R28FSV-1000Digital Voice Recorder

Made in korea Version 2005.2 Voice Recorder Be sure to read this user manual before using the recorder.Keep this manual in good custody as it may be useful later. Voice Recorder

























…

Text truncated - open the document above for the full version.

FLASH MEMORY USB DRIVER (12MHz) DATA BUS MICOM (8.192MHz) LCD KEYS VOICE COMPRESSION ENCODER & DECODER (DSPG D36531) MIC SPEAKER FSV- 100 0 SYSTEM BLOCK DIAGRAM RTC (32.768kHz)

ID Label Sample & Location Information

IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0121 1 of 19 Certification of Compliance CFR 47 Part 15 Subpart B Test Report File No. : 05-IST-0121 Date of Issue : March 07, 2005 Model(s) : FSV-1000 Kind of Product : Digital Voice Recorder Applicant : Forus Electronics Co., Ltd. Address : 135-270, 4th Fl, 419-5, Dogok-Dong, Kangnam-Gu, Seoul, Korea Manufacturer : Forus Electronics Co., Ltd. Address : 135-270, 4th Fl, 419-5, Dogok-Dong, Kangnam-Gu, Seoul, Korea Test Result ■ Positive □ Negative Reviewed By Approved By S.J.CHO / EMC Group Manager J.H.LEE / Chief Comment(s) - Investigations requested : Measurement to the relevant clauses of FCC rules and regulations Part 15 Subpart B – Unintentional Radiators, Class B. - The test report with appendix consists of 19 pages. - The test result only responds to the tested sample. - It is not allowed to copy this report even partly without the allowance of IST EMC Laboratory. - This equipment as for has been shown to be capable of continued compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4 2003. IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0121 2 of 19 TABLE OF CONTENTS Table of contents 2 Information of test laboratory, Environmental conditions, Power used, Product information 3 Descriptions of test Conducted Emission 4 Radiated Emission 5 Equipment Under Test 6 Summary 7 ■ Test Conditions and Data - Emissions ◆ Conducted Emissions 0.15MHz - 30MHz Applicable Test Conditions / Data and Plots 8-10 ◆ Radiated Emissions 30MHz - 1GHz Applicable Test Conditions / Data and Plots 11-13 Appendix A. The Photos of Test Setup 14-16 B. The Photos of Equipment Under Test 17-19 Note : IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0121 3 of 19 INFORMATIONS OF TEST LABORATORY EMC LABORATORY of IST Co., Ltd. (FCC Filing Lab.) San 21-8, Goan-Ri, Baekam-Myun, Yongin-City Kyonggi-Do, 449-860, Korea TEL : +82 31 333 4093 FAX : +82 31 333 4094 ENVIRONMENTAL CONDITIONS Temperature 16.5 °C Humidity 31 % Atmospheric pressure 1014 mbar POWER SUPPLY SYSTEM USED Power supply system AC 120Vac, 60Hz(PC Power) (Refer to the product information) PRODUCT INFORMATION Recording medium: Built-in Flash Memory(128MB) Continuous recording time: XG:15Hours, HQ:22Hours, SP:30Hours, LP:65Hours Maximum number of recordieg files: 99 files per folder x 4 folders=396 files Dimension: 32 x 16 x 86.5 mm Weight: 33.3g(excluding the batteries weight of 24g) Power Source: DC 3V (Size AAA x 2) PC interface: USB - EMC suppression device is not used during the test . - Please refer to user’s manual. IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0121 4 of 19 < Concept Drawing > 215 >150 >40 80 Receiver EUT LISN 80 ≥ 80 80 40 ≥ 80 Measuring apparatus Mains Filter Mains Front side Equipment under test Coaxial cable Artificial mains networ k Screened room Non-metallic support 80 DESCRIPTIONS OF TEST Conducted Emissions: The measurement were performed over the frequency range of 0.15MHz to 30MHz using a 50 Ω /50uH LISN as the input transducer to a Spectrum Analyzer or a Field Intensity Meter. The measurements were made with the detector set for "Peak" amplitude within a bandwidth of 10KHz or for "quasi-peak" & “Average” within a bandwidth of 9KHz. - Procedure of Test The line-conducted facility is located inside a shielded room No.1. A 1m X 1.5m wooden table 80cm height is placed 40cm away from the vertical wall and 1.5m away from the other wall of the shielded room. The R/S ESH3-Z5 and EMCO 3825/2 LISN are bonded to bottom of the shielded room. The EUT is located on the wooden table with distance more than 80cm from the LISN and powered from the EMCO LISN .The peripheral equipment is powered from the other LISN. Power to the LISNs are filtered by a noise cut power line filters. All electrical cables are shielded by braided tinned steel tubing with inner φ 1.2cm. If the EUT is a DC-powered device, power will be derived from the source power supply it normally will be powered from and this supply lines will be connected to the EMCO LISN. All interconnecting cables more than 1m were shortened by non-inductive bundling to a 1m length. Sufficient time for the EUT, support equipment, and test equipment was allowed in order for them to warm up to their normal operating conditions. The RF output of the LISN was connected to the R/S receiver to determine the frequency producing the maximum emission from the EUT. The frequency producing the maximum level was reexamined using Quasi-Peak mode by manual measurement, after scanned by automatic Peak mode for frequency range from 0.15 to 30MHz. The bandwidth of the receiver was set to 10kHz. The EUT, peripheral equipment, and interconnecting cables were arranged and manipulated to maximize each EME emission. < Side View > IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0121 5 of 19 DESCRIPTION OF TEST Radiated Emissions: The measurement was performed over the frequency range of 30MHz to 1GHz using antenna as the input transducer to a Spectrum analyzer or a Field Intensity Meter. The measurement was made with the detector set for "quasi-peak" within a bandwidth of 120KHz. - Procedure of Test Preliminary measurements were made at 3 meter using bi-conical and log-periodic antennas, and spectrum analyzer to determine the frequency producing the max. emission in anechoic chamber. Appropriate precaution was taken to ensure that all emission from the EUT were maximized and investigated. The system configuration, mode of operation, turn-table azimuth and height with respect to the antenna were noted for each frequency found. The spectrum was scanned from 30MHz to 300MHz using S/B bi-conical antenna and 300 to 1000MHz using S/B log-periodic antenna. Above 1GHz, linearly polarized double ridge horn antennas were used. Final measurements were made at open site with 3-meters test distance using S/B bi-log antenna or horn ante…

Text truncated - open the document above for the full version.

IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0121 14 of 19 Appendix A. The Photos of Test Setup Conducted Emissions(File up/download mode) – Front View Conducted Emissions(File up/download mode) – Rear View IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0121 15 of 19 Appendix A. The Photos of Test Setup Radiated Emissions(Voice recording mode) - Front View Radiated Emissions(Voice recording mode) - Rear View IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0121 16 of 19 Appendix A. The Photos of Test Setup Radiated Emissions(File up/download mode) – Front View Radiated Emissions(File up/download mode) – Rear View
