R8S-VIAGO3Compact 4K Presentation Device

VIA GO3 Quick Start P/N: 29 0 0- 3 01 7 86 QS Rev: 1 Scan to go to website VIA GO3 Quick Start Guide Product name:Compact 4K Presentation Device For Installer This guide helps you install and use your VIA GO3 for the first time. Go to https://www.kramerav.com/product/VIA GO3 to download the latest user manual and check if firmware upgrades are available. Step 1: Check what’s in the box VIA GO3 Collaboration Device 1 VESA mounting bracket 1 Quick start guide 1 Power cords for US and EU 1 VESA screw set Step 2: Get to know your VIA GO3 # Feature Function 1 3 x USB DEVICE 3.0 Connector Connect to a USB device, for example, a USB speaker. 2 Power Button with LED Press to power ON or turn OFF the device. 3 Power Connector Connect to the 12V DC power supply. 4 1 x HDMI OUT Connector Connect to an HDMI sink. HDMI OUT 2 is unavailable. 5 RJ-45 Connector Connect to a LAN (default mode). Step 3: Mount VIA GO3 VIA GO3 can be installed on a flat surface / wall, rear of a monitor or rack mount using the included VESA mounting bracket and screw set: Mount VIA GO3 to the Mounting Bracket 1.Attach the mounting bracket to the VIA GO3 with 2 screws. This step is required for all options detailed below. To Mount to a Flat Surface / Wall To Mount to rear of monitor To Mount to a Rack Mount Secure the mounting bracket to a flat surface / wall with dedicated screws. Secure the mounting bracket to VESA holes located on rear of monitor. Secure the mounting bracket(s) to the rack mount with dedicated screws. Step 4: Connect inputs and outputs Always switch OFF the power on each device before connecting it to your VIA GO3. 1.Connect a USB device. 2.Connect an HDMI display. 3.Connect to the LAN (default mode). I f you wish to use a Kramer active optical pluggable HDMI cable with your VIA GO3, contact your local Kramer office to assist in purchasing the correct cable. To achieve specified extension distances, use the recommended Kramer cables available at www.kramerav.com/product/VIA GO3. Using third-party cables may cause damage! Step 5: Connect power Connect the 12V DC power adapter to VIA GO3 and plug it into the mains electricity. Caution: There are no operator serviceable parts inside the unit. Caution: The device is intended to be installed at a height of 2 meters or less. Warning: Use only the Kramer Electronics power adapter that is provided with the unit. Warning: Disconnect the power and unplug the unit from the wall before installing. See www.KramerAV.com for updated safety information. Step 6: Configure VIA GO3 VIA is generally pre-installed and should work right out of the box once connected to the network. If different VIA settings need to be adjusted, logging into the Gateway web interface will be necessary to customize the settings according to network, customer, or IT requirements. To open the VIA Gateway web interface for configuration, network connectivity is required. Connect the VIA box to the local network to begin. Login to VIA 1. Open Chrome browser and browse to the GO3 IP address. 2. Click Manage Gateway Settings on the upper right corner. 3. Enter the Username (default = su), Password (default = supass), Captcha and click Login. 4. After logging in, the VIA Dashboard will open. Configure VIA Network Change Hostname or Change network DHCP / Fixed IP 1 . C lick "Change Host Name" in the filter chips within the dashboard. 2 . Type to change the hostname or switch the network IP if needed, then click Apply. •VIA might be rebooted resulting from the change. Activate VIA WIFI Access Point 1 . I n case WIFI access point is required, please Click on “ Wifi Settings” in the filter chips within the dashboard. 2. Click to Activate WIFI Settings. 3. Once finished, click Apply. VIA will reboot to apply the settings. VIA Settings To personalize the VIA settings, including appearance, time zone, security, and more, you will need to adjust the VIA settings. 1 . C lick VIA Settings on the left panel. 2. Click Duplicate on the default template. 3 . C lick Publish to set the duplicate template as active. Common VIA Settings Adjustments 1 . C hange Room name. 2 . C lick “Edit Room name” in the filter chips within the dashboard. 3 . B y default, the room name will use the Host name unless you click on Custom and enter the desired room name. 4. Once done, click Save & Publish. Set Audio Settings 1. Click on “ Audio Settings” in the filter chips within the dashboard. 2 . Select the required audio device and click Save & Publish. Set NTP & Date / Time 1. Click “NTP Date/Time” in the filter chips within the dashboard. 2 . S elect the required date format, time zone and set NTP, click Save & Publish. Set Miracast / Airplay 1. Click on “ Add Miracast / Airplay” in the filter chips within the dashboard. 2 . Clic k to adjust Airplay. 3. Click to adjust Miracast. 4. Once done, click Save & Publish. VIA Screen Editor To personalize VIA Screen template, please adjust the Screen Editor. 1 . C lick VIA Screen Editor on the left panel. 2. Click to Add Screen Layout. 3. Drag VIA default wallpaper or browse to any custom wallpaper instead. 4 . U sing the left widget panel, drag & drop any widget to build the required display. 5 . C licking on each of the widget will open Properties window that will allow to adjust the widget properties. Example of text widget PROPERTIES and COLORS windows: Scan to go to website VIA GO3 Quick Start Guide For User This guide helps you install and use your VIA GO3 for the first time. Go to https://www.kramerav.com/product/VIA GO3 to download the latest user manual. Step 1: Connect your personal device to the proper network Connect your personal device to the same Wi-Fi or LAN network as the VIA GO3 in your meeting room. Step 2: Run or Download the Kramer VIA app See “Installing or Running the VIA app” in the User Manual. For Mac or PC: 1.Enter the Room Name or IP of the VIA GO3 in your computer’s browser. The Welcome page of VIA GO3 appears. 2.Click Run VIA to execute the Kramer VIA app without…

Text truncated - open the document above for the full version.

Kramer Electronics Ltd. 2 Negev St. Airport City Israel 7019900 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-9-19 To whom it may concern: We, Kramer Electronics Ltd., hereby certify that the equipment for which authorization is sought (FCC ID: R8S-VIAGO3) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Niv Reuven Products Compliance Engineer Kramer Electronics Ltd. 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Kramer Electronics Ltd. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/17/2024 U.S. Agent Designation Kr amer Electronics Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: R8S-VIAGO3): Name and company of U.S. agent: FCC US Agent, LLC Physical U.S. address of agent: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN of U.S. agent: 0033402884 Email address of U.S. agent: [email protected] FCC US Agent, LLC acknowledges their obligation to accept service of process on behalf of Kramer Electronics Ltd.. Kramer Electronics Ltd. with the FRN 0022212278 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Since rely, Signature Niv Reuven Products Compliance Engineer Kramer Electronics Ltd. Signature Tim Payne Manager FCC US Agent, LLC 48_[model] US_Agent_2.911(d)(7)-U, V05

Kramer Electronics Ltd. Add: 2 Negev St. Airport City Israel 7019900 Date: 2024-9-19 FCC ID: R8S-VIAGO3 Dear Sir/Madam, We, Kramer Electronics Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Compact 4K Presentation Device Model no.: VIA GO3, KC-Virtual Brain1, KC-Virtual Brain5, Panta Rhei-Site Agent, AVoIP Manager Sincerely, Name/Title： Niv Reuven/Products Compliance Engineer Company: Kramer Electronics Ltd. Address: 2 Negev St. Airport City Israel 7019900 Phone: +972-73-2650284 Fax: +972-26518830 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-9-19> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name R8S-VIAGO3 VIA GO3 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Niv Reuven/Products Compliance Engineer Company: Kramer Electronics Ltd. Address: 2 Negev St. Airport City Israel 7019900 Phone: +972-73-2650284 Fax: +972-26518830 E-Mail: [email protected]

Kramer Electronics Ltd. 2 Negev St. Airport City Israel 7019900 UNII Device Declaration Letter To whom it may concern: We have declared below featured for FCC equipment authorization, Device FCC ID: R8S-VIAGO3 (1) DFS Device: Master Client with Radar detection capability N/A Client without radar detection capability, (2) Active / Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 5180-5240 Yes No Yes No Yes No Yes No 5190-5230 Yes No Yes No Yes No Yes No 5210-5210 Yes No Yes No Yes No Yes No 5260-5320 Yes No Yes No Yes No Yes No 5270-5310 Yes No Yes No Yes No Yes No 5290-5290 Yes No Yes No Yes No Yes No 5500-5700 Yes No Yes No Yes No Yes No 5510-5690 Yes No Yes No Yes No Yes No 5530-5610 Yes No Yes No Yes No Yes No 5745-5825 Yes No Yes No Yes No Yes No 5755-5795 Yes No Yes No Yes No Yes No 5775-5775 Yes No Yes No Yes No Yes No (3) Country code selection ability Yes No If yes, pls explain how it was implemented: (4) Meet 15.202 requirement Yes No pls check below : A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes cannot be modified by end user or an installer. Apply Does not apply (If apply, pls help to provide explanation on it was implement, and how software was controlled) Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name/Title： Niv Reuven/Products Compliance Engineer Company: Kramer Electronics Ltd. Address: 2 Negev St. Airport City Israel 7019900 Phone: +972-73-2650284 Fax: +972-26518830 E-Mail: [email protected]

Kramer Electronics Ltd. 2 Negev St. Airport City Israel 7019900 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-9-19 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: R8S-VIAGO3 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Niv Reuven/Products Compliance Engineer Company: Kramer Electronics Ltd. Address: 2 Negev St. Airport City Israel 7019900 Phone: +972-73-2650284 Fax: +972-26518830 E-Mail: [email protected]

Page 1 of 6 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 6 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 6 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 6 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 6 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9 Fig. 10 Page 6 of 6 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 11

Page 1 of 1 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Label and Location Size: L: 44.70mm*W: 29.70mm Material: tagboard Glue: adhesive sticker Front color: White Label color: black (Size: L 3.5cm x W 3.5cm) Label Location Compact 4K Presentation Device Test Model:VIA GO3 FCC ID:R8S-VIAGO3 L W

Page 1 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 BT/WIFI ANT1 WIFI ANT 2 Page 2 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9 Fig. 10 Page 6 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 11 Fig. 12 Page 7 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 13 Fig. 14 Page 8 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 15 Fig. 16 Page 9 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 17 Fig. 18 Page 10 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 19 Fig. 20 Page 11 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 21 Fig. 22 Page 12 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 23 Fig. 24 Page 13 of 13 FCC ID:R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 25 Fig. 26

Page 1 of 16 FCC ID: R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Maximum Permissible Exposure Report 1. Product Information EUT : Compact 4K Presentation Device Test Model : VIA GO3 Additional Model No. : KC-Virtual Brain1, KC-Virtual Brain5, Panta Rhei-Site Agent, AVoIP Manager Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply : Input: 12.0V5.0A For AC Adapter Input: 100-240V~, 50-60Hz, 1.8A Adapter Output: 12.0V5.0A, 60.0W DC 3V By CR2032 Button Battery Hardware Version : / Software Version : / Bluetooth: Frequency Range : 2402MHz~2480MHz Channel Number : 79 channels for Bluetooth V5.3(DSS) 40 channels for Bluetooth V5.3 (DTS) Channel Spacing : 1MHz for Bluetooth V5.3 (DSS) 2MHz for Bluetooth V5.3 (DTS) Modulation Type : GFSK, π/4-DQPSK, 8-DPSK for Bluetooth V5.3(DSS) GFSK for Bluetooth V5.3 (DTS) Bluetooth Version : V5.3 Antenna Description : FPC Antenna, 2.99dBi(Max.) WIFI(2.4G Band): Frequency Range : 2412MHz~2462MHz Channel Spacing : 5MHz Channel Number : 11 Channels for 20MHz bandwidth (2412~2462MHz) 7 Channels for 40MHz bandwidth (2422~2452MHz) Modulation Type : IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Description : Ant1: FPC Antenna, 2.99dBi(Max.) Ant2: FPC Antenna, 2.99dBi(Max.) WIFI(5.2G Band): Frequency Range : 5180MHz~5240MHz Channel Number : 4 Channels for 20MHz bandwidth(5180MHz~5240MHz) 2 channels for 40MHz bandwidth(5190MHz~5230MHz) Page 2 of 16 FCC ID: R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 1 channels for 80MHz bandwidth(5210MHz) Modulation Type : IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Antenna Description : Ant1: FPC Antenna, 2.88dBi(Max.) Ant2: FPC Antenna, 2.88dBi(Max.) WIFI(5.3G Band): Frequency Range : 5260MHz~5320MHz Channel Number : 4 Channels for 20MHz bandwidth(5260MHz~5320MHz) 2 channels for 40MHz bandwidth(5270MHz~5310MHz) 1 channels for 80MHz bandwidth(5290MHz) Modulation Type : IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Antenna Description : Ant1: FPC Antenna, 2.88dBi(Max.) Ant2: FPC Antenna, 2.88dBi(Max.) WIFI(5.5G Band): Frequency Range : 5500MHz~5700MHz Channel Number : 11 Channels for 20MHz bandwidth(5500MHz~5700MHz) 5 Channels for 40MHz bandwidth(5510MHz~5670MHz) 2 Channels for 80MHz bandwidth(5530MHz, 5610MHz) Modulation Type : IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Antenna Description : Ant1: FPC Antenna, 2.88dBi(Max.) Ant2: FPC Antenna, 2.88dBi(Max.) WIFI(5.8G Band) Frequency Range : 5745MHz~5825MHz Channel Number : 5 channels for 20MHz bandwidth(5745MHz~5825MHz) 2 channels for 40MHz bandwidth(5755MHz~5795MHz) 1 channels for 80MHz bandwidth(5775MHz) Modulation Type : IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Antenna Description : Ant1: FPC Antenna, 2.88dBi(Max.) Ant2: FPC Antenna, 2.88dBi(Max.) Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Mobile Device Page 3 of 16 FCC ID: R8S-VIAGO3 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB p…

Text truncated - open the document above for the full version.

DATE DATE WIFI MAIN ANT Part Number: LJF02-240808002M-R0A 李明进 Issued Date: 2024/8/8 Write By : ECN/ECR Shenzhen Lejin radio frequency technology Co., LTD SPECIFICATIONS FOR APPROVAL All data in this report only represent the data when the sample antenna is correctly installed in the designated test object. Replacing the test object or changing the installation method and position of the antenna will render the data in the report invalid. Antenna manufacturer：Shenzhen Lejin radio frequency technology Co., LTD Company Address: 3rd Floor, Building A4, No. 176 Chongqing Road, Fuhai Street, Bao'an District, Shenzhen, Guangdong Province.（Phone number: 13603098741） 智纬 Product Name: MP21 Customer Name: LEJIN R&D DEPT ENGINEER R&D DEPT APPROVAL Edition/Part number CUSTOMER ENGINEER R&D DEPT BUSSINESS DEPT APPROVED BY Edition/Part number Product Model: Lejin radio frequency Proprietary Confidential © 2017 Lejin radio frequency Corporation. All rights reserved. Shenzhen Lejin radio frequency technology Co., LTD 2、目录 （Index） 4、测试设备（Test Equipment & Conditions） 5、性能测试报告（Test Report） 6、天线图片（Antenna Picture ） 7、射频线规格（Transmission line Specification） 8、工程图纸（Product Drawing） 目 录 Index 1、封面 （Cover） 3、规格（Product Specification） Lejin radio frequency Proprietary Confidential © 2017 Lejin radio frequency Corporation. All rights reserved. 113黑 色 Frequency VSWR Efficiency Impedance Polarizatio n Gain Electrical Characteristics Shenzhen Lejin radio frequency technology Co., LTD ≥1 DB ≥1 DB Material & Mechanical CharacteristicsEnvironmental Linear Linear 2400 MHz ~2500 MHz 5100MHZ--5900 MHZ >25% <2.5>30%50 Ohm <250 Ohm Material of Radiator Connector Type KCC451-140 Operation Temperature FPC black/YELLOW- 20 ̊C ~ + 50 ̊C Cable Type Dimension Storage Temperature - 30 ̊C ~ + 80 ̊C Test Equipment & Conditions 1． Network Analyzers :Agilent 8753SE 5071C 2． Communications Test Set:Agilent E5515C/CMW500 3. 3D Chamber Test System(ETS743) Lejin radio frequency Proprietary Confidential © 2017 Lejin radio frequenc…

Text truncated - open the document above for the full version.
