QRO2350-49RXRC Car

Fig 7 Fig 8 Fig 9 Handling Mutator ® Always pick up and hold your Mutator vehicle from the back as shown, or from the front and back with both hands. Keep hair, hands, fingers, face and loose clothing away from wheels while the vehicle is switched on or while the transmitter is operating. Never pick up by the wheels. (Fig. 1) Battery Charging and Care (Battery Pack and Charger included only with Mutator model no. 2351; not included with model no. 2350. Retailer decides which version to carry.) Vehicle will not run without a 9.6V rechargeable NiCd or NiMH battery pack and matching charger, commonly available for R/C vehicles at many toy and hobby dealers. Always follow the instructions that came with your battery pack and charger. Adult supervision of battery charging is required. Dr ain Down — Cool Down — Charge Up 1. For best performance, run battery pack ALL THE WAY DOWN before recharging. Run until wheels slow to a stop. 2. Allow the battery pack to cool AT LEAST 20 MINUTES before recharging. 3. Charge fully according to the battery/charger manufacturer's instructions. Charging times differ with different types, brands, models, ages and conditions of battery packs and chargers. The first few charges of a new battery will provide shorter run times than later charges. You may need to repeat steps 1, 2 and 3 six or seven times to break in battery. Battery Heat 1. Battery gets hot after use! This is normal, but be careful. Wait until battery is cool (20 minutes or more if needed) before charging. Charging batteries when they are hot will severely reduce the number of times they can be recharged. 2. After charging, battery pack will be warm. This is normal. Running and Charging Times 1. NiCd and NiMH battery packs are not like alkaline batteries. They lose all their power suddenly, not gradually, and vehicle will stop very soon after slowing down becomes noticeable, with little warning. This is normal. 2. Typical running time will be between 9 to 15 minutes for a typical freshly charged NiCd battery pack in good condition, depending on how you operate your vehicle, but observe how long your battery runs in your vehicle under the conditions you operate in. Running time may vary over life of battery, with the first 6 charge cycles yielding significantly shorter run times than later charges. "Cycle" your battery (Drain Down/Cool Down/Charge Up) at least 6 times before evaluating run time. IMPORTANT: NEW RECHARGEABLE BATTERIES NEED SEVERAL CHARGE/DISCHARGE CYCLES TO DELIVER MAXIMUM POWER AND LONGEST RUNNING TIMES. A FRESHLY CHARGED BATTERY (STILL WARM) WILL DELIVER THE LONGEST RUNNING TIME. Battery Installation The bed lid of the vehicle removes to reveal the battery compartment. 1. Push BATTERY LATCH on the back of the vehicle downward to open and remove BATTERY LID. (Fig. 2 & 3) 2350-US "POWER ON" LIGHT Note: There is no on/off switch on Transmitter. Moving the sticks turns it on. It turns off after a period of non-use to save battery power. RIGHT STICK Left — Straight -— Right LEFT STICK Forward Neutral Reverse ANTENNA Hold Transmitter so antenna points straight up in the air. Don't touch during operation. ® MUTATE BUTTON Fig 1 Fig 2 Fig 3 Fig 6 Fig 5 Fig 4 Fig 10 Mutation Operation MUTATE BUTTON on back of transmitter controls MUTATE ACTION. Press to cycle through the 4 main MUTATE POSITIONS and everything in between. Release button when desired position is reached. If you miss the exact position you want, just press again until it comes around again. Start with the MAIN 4 MUTATE positions and invent your own ENERGETICALLY ENGINEERED MUTATIONS! See next page for Stunt Guide. Transmitter Operation 1. LEFT STICK controls POWER. Move stick up to go forward. Release to coast. Move down to brake or go in reverse. "PULSE" THE STICK (rapid push up-release-push up-release) for slower speeds and better maneuverability. 2. RIGHT STICK is STEERING. Move stick to left to turn left, release to go straight, to right to go right. Transmitter Battery Installation 1. Slide open BATTERY DOOR on back of TRANSMITTER. (Fig. 7) 2. Insert a fresh, new 9-VOLT ALKALINE BATTERY with the polarity (+/-) as shown on the bottom of battery compartment. (Fig. 8) 3. Hold battery in place with thumb and replace BATTERY DOOR. (Fig. 9) 4. Check for transmitter operation by looking for the red "POWER ON" LIGHT on front to light when a JOYSTICK is pushed. If LIGHT does not come on, check battery polarity. If LIGHT still does not light, install a brand-new battery. 2. Plug BATTERY PLUG into VEHICLE JACK as shown. (Fig. 4) 3. Place fully and freshly charged BATTERY PACK into BATTERY COMPARTMENT and place PLUG/JACK/WIRE as shown so they're out of the way when you replace the LID. (Fig. 5) 4. Replace BATTERY LID and press into place until LATCH secures it in place. (Fig. 6) TRIM CONTROL: If vehicle steers to one side when you release the right stick, move TRIM CONTROL on bottom of vehicle slightly in the opposite direction to correct. (Fig. 10) Test (with the vehicle driving away from you) and readjust if needed. OWNER'S MANUAL SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. THEY CONTAIN IMPORTANT INFORMATION. Important! Please read your Owner's Manual all the way through before operating your vehicle. Safety First • Adult supervision is recommended. • Drive your vehicle in a safe area away from people, pets, cars, etc. Not in streets, in or near water, or in darkness! • Don't touch or try to pick up vehicle when it is in motion or while it is mutating. Wait until it stops completely. Never pick up by the wheels. • Keep hair, fingers, face and loose clothing away from wheels while the vehicle is switched on or while the transmitter is operating. • Be a responsible Mutator ® operator! DO NOT RUN VEHICLE IN WATER OR RAIN—WARRANTY WILL BE VOIDED Batteries and Charger Required (9.6V Battery Pack and Charger included only with Mutator model no. 2351; not included with model no. 2350. Retailer decides which version to carry.) 1. 9.6-Volt …

Text truncated - open the document above for the full version.

FCC ID : QRO2350-49RX Ophoto1 Ophoto2 FCC ID : QRO2350-49RX Ophoto3

FCC ID : QRO2350-49RX Iphoto1 Iphoto2 FCC ID : QRO2350-49RX Iphoto3 Iphoto4

FCC ID: QRO2350-49RX Technical Description : The brief circuit description is listed as follows : - Q1 and associated circuit act as Super-Regenerative Receiver. - IC1 and associated circuit act as Decoder. - Q3 ~ Q8 and Q11 ~ Q16 and associated circuit act as Motor Drive Circuit. Antenna Used : An internal permanent wire antenna has been used.

• The test results reported in this report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited • The evaluation data of the report will be kept for 3 years from the date of issuance. FCC ID : QRO2350-49RX Taiyo Edge (HK) Limited Application For Certification (FCC ID: QRO2350-49RX) Superregenerative Receiver Sample Description : Mutator, Model : 2350 0309072 WN/at June 27, 2003 INTERTEK TESTING SERVICES FCC ID: QRO2350-49RX i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: QRO2350-49RX ii MEASUREMENT/TECHNICAL REPORT Taiyo Edge (HK) Limited - MODEL: 2350 FCC ID: QRO2350-49RX June 27, 2003 This report concerns (check one:) Original Grant X Class II Change Equipment Type: Superregenerative Receiver (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart B for intentional radiator Report prepared by: Wilbur Ng Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, HONG KONG Phone: 852-2173-8502 Fax: 852-2742-9149 INTERTEK TESTING SERVICES FCC ID: QRO2350-49RX iii Table of Contents 1.0 General Description................................................................................................................. 2 1.1 Product Description.............................................................................................................. 2 1.2 Related Submittal(s) Grants.................................................................................................. 2 1.3 Test Methodology ................................................................................................................ 3 1.4 Test Facility.......................................................................................................................... 3 2.0 System Test Configuration ...................................................................................................... 5 2.1 Justification .......................................................................................................................... 5 2.2 EUT Exercising Software .....................................................................................................5 2.3 Support Equipment List and Description .............................................................................. 5 2.4 Equipment Modification....................................................................................................... 6 2.5 Special Accessories.............................................................................................................. 6 3.0 Emission Results ....................................................................................................................... 8 3.1 Field Strength Calculation .................................................................................................... 9 3.2 Radiated Emission Configuration Photograph .................................................................... 10 3.3 Radiated Emission Data .....................................................................................................11 4.0 Equipment Photographs ........................................................................................................ 14 5.0 Product Labelling ................................................................................................................... 16 6.0 Technical Specifications......................................................................................................... 18 7.0 Instruction Manual ................................................................................................................ 20 8.0 Miscellaneous Information .................................................................................................... 22 8.1 Stabilization Waveform...................................................................................................... 23 8.2 Emissions Test Procedures ................................................................................................. 24 8.2 Emissions Test Procedures (cont'd) .................................................................................... 25 INTERTEK TESTING SERVICES FCC ID: QRO2350-49RX iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission radiated photos.pdf Test Report Bandwidth Plot bw.pdf External Photo External Photo external photos.pdf Internal Photo Internal Photo internal photos.pdf Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf INTERTEK TESTING SERVICES FCC ID: QRO2350-49RX 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: QRO2350-49RX 2 1.0 General Description 1.1 Product Description The equipment under test (EUT) is a receiver for a RC Car operating at 49.860 MHz. The EUT is powered by a 9.6V rechargeable battery pack. The EUT has a switch to control the EUT to power ON or OFF. The EUT can be controlled to move forward or backward, to turn left or right and to transform by the controller. The Model: 2351 and 2352 are the same as the…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICE Front View Back View
