Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 8 | 24E | 1.85 GHz - 1.91 GHz | 254.00 mW | 4M17F9W | 2.5
ppm |
Modular TypeLimited Single Modular ApprovalConfidentialityLong Term Grant NotesPower Output listed is Conducted. The highest radiated power measured in specific configurations shown in this filing is Part 22 0.841W ERP and Part 24 0.979W EIRP. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. Limited Modular Approval for general mobile application which the radiator can be installed at least 20cm away from the user and for evaluated specific portable application with Getac tablet PC model: E110 as described in this filing. Antenna gain including cable loss must not exceed 2dBi in Cellular 800MHz band and 2.1dBi in PCS 1900MHz bands for purposes of 2.1043 and 2.1091. Other usage(s) or co-located application(s) not described in this filing will need a separate approval or new ID. Compliance of this device in all final product configurations is the responsibility of the Grantee. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The highest reported SAR value for body-worn use condition is 1.27 W/kg.
