.5 39.0 +/- 0.1 mm 3.5 39.9 2006.04 REV.01 xxxxxx xxxx 0889 1.0A

UPL2 1.0A 43.4 +/- 0.1 mm 19.5 FCC ID : QQXUPX001 IMEI: 35889800100001 M/N:10600622944 S/N:YEXXxxxxxxxxxx P/N:S26391-K182-V815 Made in Taiwan Pocket LOOX T810 Agency Series PLT800MD IC : 4626A-UPX001 2.5 9.0 10.5 39.0 +/- 0.1 mm 3.5 39.9 2006.04 REV.01 xxxxxx xxxx 0889 1.0A FCC ID : QQXUPX001 IMEI: 35889800100001 M/N:10600622944 S/N:YEXXxxxxxxxxxx P/N:S26391-K182-V815 Made in Taiwan Pocket LOOX T810 Agency Series PLT800MD IC : 4626A-UPX001 2006.04 REV.01 xxxxxx xxxx 0889

FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B1 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 APPENDIX B. Internal Photographs of EUT FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B2 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B3 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B4 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 GSM Antenna FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B5 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B6 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B7 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B8 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B9 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 BT Antenna WLAN Antenna BT FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B10 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B11 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 WLAN GSM FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B12 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B13 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B14 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B15 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC/IC TEST REPORT REPORT NO. : FG650602-A SPORTON International Inc. Page Number : B16 OF B16 TEL : 886-2-2696-2468 Report Issued Date : May 18, 2006 FAX : 886-2-2696-2255 Report Version : Rev. 01

©2006 SPORTON International Inc. SAR Testing Lab This report shall not be reproduced except in full, without the written approval of Sporton. Rev. 01 FCC SAR Test Report Test Report No FA650602-1-2-01 Specific Absorption Rate (SAR) Test Report for COMPAL COMMUNICATIONS, INC. on the PDA Phone Report No. : FA650602-1-2-01 Trade Name : Fujitsu Siemens Computers GmbH Model Name : Pocket LOOX T830 / Pocket LOOX T810 FCC ID : QQXUPX001 IC ID : 4626A-UPX001 Date of Testing : Apr. 28, May 10 and 29, 2006 Date of Report : May 30, 2006 Date of Review : May 30, 2006 ‚ The test results refer exclusively to the presented test model/sample only. ‚ Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. ‚ Report Version: Rev. 01. SPORTON International Inc. 6F, No.106, Sec. 1, Hsin Tai Wu Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. 1190 ILAC MRA ©2006 SPORTON International Inc. SAR Testing Lab This report shall not be reproduced except in full, without the written approval of Sporton. Rev. 01 Tel:886-22696-2468 Fax:886-2-2696-2255 FCC SAR Test Report Test Report No FA650602-1-2-01 Table of Contents 1. Statement of Compliance ---------------------------------------------------------------------------------------------------------------------------------- 1 2. Administration Data ------------------------------------------------------------------------------------------------------------------------------------------ 2 2.1 Testing Laboratory -------------------------------------------------------------------------------------------------------------------------------------- 2 2.2 Detail of Applicant--------------------------------------------------------------------------------------------------------------------------------------- 2 2.3 Detail of Manufacturer --------------------------------------------------------------------------------------------------------------------------------- 2 2.4 Application Detail---------------------------------------------------------------------------------------------------------------------------------------- 2 3. General Information------------------------------------------------------------------------------------------------------------------------------------------ 3 3.1 Description of Device Under Test (DUT) ---------------------------------------------------------------------------------------------------------- 3 3.2 Product Photo-------------------------------------------------------------------------------------------------------------------------------------------- 4 3.3 Applied Standards:-----------------------------------------------------------------------------------------------------------…
