1. RF Exposure Requirements 1.1 General Information Client Information Applicant: AFCO INC. Address of applicant: 122 Gayoso Ave Memphis, TN 38103 Manufacturer: SHENZHEN TOKWA PRECISION TECHNOLOGY CO., LTD . Address of manufacturer: A5 Building, Tongxin Industrial Zon, No.87, Tongxin Road, Longgang District, Shenzhen City, Guangdong Province, P.R.China General Description of EUT: Product Name: Marine Media Center Trade Name MEMPHIS Model No.: MXAZ24MC Adding Model(s): KSM1803 Rated Voltage: DC 14.4V Battery Capacity: / Adapter Model: / Software Version: / Hardware Version: KGM1803_TFT_VER1.0 FCC ID: QWI-MXAZ24MC Equipment Type: Mobile device Technical Characteristics of EUT: Bluetooth Bluetooth Version: V3.0 (BR/EDR mode) Frequency Range: 2402-2480MHz RF Output Power: -2.39dBm (Conducted) Data Rate: 1Mbps, 2Mbps, 3Mbps Modulation: GFSK, π/4 DQPSK, 8DPSK Quantity of Channels: 79 Channel Separation: 1MHz Type of Antenna: PCB Antenna Antenna Gain: 3.3dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Min. Frequency Max. Output Power Max. Tune-Up Output Power Antenna Gain Duty Cycle Tune-Up EIRP (MHz) (dBm) (dBm) (dBi) (%) (dBm) Bluetooth 2402 -2.39 -2.0 3.3 100 1.30 Frequency Option Min. Distance Tune-Up ERP Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 C 20.00 -0.85 0.82 768.00 0.01 Pass Note: 1. ERP=EIRP-2.15dB; EIRP= Output Power + Antenna gain 2. Option A, B and C refers as clause 1.2. 3. For option B, Pth(mW) convert to Exposure Limit(mW); For option C, ERP(W) convert to Exposure Limit(mW). 4. Ratio= Tune-Up ERP(mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail -- -- -- -- -- -- Result: Pass

1 1.Project specification NC Content Page Number 1 Project specification 1 2 Electrical performance test report 2 3 Product graph 2 4 Network analyzer graph 3 5 Efficiency and Gain test results 4 6 Radiation pattern 5 3 4.Network analyzer graph 4 5.Efficiency and Gain test results Frequency：2.402-2.480GHz Frequency Point(MHz) Efficiency(%) Efficiency(dB ) Gain(dBi) 2400 60.56% -2.2 3.1 2410 61.20% -2.1 3.1 2420 65.76% -1.8 3.3 2430 65.29% -1.9 3.2 2440 61.95% -2.1 2.8 2450 63.69% -2.0 2.8 2460 63.38% -2.0 2.6 2470 69.39% -1.6 2.9 2480 73.52% -1.3 3.1 Mean value 64.97% -1.88 2.98 5 6.Radiation pattern 3D Diagram: 2.400GHZ Diagram： (Theta 0) 6 （Phi 0） （Phi 90） 7 (Theta 0) （Phi 0） 2.440GHz Diagram: 8 (Theta 0) （Phi 90） 2.480GHz Diagram 9 （P hi 0） （Phi 90）
