QSF38860Remote Control Transmitter

GOOD-LITE  INSTA-LINE PLUS TM INSTRUCTIONSGOOD-LITE  INSTA-LINE PLUS TM INSTRUCTIONS 1. Introduction The INSTA-LINE PLUS TM is a “3-in-one” instrument designed to test visual acuity, hyperopia and muscle imbalance. It can be used to test visual acuity in preschool and school age popula- tions. The INSTA-LINE PLUS TM is housed in a sturdy carrying case to meet the rigid demands of active nurses or examiners who are often moving between locations. This self contained vision testing unit is a precision instrument with standardized illumination that is designed for use in a 10 foot testing lane. 2. Setup The only requirements needed for vision testing with the INSTA-LINE PLUS TM is a 10 foot testing lane, two chairs, a table and an electrical outlet. Place the instrument on a low table, remove top, remove front and back panels, insert test chart to be used and replace top. Remove the Remote Control Device (RCD) from back holder and unwind power cord. The power cord which is used as a measuring device for setting up the test- ing lane has two white marks that are exactly ten feet apart. One white mark should be placed flush with the face of the chart and the other when the power cord is pulled tight should be located at the face of the child being tested. After completing testing lane setup plug pow- er cord into a source of 120 VAC, 60 Hz outlet. The RCD should be placed on a table with a chair placed on each side of the table. The child faces the instru- ment while the examiner faces the child with their back to the chart (FIG. 1). This allows the examiner to observe the child ���������� ����� ����� ������ ������� ������ �������� GOOD-LITE CO. ��������������� �������������� ����������������� ����� ���� FIG. 1 1 20 GOOD-LITE  INSTA-LINE PLUS TM INSTRUCTIONSGOOD-LITE  INSTA-LINE PLUS TM INSTRUCTIONS at all times, to detect squinting or faulty head positions. No intense light sources should be within the field of vision as the child looks at the instrument from 10 feet away. RCD overlays are provided with each chart. RCD overlays are also available separately (refer to section 20 for more information.). At- tach RCD overlay with hook and loop fasteners noting bottom label on the RCD and back of overlay. 3. Remote Control Device (RCD) This remote control device (RCD) is only compatible with this test cabinet. It is important that you register your GOOD-LITE  product if you require technical support or service. This will ensure that we have the necessary information needed for re- placements or repairs. Please fill in and return enclosed regis- tration card. The RCD has several features built into the electronic design to enhance the overall operation. Depressing the keypad buttons will turn ON the respective light in the test cabinet. Although each frosted light bulb will turn OFF in approximately thirty seconds, the OFF button may be depressed to turn OFF earlier. The RED muscle light bulbs will stay on for approximately one min- ute or may be turned OFF earlier by depressing the OFF button. FIG. 2 ��������������������� ���� �� �������������� ����������������� ���� ��� ������ ���� ������� ���� ����� ��� ���������� ����� ���������� ���������� ���������� ���������� ����� ����� ����� ����� 2 GOOD - LITE � ��������������������������������� ���� �������� ������������������������� ������������������������������������������ ����������������� 900540 HOTV RESPONSE PANEL 600501 SYMBOL FLASH CARDS (3) 600012 SYMBOL RESPONSE PANEL 900579 LEA SYMBOLS® RESPONSE PANEL 900580 LEA SYMBOLS® FLASH CARDS (4) 21. Legal Notices FCC Notification Changes or modifications not expressly approved by GOOD-LITE  may void the user’s authority granted by the FCC to operate the subject equipment and should not be made. Re- placement of any component not authorized by the FCC equip- ment authorization for this equipment could violate FCC rules. Software Lincense The GOOD-LITE  products described in this manual may in- clude copyrighted GOOD-LITE  and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for GOOD-LITE  and third party software providers certain exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copy- righted software contained in the GOOD-LITE  products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the GOOD-LITE  products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of GOOD-LITE  or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. 19 GOOD-LITE  INSTA-LINE PLUS TM INSTRUCTIONSGOOD-LITE  INSTA-LINE PLUS TM INSTRUCTIONS The RCD resumes a low power mode after the pressed key- pad button is released, to conserve battery life. However, the batteries will eventually become too low for proper operation. A built-in battery detector will cause multiple beeps when the keypad is depressed to alert the operator to replace the four (4) AA alkaline batteries. Rechargeable batteries should never be used. When the RCD will not be used for several weeks, the batteries should be removed to prevent unnecessary drain. Other than replacing batteries, there are no user serviceable parts inside the RCD. Batteries are removed and replaced by sliding off the battery cover. Remove the batteries and replace the new ones with the proper polarity “+” and “-” as indicated inside the battery compartment. When the last battery is inserted into place, a single beep will be produced indicating the RCD is ready to operate. Replace battery cover. Light Test Auto Run The RCD also includes a light test auto run feature for a quick light test and demonstration purposes. The mode is entered by simultaneously depressing the …

Text truncated - open the document above for the full version.

FCC ID: QSF38860 Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, Good-Lite Company, Inc. hereby requests confidentiality for the subject block diagram, schematics, operating manual and product information presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. William S. Kowalski Elan Engineering Corporation Technical Contact for Good-Lite Company, Inc.

MODEL 900PLUS TRANSMITTER FCC LABEL
