QTG-HWCDHALO Wireless Charging Dock 10K

WIRELESS CHARGING DOCK WITH POWER BANK PLEASE READ BEFORE OPERATING THIS EQUIPMENT Contains a 10,000 mAh internal battery HALO WIRELESS CHARGING DOCK WITH POWER BANK Thank you for choosing the HALO WIRELESS CHARGING DOCK WITH POWER BANK. Please read the operating instructions carefully before using the HALO WIRELESS CHARGING DOCK WITH POWER BANK. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS WARNING: When using this product, basic precautions should always be followed, including the following: • Read all the instructions before using the product. • To reduce the risk of injury, close supervision is necessary when the product is used near children. • Do not put ngers or hands into the product. • Do not expose product to rain or snow. • Use of a power supply or charger not recommended or sold by product manufacturer may result in a risk of re or injury to persons. • Do not use the product in excess of its output rating. Overload outputs above rating may result in a risk of re or injury to persons. • Do not use the product that is damaged or modied. Damaged or modied product may exhibit unpredictable behavior resulting in re, explosion or risk of injury. • Do not disassemble the product. Take it to a qualied service person when service or repair is required. Incorrect reassembly may result in a risk of re or injury to persons. • Do not expose a product to re or excessive temperature. Exposure to re or temperature above 100°C/212°F may cause explosion. • Unplug the product when not in use. • Improper use of this product may result in product damage, excess heat, toxic fumes, re or explosion, for which damages you (“Purchaser”), and not HALO2CLOUD LLC. (HALO) (“Manufacturer”) are responsible. • This product should be operated only in open-air conditions. It should not be operated in an enclosed, unventilated space such as a carrying bag, pocket, purse or bedding. Failure to follow these instructions may damage the product by overheating. • Be cautious of drops, bumps, abrasions, or other impacts to this product. If there is any damage to the product such as dents, punctures, tears, deformities, or corrosion due to any cause, discontinue use. Contact Manufacturer or dispose of it in an appropriate manner. • Do not disassemble this product or attempt to re-purpose or modify it in any manner. • Do not attempt to replace any part of this device. • Have servicing performed by a qualied repair person using only identical replacement parts. This will ensure that the safety of the product is maintained. • Never dispose of batteries in the garbage. Disposal of batteries in the garbage may be unlawful under state and federal environmental laws and regulations. Always take used batteries to your local battery-recycling center. • The lithium-ion rechargeable battery used in this device may present a risk of re or chemical burn if mistreated. Do not expose to re or excessive temperature. • For questions or instructions for the various ways to charge this device, refer to the illustrations inthis operating instructions. • If this device is accessible to or may be used by a minor, purchasing adult agrees to be solely responsible for providing supervision, instruction, and warnings. Purchaser agrees to defend, indemnify, and hold Manufacturer harmless for any claims or damages arising from unintended use or misuse by a minor. • All products have gone through a thorough quality assurance inspection. If you nd that your device is excessively hot, is emitting odor, is deformed, abraded, cut, or is experiencing or demonstrating an abnormal phenomenon, immediately stop all product use and contact Manufacturer. • This device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. • Switch o the power bank when not in use. CAUTION: Risk of Fire and Burns. Do Not Open, Crush, Heat Above (100°C) or Incinerate. Do not place any metal obstructions between the wireless charging pad and your electronic device while charging wirelessly. Follow Manufacturer’s Instructions. TABLE OF CONTENTS Safety Precautions Included Items Operating Instructions Specications Warranty and Contact Information INCLUDED ITEMS - Wireless Charging Dock - Wireless Charging Power Bank - AC Charging Adapter Wireless Charging Power Bank Wireless Charging Dock 1 | USB Type-C Input/Output 2 | USB A Output 3 | Wireless Charging Output 4 | Wireless Charging ON/OFF Button 5 | Battery Indicators 6 | Power Bank Pogo Pin Input 7 | Wireless Charging LED Indicator OPERATING INSTRUCTIONS The HALO WIRELESS CHARGING DOCK can be charged using the supplied wall plug. The charge time is 3-4 hours. There are several ways to charge your smartphone. 1. Via Wireless Charging Power Bank 2. Via the USB-A or USB-C port on the Wireless Charging Power Bank. 3. Via Wireless Charging Power Bank while connected to the charging dock. 4. Via built-in wireless pad on the HALO WIRELESS CHARGING DOCK 5. Via the USBA output port on the back of the wireless charging dock. SETTING THE CLOCK DISPLAY To set the correct time, locate the adjustment buttons on the back of the charging dock base. S Button: Press the button to select the hours or minutes value to adjust. Blinking will indicate the value has been selected. V Button: Press button to increase the selected value. V Button: Press button to decrease the selected value. AM/PM Selection: Scroll the time in 12 hour increments to change from AM to PM. 10,000 POWER BANK BATTERY INDICATORS The top most battery indicator will turn from blue to green when smartphone is successfully being charged wirelessly. When the smartphone is on the dock, LED Indicator 1 will be white. When the Power Bank is on the dock, LED Indicator 2 will be white. CHARGING YOUR PERSONAL ELECTRONIC DEVICE Use the appropriate USB charging cable with the HALO WIRELESS CHARGING DOCK to charge your electronic device. Once your electronic device is connected, it will…
