RB6-DPU-4500Satellite Vehicle Tracking Unit

InfoTrack Vehicle Tracking Systems Installation and commissioning manual Data Processing Unit DPU 4500 Technical details in this document are subject to change without notice Trackcom Ltd., Trackcom House, 2 Newmarket Court, Kingston, Milton Keynes, MK10 0AQ Tel: 00 (44) 1908 288288 Fax: 00 (44) 1908 288280 Email: [email protected] 2 INDEX 1 INTRODUCTION ............................................... 6 1.1 InfoTrack Vehicle Tracking Systems ....................................... 6 1.2 Functionality............................................................................... 6 1.3 Vehicle equipment ..................................................................... 6 1.4 Data Processing Unit DPU 4500 ............................................... 6 1.5 External roof antenna GSM/GPS .............................................. 7 1.6 Covert antenna GSM/GPS ......................................................... 8 1.7 Power cable ................................................................................ 8 2 INSTALLATION CODE OF PRACTICE ............ 8 2.1 Installation C.O.P ....................................................................... 8 2.2 Approved installers ................................................................... 8 2.3 Vehicle inspection ..................................................................... 8 2.4 Installation .................................................................................. 9 2.5 Commissioning .......................................................................... 9 2.6 Final inspection.......................................................................... 9 2.7 Customer Handover ................................................................ 10 3 INSTALLATION............................................... 11 3.1 Introduction to installation ..................................................... 11 3.2 Importance of a good installation .......................................... 11 3 3.3 Crimp connectors .................................................................... 11 3.4 Equipment Earthing................................................................. 12 3.5 Advance requirements ............................................................ 12 3.6 Checks before installation. ..................................................... 12 3.7 Vehicle voltage supply and polarity....................................... 13 3.8 Position of the DPU. ................................................................ 13 3.9 Antenna position. .................................................................... 14 3.10 Cable runs ................................................................................ 14 3.11 Earth Points.............................................................................. 15 3.12 Installing the equipment ......................................................... 15 3.13 Installing the Data Processing Unit 4500 .............................. 16 3.14 External roof antenna .............................................................. 16 3.15 Covert antenna......................................................................... 18 3.16 Power cable .............................................................................. 19 4 INSTALLING THE INFOTRACK SOFTWARE 21 4.1 Software Installation................................................................ 21 5 COMMISSIONING ........................................... 21 5.1 Introduction .............................................................................. 21 5.2 Testing equipment ................................................................... 21 5.3 Commissioning procedure ..................................................... 21 4 5.4 Basic installation checks ........................................................ 22 5.4.1 Mechanical checks ............................................................ 22 5.4.2 Electrical checks ............................................................... 22 5.5 Siting vehicle............................................................................ 22 5.5.1 Buildings and structures.................................................... 23 5.5.2 Power lines........................................................................ 23 5.5.3 Other sources of interference............................................ 23 5.6 Power up................................................................................... 23 5.7 Power up checks ..................................................................... 23 5.8 Connecting to the DPU............................................................ 24 5.8.1 Adding a vehicle ................................................................ 24 5.9 Live Track ................................................................................. 25 5.10 Data Download ......................................................................... 25 5.11 Clean and secure ..................................................................... 26 6 MAINTENANCE .............................................. 27 6.1 Introduction to maintenance .................................................. 27 6.2 Fault finding assistance .......................................................... 27 6.2.1 Confirm reported defect .................................................... 28 6.2.2 Advance requirements ...................................................... 28 6.2.3 Test equipment ................................................................. 28 6.3 Fault report and remedial action ............................................ 28 6.3.1 Cannot connect to a vehicle from the PC.......................... 28 6.3.2 The PC will connect to a vehicle but there is no icon on the map .................................................................................. 29 6.3.3 The PC is showing a 'GPS initialising. Please wait 5 minutes...' message .......................................................…

Text truncated - open the document above for the full version.

Model number: DPU 4500 FCC I.D: RB6-DPU-4500 This device complies with part 15 of the FCC rules. operation is subject to the following two conditions: 1) This device may not cause harmful interference and 2) This device must accept any interference received including interference that may cause undesired operation. Actual label size 29mm X 45mm Labeling requirement for USA FCC Certification Model number: DPU 4500 FCC I.D: RB6-DPU-4500 This device complies with part 15 of the FCC rules. operation is subject to the following two conditions: 1) This device may not cause harmful interference and 2) This device must accept any interference received including interference that may cause undesired operation.

Test Report 2-20542043b/02, Page 57 of 65 20542043b_02.doc 7.2. Internal photos of EUT Photograph 2: EUT front side without shielding

From: "Nigel Couch" <[email protected]> To: <[email protected]> Cc: <[email protected]>, <[email protected]>, "'Greg Ellaway'" <[email protected]> Date: 08/08/2003 08:59 AM Subject: RF Output power from the DPU4500 Dear Kyle, I understand that there has been a question of the output power from the GSM modem in the DPU4500. The modem is a Siemens’ MC45 modem, FCC ID: Q1PMC45. This has maximum output powers of 2W for EGSM900, 1W for GSM1800 and GSM19 00. As part of the DPU4500, we interact with the MC45 at the AT Commands Level. This does not give us access to control the output power of the module in any way, with the exception of the ability to turn it off. The firmware supplied with the module by Siemens controls the output power, as per their FCC approval. We have made no modifications whatsoever to the Siemens firmware. I hope that this statement gives you what you need? Regards Nigel Attachments: Pa g e 1 of 1 8/8/03 htt p ://www.celectronics.com:3000/WorldClient.dll?Session=CJLQRWI&View=Attachment&Part=2.0&Filename=ATT00003.ms g

Report Number: B30710D1 FCC Part 24 Test Report Satellite Vehicle Tracking Unit Model: DPU 4500 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 1 of 17 FCC PART 24 TEST REPORT for SATELLITE VEHICLE TRACKING UNIT Model: DPU 4500 Prepared for TRACKCOM, LTD. TRACKCOM HOUSE, 2 NEWMARKET COURT CHIPPENHAM DRIVE, MILTON KEYNES, MK10 0AQ, UNITED KINGDOM Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ SCOTT McCUTCHAN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JULY 14, 2003 REPORT APPENDICES TOTAL BODY A B C D E PAGES 17 2 2 12 5 2 40 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B30710D1 FCC Part 24 Test Report Satellite Vehicle Tracking Unit Model: DPU 4500 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 17 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. Description of Test Configuration 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment 12 6. TEST SITE DESCRIPTION 13 6.1 Test Facility Description 13 6.2 EUT Mounting, Bonding and Grounding 13 7. Test Procedures 14 7.1 Radiated Emissions (Spurious and Harmonics) Test for Part 24 14 7.2 Radiated Emissions Specification Limits, Section 24.238 (a) 16 8. CONCLUSIONS 17 Report Number: B30710D1 FCC Part 24 Test Report Satellite Vehicle Tracking Unit Model: DPU 4500 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 17 LIST OF APPENDICES APPENDIX TITLE A Modifications to the EUT B Additional Models Covered Under This Report C Diagrams, Charts and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors D Data Sheets E Laboratory Recognitions LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Test Site Report Number: B30710D1 FCC Part 24 Test Report Satellite Vehicle Tracking Unit Model: DPU 4500 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 17 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested: Satellite Vehicle Tracking Unit Model: DPU 4500 S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Manufacturer: Trackcom, Ltd. Trackcom House, 2 Newmarket Court, Chippenham Drive, Milton Keynes MK10 0AQ, United Kingdom Test Dates: July 9 and 10, 2003 File # For Canada: IC2154-D Test Specifications: EMI requirements CFR Title 47, Part 15 Subpart B; and CFR Title 47 Part 24 Section 24.238 (a) Test Procedure: ANSI C63.4: 1992 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B30710D1 FCC Part 24 Test Report Satellite Vehicle Tracking Unit Model: DPU 4500 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 17 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Radiated Spurious Emissions on the EUT, 10 kHz to 19500 MHz Complies with the limits of CFR Title 47, Part 24 Section 24.238 (a) Report Number: B30710D1 FCC Part 24 Test Report Satellite Vehicle Tracking Unit Model: DPU 4500 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 17 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Satellite Vehicle Tracking Unit Model: DPU 4500. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 1992. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the specification limits defined by CFR Title 47, Part 24, Section 24.238 (a). Report Number: B30710D1 FCC Part 24 Test Report Satellite Vehicle Tracking Unit Model: DPU 4500 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 7 of 17 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 114 Olinda Drive, Brea, California 92823. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST) . 2.3 Cognizant Personnel Trackcom, Ltd. Del Shindell President Compatible Electronics Inc. Kyle Fujimoto Test Engineer Scott McCutchan Lab Manager 2.4 Date Test Sample was Received The test sample was received on July 9, 2003. 2.5 Disposition of the Test Sample The test sample has not been returned to Trackcom, Ltd. as of July 14, 2003. 2.6 Abbreviations and Acronyms The following abbreviations and acronyms may be used in this document. RF Radio Frequency EMI Electromagnetic Interference EUT Equipm…

Text truncated - open the document above for the full version.
