QVQ-QNRS283Rolling Code Remote Control to Compatible with Original Genie Remote

Instruction Manual of QN-RS283 ---to Compatible with original Genie Remote Introduction of original Genie remote and compatible remote control QN-RS283 As pictures shown above: 1、 Picture 3 is original Genie remote, model G3T-BX, frequency 390MHZ ; 二、Instruction of our model QN-RS283 how to work with original Genie Receiver 一）、2 original Genie receiver boxes to work with Genie remote, as show in Picture5 (Genie receiver box A) and Picture6 (Genie receiver box B), as follows; Picture5 (Genie receiver box A) Picture6 (Genie receiver box B) Note: 1、 Picture5 (Genie receiver box A): Receiving frequency is 390MHZ, LED is Two-color LED lights, Green light after the power supply has been in a state of slow flash, the red light is used for remote learning and remote control when the state of the instructions, OFF state under normal condition; 2、 Picture6 (Genie receiver box B)：；Receiving frequency is dual frequency of 390MHZ, LED is monochrome LED lights, is used for remote learning and remote control when the state of the instructions, OFF state under normal condition; 3、 Both receiver box access Power supply: DC 12V-24V 二）、Steps learning remote codes： 1、 Press the learning button on the receiver and then release, the red LED on the receiver box will flash 2 times per second; 2、 Press the button you want to learn with receiver within 30 seconds, you will see the red LED on the receiver then keep lighting; 3、 Within 30 seconds press again the same button you want to learn with receiver , the red LED will go out, then the end of the study; 三）、The control state of Receiver When press the remote button we’ve learned, the red LED will lighting about 1S and then flashing; When press the remote control button is no learning or learning unsuccessful, the red LED will keep blinking; 四）、Removed the remote code that receiver has recorded Press the learn button of receiver until the red LED on the receiver go out, then deleted successfully; Please Note: Each remote control has only one valid button to control the receiver, that is, if you learn all the keys of the remote control into the receiver, then only the last significant study supporting the receiver and remote control key to be able to work. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.

November 24, 2014 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: QVQ-QNRS283____ Product Name: Rolling Code Remote Control to Compatible with Original Genie Remote _ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this November 24, 2014 Agency agreement expiration date: Usually Give 8 - 12 Months By: Branda Wu Signature Printed Title: Sales woman On behalf of : (Company Name) Qinuo Electronics Co., Ltd Telephone: 595-22569016

November 24, 2014 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Alpha Product Testing Laboratory Address: 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2nd Road, Bao'an District, Shenzhen 518126, P.R. China Person: Mark Zhu (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Qinuo Electronics Co., Ltd. Address: 3/F, Bldg. A, Yucheng Base, Keji Rd., High-Tech Industrial Park, Fengze, Quanzhou, Fujian, China 362000 ( applicant name and address). Signature: Name Branda Wu Position Sales woman Company Name Qinuo Electronics Co., Ltd. Address 3/F, Bldg. A, Yucheng Base, Keji Rd., High-Tech Industrial Park, Fengze, Quanzhou, Fujian, China 362000 Tel 595-22569016 Fax 595-22561208 Email [email protected]

5mm 3mm FCC ID: QVQ-QNRS283 Label Location

ANTENNA

FCC ID: QVQ-QNRS283 Page 1 of 30 TEST REPORT FCC ID: QVQ-QNRS283 Applicant : Qinuo Electronics Co., Ltd Address : 3/F, Bldg. A, Yucheng Base, Keji Rd., High-Tech Industrial Park, Fengze, Quanzhou, Fujian, China 362000 Equipment under Test (EUT): Name : Rolling Code Remote Control to Compatible with Original Genie Remote Model : QN-RS283 Standards : FCC PART 15, SUBPART C : 2012 (Section 15.231) Report No. : A1840902 01 Date of Test : November 3-10, 2014 Date of Issue : November 11, 2014 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Simple Guan) Project Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Page 2 of 30 Report No.: A1840902 01 FCC ID: QVQ-QNRS283 Page 2 of 30 TABLE OF CONTENT Description Page 1 General Information ----------------------------------------------------------------------------------3 1.1 Description of Device (EUT) -------------------------------------------------------------------- 3 1.2 Description of Test Facility ---------------------------------------------------------------------- 3 2 EMC Equipment List ---------------------------------------------------------------------------------4 3 Test Procedure ----------------------------------------------------------------------------------------4 4 Summary of Measurement -------------------------------------------------------------------------6 4.1 Summary of test result --------------------------------------------------------------------------- 6 4.2 Block Diagram ------------------------------------------------------------------------------------ 6 4.3 Assistant equipment used for test --------------------------------------------------------------- 6 4.4 Test Conditions ----------------------------------------------------------------------------------- 7 4.5 Measurement Uncertainty (95% confidence levels, k=2) ------------------------------------ 7 5 Radiation Emission ----------------------------------------------------------------------------------8 5.1 Radiation Emission Limits(15.209&231) ------------------------------------------------------ 8 5.2 Test Setup ----------------------------------------------------------------------------------------- 8 5.3 Test Procedure ---------------------------------------------------------------------------------- 10 5.4 Test Equipment Setting For emission test. --------------------------------------------------- 11 5.5 Test Condition ---------------------------------------------------------------------------------- 11 5.6 Test Result --------------------------------------------------------------------------------------- 11 6 POWER LINE CONDUCTED EMISSION ------------------------------------------------------ 17 6.1 Conducted Emission Limits(15.209) --------------------------------------------------------- 17 6.2 Test Setup --------------------------------------------------------------------------------------- 17 6.3 Test Procedure ---------------------------------------------------------------------------------- 18 6.4 Test Results ------------------------------------------------------------------------------------- 18 7 Occupied bandwidth ------------------------------------------------------------------------------- 19 7.1 Test limit ----------------------------------------------------------------------------------------- 19 7.2 Method of measurement ----------------------------------------------------------------------- 19 7.3 Test Setup --------------------------------------------------------------------------------------- 19 7.4 Test Results ------------------------------------------------------------------------------------- 19 8 Transmission time ---------------------------------------------------------------------------------- 21 8.1 Test limit ----------------------------------------------------------------------------------------- 21 8.2 Method of measurement ----------------------------------------------------------------------- 21 8.3 Test Setup --------------------------------------------------------------------------------------- 21 8.4 Test Results ------------------------------------------------------------------------------------- 21 9 Band Edge Check ----------------------------------------------------------------------------------- 23 9.1 Test limit ----------------------------------------------------------------------------------------- 23 9.2 Test Procedure ---------------------------------------------------------------------------------- 23 9.3 Test Setup --------------------------------------------------------------------------------------- 23 9.4 Test Result --------------------------------------------------------------------------------------- 23 10 Antenna Requirement ----------------------------------------------------------------------------- 24 10.1 Standard Requirement -------------------------------------------------------------------------- 24 10.2 Antenna Connected Construction ------------------------------------------------------------- 24 10.3 Result -------------------------------------------------------------------------------------------- 24 11 Photographs of Test Setup ---------------------------------------------------------------------- 25 12 Photographs of EUT ------------------------------------------------------------------------------- 26 Page 3 of 30 Report No.:…

Text truncated - open the document above for the full version.

Radiated Emission Test Setup in Chamber
