R6H-ZTEWP755GSM/WCDMA Wireless Phone

1 ZTE WP755 WCDMA Wireless Phone User Guide 2 Feature list  Support WCDMA850/2100 MHz, GSM 850/900/1800/1900 MHz  Phone book function  Hand-free function  Volume adjust of handset and speaker  10 group of incoming ring selected,  6 group of SMS ring and silent selectable  Received and send SMS, which can save 500 item SMS.  LCD display date, time, signal, battery capacity.  Call Log 250 groups  Size:145*52*19mm  Working voltage:AC220V,50Hz;DC 5V 500mA  Additional battery: recharger battery  Standby time: more than 48 hours  Talk time: around 4 hours. Noted: the standby time and talk time is affected by network preference. 3 Know Your Phone Key Instruction Key Description 1. Message • To edit message 2. Profiles • Set profiles of your phone. 3. OK • Enter main menu. • Performs the function indicated at the left bottom of the screen. 4. CALL • Make a call or answer an incoming call. • In standby mode, press this key to enter Dialed calls list. 5. END • To turn ON/OFF the unite 4 Key Description 6.Scrolling • Press these keys to scroll cursor to the left, right, up or down when inputting characters or selecting items. • Default functions in standby mode are set in Settings menu. 7. Number • Use these keys to enter numbers and characters. 8. # , * • Perform different functions under different conditions. Installation 1. {tc "Handset" \f A}{tc "Handset" \f B}{tc " Handset" \f E}Battery Install the battery as below diagram, 2. {tc "SIM card" \f A}{tc "SIM card" \f B}{tc " SIM card" \f E}SIM card Always switch the phone off before removing or inserting SIM card. Open the bottom cover of the battery. Remove the battery, slide the SIM card into the SIM card slot. Make sure that the contact area of the card is facing down, and the beveled corner matches with the SIM card slot. Put in the battery and install the bottom cover. 5 How to Power on/off  To power on the phone, well installed the battery and then hold the END key till the phone is powered on.  To power off the phone, at standby mode, hold the END key till the phone is powered off. Notes: The phone will charge the internal battery automatically when it is connected to external power outlet. How to Make a Call Enter the number or select recipient’s number from Phonebook, or press CALL key to select a number from the Dialed calls list, then press CALL key to make the call. Notes: Add the international prefix, country code and area code (without the leading 0) before the number when making an international call. Message Select Message in Menu, • Select Write message to choose New SMS or New New MMS, Press Options select Send, Insert template, Add contact info, Add phiz or Save as draft. • Select Inbox to view messages received. 6 • Select Outbox to view the failure messages. • Select Drafts to view the draft messages. • Select Sentbox to view the successfully sent messages. • Select Templates to View the template messages. • Select Voice mail service to enter Voice mail, • Select Broadcast message to review the broadcast message list. • Press Options to enter Settings and Message capacity, to View the message of saved entries and maximum number of entries capacity in phone and SIM. Security setting Security setting could prevent your phone from unauthorized use. The default phone code is 1234. Change it to your own as soon as possible. If you change the default phone code to a new one, remember it or place it at secure place. PIN Code and PUK Code • PIN code: PIN code could prevent your SIM card from illegal use. When PIN code is enabled, you should enter the PIN code when powering on the phone again. Change the default PIN code to your own as soon as possible. • PUK code: The SIM card will be locked if you enter a wrong PIN code consecutively for three times. To unlock, you need PUK code. Notes: PIN code and PUK code may be offered together with the SIM card. If not, contact your service provider. Text Input 7 Operation Method Input digits “123”, press the Number keys to input the digits you want directly. Input letters “abc”, “ABC”, “PO”, ”Po”, ”po”, press corresponding letter key till the letter appears. Input words “En”, “en”, “EN” to enter English, “sPo”, ”sPO”, ”spo” to enter Portuguese, press the Number keys to input the characters of the word. Then press OK key to confirm. Input symbol Press * key, and then select corresponding symbol by using Scrolling keys. Input space Apart from Numbers input mode, press “0” key to add space. Erase character Press Clear key. Hold Clear key until the cursor before the character be erased. Move the cursor Press Scrolling keys. Change input mode Press # key to change text input mode. Menu Function Hereinafter are brief instructions for menu functions of the phone. Function Description Selection Create message Create SMS and MMS send to others. Menu→ Message→ Write message→ New SMS/New MMS Read message Read message in Inbox, Outbox, Drafts, Sentbox. Menu→ Message→ Inbox/Outbox/Drafts/Sent messages Message settings Make some necessary settings. Menu→ Message→ Options → Settings 8 Function Description Selection Call Logs View or dial all recent calls. Menu→ Call logs→ Missed calls/Dialed calls/Received calls/Delete all Call timers Check the Last call, Received calls, Dialed calls or Call history duration. Menu→ Call logs →Call timers GPRS counter Check the GPRS data usage status Menu→ Call logs →GPRS counter Contacts View contacts Menu→ Contacts Add new contact Save phonebook number Menu→ Contact→ Options→ New Speed dial Set and view speed dial list. Menu→ Contact→ Options→ Others → Speed dial Call divert Specify the conditions under which the call types should be diverted to another number. Menu→ Settings→ Call settings→ Call divert Call waiting Put the current call on hold to answer the other incoming call. Menu→ Settings→ Call settings→ Call waiting Call barring Restrict the dialing or receiving of certain calls. Menu→ Settings→ Call settings→ Call barring Advanced settings Other setti…
