QSQ-REMOTEREMOTE CONTROLLER FOR GOF-CART

User Manual Bat-Caddy X4 & X4R ATTENTION: PLEASE FOLLOW ALL ASSEMBLY INSTRUCTIONS AND READ AND UNDERSTAND THE OPERATING INSTRUCTIONS BEFORE YOU OPERATE THE CADDY, EITHER MANUALLY OR BY REMOTE CONTROL. 2 TABLE OF CONTENTS Page Packing List..............................................................................................................................3 Parts Glossary..........................................................................................................................4 Assembly Instructions ..........................................................................................................5 Operating Instructions ..........................................................................................................7 Maintenance & Additional Instructions...........................................................................11 Technical Specifications......................................................................................................15 Frequently Asked Questions..............................................................................................18 NOTE: This device complies with part 15 of the FCC Rules and with Industry Canada license‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT Bat-Caddy X4R FCC ID: QSQ-REMOTE IC ID: 10716A-Remote 3 PACKING LIST 1. Standard Parts (X4)  1 Caddy Frame  2 Rear Wheels (Left & Right)  1 Battery Pack (Battery, Bag, Leads)  1 Charger  1 Tool Kit  1 User Manual, Warranty, Terms & Conditions 2. Standard Parts (X4R)  1 Caddy Frame  1 Anti-Tip Wheel & Pin  2 Rear Wheels  1 Battery Pack (Battery, Bag, Leads)  1 Charger  1 Tool Kit  1 Remote Control (needs 2 AAA Batteries)  1 User Manual, Warranty, Terms & Conditions 3. Optional Accessories (X4 & X4R)  1 Scorecard Holder  1 Cup Holder  1 Umbrella Holder  1 Seat Cushion, Stand, & Hardware  Carry Case Addition accessories available for purchase on www.batcaddy.com 4 PARTS GLOSSARY 1. Manual Rheostat Speed Control 2. Upper Bag Support 3. Bag Support Strap 4. Battery 5. Rear Wheel 6. Wheel Hubcap 7. Rear Wheel Quick Release Catch 8. Dual Motors 9. Lower Bag Support & Strap 10. Front Wheel 11. Upper Frame Locking Knob 12. Handle IC Controller 13. Battery Plug 14. Front Wheel Tracking Adjustment 15. Scorecard Holder 16. Lower Frame Locking Knob Not shown: charger, remote control (X4R) 5 ASSEMBLY INSTRUCTIONS 1. Unpack all items carefully and check inventory. 2. Place frame structure (one piece) on soft and clean ground to protect frame from being scratched. Attach wheels to axles by pushing wheel locking button on the outside of the wheel and inserting the axle extension into the wheel. Make sure to keep the locking button on the outside of the wheel pushed in during this process, in order to enable the axle extensions, including the two pins, to be inserted all the way into the wheel. If not locked in, the wheel will not be connected to the axle and will not be propelled! Test the lock by trying to pull the wheel out. Note: the X4 caddy has a right (R) and a left (L) seen from behind in driving direction. Please make sure that the wheels are assembled on the correct side, as otherwise the clutches will not engage. To disassemble the wheels proceed in reverse order. 3. Erect Frame by unfolding and connecting the main frame tubes together at the two frame locks by fastening the lower and upper frame locking knobs. Proceed in reverse for folding the caddy. 6 4. Place battery pack on battery tray and fasten both Velcro straps around battery and frame tightly. Insert 3 prong battery plug into caddy outlet. (Note: Do not screw plug nut into caddy to prevent damage in case of a tip-over). Note: BEFORE CONNECTING make sure that caddy power is OFF, Rheostat Speed Control on handle is in OFF position and the remote control is stored securely! 5. For X4R insert anti tip wheel into holding bar on motor housing and secure with pin. 6. Install optional accessories, such as Scorecard/Beverage/Umbrella holder, below handle in the foreseen places or receptors. 7 OPERATING INSTRUCTIONS 1. Handle Control Functions – Design A 1. The rheostat speed button on the right side of the handle lets you choose your preferred speed seamlessly. Dial forward to increase speed. Dial backwards to reduce speed. 2. Press ON/OFF power button for about 2 seconds to turn caddy on or off 3. The Digital Cruise Control: Select the ideal speed to match your pace with the rheostat speed knob. In order to stop press the red cruise control button on the top of the handle. The cart will remember its last speed setting when you stop. Once you are ready to go press the button again, and the caddy will automatically travel at the same speed, except if you change the speed knob position. 4. The caddy is equipped with a "Soft start" ability which ensures smooth acceleration up to selected speed by pressing the stop/start button on the handlebar control panel. 5. The battery indicator LED with green or red color on the handle shows the battery charge at any time. If green the battery is charged. When it turns red please recharge the battery soon. 2. Handle Control Functions – Design B 8  Timer: Press 'timer' one time, the trolley will move 10m/y and stop. Press 'timer' two times, the trolley will move 20m/y and stop. Press 'timer' three times, the trolley will move 30m/y and stop. (Note: while the trolley moving, you can press the 'timer' button again and the preset distance will be increased by an additional 10m/y)  ON/OFF Function: Press this button for at least 2 seconds to switch…

Text truncated - open the document above for the full version.

Block Diagram

External Photos - Top View - Bottom View

Label Location Label Location

WUYIJINYUEENGINESCIENCEANDTECHNOLOGYCO.,LTD FCCID:QSQ-REMOTE ICID:10716A-REMOTE M/N:TP-20121113 ThisdevicecomplieswithPart15oftheFCCrules. Operationissubjecttothefollowingtwoconditions (1)Thisdevicemaynotcauseharmfulinterference. (2)Thisdevicemustacceptanyinterferencereceived,includinginterference thatmaycauseundesiredoperation.

Internal Photos - Top View - Bottom View

General description of golf remote control: 1. The voltage of remote control is 3 volt and the frequency is 433.92MHZ. The range of the remote control varies between 80-120 yards. 2. Each remote control directs one controller box in the golf trolley. The input voltage of controller box is 12volt and the output maximum current is 28Ah. The controller box has the functions of controlling trolley to move forward, move backward, turn left, turn right and stop. The drawing schematic: The frequency of remote: 433.92MHZ The following are photos of PCB: (Front side) (Back side) (outside)

Schematic

TEST REPORT For WuYi JinYue Engine Science and Technology 229# XinXing RD Wuyi City, Zhejiang Province China Date: October 22, 2012 Report No.: 10959-1E Revision No.: 0 Project No.: 10959 Equipment: Remote Controller Model No.: Remote ONE STOP GLOBAL CERTIFICATION SOLUTIONS 3133-20800 Westminster Hwy, Richmond, BC V6V 2W3, Canada Phone: 604-247-0444 Fax: 604-247-0442 www.labtestcert.com Prepared by: LabTest Certification Inc. Client: WuYi JinYue Engine Science & Tech. Date Issued: October 22, 2012 Report No.:10959-1E Project No: 10959 Revision No.: 0 Page 2 of 46 This document shall not be reproduced or utilized in any form or by any means, except in full, without the written approval of LabTest Certification Inc. DCN: 1034, Rev 4 TABLE OF CONTENTS TEST REPORT ................................................................................................................................................ 3 General product information: ............................................................................................................................ 5 Frequencies...................................................................................................................................................... 5 List of ancillary and/or support equipment provided by the applicant .............................................................. 5 Description of Interface Cables for Testing ...................................................................................................... 5 Software and Firmware .................................................................................................................................... 5 Worst-case configuration and mode of operation during testing...................................................................... 5 Modifications Required for Compliance............................................................................................................ 5 Test Equipment Verified for function ................................................................................................................ 5 Measurement Uncertainty ................................................................................................................................ 6 Markings ........................................................................................................................................................... 6 Test Summary .................................................................................................................................................. 7 AC Power Line Conducted Emission ............................................................................................................... 8 Test Limits..................................................................................................................................................... 8 Test Results .................................................................................................................................................. 8 Summary of the operation of RF Transmission................................................................................................ 9 Test Limits..................................................................................................................................................... 9 Reviewed Results: ........................................................................................................................................ 9 Field Strength of Fundamental – Intentional Radiator.................................................................................... 11 Test Limits................................................................................................................................................... 11 Test Setup................................................................................................................................................... 12 Setup Block Diagram .................................................................................................................................. 12 Test Setup in Chamber ............................................................................................................................... 12 Test Results: ............................................................................................................................................... 13 Field Strength of Spurious Emission .............................................................................................................. 15 Test Limits................................................................................................................................................... 15 Test Setup................................................................................................................................................... 16 Test Results: ............................................................................................................................................... 16 Radiated Emission; Intentional Radiators ...................................................................................................... 24 Test Limits................................................................................................................................................... 24 Test Results: ............................................................................................................................................... 24 The Bandwidth of the emission ...................................................................................................................... 35 Test Limits................................................................................................................................................... 35 Test Setup...............................................................................................................…

Text truncated - open the document above for the full version.

Prepared by: LabTest Certification Inc. Client: WuYi JinYue Engine Science & Tech. Date Issued: October 22, 2012 Report No.:10959-1E Project No: 10959 Revision No.: 0 Page 40 of 46 This document shall not be reproduced or utilized in any form or by any means, except in full, without the written approval of LabTest Certification Inc. DCN: 1034, Rev 4 APPENDIX C: Test setup photos - Test configuration for Field Strength measurement #1 Prepared by: LabTest Certification Inc. Client: WuYi JinYue Engine Science & Tech. Date Issued: October 22, 2012 Report No.:10959-1E Project No: 10959 Revision No.: 0 Page 41 of 46 This document shall not be reproduced or utilized in any form or by any means, except in full, without the written approval of LabTest Certification Inc. DCN: 1034, Rev 4 - Test configuration for Field Strength measurement #2 Prepared by: LabTest Certification Inc. Client: WuYi JinYue Engine Science & Tech. Date Issued: October 22, 2012 Report No.:10959-1E Project No: 10959 Revision No.: 0 Page 42 of 46 This document shall not be reproduced or utilized in any form or by any means, except in full, without the written approval of LabTest Certification Inc. DCN: 1034, Rev 4 - Set-up for Orthogonal X - Set-up for Orthogonal Y - Set-up for Orthogonal Z
