Shenzhen Mission Electronic Limited 3F, No 10-3, 1st Road Min Sheng, Langxin Community, Shiyan Town, Baoan Zone, Shenzhen, China 1 | P a g e Attestation Statements To: Federal Communications Commission Date: Dec. 17, 2025 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: R5B-G07 Product Name: True Wirless Stereo This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: Yunlong Xie Title: Electronics Engineers Address: 3F, No 10-3, 1st Road Min Sheng, Langxin Community, Shiyan Town, Baoan Zone, Shenzhen, China Tel.: 13410762996 Email: [email protected] Shenzhen Mission Electronic Limited 3F, No 10-3, 1st Road Min Sheng, Langxin Community, Shiyan Town, Baoan Zone, Shenzhen, China 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. Compliance ☐ The Memory used is limited to run the Cybersecurity or anti-virus software. Compliance ☐ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. Compliance ☐ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. Compliance Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check

Shenzhen Mission Electronic Limited 3F, No 10-3, 1st Road Min Sheng, Langxin Community, Shiyan Town, Baoan Zone, Shenzhen, China Dec. 17, 2025 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID: R5B-G07 Models: G07, T21, M01, T8, T9, K18, G40, T13, T18, G05 To Whom It May Concern: We, The Shenzhen Mission Electronic Limited hereby declare that the model : T21, M01, T8, T9, K18, G40, T13, T18, G05 is identical with the model : G07, except the model name. All the models are the same circuit and RF module. Sincerely, Shenzhen Mission Electronic Limited Signature: [Yunlong Xie, Electronics Engineers]

Shenzhen Mission Electronic Limited 3F, No 10-3, 1st Road Min Sheng, Langxin Community, Shiyan Town, Baoan Zone, Shenzhen, China Dec. 17, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: R5B-G07 I, the undersigned, hereby authorize (Attestation of Global Compliance (Shenzhen) Co., Ltd) to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by (Attestation of Global Compliance (Shenzhen) Co., Ltd) shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with Shenzhen Mission Electronic Limited. We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, (Signature) Full name of contact person listed on FCC’s website: Yunlong Xie Title: Electronics Engineers Tel.: 13410762996 Email: [email protected]

Report No.: AGC00727251101AP02 Page 1 of 3 EXTERNAL PHOTOS TOP VIEW OF EUT BOTTOM VIEW OF EUT Report No.: AGC00727251101AP02 Page 2 of 3 FRONT VIEW OF EUT BACK VIEW OF EUT Report No.: AGC00727251101AP02 Page 3 of 3 LEFT VIEW OF EUT RIGHT VIEW OF EUT ****************************************End of Report*************************************

FCC ID Label Location The product does not have enough space to place the label, and FCC ID is located in the user manual and package. User manual as below: Package as below: True Wirless Stereo G07 FCC ID：R5B-G07

Report No.: AGC00727251101AP02 Page 1 of 6 INTERNAL PHOTOS Left OPEN VIEW OF EUT BATTERY VIEW OF EUT Report No.: AGC00727251101AP02 Page 2 of 6 INTERNAL VIEW OF EUT (FIGURE 1) INTERNAL VIEW OF EUT (FIGURE 2) Report No.: AGC00727251101AP02 Page 3 of 6 INTERNAL VIEW OF EUT (FIGURE 3) INTERNAL VIEW OF EUT (FIGURE 4) BT Antenna Report No.: AGC00727251101AP02 Page 4 of 6 Right OPEN VIEW OF EUT BATTERY VIEW OF EUT Report No.: AGC00727251101AP02 Page 5 of 6 INTERNAL VIEW OF EUT (FIGURE 1) INTERNAL VIEW OF EUT (FIGURE 2) Report No.: AGC00727251101AP02 Page 6 of 6 INTERNAL VIEW OF EUT (FIGURE 3) INTERNAL VIEW OF EUT (FIGURE 4) ****************************************End of Report************************************* BT Antenna

Page 1 of 10 RF Exposure Report Report No.: AGC00727251101FH01 FCC ID : R5B-G07 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : True Wirless Stereo BRAND NAME : N/A MODEL NAME : G07, T21, M01, T8, T9, K18, G40, T13, T18, G05 APPLICANT : Shenzhen Mission Electronic Limited DATE OF ISSUE : Dec. 29, 2025 STANDARD(S) : FCC Part 2 Subpart J §2.1093 FCC KDB 447498 D01 V06 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC00727251101FH01 Page 2 of 10 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Dec. 29, 2025 Valid Initial Release Report No.: AGC00727251101FH01 Page 3 of 10 Table of Contents 1. General Information ........................................................................................................................................ 4 2. Product Information ........................................................................................................................................ 5 2.1 Product Technical Description ................................................................................................................... 5 3. Test Environment ............................................................................................................................................ 6 3.1 Address Of The Test Laboratory ............................................................................................................... 6 3.2 Test Facility ................................................................................................................................................ 6 3.3 Environmental Conditions ......................................................................................................................... 7 4. Portable Device Evaluation Method and Limit ............................................................................................. 8 5. Measurement Results ..................................................................................................................................... 9 6. Measurement Evaluation ................................................................................................................................ 9 Report No.: AGC00727251101FH01 Page 4 of 10 1. General Information Applicant Shenzhen Mission Electronic Limited Address 3F, No 10-3, 1st Road Min Sheng, Langxin Community, Shiyan Town, Baoan Zone, Shenzhen, China Manufacturer Shenzhen Mission Electronic Limited Address 3F, No 10-3, 1st Road Min Sheng, Langxin Community, Shiyan Town, Baoan Zone, Shenzhen, China Factory Shenzhen Mission Electronic Limited Address 3F, No 10-3, 1st Road Min Sheng, Langxin Community, Shiyan Town, Baoan Zone, Shenzhen, China Product Designation True Wirless Stereo Brand Name N/A Test Model G07 Series Model(s) T21, M01, T8, T9, K18, G40, T13, T18, G05 Difference Description All the same except for the model name. Date of receipt of test item Nov. 25, 2025 Date of Test Nov. 25, 2025 to Dec. 29, 2025 Deviation from Standard No any deviation from the test method Condition of Test Sample Normal Test Result Pass Test Report Form No AGCER-FCC-RF Exposure-V1 Note: The test results of this report relate only to the tested sample identified in this report. Prepared By Jasiel Xie (Project Engineer) Dec. 29, 2025 Reviewed By Bibo Zhang (Reviewer) Dec. 29, 2025 Approved By Angela Li (Authorized Officer) Dec. 29, 2025 Report No.: AGC00727251101FH01 Page 5 of 10 2. Product Information 2.1 Product Technical Description Frequency Band (Operating) Bluetooth: 2.402GHz ~ 2.480GHz Other: Hardware Version V1.0 Software Version V1.0 Modulation Type BR GFSK, EDR π /4-DQPSK, 8DPSK BLE GFSK 1Mbps GFSK 2Mbps Maximum Transmitter Power BR&EDR: Left earphone: 3.614dBm Right earphone: 2.953dBm BLE: Left earphone: BLE GFSK 1Mbps: 2.444dBm BLE GFSK 2Mbps: 2.705dBm Right earphone: BLE GFSK 1Mbps: 1.941dBm BLE GFSK 2Mbps: 2.111dBm Device Category Portable (<20cm separation) Mobile (>20cm separation) Others: Antenna Diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Antenna Designation Chip Antenna Antenna Gain 1.95dBi Minimum Assessment Distance 5mm Evaluation Applied MPE Evaluation SAR Evaluation Note: The EUT comprises left and right channel headsets, both of which are different and have been tested and recorded in this report. Report No.: AGC00727251101FH01 Page 6 of 10 3. Test Environment 3.1 Address Of The Test Laboratory Laboratory: Attestation of Global Compliance (Shenzhen) Co., Ltd. Address: 1-2/F, Building 19, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 3.2 Test Facility The test facility is recognized, certified, or accredited by the following organizations: CNAS-Lab Code: L5488 Attestation of Global Compliance (Shenzhen) Co., Ltd. has been assessed and proved to follow CNAS-CL01 Accreditation Criteria for Testing and Calibration Laboratories (identical to ISO/IEC17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories.) A2LA-Lab Cert. No.: 5054.02 Attestation of Global Compliance (Shenzhen) Co., Ltd. EMC Laboratory has been accredited by A2LA for technical competence in the field of electrical testing, and proved to follow ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories and any additional program requirements in the identified field of testing. FCC-Registration No.: 975832 Attestation of Global Compliance (Shenzhen) Co., Ltd. EMC Laboratory has been registered and fully described in a report filed with the FCC (Federal Communications Commission). The acceptance letter from the FCC is maintained in our files with Registration 975832. IC-Registration No.: 24842(CAB identifier: CN0063) Attestation of Global Compliance (Shenzhen) Co., Ltd. EMC Laboratory has been registered and fully described in a report filed with the Certification an…

Text truncated - open the document above for the full version.

2.4GHz 2012 Chip Antenna: RANT2012F245C07 Dimension (mm) L2.05+-0.15 W1.20+-0.15 T0.85+-0.10 No.Terminal Name 1Feeding/GNG 2GND Application: WLAN, 802.11b/g, Bluetooth, WLAN, etc... Features SMD, high reliability, ultra Impact, Omni-directional... Part number Information RANT2012F245C07 (A) (B)(C)(D)(E)(F) (A)Product TypeChip Antenna (B) Size Code2.0x1.2mm(+-0.2mm) (C) MaterialHigh K material (D) Frequency2.4 ~ 2.5GHz (E) Feeding modePIFA & Single Feeding (F) Antenna typeType=06 Electrical Specification Working Frequency Range2400 ~2500 MHz Bandwidth84 (Min.) Peak Gain1.95 dBi (Typ.) Impedance50 Ohm Return loss10 dB ( Min) PolarizationLinear Azimuth BeamwidthOmni-directional Operation Temperature( °C )-40 ~85 °C Resistance to Soldering Heats 10sec. ( @ 280°C) TerminationNi / Au (Leadless) The specification is defined on EVB. Dimension and Terminal Configuration RAIN International Technology Co., Ltd. Room709,BuildingF,Yuxing Technology Industrial Park, Nanchang Third Industrial Zone, Nanchang Community, Xixiang Street, Bao'an District,Shenzhen TEL:13530576606 2.4GHz 2012 Ch ip Antenna: RA NT2012F245C07 Ev aluati on BoardRefe rence PCB Dimens ionAntenna La yout Referenc e Unit :mm ElectricalCharacteristics ReturnLoss ReturnLoss&Radiation 1 Frequency(MHz) S11 (dB) 2400-10.7 7 2450-24.8 1 2500-10.2 43 Radi ation Z Y X 2400MHz2450MHz 2500MHz Efficiency70.56%75.25%71.01% Peak Ga in1.72 dBi1.95 dBi1.69 dBi Directivity2.26 dBi2.69 dBi2.11 dBi 2.4GHz2012ChipAntenna:RANT2012F245C07 TapingSpecifications ReelandTapingSpecification ReelSpecification TYPESIZEABCD 20127”5K/Reel 9.0±0.5 60±213.5±0.5178±2 TappingSpecification PackagingTypeABWEFGHTDP PaperType2012 1.50±0.202.30±0.208.0±0.201.75±0.103.5±0.054.0±0.102.0±0.050.75±0.101.57±0.104.0±0.1 2.4GHz2012ChipAntenna:RANT2012F245C07 ReliabilityTable TestItemProcedure Requirements CeramicType Remark (Reference) Electrical Characterization Fulfilltheelectrical specification UserSpec. Thermal Shock 1.Preconditioning: 50±10°C/1hr,thenkeepfor24±1hrsatroomtemp. 2.Initialmeasure:Spec:referInitialspec. 3.Rapidchangeoftemperaturetest: -30°Cto+85°C;100cycles; 15minutesatLowercategorytemperature; 15minutesatUppercategorytemperature. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 107 Temperature Cycling 1.Initialmeasure:Spec:referInitialspec. 2.100Cycles(-30°Cto+85°C),SoakMode=1(2Cycle/hours). 3.Measurementat24±2Hoursaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. JESD22 JA104 HighTemperature Exposure 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered;500hours@T=+85°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 LowTemperature Storage 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered:500hours@T=-30°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 Solderability (SMDBottomSide) Dippingmethod: a.Temperature:235±5°C b.Dippingtime:3±0.5s Thesoldershouldcover over95%ofthecritical areaofbottomside. IEC60384-21/22 4.10 SolderingHeat Resistance (RSH) Preheatingtemperature:150±10°C. Preheatingtime:1~2min. Soldertemperature:260±5°C. Dippingtime:5±0.5s NoVisibleDamage.IEC60384-21/22 4.10 Vibration5g'sfor20min.,12cycleseachof3orientations Note:Use8"X5"PCB.031"thick7securepointson,onelong sideand2securepointsatcornersofoppositesides.Parts mountedwithin2"fromanysecurepoint.Testfrom10-2000 Hz. NoVisibleDamage.MIL-STD-202 Method204 Mechanical Shock Threeshocksineachdirectionshallbeappliedalongthethree mutuallyperpendicularaxesofthetestspecimen(18shocks) Peakvalue:1,500g’s Duration:0.5ms Velocitychange:15.4ft/s Waveform:Half-sine NoVisibleDamage.MIL-STD-202 Method213 Humidity Bias 1.Humidity:85%R.H.,Temperature:85±2°C. 2.Time:500±24hours. 3.Measurementat24±2hrsaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 Method106 2.4GHz2012ChipAntenna:RANT2012F245C06 2.4GHz2012ChipAntenna:RANT2012F245C07 _ Board Flex (SMD) 1.Mountingmethod: IR-Reflow.PCBSize(L:100×W:40×T:1.6mm) 2.Applytheloadindirectionofthearrowuntilbendingreaches 2mm. NoVisibleDamage.AEC-Q200 005 AdhesionForceof1.8Kgfor60seconds.NoVisibleDamage Magnificationof20Xor greatermaybeemployed forinspectionofthe mechanicalintegrityofthe devicebodyterminalsand body/terminaljunction. AEC-Q200 006 Physical Dimension Anyapplicablemethodusingx10magnification,micrometers, calipers,gauges,contourprojectors,orothermeasuring equipment,capableofdeterminingtheactualspecimen dimensions. Inaccordancewith specification. JESD22 JB100 RevisionHistory RevisionDateContent 12020/10/15NewDatasheet

Page 1 of 89 FCC Test Report Report No.: AGC00727251101FR02 FCC ID : R5B-G07 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : True Wirless Stereo BRAND NAME : N/A MODEL NAME : G07, T21, M01, T8, T9, K18, G40, T13, T18, G05 APPLICANT : Shenzhen Mission Electronic Limited DATE OF ISSUE : Dec. 29, 2025 STANDARD(S) : FCC Part 15 Subpart C §15.247 REPORT VERSION : V1.0 Attestation Of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC00727251101FR02 Page 2 of 89 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Dec. 29, 2025 Valid Initial Release Report No.: AGC00727251101FR02 Page 3 of 89 Table of Contents 1. General Information ........................................................................................................................................ 5 2. Product Information ........................................................................................................................................ 6 2.1 Product Technical Description ................................................................................................................... 6 2.2 Test Frequency List ................................................................................................................................... 6 2.3 Related Submittal(S) / Grant (S) ............................................................................................................... 7 2.4 Test Methodology ...................................................................................................................................... 7 2.5 Special Accessories .................................................................................................................................. 7 2.6 Equipment Modifications ........................................................................................................................... 7 2.7 Antenna Requirement................................................................................................................................ 7 3. Test Environment ............................................................................................................................................ 8 3.1 Address of the Test Laboratory ................................................................................................................. 8 3.2 Test Facility ................................................................................................................................................ 8 3.3 Environmental Conditions ......................................................................................................................... 9 3.4 Measurement Uncertainty ......................................................................................................................... 9 3.5 List of Equipment Use ............................................................................................................................. 10 4. System Test Configuration ........................................................................................................................... 12 4.1 EUT Configuration ................................................................................................................................... 12 4.2 EUT Exercise ........................................................................................................................................... 12 4.3 Configuration of Tested System .............................................................................................................. 12 4.4 Equipment Used In Tested System ........................................................................................................ 13 4.5 Summary of Test Results ........................................................................................................................ 14 5. Description of Test Modes ........................................................................................................................... 15 6. Duty Cycle Measurement ............................................................................................................................. 17 7. RF Output Power Measurement .................................................................................................................. 18 7.1 Provisions Applicable .............................................................................................................................. 18 7.2 Measurement Procedure ......................................................................................................................... 18 7.3 Measurement Setup (Block Diagram of Configuration) .......................................................................... 18 7.4 Measurement Result ............................................................................................................................... 18 8. 6dB Bandwidth Measurement ...................................................................................................................... 26 8.1 Provisions Applicable .............................................................................................................................. 26 8.2 Measurement Procedure ......................................................................................................................... 26 8.3 Measurement Setup (Block Diagram of Configuration) .......................................................................... 26 8.4 Measurement Results ............................................................................................................................. 27 9. Power Spectral Density Measurement ........................................................................................................ 41 9.1 Provisions Applicable ......................................................................................................…

Text truncated - open the document above for the full version.

Report No.: AGC00727251101FR02 Page 80 of 89 Radiated Emissions Test Results for Above 1GHz EUT Name True Wirless Stereo Model Name G07 Temperature 22.1°C Relative Humidity 59.3% Pressure 960hPa Test Voltage DC 3.7V by battery Test Mode Mode 5 Antenna Polarity Horizontal FrequencyMeter ReadingFactorEmission LevelLimitsMargin (MHz)(dBμV)(dB)(dBμV/m)(dBμV/m)(dB) 4880.00045.280.1445.4274-28.58 peak 4880.00036.490.1436.6354-17.37 AVG 7320.00043.212.3645.5774-28.43 peak 7320.00031.582.3633.9454-20.06 AVG Remark: Factor = Antenna Factor + Cable Loss – Pre-amplifier. Value Type EUT Name True Wirless Stereo Model Name G07 Temperature 22.1°C Relative Humidity 59.3% Pressure 960hPa Test Voltage DC 3.7V by battery Test Mode Mode 5 Antenna Polarity Vertical FrequencyMeter ReadingFactorEmission LevelLimitsMargin (MHz)(dBμV)(dB)(dBμV/m)(dBμV/m)(dB) 4880.00046.780.1446.9274-27.08 peak 4880.00037.250.1437.3954-16.61 AVG 7320.00042.142.3644.574-29.5 peak 7320.00032.192.3634.5554-19.45 AVG Remark: Factor = Antenna Factor + Cable Loss – Pre-amplifier. Value Type RESULT: PASS Report No.: AGC00727251101FR02 Page 81 of 89 Radiated Emissions Test Results for Above 1GHz EUT Name True Wirless Stereo Model Name G07 Temperature 22.1°C…
