QTG-IFAYTWSP2AIRTIME LUXE 2(Pro 2)

AIRTIME LUXE 2(Pro 2) TRULY WIRELESS EARBUDS Quick Start Guide Warranty information available at www.zagg.com/warranty-policies ©2020 ZAGG Inc All Rights Reserved | NASDAQ: ZAGG | MADE IN CHINA The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by ZAGG Inc is under license. USB-C is a trademark of USB Implementers Forum. Other trademarks are property of ZAGG. *All hours usage and charging claims are estimates based on internal testing and will vary based on individual usage. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS OR CHANGE TO THIS EQUIPMENT. SUCH MODIFICATIONS OR CHANGE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 314-0465-A | 06/04/20 Drivers: 6mm Resistance: 16 Ohms ± 15% Sensitivity: 102dB ± 3dB Frequency: 50Hz - 20KHz Working Time: 5+25hrs Charging Time: 1.5-2h FCC ID: QTG-IFAYTWSP2 EN Airtime Luxe 2 Instructions Introduction Welcome to truly wireless audio with 30 hours * of combined battery life and quick charging case. Pairing the Wireless Earbuds with Your Device 1. Simply open the case and remove the earbuds. A pairing signal will be sent to your Bluetooth ® device. The earbuds will flash red and white, indicating pairing mode. 2. On your device, go to Bluetooth under Settings and select IFROGZ ® Airtime Luxe 2. 3. Complete any additional steps your device may require. The lights on the earbuds will flash white and then turn off, indicating that pairing was successful. Turning Earbuds On/Off To turn the earbuds on, simply remove the buds from the case. To turn the earbuds off, simply return them to the case. If you’d like to turn an individual bud on, press and hold the touch sensor on the earbud for 3 seconds. It will flash white until it’s connected to a device. It will turn off if not paired within 60 seconds. You can also tap and hold the IFROGZ icon on the earbud for 10 seconds to turn it off; it will flash red, indicating the power is off. The earbuds will go into hibernation mode if not used for 20 minutes. Using the Earbuds Airtime Luxe 2 true wireless earbuds have built-in touch navigational controls. Just tap on the end of the earbud (on the IFROGZ logo) to navigate. Music Controls Left BudActionsRight Bud Play / Pause Quick TapPlay / Pause Previous Track 2x TapsNex t Track Decrease Volume Tap & HoldIncrease Volume Call Controls Answer Call / End Call Quick Tap Answer Call / End Call Cancel Call Tap & HoldCancel Call Siri / Voice Command 3x Taps Siri / Voice Command Charging the Wireless Earbuds The case carries enough power to charge the earbuds up to 5 times * . 1. Place the earbuds in the charging case. You’ll feel them magnetically click into place. 2. A red light on the earbuds will indicate charging. A white light will illuminate for 60 seconds, then turn off when earbuds are fully charged. Charging the Case Your case comes charged and ready to go. You can re-charge the case wirelessly using a wireless charging pad, or charge the case manually using the included USB-C ® cable. Wireless Charging 1. Simply drop the charging case on a compatible wireless charging pad. 2. The Battery Indicator light will flash according to its current battery level. This indicates your case is charging. When the case is fully charged, all four lights will illuminate for 20 seconds then turn off. Manual Charging 1. Connect the included USB-C charging cable to the port on the side of your case. 2. Connect the USB-A end of the cable to your preferred 5V USB outlet. 3. The Battery Indicator light will flash according to its current battery level. This indicates your case is charging. When the case is fully charged, all four lights will illuminate and then turn off. 4. Disconnect the charging cable. Quick Charge Feature Get one more hour of playtime by nesting the earbuds in the charging case for ten minutes. Checking the Battery Level Your case carries enough power to charge your wireless earbuds 5 times for a total of 25 hours. To check how much power your case still has, place the earbuds in the case. The LED on the front of the case will illuminate, indicating how much battery remains in the case: ·If it lights up completely, 75% or more remains ·If it lights up ¾ of the way, between 50-74% remains ·If it lights up ½ of …

Text truncated - open the document above for the full version.

(ZAGG Inc.) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: QTG-IFAYTWSP2 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ( Dan Oakeson) Rev 11/20/07

(ZAGG Inc.) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2020/7/6 SUBJECT: FCC Application for FCC ID: QTG-IFAYTWSP2 To Whom It May Concern: We, the undersigned, hereby authorize Alan Mei at Shenzhen BCTC Testing Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Alan Mei of Shenzhen BCTC Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, ( Dan Oakeson)

External Photos

FCC ID: QTG-IFAYTWSP2

Internal Photos Antenna

RF EXPOSURE EVALUATION METHOD FCC ID: QTG-IFAYTWSP2 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BT-EDR max possible output power (PK,conducted)：2±1dbm 2dBi logarithmic terms convert to numeric result is nearly 1.59 3dBm=2.00mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]=2.00/5*√2.402=0.62≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Modulation Frequency (MHz) Output Power (dBm) Max Antenna Gain (dBi) GFSK 2402 0.57 2 GFSK 2441 0.36 2 GFSK 2480 -0.18 2 Pi/4 DQPSK 2402 1.71 2 Pi/4 DQPSK 2441 1.51 2 Pi/4 DQPSK 2480 0.95 2 8DPSK 2402 2.03 2 8DPSK 2441 1.91 2 8DPSK 2480 1.46 2 2441MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2.00/5*√2.441 =0.62≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]=2.00/5*√2.48=0.63≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. BT-BLE max possible output power (PK,conducted)：1±1dbm 2dBi logarithmic terms convert to numeric result is nearly 1.59 2bm=1.58mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]=1.58/5*√2.402=0.49≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. 2440MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 1.58/5*√2.440 =0.49≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Modulation Frequency (MHz) Output Power (dBm) Max Antenna Gain (dBi) GFSK 2402 0.62 2 GFSK 2440 -0.27 2 GFSK 2480 -0.85 2 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]=1.58/5*√2.480 =0.50≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2006001215-1E TEST REPORT FCC ID: QTG-IFAYTWSP2 Compiled by: Reviewed by: Approved by: Willem Wang Eric Yang Zero Zhou/Manager The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: AIRTIME LUXE 2(Pro 2) Trademark: IFrogz Model Number: IFIETWS29C Prepared For: ZAGG Inc. Address: 910 West Legacy Center Way, Suite 500 Midvale, Utah 84047, USA. Manufacturer: ZAGG Inc. Address: 910 West Legacy Center Way, Suite 500 Midvale, Utah 84047, USA. Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Sample Received Date: Jun. 15, 2020 Sample tested Date: Jun. 15, 2020 to Jul. 01, 2020 Issue Date: Jul. 01, 2020 Report No.: BCTC2006001215-1E Test Standards FCC Part15.247 ANSI C63.10-2013 Test Results PASS Remark: This is Bluetooth Classic radio test report. Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 1 of 70 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2006001215-1E TABLE OF CONTENT Test Report Declaration Page 1. VERSION ............................................................. 4 2. TEST SUMMARY ...................................................... 5 3. MEASUREMENT UNCERTAINTY........................................ 6 4. PRODUCT INFORMATION AND TEST SETUP ............................ 7 4.1 Product Information ..................................................... 7 4.2 Test Setup Configuration ................................................ 7 4.3 Support Equipment ..................................................... 8 4.4 Channel List ........................................................... 8 4.5 Test Mode ............................................................. 9 4.6 table of parameters of text software setting ................................. 9 4.7 Copy of marking plate .................................................. 10 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 11 5.1 Test Facility ........................................................... 11 5.2 Test Instrument Used .................................................. 11 6. CONDUCTED EMISSIONS ............................................. 13 6.1 Block Diagram Of Test Setup ........................................... 13 6.2 Limit ................................................................. 13 6.3 Test procedure ........................................................ 13 6.4 EUT operating Conditions .............................................. 13 6.5 Test Result ........................................................... 14 7. RADIATED EMISSIONS ............................................... 16 7.1 Block Diagram Of Test Setup ........................................... 16 7.2 Limit ................................................................. 17 7.3 Test procedure ........................................................ 18 7.4 EUT operating Conditions .............................................. 19 7.5 Test Result ........................................................... 20 8. RADIATED BAND EMISSION MEASUREMENT AND RESTRICTED BANDS OF OPERATION .......................................................... 24 8.1 Block Diagram Of Test Setup ........................................... 24 8.2 Limit ................................................................. 24 8.3 Test procedure ........................................................ 25 8.4 EUT operating Conditions .............................................. 25 8.5 Test Result ........................................................... 26 9. CONDUCTED EMISSION .............................................. 27 9.1 Block Diagram Of Test Setup ........................................... 27 9.2 Limit ................................................................. 27 9.3 Test procedure ........................................................ 27 9.4 Test Result ........................................................... 27 10. 20 DB BANDWIDTH .................................................. 37 10.1 Block Diagram Of Test Setup .......................................... 37 10.2 Limit ................................................................ 37 Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 70 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2006001215-1E 10.3 Test procedure ....................................................... 37 10.4 Test Result .......................................................... 38 11. MAXIMUM PEAK OUTPUT POWER .................................... 43 11.1 Block Diagram Of Test Setup .......................................... 43 11.2 Limit ................................................................ 43 11.3 Test procedure ....................................................... 43 11.4 Test Result .......................................................... 44 12. HOPPING CHANNEL SEPARATION .................................... 49 12.1 Block Diagram Of Test Setup .......................................... 49 12.2 Limit ................................................................ 49 12.3 Test procedure ....................................................... 49 12.4 Test Result .......................................................... 50 13. NUMBER OF HOPPING FREQUENCY .................................. 55 13.1 Block Diagram Of Test Setup .......................................... 55 13.2 Limit ................................................................ 55 13.3 Test procedure ......................................................…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2006001215E 15. EUT TEST SETUP PHOTOGRAPHS Conducted emissions Radiated Measurement Photos Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 41 of 42 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2006001215E ※※※※※ END OF REPORT ※※※※※ Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 42 of 42
