QTP-SCPA-PCS1900Single Carrier Power Amplifier

CSA Label 85 2 4

EUT PARTIALLY DISASSEMBLED INTERNVAL VIEW WITHOUT COVER DRIVER AND TLA BOARDS REMOVED POWER SUPPLY DRIVER BOARD COMPONENT SIDE PS DRIVER BOARD FOIL SIDE PLK 4316 PIT DC CONVERTER COMPONENT SIDE PLK 4316 PIT DC CONVERTER LOWER SIDE TLA 0362 UPPER SIDE TLA 0362 LOWER SIDE / TLA 0364 COMPONENT SIDE TLA 0364 LOWER SIDE OUTPUT CIRCUIT COMPONENT SIDE OUTPUT CIRCUIT FOIL SIDE INTERCONNECTION BOARD COMPONENT SIDE INTERCONNECTION BOARD FOIL SIDE

BOTTOM OF TLA0362 BOTTOM OF TLA0364 DCDC SIDE 1 DCDC SIDE 2 TLA0362A TLA0362B TLA0364A TLA0364B

Test Report No. RD2003/002 FCC-ID: QTP-SCPA-PCS1900 Date January 10th, 2003 TÜV ITALIA 1/42 MEASUREMENT/TECHNICAL REPORT FCC Parts 2, 15, 24 Forem FCC-ID: QTP-SCPA-PCS1900 S8000 45W EDGE / 60W GMSK PCS 1900 MHz SCPA (single channel power amplifier) January 10th, 2003 This report concerns (check one): Original grant __X__ Class II change____ Equipment type: SCPA (single channel power amplifier) (ex.: computer, printer, modem, etc.) Deferred grant request per 47 CFR 0.457(d)(1)(ii)? yes _____ no __X__ If yes, defer until: ______________ date Company Name agrees to notify the Commission by ______________ Date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by: Giuseppe MECCHIA TÜV ITALIA S.R.L. Via Montalenghe 12 10010 Scarmagno ( TO ) Italy Phone : 0125 - 525441 Fax : 0125 – 525499 Test Report No. RD2003/002 FCC-ID: QTP-SCPA-PCS1900 Date January 10th, 2003 TÜV ITALIA 2/42 Table of Contents Page 1 GENERAL INFORMATION ................................................................ 3 1.1 Product Description ................................................................ 3 1.2 Related Submittal(s)/Grant(s)................................................. 3 1.3 Tested System Details............................................................ 5 1.4 Test Methodology..................................................................... 6 1.5 Test Facility............................................................................... 6 1.6 Test Equipment List................................................................. 6 2 PRODUCT LABELING........................................................................ 7 Figure 2.1 FCC ID Label............................................................... 7 Figure 2.2 Location of the Label on EUT..................................... 8 3 SYSTEM TEST CONFIGURATION.................................................... 9 3.1 Justification............................................................................... 9 3.2 EUT Exercise Software...........................................................10 3.3 Special Accessories................................................................11 3.4 Equipment Modifications.........................................................11 3.5 Configuration of the Tested System.......................................12 Figure 3.1 Configuration of the Tested System............................12 4 BLOCK DIAGRAM(S) OF THE EUT..................................................13 4.1 Block Diagram Description......................................................13 Figure 4.1 Block Diagram of the EUT..........................................14 5 CONDUCTED AND RADIATED MEASUREMENT PHOTOS.......15 6 PART 2 and PART 24 requirements..................................................19 7 PART 15 requirements .......................................................................38 8 PHOTOS OF TESTED EUT...............................................................41 Test Report No. RD2003/002 FCC-ID: QTP-SCPA-PCS1900 Date January 10th, 2003 TÜV ITALIA 3/42 1 GENERAL INFORMATION 1.1 Product Description SCPA basic function consist in amplifying the level of a modulated RF signal, generated by the base station in which it is allocated, up to the RF power level of the whole transmitter. SCPA amplifies the small signal delivered by the digital part of the base station up to a level 48dB higher ( around 60000 higher) to be radiated by the Antenna. SCPA is a stand-alone unit, mounted in a closed metal housing (for EMI containment) fitted with a suitable heat sink and provided with RF coaxial and DC and Multi-way connectors. It also includes its own DC/DC converter. The main characteristics of this SCPA are : ÿ Range: 1930-1990 MHz ÿ Gain: 48 dB ÿ Modulation supported: GMSK (60W), 8-PSK (45W) ÿ Supply –48V +/- 20% ÿ Power consumption < 290W Power Amplifier Module is rated for an average output power of 45 Watts with an EDGE signal and 60 Watts with a GMSK signal. The power amplifier comply with the output spectrum due to modulation and switching transients specifications. RF signal to be amplified by the PA is an RF burst with a duration of 577 μs (including leading and trailing edges). The useful part of the burst, defined as the time during which the power level shall stay constant to ± 1dB accuracy, is 543 μs. Test Report No. RD2003/002 FCC-ID: QTP-SCPA-PCS1900 Date January 10th, 2003 TÜV ITALIA 4/42 The alarms provided by the PA consist of : ÿ the temperature overload : the measured temperature is locally compared to a fixed limit by the PA ÿ the power supply current overload measured and compared to a fixed limit by the PA ÿ the DC/DC converter alarm : optional (depends on DC/DC converter type) ÿ the communication alarm ÿ the input overdrive PA shutdown alarm The only components allowed to be located outside the module are the connectors. 1.2 Related Submittal(s)/Grant(s) None Test Report No. RD2003/002 FCC-ID: QTP-SCPA-PCS1900 Date January 10th, 2003 TÜV ITALIA 5/42 1.3 Tested System Details The FCC IDs for all equipment, plus descriptions of all cables used in the tested system (including inserted cards, which have grants) are: Model & Serial No. FCC ID Description Cable Descriptions E15Q40P09 C s/n 05082683 S8000 45W EDGE / 60W GMSK PCS 1900 MHz (SCPA) Unshielded power cord Shielded signal cables Connected to (remotes for radiated emissions tests): Elind HL 1200W series S/n 2821/03 None DC regulated power supply Unshielded power cords Agilent E4432B S/n GB40051310 None CE ISM 1-A, CSA ESG-D series signal generator Unshielded power cord Shielded signal cable Forem P/N D14C01P34-00 S/n 01636806 None Directional coupler Shielded signal cables Agilent E4406A S/n US40061643 None CE ISM 1-A, CSA VSA series Transmitter tester Unshielded power cord Shielded signal cables Forem W21N01M02 S/n 02299467 None RF load Shielded signal cables (1) EUT submitted for grant. Test Report …
