CardioMessenger II ® Transmitter for BIOTRONIK Home Monitoring ® sbiotronik Technical Manual 356845_Cover_CMII_US.qxd 10.05.06 13:45 Seite 1 Overview Physician callback signal . . . . . . . . . . .Follow-up data transmission . . . . . . . .Ready (CardioMessenger II) . . . . . . . . .Battery monitor light . . . . . . . . . . . . . . .Ready (charging station) . . . . . . . . . . . .Data interface A view of the rear side of the device can befound on the back cover. 356845_Cover_CMII_US.qxd 10.05.06 13:45 Seite 2 Overview On/off buttonRestartPower supply portTelephone jackBelt clip 356845_Cover_CMII_US.qxd 10.05.06 13:45 Seite 3 BIOTRONIK GmbH & Co. KGWoermannkehre 112359 Berlin · GermanyTel +49 (0) 30 68905-0Fax +49 (0) 30 6852804BIOTRONIK, Inc.6024 SW Jean rd. Bldg. BLake Oswego, OR 97035Phone (800) 547-0394 (24-hr)Fax (503) 635-9936sales @ biotronik.com www.biotronik.com © by BIOTRONIK GmbH & Co. KG All rights reserved. Specifications subject to modification, revisionand improvement. ® CardioMessenger is a r egistered trademark of BIOTRONIK GmbH & Co. KG sbiotronik 356845/A/6D20 356845_Cover_CMII_US.qxd 10.05.06 13:45 Seite 4 1 ContentsWhat is Home Monitoring? . . . . . . . . . . . . 3Included Equipment . . . . . . . . . . . . . . . . . . 4How Do I Use the CardioMessenger? . . . . 6Where Should I Put the CardioMessenger? 6How Do I Install the CardioMessenger? . . 9 Telephone Connection . . . . . . . . . . . . . 12 Version A . . . . . . . . . . . . . . . . . . . . . . . . 13 Version B . . . . . . . . . . . . . . . . . . . . . . . . 19 How Do I Understand the Lights of the CardioMessenger? . . . . . . . . . . . . . . . . . . 25 Light 1 . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Light 2 . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Light 3 . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Light 4 . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Light 5 . . . . . . . . . . . . . . . . . . . . . . . . . . 28 How Do I Turn On the CardioMessenger? 29How Do I Turn Off th e CardioMessenger? 30 How Do I Charge the CardioMessenger? . 31How Do I Resolve Problems? . . . . . . . . . . 32 Light 3 . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Light 4 . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Light 5 . . . . . . . . . . . . . . . . . . . . . . . . . . 33 How Do I Reset the CardioMessenger? . . 34How Do I Take Care of the CardioMessenger? . . . . . . . . . . . . . . . . . . . 35 How Do I Carry the CardioMessenger? . . 36Safety Precautions - What Should I Watch Out For? . . . . . . . . . . . . . . . . . . . . . . . . . . . 38Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . 40USA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Electromagnetic Compatibility . . . . . . . . . 42Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 CardioMessenger.book Page 1 Tuesday, May 2, 2006 5:05 PM 2 Technical Data . . . . . . . . . . . . . . . . . . . . . . 44General . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Permissible Environmental Conditions . . 44 During Operation: . . . . . . . . . . . . . . . . . 44 Shipping and Storage: . . . . . . . . . . . . . 44 CardioMessenger Remote Unit . . . . . . . . 44CardioMessenger Charging Station . . . . 45Rechargeable Battery (integrated) . . . . . 45Power Supply . . . . . . . . . . . . . . . . . . . . . . . 45 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . 46 CardioMessenger.book Page 2 Tuesday, May 2, 2006 5:05 PM 3 What is Home Monitoring?Dear Patient:You have received a BIOTRONIK pacemaker or implantable cardioverter-defibrillator (ICD) with Home Monitoring function. Home Monitoring pacemakers and ICDs are additionally equipped with a special transmitter. This transmitter automatically transmits medical and technical information to a mobile device, the CardioMessenger. The CardioMessenger works like a cell phone and automatically transmits the information received from your implant as encoded messages to the BIOTRONIK Service Center.The transmission power from your implant is low so as to not impair your health in any way. Since the transmis sion range is short, the CardioMessenger is needed to send the information to the BIOTRONIK Service Center.At the Service Center, the data are processed and can be viewed only by your physician on a secured Internet site in the form of a comprehensive report called a Cardio Report. Your doctor can use this Cardio Report to decide whether your implant settings need to be updated or if your therapy plan needs to be changed. Thus, Home Monitoring serves as a practical diagnostic aid. CardioMessenger.book Page 3 Tuesday, May 2, 2006 5:05 PM 4 Included EquipmentThe set comes equipped with the following components:1. Mobile unit2. Charging station3. Power supply unit4. Power supply cable5. Belt clip (already affixed)6. Carrying strap7. Patient manual8. Telephone cable CardioMessenger.book Page 4 Tuesday, May 2, 2006 5:05 PM 5 Before use, make sure that none of the components are visibly damaged and that all necessary components have been delivered to you. Caution! Never use the CardioMessenger if it has been damaged; return it to your physician. Only use the following original BIOTRONIK devices, as other accessories can increase the interference emitted and the device's susceptibility to interference:- The CardioMessenger- The charging station with the appropriate power supply unit (type: FW 7555 M/06)- The power cord (type: BIOTRONIK NK-29, NK-30, or NK-31) - The telephone cord (type: BIOTRONIK VK-117) CardioMessenger.book Page 5 Tuesday, May 2, 2006 5:05 PM 6 How Do I Use the CardioMessenger?The following section describes: 2 How to optimize CardioMessenger placement 2 How to operate it 2 How it functions Where Should I Put the CardioMessenger?On your bedside table or close to your bed is a suitable place for your CardioMessenger since it generally fulfills …

Text truncated - open the document above for the full version.

15 Take the telephone cable that came with the CardioMessenger, remove the second safety plug from the charging station and plug one end of the telephone cable into the port. CardioMessenger.book Page 15 Tuesday, May 2, 2006 5:05 PM 16 Insert the other end of your telephone cable into the telephone socket in your wall. CardioMessenger.book Page 16 Tuesday, May 2, 2006 5:05 PM 17 Now, place the CardioMessenger into the charging station. The CardioMessenger should switch itself on immediately, unless the batteries are completely depleted. A brief tone will sound when the CardioMessenger is switched on. If the batteries are completely depleted, then the CardioMessenger first charges itself and then switches itself on later (approximately after 30 minutes). Additional information can be found in „Version B" on page 19. CardioMessenger.book Page 17 Tuesday, May 2, 2006 5:05 PM 18 When you are finished, the connection should look like as follows: CardioMessenger.book Page 18 Tuesday, May 2, 2006 5:05 PM 19 Version BIf you wish to set up the CardioMessenger close to a telephone outlet, but there is no telephone, you may connect the CardioMessenger directly to the telephone outlet. Please proceed as follows:Take the telephone cable that came with the CardioMessenger and remove the safety plug on port 1 on the rear side of the charging station. CardioMessenger.book Page 19 Tuesday, May 2, 2006 5:05 PM 20 Now insert one end of your telephone cable into the port of the charging station. CardioMessenger.book Page 20 Tuesday, May 2, 2006 5:05 PM 21 Insert the other end of your telephone cable into the telephone socket in your wall. CardioMessenger.book Page 21 Tuesday, May 2, 2006 5:05 PM 22 Now, place the CardioMessenger in the charging station. The CardioMessenger should switch itself on immediately, unless the batteries are completely depleted. A brief tone will sound when the CardioMessenger is switched on. If the batteries are depleted, then the CardioMessenger first charges itself and then switches itself on later (approximately after 30 minutes). Additional information can be found in „Version B" on page 18. CardioMessenger.book Page 22 Tuesday, May 2, 2006 5:05 PM

23 When you are finished, the connection should look like as follows: CardioMessenger.book Page 23 Tuesday, May 2, 2006 5:05 PM 24 CardioMessenger.book Page 24 Tuesday, May 2, 2006 5:05 PM 25 How Do I Understand the Lights of the CardioMessenger?Your CardioMessenger has four lights and one light on the ch arging station. The lights numbered 1 - 3 represent the general functions of the CardioMessenger, light 4 is the battery mo nitor light, and light 5 shows the operational status of the charging station.Note: Whether or not the li ghts flash or are lit continuously, the operation of your implant remains unaffected. Light 1 Off – This is the normal status. Yellow flashing – When this light flashes yellow, your physician wa nts you to call. This situation may never occur. You will be informed by your physician if s/he will use this feature. CardioMessenger.book Page 25 Tuesday, May 2, 2006 5:05 PM 26 Note: After you have switched the CardioMessenger off and on, this light will not flash anymor e. However, please do not forget to call your physician. Light 2 This light will only be used during a follow- up visit and can be triggered via the implant programmer ICS 3000. Your physician will find further information in the ICS 3000 manual.Note: Light 2 is not illuminated when your implant transmits regular messages. This light may be illumi nated or flash yellow, or flash green. Off – This is the normal status. Yellow illumination – When the light is illuminated yellow, the CardioMessenger is receiving a message. Please wait until the data transmission has finished (light flashing green) before yo u walk away from the CardioMessenger. Green flashing – When the light flashes green several times, the transmission of the message has been completed.Yellow flashing – However, when the light flashes yellow several times, the transmission was not successful. Your physician will decide what to do next. Light 3 This light informs you about the normal operation of the CardioMessenger. Green flashing – When the light sing le-flashes green repeatedly, the CardioMessenger is operating properly. This is the normal status. CardioMessenger.book Page 26 Tuesday, May 2, 2006 5:05 PM 27 Green flashing – When the light double-flashes green repeatedly, the CardioMessenger is also operating properly. Additionally, there are messages stored that have to be transmitted to the Service Center.Yellow flashing – When the light doubl e-flashes yellow repeatedly, there is no connection to the GSM network or modem and additionally the CardioMessenger has messages stored to be transmitted to the Service Center. For further information, see the „How Do I Resolve Problems?" on page 32. Yellow illumination – When the light is illuminated yellow, the CardioMessenger is performing a self-test. This test should last no longer than 10 seconds after the CardioMessenger has been switched on. Off – The CardioMessenger is switched off. Light 4 In the following, the four statuses of the battery monitor light are described as follows:Green Illumination – When the light is illuminated green, the CardioMessenger is fully charged. You may now use it in mobile operation for at least 24 hours. But the CardioMessenger can certainly also be kept in the charging station. Off – This is the normal status when the CardioMessenger is used in mobile operation.When this light is off but the CardioMes-senger is in the char ging station, please refer to „How Do I Resolve Problems?" on page 32. CardioMessenger.book Page 27 Tuesday, May 2, 2006 5:05 PM 28 Red flashing – When the light flashes red, the CardioMessenger batteries are nearly depleted. Please place the CardioMessenger in the charging station.Yellow illumination – When the light is illuminated yellow, the CardioMessenger is charging. Light 5 Green Illumination – This is the normal status when the charging station is connected to the power supply. If this is not the ca se, there might be an error. Additional information can be found in „How Do I Resolve Problems?" on page 32. CardioMessenger.book Page 28 Tuesday, May 2, 2006 5:05 PM 29 How Do I Turn On the CardioMessenger?As soon as you place the CardioMessenger in the charging station, it is automatically switched on. You certainly may also switch on the CardioMessenger when it is not placed in the charging station; the On/Off button is located on the right side of the CardioMessenger.Press the On/Off button of the CardioMessenger until you can feel slight resistance. A brief tone will sound, the CardioMessenger will start its self-test, and light 3 will be illuminated yellow. You can now release the button. CardioMessenger.book Page 29 Tuesday, May 2, 2006 5:05 PM 30 When the self-test of the CardioMessenger has finished, light 3 flashes yellow. Now, the CardioMessenger will try to connect to the BIOTRONIK Service Center.After a successful connection to the Service Center, light 3 flashes green. Your CardioMessenger is now operational. In case light 3 does not flash green, please refer to „How Do I Resolve Problems?" on page 32. Note: When the CardioMessenger has not been used for a long time or if it was stored below operational temperature, the battery can be completely depleted. In this case, the CardioMessenger switches itself on only after the battery has been charged for about 30 minutes. How Do I Turn Off the CardioMessenger?Press and hold the CardioMessenger On/Off button for at least two seconds. A brief tone will sound and light 3 wi ll go out after a short period of time.The CardioMessenger is switched off; no data can be received or transmitted.Note: A switched-off or improperly functioning CardioMessenger does not affect the operation of your implant. CardioMessenger.book Page 30 Tuesday, May 2, 2006 5:05 PM 31 How Do I Charge the CardioMessenger?The CardioMessenger has to be charged when the battery moni tor light (light 4) flashes red. If you wish to use the CardioMessenger in mobile operation, you should charge it every 24 hour…

Text truncated - open the document above for the full version.
