QTTATCMAGICW3Microcomputer with Integrated Telephony

Magic W3 Start Guide Magic W3 Start Guide Package Contents • Magic ® W3 ™ Unit • Start Guide • Earphone/ Handsfree kit • Car Charging Adaptor • Mini USB to USB Adaptor • HDMI Cable • Magic ® Installer CD • Windows 7 with CD (License Pack) • Power Adaptor • Protective Case (product key for activation is available here) • Warranty Card Device Overview Component Description 1 Volume Button To adjust volume 2 Power/ Lock switch Switches on W3 & locks the touch screen. Push towards “power” and hold to switch on. Push left to lock touch screen 3 SD card slot Insert the SD card for extra storage capacity Advance Tech Communications Sdn. Bhd. 4 Stylus Use with the touch screen 5 Speaker Built ‐ in stereo speaker 6 Touch screen This can be used for all W3 functionalities A New SMS Compose new SMS B Inbox List of received SMS C Sent List of sent SMS D Drafts List of draft SMS Call log A All calls List of all type of calls B Incoming List of only incoming calls C Outgoing List of only outgoing calls D Missed List of only missed calls E Display range Filters the list based on time period Settings A Airplane Mode Activate/ deactivate airplane mode B Cell Network Activate cell network automatically/ manually C Call Forwarding D Call Switching Activate/ deactivate call switching feature E Require PIN Activate PIN entry requirement F Change PIN Change SIM PIN number G Ringtone Change ringtone for incoming call H SMS Tone Change ringtone for SMS received I Vibrate On Notification Activate/ deactivate vibrate on notification 7 Call To make phone call after dialing 8 End call To hang up calls 9 Earphone jack For hands free kit 10 HDMI port Connect to HDMI cable for HDMI display 11 SIM card slot For phone calls and 3G (depending on SIM) 12 I/O port Connection to charger and docking 13 Mini USB port Connect other USB devices to W3 Preparing the Device Insert the SIM card Insert the SIM card and ensure that the golden connector of the SIM card is facing up Insert the micro SD card Open the cover beside the touch screen lock/ power switch. Insert the micro SD card with the golden connector facing up J Play Ringtone & Notification Sounds Activate/ deactivate ringtone & notification sounds Switching on W3 Slide the switch to the power symbol and hold until touch screen blinks Activating Windows • the product key is located on the inner side of the protective case that is included in the packaging Dialer Tap the numbers on the dialer then press to make a call Phonebook A Contact List List of contacts based on option set in filter list B Filter Contacts To list out contacts based on alphabet character C New Contact Add new contact D Delete Contact Delete existing contact E Search Contact Search for a specific contact F Filter List List out contact in a specific caller group G Edit Group Make changes to a specific caller group (add more/ remove contact to group) H Add New Group Add new caller group SMS • Tap ‐ > Go to Computer ‐ > tap & hold ‐ > tap Properties W3 Telephony SIM pin entry W3 Telephony is activated by double tapping on the desktop. Upon starting, user are required to input the SIM pin as shown. Note: SIM pin must be between 4 to 8 digits in length. Overview After SIM pin has been entered, W3 Telephony displays the Dialer. The functions of W3 Telephony are shown in the following table A Dialer Tab For outgoing calls. Favorites list of contacts are available here for quick dialing B Phonebook Tab List of all contacts are located here. C SMS Tab SMS functionalities D Call Log Tab Lists the incoming calls, outgoing calls, missed calls E Settings Tab Settings include: airplane mode, call forwarding, switching, SIM pin settings, call and SMS ringtone and notifications settings F Favorites list List of contacts that are saved as favorites G Numeric Display Bar Displays the phone number that is dialed • Windows Activation section is located in the lower part of System Properties • Tap on Activate Windows now • Ensure that W3 is connected to Internet to activate Windows. Tap on Activate Windows online now User Interface Tapping • Tap: tap the touch screen once. A diamond shaped cursor will appear on the area that is tapped. • Double tap: tap the touch screen twice. This is normally use to run applications/ programs or opening files H Cancel To delete numbers that are entered in the display bar I Dialer buttons To input phone number J Favorites Will save the dialed number as favorites K Call Calls the dialed number L Save Save the dialed number as contact M Current Display Tab Displays the Current Tab, network name, signal strength & minimize. • Tap and hold (Right click): tap the touch screen and hold until a “ring” appears Selection Tap any area on the touch screen and drag Keyboard Tap on on the taskbar to use the keyboard W3 Control Panel Peripherals in W3 that can be switched on 1 Wi ‐ Fi Switch on to use Wi ‐ Fi GPS Tap on the GPS section of the control panel and GPS is activated A ‐ GPS Tap on the “Activate A ‐ GPS” button and enter APN and SUPL server. Once APN and SUPL is entered, tap the Ok button 3G If the SIM card that is inserted into W3 has 3G capability, Mobile Broadband Connection is automatically detected. Tap “Connect” to use the Mobile Broadband connection, SIM card pin entry might be required. 2 GPS Switch on to activate GPS 3 Rotation Sensor Switch on to activate auto ‐ rotation of desktop orientation Note: the telephony application must be started before any 3G data connection FCC Caution Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class…

Text truncated - open the document above for the full version.

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT – All View EUT – Front View EUT – Rear View EUT – Top View EUT – Bottom View EUT – Left Side View EUT – Right Side View EUT – Adapter View EUT – Adapter Label View

Made in Malaysia FCC ID: QTTATCMAGICW3 1313 MODEL

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Cover off View EUT – Main Board Top View EUT – Main Board Bottom View EUT – Keyboard Top View EUT – Keyboard Bottom View EUT – GSM Module View EUT – DDR Top View EUT – DDR Bottom View EUT – Screen Top View EUT – Screen Bottom View EUT – Wi-Fi Antenna View EUT – Battery Top View EUT – Battery Bottom View

Part List Revised: Wednesday, November 28, 2012 Revision: RV3MAGIC W3Bill Of Mater i Page1 Description Item Reference Quant i Part Number Value Type Voltage Tolerance Footprint Stuffing ______________________________________________Diode 1 CR1,CR2,CR3,CR4,CR5,CR10,CR11,CR12,CR13,CR14,CR15,CR16,CR17,CR18,CR19,CR20,CR21,CR22 18 PGB1010402 Clamping-Diode Clamp, ESD Surprs SMESD0402 Diode 2 CR6,CR7,CR8,CR9 4 PGB1010402 Clamping-Diode Clamp, ESD Surprs SMESD0402 NO_STUFF Diode 3 D17,D18,D19,D20,D21,D29,CR8V1,CR8V2,CR8V3 9 RB521CS-30 RB521 CS-30 Schottky VMN2 Diode 4 CR8V4 1 RB162VA-20 RB162VA-20 Schottky TUMD2 Diode 5 CR4306,CR4307 2 RB715Z RB715Z Schottky VMD3 Diode 6 CR4312,CR4313 2 ESDALC6V1-5M6 ESDALC6V1-5M6 ESD Protection Mic roQFN-6L Diode 7 CR4314,CR4315 2 RClamp0514M RCLAMP0514M MSOP-10L Diode 8 CR4316 1 RClamp0503F.TCT RClamp0503F ESD SIM SC70-5L Capacitor 9 C1A2,C5H1,C5H2,C5T3,C5T4,C5T5,C6T6,C6T8,C8C6,C8C7,C8C9,C142,C146,C147,C171,C172,C173,C177,C178,C179,C181,C182,C194,C197,C198,C201,C2R13,C218,C2R34,C2R50,C297,C311,C312,C313,C5T11,C5T12,C5T16,C5T19,C5T34,C5T50,C5T57,C5T60,C5T61,C6T21,C9C13,C4303,C4315,C6129,C6131,C6133,C6181,C6182,C6186 53 K0402X1 05KCT 1.0uF X5R 6.3V 10% SMC0402 . Capacitor 10 C1N1,C1FF1,C1N9,C2N7,C2N8,C165,C167,C170,C174,C303,C304,C6175,C6176 13 K0805X226MCT 22uF X5R 6.3V 20% SMC0805 . Capacitor 11 C1V2,C1FF2,C1G3,C1FF3,C1FF4,C1G5,C2R1,C2R2,C2R3,C3N1,C3M8,C5T2,C5N2,C5M4,C5T6,C5B9,C6T1,C6C1,C6B5,C6C7,C70,C7T1,C8V1,C8R1,C8R2,C8D2,C8R3,C8R4,C8R5,C8W6,C8R6,C8D6,C8R7,C99,C104,C105,C106,C107,C108,C109,C111,C112,C113,C114,C115,C116,C117,C120,C122,C123,C124,C125,C126,C127,C128,C129,C130,C131,C132,C135,C136,C143,C152,C153,C154,C159,C160,C161,C162,C163,C164,C166,C168,C169,C176,C180,C183,C184,C199,C202,C208,C209,C210,C211,C212,C213,C2R14,C215,C216,C217,C219,C220,C221,C223,C224,C225,C272,C273,C276,C292,C294,C301,C306,C307,C309,C331,C332,C333,C337,C338,C339,C340,C4M19,C5M12,C5B12,C5V14,C5T23,C5T24,C5T31,C5T52,C6R10,C6T20,C6T23,C6T24,C4320,C6139,C6154,C6192,C6199,C6200,C6202 131 N0402X104KCT 0.1uF X5R 10V 10% SMC0402 . Capacitor 12 C1G1,C1G4,C1G7,C4300,C4307,C4310,C4311,C4312 8 C3216X5 R0J107MT 100uF X5R 6.3V 20% SMC1206 . Capacitor 13 C2F2,C2F3,C148,C155,C277 5 N0402X104KCT 0.1uF X5R 10V 10% S MC0402 NO_STUFF Capacitor 14 C2N4,C2N6,C8C8,C287,C288,C289,C299,C310,C314,C315,C316,C6195 12 T0402R103KCT 0.01uF X7R 25V 10% SMC0402 . Capacitor 15 C3B1,C4B1,C5W1,C6130,C6132,C6134,C6135,C6136,C6137 9 K 1206X476MCT 47uF X5R 6.3V 20% SMC1206 . Capacitor 16 C3B2,C4B2,C365 3 U0201R471KCT 470pF X7R 50V 10% SMC0201 . Capacitor 17 C3N3,C5N4,C5N5,C5B5,C6B6,C6B7,C7B4,C6B10 8 U0402R272KC T 2700pF X7R 50V 10% SMC0402 . Capacitor 18 C4B3 1 T0201C470JCT 47pF C0G 25V 5% SMC0201 . Capacitor 19 C5T1,C5C7,C185,C187,C188,C189,C192,C193,C196,C200,C2R22,C2R23,C2R26,C2R28,C2R30,C2R31,C2R32,C2R35,C2R36,C2R37,C5T20,C6191,C6193 23 K0603X225KCT 2.2uF X5R 6.3V 10% SMC0603 . Capacitor 20 C6F1,C6E1,C8D3,C8D4 4 U0402C180JCT 18pF C0G 50V 5% SMC0402 . Capacitor 21 C8E1,C8V2,C305,C6184,C6185 5 K0603X106MCT 10uF X5R 6.3V 20 % SMC0603 . Capacitor 22 C8T1,C8T2,C8E4,C186,C4302,C4309,C4314,C4319,C6143,C6 144 10 N0805X106KCT 10uF X5R 10V 10% SMC0805 . Capacitor 23 C102,C144,C175,C214,C222,C341,C343,C356,C357,C5V12,C6196,C6197 12 U0402R102KCT 1000pF X7R 50V 10% SMC0402 . Capacitor 24 C103,C149,C150,C151,C190 5 K0402X224MCT 0.22uF X5R 6.3V 20 % SMC0402 . Capacitor 25 C110,C121,C134,C290,C291,C293,C298,C300,C302,C308 10 T CM1A106M8R 10uF TANT 10V 10% SMC0603 Capacitor 26 C118,C119,C133,C156,C195 5 N0402C101JCT 100pF C0G 10V 5% SM C0402 . Capacitor 27 C137,C138,C139,C140 4 U0402C100JCT 10pF C0G 50V 5% SMC0402 . Capacitor 28 C141 1 U0402R821KCT 820pF X7R 50V 10% SMC0402 . Capacitor 29 C145,C157,C191 3 N0402C120JCT 12pF C0G 10V 5% SMC0402 . Capacitor 30 C158 1 U0402C220JCT 22pF C0G 50V 5% SMC0402 . Capacitor 31 C203 1 RF15N130F500CT 13pF NP0 50V 5% SMC0402 . Inductor 32 C204 1 ELJRF4N7DFB 4.7nH NP0 50V 0.05pF SMC0402 . Capacitor 33 C205 1 RF15N1R0A500CT 1.0pF NP0 50V 0.05pF SMC0402 NO_STUFF Capacitor 34 C206 1 RF15N100F500CT 10pF NP0 50V 5% SMC0402 . Capacitor 35 C207 1 RF18N390F500CT 39pF NP0 50V 5% SMC0603 . Capacitor 36 C295,C296 2 TCTP1A336M8R 33uF TANT 10V 10% SMC0805 Capacitor 37 C3T50 1 K0201X104KCT 0.1uF X5R 6.3V 10% SMC0201 . Capacitor 38 C342,C344 2 T0402R473KCT 47nF X7R 25V 10% SMC0402 . Capacitor 39 C5C10,C5C11 2 T0201C150GCT 15pF C0G 25V 2% SMC0201 . Capacitor 40 C4301,C4321,C4322,C4323 4 B0603R104KCT 0.1uF X7R 16V 10% SM C0603 . Capacitor 41 C4304,C4313 2 U0402C331JCT 330pF C0G 50V 5% SMC0402 . Capacitor 42 C4305,C4308,C4316,C6198 4 K0201X223KCT 22nF X5R 6.3V 10% SM C0201 . Capacitor 43 C4306 1 U0402C471JCT 470pF C0G 50V 5% SMC0402 . Capacitor 44 C4317 1 K1206X226KCT 22uF X5R 6.3V 10% SMC1206 . Capacitor 45 C4318 1 N0402R333JCT 33nF X7R 25V 10% SMC0402 . Capacitor 46 C6122,C6123,C6124,C6125,C6126,C6204,C6205,C6206 8 K060 3X475KCT 4.7uF X5R 6.3V 10% SMC0603 . Capacitor 47 C6127,C6128 2 T0201C330GCT 33pF C0G 25V 2% SMC0201 . Capacitor 48 C6145 1 2R5TPE220MIB 220uF POSCAP 2.5V 10% B2 Capacitor 49 C6194 1 U0402R152KCT 1500pF X7R 50V 10% SMC0402 . Diode 50 D22,D23 2 RB521CS-30 RB521CS-30 Schottky VMN2 NO_STUFF Diode 51 D24 1 LNJ208R8ARA RED Red, <5mA SMD0603 NO_STUFF IC 52 EU44 1 9UMS9610CKLFT CK610 - 9UMS9610 System Clock QFN48_4MM IC 53 EU4413 1 LTC4413 LTC4413 Dual Diode DFN10_3MM_LTC4413 IC 54 EU4415 1 MAX8796 MAX8796 IMVP-6 QFN32 Ferrite Bead 55 FB1,FB6,FB14 3 BLM18SG700TN1 70ohm@100MHZ 4A SMF0603 Ferrite Bead 56 FB2 1 BLM15PD300SN1 30ohm@100MHZ 2200mA SMF0402 Ferrite Bead 57 FB3 1 BLM18SG121TN1 120ohm@100MHZ 3A SMF0603 Ferrite Bead 58 FB7 1 BLM18SG260TN1 26ohm@100MHZ 4A SMF0603 Ferrite Bead 59 FB8,FB9,FB10,FB11,FB12,FB13,FB5N2 7 BLM15HG601SN1 60 0ohm,1000ohm 300mA SMF0402 Ferrite Bead 60 FB1TS1,FB1TS2,FB1TS3 3 BLM03AG800SN1 80ohm@100MHZ 200 mA SMF0201 Ferrite Bead 61 FB42 1 BLM15AG121SN1 120ohm@100MHZ 500mA SMF0402 Ferrite Bead 62 FB5N1 1 BLM15HG601SN1 600ohm,1000ohm 300mA SMF0402 NO_S TUFF IC 63 F1,U22,U24 3 TPS…

Text truncated - open the document above for the full version.

Advance Tech Communications Sdn Bhd Address: Persoft Tower , Level 6 , 6B , Persiaran Tropicana , Tropicana Golf and Country Resort , Petaling Jaya , Selangor DE , Malaysia . Tel: 603-78065263 Pax: 603-78065236 Declaration To Whom It May Concern, We, Advance Tech Communications Sdn Bhd, hereby declare that our Microcomputer with integrated Telephony, Model Number W3 that was certified by BACL. We use the wireless module named as MO6612 that was manufactured by Option nv, FCC ID to the wireless module is NCMOMO6612 which was granted on 07/07/2011.,we declare that we have not made any change regarding the RF power and frequency, so the tune-up procedure about W3 can refer to the wireless module. Please kindly handle on the project. 2013.01.23

Note: This test report is prepared for the customer shown above and for the equipment described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and shall be marked with an asterisk “★” SAR EVALUATION REPORT For Advance Tech Communications Sdn Bhd Persoft Tower , Level 6 , 6B , Persiaran Tropicana , Tropicana Golf and Country Resort , Petaling Jaya ,Selangor DE , Malaysia FCC ID: QTTATCMAGICW3 Report Type: Original Report Product Type: Microcomputer with integrated Telephony Test Engineer: Sandy Wang Report Number: RSZ121120005-20 Report Date: 2013-01-17 Reviewed By: Alvin Huang RF Leader Test Laboratory: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F, the 3rd Phase of WanLi Industrial Building, ShiHua Road, FuTian Free Trade Zone Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No: RSZ121120005-20 SAR Evaluation Report 2 of 131 Attestation of Test Results Company Name Advance Tech Communications Sdn Bhd EUT Description Microcomputer with integrated Telephony FCC ID QTTATCMAGICW3 Model Number W3 EUT Information Test Date 2013-01-04 to 2013-01-06 Frequency Max. SAR Level(s) Measured Limit(W/Kg) Cellular Band 0.013 W/kg 1g Head SAR 0.099 W/kg 1g Body SAR PCS Band 0.015 W/kg 1g Head SAR 0.746 W/kg 1g Body SAR WCDMA850 0.008 W/kg 1g Head SAR 0.118 W/kg 1g Body SAR WCDMA1900 0.006 W/kg 1g Head SAR 1.252 W/kg 1g Body SAR Max Simultaneous SAR 1.342 W/kg 1g Body SAR 1. 6 ANSI / IEEE C95.1 : 2005 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fileds,3 kHz to 300 GHz. ANSI / IEEE C95.3 : 2002 IEEE Recommended Practice for Measurements and Computations of Radio Frequency Electromagnetic Fields With Respect to Human Exposure to SuchFields,100 kHz—300 GHz. OET BULLETIN 65 SUPPLEMENT C Evaluating Compliance with FCC Guidelines for Human Exposure To Radiofrequency Electromagnetic Fields Applicable Standards IEEE1528:2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in ANSI/IEEE Standards and has been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C and IEEE 1528-2003. The results and statements contained in this report pertain only to the device(s) evaluated. Bay Area Compliance Laboratories Corp. (Shenzhen) Report No: RSZ121120005-20 SAR Evaluation Report 3 of 131 TABLE OF CONTENTS DOCUMENT REVISION HISTORY .........................................................................................................................4 EUT DESCRIPTION ....................................................................................................................................................5 TECHNICAL SPECIFICATION.........................................................................................................................................5 REFERENCE, STANDARDS, AND GUILDELINES ...............................................................................................6 SAR LIMITS.................................................................................................................................................................7 FACILITIES AND ACCREDITATION .....................................................................................................................8 DESCRIPTION OF TEST SYSTEM ..........................................................................................................................9 EQUIPMENT LIST AND CALIBRATION .............................................................................................................16 EQUIPMENTS LIST & CALIBRATION INFORMATION....................................................................................................16 SAR MEASUREMENT SYSTEM VERIFICATION ..............................................................................................17 LIQUID VERIFICATION...............................................................................................................................................17 SYSTEM ACCURACY VERIFICATION...........................................................................................................................20 SAR SYSTEM VALIDATION DATA .....................................................................................................................21 EUT TEST STRATEGY AND METHODOLOGY .................................................................................................29 TEST POSITIONS FOR DEVICE OPERATING NEXT TO A PERSON’S EAR........................................................................29 CHEEK/TOUCH POSITION...........................................................................................................................................30 EAR/TILT POSITION...................................................................................................................................................30 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS..............................................................................31 SAR EVALUATION PROCEDURE.................................................................................................................................32 CONDUCTED OUTPUT POWER MEASUREMENT ........................................................................................…

Text truncated - open the document above for the full version.

Note: This test report is prepared for the customer shown above and for the equipment described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. FCC PART 22H, PART 24E TEST REPORT For Advance Tech Communications Sdn Bhd Persoft Tower, Level 6, 6B, Persiaran Tropicana, Tropicana Golf and Country Resort, Petaling Jaya , Selangor DE , Malaysia . FCC ID: QTTATCMAGICW3 Report Type: Original Report Product Type: Microcomputer with integrated Telephony Test Engineer: Henry Ding Report Number: RSZ121120005-00C Report Date: 2012-12-31 Reviewed By: Alvin Huang RF Leader Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F, the 3rd Phase of WanLi Industrial Building ShiHua Road, FuTian Free Trade Zone Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ121120005-00C FCC Part 22H/24E Page 2 of 14 TABLE OF CONTENTS GENERAL INFORMATION.......................................................................................................................................3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .....................................................................................3 OBJECTIVE...................................................................................................................................................................3 RELATED SUBMITTAL(S)/GRANT(S).............................................................................................................................3 TEST METHODOLOGY..................................................................................................................................................3 TEST FACILITY.............................................................................................................................................................4 SYSTEM TEST CONFIGURATION ..........................................................................................................................5 DESCRIPTION OF TEST CONFIGURATION......................................................................................................................5 EQUIPMENT MODIFICATIONS.......................................................................................................................................5 BLOCK DIAGRAM OF TEST SETUP................................................................................................................................5 SUMMARY OF TEST RESULTS...............................................................................................................................6 FCC §1.1307 & §2.1093 - RF EXPOSURE..................................................................................................................7 APPLICABLE STANDARD..............................................................................................................................................7 TEST RESULT...............................................................................................................................................................7 FCC §2.1047 - MODULATION CHARACTERISTIC ..............................................................................................8 FCC § 2.1046, § 22.913 (A) & § 24.232 (C) - RF OUTPUT POWER........................................................................9 APPLICABLE STANDARD..............................................................................................................................................9 TEST PROCEDURE........................................................................................................................................................9 TEST EQUIPMENT LIST AND DETAILS...........................................................................................................................9 TEST DATA................................................................................................................................................................10 FCC §2.1053, §22.917 & §24.238 - SPURIOUS RADIATED EMISSIONS ...........................................................12 APPLICABLE STANDARD............................................................................................................................................12 TEST PROCEDURE......................................................................................................................................................12 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................12 TEST DATA................................................................................................................................................................13 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ121120005-00C FCC Part 22H/24E Page 3 of 14 GENERAL INFORMATION Product Description for Equipment under Test (EUT) The Advance Tech Communications Sdn Bhd’s product, model number: W3 (FCC ID: QTTATCMAGICW3) or the "EUT" in this report was a Microcomputer with integrated Telephony, which was measured approximately: 14.0 cm (L) x 8.0 cm (W) x 2.5 cm (H), rated input voltage: DC 3.7 V Li-ion battery. * All measurement and test data in this report was gathered from production sample serial number: 1211115 (Assigned by BACL, Shenzhen). The EUT supplied by the applicant was received on 2012-11-20. Objective This test report is prepared on behalf of Advance Tech Communications Sdn Bhd in accordance with Part 2-Subpart J, Part 22-Subpart H, and Part 24-Subpart E of the Federal Communication Commissions rules. The objective is to determine the compliance of the EUT with FCC rules for output power, modulation characteristic, occupied bandwidth, and spurious emission at antenna terminal, spurious rad…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emissions Test View (Below 1 GHz) Radiated Emissions Test View (Above 1 GHz)
