THE HELPMATE Thank you for choosing the Helpmate. The Helpmate serves as a perfect personal safety system that is designed for the elderly, disabled persons, and long-term care patients in the household who require the assistance of their caregiver or family member. The Helpmate features a remote call unit that activates the receiver when the call button is pressed – the caregiver can immediately provide assistance to the user upon hearing a continuous loud beep and observing the flashing lights on the receiver. Please read this Instruction Manual thoroughly before using the product. Keep this manual in a convenient place for future reference. PRODUCT OVERVIEW Call Unit Receiver Style 1: Tea Pot with clock Style 2: Fishman Style 3: Chef INSTALLING BATTERIES The Call Unit uses one 9V battery and the Receiver uses three AA batteries. To install or replace the batteries, please follow these steps: 1. Unscrew the battery cover on the Call unit/Receiver. 2. Insert the batteries observing the correct polarity. 3. Replace the battery cover and tighten the screw. (To install or replace the batteries and to set the time for teapot style clock, open the clock face by simply turning the clock face to the right. Insert the batteries and set the time by turning the knob at the back until the correct time is selected. When finished, replace the clock face and turn it until the arrows align.) ** Change the batteries when the signal is unclear or the system does not appear to be functioning properly. **Alkaline batteries are recommended. THE CALL UNIT/THE RECEIVER The Call Unit can be attached to any convenient location (preferably near the user) using Velcro tape or by mounting it on a wall with a screw. The Receiver should be placed near the caregiver so that the beeping sound or flashing lights can be heard or seen when the Receiver is activated. HOW TO USE 1. Place the Call Unit near the user and the receiver near the caregiver. 2. When the user requires assistance, press the Call button on the Call unit until the LED light blink. 3. A light will flash and loud continuous beeping will sound from the Receiver, signaling that the user requires immediate attention. 4. The caregiver can turn off the beeping sound and flashing light by pressing the button on the Receiver. SPECIFICATION - Power Requirements: Call unit - 3xAA Battery operated Receiver - 1x9A Battery operated (Tea Pot style requested one additional AA battery for the clock) - Operating Frequency: 433MHz - Alarm Sound: 92 Decibels - Weight (without Battery): Receiver Style 1 - Fishman: 172g Receiver Style 2 - Tea Pot with clock: 213g Receiver Style 3 - Chef: 183g Call Unit – 87g - Working range: up to 45 meters - Battery life cycle: Approx. 1 year for the Call Unit Approx. 70 days for the Receiver TROUBLESHOOTING - Within ferro-concrete rooms (basements, superstructures), the signal is naturally weakened and in extreme cases the signal may not be received. In this case, place the unit close to a window so that it faces the general direction of the transmitter. THE HELPMATE Instruction Manual Federal Communications Commission (FCC ) Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference received, including interference that may cause undesired operation of the device. Note: The manufacturer is not responsible for any radio of TV interference caused by unauthorized modification to this equipment. Such modification could void the user’ s authority to operate the equipment.

Applicant: Marco Manufacturing Limited FCC ID: R2P91001 433.8MHz

Applicant: Marco Manufacturing Limited FCC ID: R2P91001 EUT top view EUT bottom view

Applicant: Marco Manufacturing Limited FCC ID: R2P91001 Proposed Label Location on EUT EUT Bottom View/Proposed FCC ID Label Location FCC ID: R2P91001

Applicant: Marco Manufacturing Limited FCC ID: R2P91001 EUT inside whole view Main board component side Main board solder side

Applicant: Marco Manufacturing Limited FCC ID: R2P91001 Operation Description The 91001 Helpmate serves as a perfect personal safety system that is designed for the elderly, disabled persons, and long-term care patients in the household who require the assistance of their caregiver or family member. The working frequency is 433MHz. when push the switch, the LED will active. The encoder will send a signal to the RF transmitter. The RF transmitter will modulate the signal and send it out. Ten working frequency is depend on the IC of the transmitter. It is set to 433MHz.

Applicant: Marco Manufacturing Limited FCC ID: R2P91001

The test report consists 24 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Ke Mei Ou Laboratory Corporation. The test result in the report only applied to the tested sample. FCC TEST REPORT Under : FCC 15 Subpart C, Paragraph 15.231 Prepared For : Marco Manufacturing Limited Pen Nan Industrial Centre Sanxiang Town, Zhongshan Guangdong China April 8, 2004 FCC ID: R2P91001 EUT: Helpmate Model: 91001 Report Type: Original Report Test Engineer: Peter Lin Test Date: April 6, 2004 Review By: Apollo Liu / Manager FEDERAL COMMUNICATIONS COMMISSION Registration Number: 125782 INDUSTRY CANADA Registration Number: IC4986 Ke Mei Ou Laboratory Co., Ltd. 7A, Jiaxiangge, Jiahuixincheng, No.3027, Shennan Rd., Futian, Shenzhen, Guangdong, P.R.China. Zip Code: 518033 Tel: + 86 755 83642690 Fax: + 86 755 83297077 www.kmolab.com Marco Manufacturing Limited. FCC ID: R2P91001 KMO FCC ID Report Report #: KSZ2004040601J Page 2 of 24 TABLE OF CONTENTS 1. General Information...........................................................................................................................................................3 1. 1 Notes...............................................................................................................................................................................3 1. 2 Testing Laboratory..........................................................................................................................................................3 1. 3 Details of Applicant........................................................................................................................................................3 1. 4 Application Details.........................................................................................................................................................3 1. 5 Test Item.........................................................................................................................................................................3 1. 6 Test Standards.................................................................................................................................................................4 2. Technical Test.......................................................................................................................................................................5 2. 1 Summary of Test Results................................................................................................................................................5 3. EUT Modifications..............................................................................................................................................................6 4. Conducted Power Line Test................................................................................................................................................7 4. 1 Test Equipment...............................................................................................................................................................7 4. 2 Test Procedure................................................................................................................................................................7 4. 3 Test Setup.......................................................................................................................................................................7 4. 4 Configuration of The EUT..............................................................................................................................................8 4. 5 EUT Operating Condition...............................................................................................................................................9 4. 6 Conducted Power Line Emission Limits........................................................................................................................9 4. 7 Conducted Power Line Test Result...............................................................................................................................10 5. Radiated Emission Test......................................................................................................................................................11 5. 1 Test Equipment.............................................................................................................................................................11 5. 2 Test Procedure..............................................................................................................................................................11 5. 3 Radiated Test Setup......................................................................................................................................................11 5. 4 Configuration of The EUT............................................................................................................................................12 5. 5 EUT Operating Condition.............................................................................................................................................12 5. 6 Radiated Emission Limit..............................................................................................................................................12 5. 7 Radiated Emission Test Result......................................................................................................................................13 6. Technical Characteristic....................................................................................................................................................14 6. 1 Band Edge.....................................................................................................................................…
