R5O-ALCH7HANDHELD METAL DETECTOR

Use or disclosure of information contained on this page is proprietary and may not be reproduced or disclosed to any other parties for any other purpose without the expressed written permission of Microsemi. ACUG_Ver1_12/2011 1 D D R R A A F F T T User Guide – AllClear The material contained herein is the proprietary information of Microsemi, Inc. It is intended solely for the information and use of parties operating and maintaining the equipment. Such proprietary information may not be used, reproduced or disclosed to any other parties for any other purpose without the expressed written permission of Microsemi. Overview The Microsemi® AllClear® is a hand-held passive millimeter wave (PMMW) people screening device designed to detect metallic and non-metallic objects and is an alternative to a personal pat-down. Unlike many current security measures in use today which are perceived as invasive and an infringement on civil liberties, the AllClear takes no images, is completely safe and alleviates the need for direct physical contact. The AllClear measures the body’s natural millimeter wave (MMW) energy. When an object is placed or hidden between the skin and clothing, the AllClear detects the difference in the amount of energy collected allowing the device to detect concealed objects. This normally is an indication of either an absorptive or reflective object between the human body and the AllClear. There are those who compare the AllClear and all millimeter wave technology to a metal detector. The defining difference is that a metal detector is not capable Use or disclosure of information contained on this page is proprietary and may not be reproduced or disclosed to any other parties for any other purpose without the expressed written permission of Microsemi. ACUG_Ver1_12/2011 2 of detecting objects other than those made of metal. It is impossible for a metal detector to detect a non-metallic object of any size, composition or temperature. In order to fully understand the functionality of the AllClear, a clear understanding of millimeter wave technology is necessary. Passive Millimeter Wave Theory All non-metallic objects emit electromagnetic energy based on their temperature. This means that if the energy from an object is analyzed, the temperature of the object can be determined. However, this has also been proven to work in reverse. If the temperature of a specific object is known, detectors which are designed to detect energy being emitted can be used to identify objects in the area of the temperature. Millimeter waves do not generally get blocked by fabric materials. This makes millimeter waves ideal for detecting objects hidden behind clothing and other coverings on the human body. There are three basic ways in which millimeter waves behave when their travel path intersects with an object: Reflectors - Similar to the way light is reflected by a mirror, objects made of metal reflect millimeter wave energy. These objects emit very little energy until they are heated well above temperatures at which a human could handle them, or conceal them. Just as you may have trouble using a cell phone in a metal building or elevator, these materials are considered blockers of electromagnetic emissions. The AllClear can detect these objects because they are blocking the natural energy emitted by the human by reflecting the environment. Absorbers – Most other materials fall into this category. They are dense enough to block or partially block millimeter wave energy. Materials such as wood, ceramics, glass and dense plastics are examples. These materials will appear as either slightly cooler than or warmer than the human body. Because of this difference the AllClear can detect the object. Transparent – These materials have very little effect on millimeter wave energy. Examples are woven fabrics, drywall, thin sheets of plastic and polymers. Health Concerns Our passive millimeter wave device emits absolutely no radiation or harmful energy to any individual involved in the scanning/screening process. Passive millimeter wave devices simply receive and measure the body’s natural millimeter wave energy, eliminating the person’s concerns for safety and privacy. Therefore, the AllClear may be used to scan women who are pregnant or may be Use or disclosure of information contained on this page is proprietary and may not be reproduced or disclosed to any other parties for any other purpose without the expressed written permission of Microsemi. ACUG_Ver1_12/2011 3 used to scan those individuals who have medical devices implanted within or attached to their bodies. The AllClear poses no health risks to anyone, including children. Object Detection Utilizing millimeter wave technology, the AllClear will detect an object as small as 3.8 x 3.8 cm (1.5” x 1.5”), whether metallic or non-metallic hidden on the body of an individual. The AllClear is used for scanning the outside body surface and can not be used for detecting objects in body cavities. The list of objects detectable includes, but is not limited to: Metallic Objects – No matter what the visible color, curved or flat surface, metallic objects will appear shiny and reflective since metallic objects do not emit energy, but instead block the energy being emitted from the body of an individual. The thickness and the temperature of the metallic object are not of importance. Objects including – Metal Weaponry, such as guns and knives Sheet metal or aluminum Ferrous or Non-Ferrous Non-metallic Objects – All non-metallic objects absorb energy differently, some more than others. Cloth for example absorbs very little millimeter wave energy since millimeter waves pass through. Some materials however do absorb more than others, silk and leather being examples. Liquids and gels absorb at a higher level because like the skin of a human body, they are comprised of mostly water millimeter waves do not pass through. Consider this example, think of your microwave oven. The…

Text truncated - open the document above for the full version.

Test Report Number 12F323B Product Safe ty Engine e ring, Inc 12955 Be llamy Brothe rs Blvd. Dade City, FL 33525 Te l (352) 588-2209 Fax (352) 588-2544 Page 2 of 12 D I R E C T O R Y - EMISSIONS Page(s) A)Documentation Test report1 - 10 Directory2 Test Regulations3 General Remarks10 Test-setups (Photos)11 - 12 B) Test data Conducted emissions10/150 kHz - 30 MHz5, 9 Radiated emissions10 kHz - 30 MHz5, 9 Radiated emissions30 MHz - 1000 MHz6, 9 Disturbance power30 MHz - 300 MHz6, 9 Equivalent Radiated emissions1 GHz - 18 GHz7, 9 Antenna Disturbance Voltage30 MHz - 1,000 MHz7,9 C) Appendix A Test Data Sheets A2 - A 3 Test Report Number 12F323B Product Safe ty Engine e ring, Inc 12955 Be llamy Brothe rs Blvd. Dade City, FL 33525 Te l (352) 588-2209 Fax (352) 588-2544 Page 3 of 12 EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: 9 - EN 61000-6-3:2007 9 - EN 61000-6-4:2007 9 - EN 55011 : 2009/A1:2010 9 - Group 1 9 - Group 2 9 - Class A9 - Class B 9 - EN 55013 : 2001 /A1:2003 /A2:2006 9 - EN 55014 -1: 2006/A2:2011 9 - Household appliances and similar 9 - Portable tools 9 - Semiconductor devices 9 - EN 55022:2010/AC:2011 9 - Class A9 - Class B 9 - CISPR 22:2008 9 - Class A9 - Class B 9 -AS/NZS CISPR 22:2009 9 - Class A9 - Class B 9 - ICES-003 9 - Class A9 - Class B 9 - CNS 13438 9 - Class A9 - Class B 9 - VCCI V-3/2010.4 9 - Class A9 - Class B # - FCC Part 15 (per ANSI C63.4) 9 - Class A9 - Class B (per 15.209) # - Certification 9 - Verification 9 - Declaration of Conformity 9 - FCC Part 18 Test Report Number 12F323B Product Safe ty Engine e ring, Inc 12955 Be llamy Brothe rs Blvd. Dade City, FL 33525 Te l (352) 588-2209 Fax (352) 588-2544 Page 4 of 12 Environmental conditions during testing: LAB OATS Temperature: * _________ : ________ Relative Humidity: ** _________ : ________ * The ambient temperature during the testing was within the range of (50 o - 104 o F) unless indicted above. ** The humidity levels during the testing was within the range of (10% - 90%) relative humidity unless indicated above. Power supply system: Volts Hz SINGLE phase Battery operated Sign Explanations: 9 - not applicable # - applicable Test Report Number 12F323B Product Safe ty Engine e ring, Inc 12955 Be llamy Brothe rs Blvd. Dade City, FL 33525 Te l (352) 588-2209 Fax (352) 588-2544 Page 5 of 12 Emissions Test Conditions: CONDUCTED EMISSIONS (Interference Voltage) The CONDUCTED EMISSIONS (INTERFERENCE VOLTAGE) measurements were performed at the following test location: # - Test not applicable 9 - Darby Test Site (Open Area Test Site) 9 - Darby Laboratory Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -8028-50Solar50 S LISN829012, 829022 9 -8012Solar50 S LISN924840 9 -EMC-30Electro-MetricsEMI Receiver191 9 -8566BHewlett-PackardSpectrum Analyzer2421A00526 9 -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -85662AHewlett Packard Analyzer Display2403A07352 9 -8028-50Solar50 S LISN903725, 903726 9 -FCC-TLISN-T4-02Fisher Custom Com.Telecom ISN20454 9 - 9 - FCC-TLISN-T8-02 LI-125 Fisher Custom Com. Com-Power Telecom ISN 50 S LISN 20452 191080/191081 Emissions Test Conditions: RADIATED EMISSIONS (Magnetic Field) The RADIATED EMISSIONS (MAGNETIC FIELD) measurements were performed at the following test location: # - Darby Test Site (Open Area Test Site) 9 - 9 - at a test distance of : # - 3 meters 9 - 30 meters 9 - Test not applicable Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -3148EMCOLog Periodic Antenna00044783 9 -BIA-25Electro-MetricsBiconical Antenna4283 # - 8566BHewlett-PackardSpectrum Analyzer2421A00526 # - 85662AHewlett-PackardAnalyzer Display2403A07352 # - 85650AHewlett-PackardQuasi-Peak Adapter2043A00209 # - ALR-30MElectro-MetricsLoop Antenna824 # - 8447DHewlett PackardPreamplifier2944A06832 9 - 9 - EMC-30 ALA-130/A Electro-Metrics Antenna Research EMI Receiver Loop Antenna 191 106 Test Report Number 12F323B Product Safe ty Engine e ring, Inc 12955 Be llamy Brothe rs Blvd. Dade City, FL 33525 Te l (352) 588-2209 Fax (352) 588-2544 Page 6 of 12 Emissions Test Conditions: RADIATED EMISSIONS (Electric Field) The RADIATED EMISSIONS (ELECTRIC FIELD) measurements, in the frequency range of 30 MHz-1000 MHz, were tested in a horizontal and vertical polarization at the following test location : # - Test not applicable 9 - Darby Site (Open Area Test Site) 9 - Darby Lab 9 - at a test distance of : 9 - 3 meters 9 - 10 meters 9 - 30 meters Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -HLP 3003CEMC AutomationHybrid Periodic Antenna017501 9 -8447DHewlett-PackardPreamplifier (26dB)1937A03247 9 -8566BHewlett-PackardSpectrum Analyzer2421A00526 9 -85662AHewlett-PackardAnalyzer Display2403A07352 9 -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -BIA 25 Electro-Metrics Biconical Antenna4283 9 -EMC-30Electro-MetricsEMI Receiver191 9 - 9 - 9 - 9 - 9 - 8566B 85650A 85662A LPA30 3104C Hewlett Packard Hewlett Packard Hewlett Packard Electro-Metrics Emco Spectrum Analyzer Quasi-Peak Adapter Analyzer Display Log Periodic Biconical Antenna 2532A02418 2043A00358 2403A06604 2280 00075927 9 - 9005 Eaton Log Periodic Antenna 1099 Emissions Test Conditions): DISTURBANCE POWER The DISTURBANCE POWER measurements were performed by using the absorbing clamp on the mains and interface cables in the frequency range 30 MHz - 300 MHz at the following test location : # - Test not applicable 9 - Darby Lab 9 - Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -MDS-21Rhode&SchwarzAbsorbing Clamp8608447020 9 -8566BHewlett-PackardSpectrum Analyzer2421A00526 9 -85662AHewlett-PackardAnalyzer Display2403A07352 9 -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -8447DHewlett-PackardAmplifier (26 dB)2944A06832 9 - EMC-30 Electro-Metrics EMI Receiver 191 Test Report Number 12F323B Product Safe ty Engine e ring, Inc 12955 Be llamy Brothe rs Blvd. Dade City, FL 33525 Te l (352) 588-2209 Fax (352) 588-25…
