Photographs of Tested E.U.T. Figure 1 Top View Closed Cover Figure 2 Top View Cover Removed

PYROLOGIC 2000 – Terminal Unit (TU) FCC ID: RBU1014401 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. MADE IN ISRAEL

Photographs of Tested E.U.T. Figure 1 Top View Closed Cover Figure 2 Top View Cover Removed Figure 3 External View Bottom Figure 4 External View Battery Cover Open Figure 5 Print Side Main Board Figure 6 Print Side Screen Figure 7 Screen Figure 8 Screen in Housing Print side

Cert. No. 1152.01 Electrical (EMC) Test Report E51151.00 RACAM - TECH LTD. Page 1 of 39 FCC ACC M Ver 1.1 05Mayl 2000 DATE: 05 August 2003 I.T.L. (PRODUCT TESTING) LTD. EMC Test for RACAM - TECH LTD.* * See customer’s statement on page 5. Equipment under test: Terminal Unit TU Approved by:_____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Cert. No. 1152.01 Electrical (EMC) Test Report E51151.00 RACAM - TECH LTD. Page 2 of 39 FCC ACC M Ver 1.1 05Mayl 2000 Measurement/Technical Report for RACAM - TECH LTD.* Terminal Unit TU FCC ID:RBU1014401 05 August 2003 This report concerns:Original Grant x Class II change Class B verification Class A verification Class I change Equipment type: Radio Telemetry Transmitter Request Issue of Grant: x Immediately upon completion of review Limits used: CISPR 22 Part 15 x Measurement procedure used is ANSI C63.4-1992. Application for Certification Applicant for this device: prepared by:(different from "prepared by") Ishaishou RazHanoch Maliss ITL (Product Testing) Ltd.RACAM –TECH LTD. Kfar Bin Nun27 Leh1 St. D.N. Shimshon 99780Bnei-Brak 51200 IsraelIsrael e-mail [email protected]:+972-3-579-8282 Fax:+972-3-579-8866 e-mail: [email protected] * See customer’s statement on page 5. Test Report E51151.00 RACAM - TECH LTD. Page 3 of 39 FCC ACC M Ver 1.1 05Mayl 2000 TABLE OF CONTENTS 1.GENERAL INFORMATION ------------------------------------------------------------------------------- 4 1.1Administrative Information .................................................................................4 1.2List of Accreditations .........................................................................................6 1.3Product Description ...........................................................................................7 1.4Test Methodology ..............................................................................................7 1.5Test Facility .......................................................................................................7 1.6Measurement Uncertainty .................................................................................7 2.PRODUCT LABELING------------------------------------------------------------------------------------- 8 3.SYSTEM TEST CONFIGURATION--------------------------------------------------------------------- 9 3.1Justification........................................................................................................9 3.2EUT Exercise Software .....................................................................................9 3.3Special Accessories ..........................................................................................9 3.4Equipment Modifications ...................................................................................9 3.5Configuration of Tested System ........................................................................9 4.BLOCK DIAGRAM -----------------------------------------------------------------------------------------10 4.1Schematic Block/Connection Diagram ............................................................10 4.2Theory of Operation.........................................................................................10 5.RADIATED MEASUREMENT PHOTOS--------------------------------------------------------------11 6.FIELD STRENGTH OF FUNDAMENTAL ------------------------------------------------------------12 6.1Test Specification ............................................................................................12 6.2Test Procedure ................................................................................................12 6.3Measured Data ................................................................................................12 6.4Test Instrumentation Used, Field Strength of Fundamental............................14 7.SPURIOUS RADIATED EMISSION, BELOW 1 GHZ ---------------------------------------------15 7.1Test Specification ............................................................................................15 7.2Test Procedure ................................................................................................15 7.3Measured Data ................................................................................................16 7.4Test Instrumentation Used, Spurious Radiated Measurements......................19 7.5Field Strength Calculation ...............................................................................20 8.SPURIOUS RADIATED EMISSION ABOVE 1 GHZ-----------------------------------------------21 8.1Radiated Emission Above 1 GHz ....................................................................21 8.2Test Data .........................................................................................................21 8.3Test Instrumentation Used, Spurious Radiated Measurements Above 1 GHz ...................................................................................................30 9.BANDWIDTH ------------------------------------------------------------------------------------------------31 9.1Test procedure ................................................................................................31 9.2Results table....................................................................................................33 9.3Test Equipment Used. .....................................................................................34 10.R.F EXPOSURE/SAFETY --------------------------------------------------------------------------------35 11.PHOTOGRAPHS OF TESTED E.U.T. ----------------------------------------------------------------36 Test Report E51151.00 RACAM - TECH LTD. Page 4 of 39 FCC ACC M Ver 1.1 05Mayl 2000 1. General Information 1.1 Administrative Information Manufacturer:RACAM - TECH LTD. (See customer’s s…

Text truncated - open the document above for the full version.

Cert. No. 1152.01 Electrical (EMC) Test Report E51151.01 RACAM - TECH LTD. Page 1 of 39 FCC ACC M Ver 1.1 05Mayl 2000 DATE: 06 August 2003 I.T.L. (PRODUCT TESTING) LTD. EMC Test for RACAM - TECH LTD.* * See customer’s statement on page 5. Equipment under test: Terminal Unit TU Approved by:_____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E51151.01 RACAM - TECH LTD. Page 17 of 39 FCC ACC M Ver 1.1 05Mayl 2000 dB m m 14 sec)(100 sec)(20 log20−= Spurious Radiated Emission E.U.T DescriptionTerminal Unit TypeTU Serial Number:00378 Specification: F.C.C., Part 15, Subpart C Antenna Polarization: HorizontalFrequency range: 30 MHz to 1.0 GHz Test Distance: 3 metersDetector: Peak FrequencyPeak Amp (1) D.C.F. (2) Correction (3) Final Result (4) SpecificationMargin (MHz)(dBμV/m)(dB)(dB)(dBμV/m)(dBμV/m)(dB μV/m) 73.6018.2-14.010.3+4.240.0-35.8 114.4319.5-14.013.3+5.543.5-38.0 156.7521.4-14.015.2+7.443.5-36.1 170.3021.7-14.015.5+7.743.5-35.8 248.1927.3-14.020.4+13.346.0-32.7 274.3127.9-14.021.7+13.946.0-32.1 325.3423.6-14.015.7+9.646.0-36.4 609.1830.6-14.022.4+16.646.0-29.4 968.0336.3-14.028.3+22.354.0-31.7 Figure 1. Spurious Radiated Emission. Antenna Polarization: HORIZONTAL. Detector: Peak Note: Margin refers to the test results obtained minus specified requirement; thus a positive number indicates failure, and a negative result indicates that the product passes the test. (1) “Peak Amp.” (dBμV/m) includes the “correction” numbers. (2) “Duty Cycle Factor (D.C.F.)=(See Section 4.2 of this report). (3) “Correction” (dB) = Test Antenna Correction Factor(dB) + Coax Cable. (4) “Final Result” (dBμV/m)=Peak Amp. (dBμV/m)+D.C.F. (dB). Test Report E51151.01 RACAM - TECH LTD. Page 18 of 39 FCC ACC M Ver 1.1 05Mayl 2000 dB m m 14 sec)(100 sec)(20 log20−= Spurious Radiated Emission E.U.T DescriptionTerminal Unit TypeTU Serial Number:00378 Specification: F.C.C., Part 15, Subpart C Antenna Polarization: VerticalFrequency range: 30 MHz to 1.0 GHz Test Distance: 3 metersDetector: Peak FrequencyPeak Amp (1) D.C.F. (2) Correction (3) Final Result (4) SpecificationMargin (MHz)(dBμV/m)(dB)(dB)(dBμV/m)(dBμV/m)(dB μV/m) 74.4023.6-14.010.3+9.640.0-30.4 130.6319.5-14.013.9+5.560.3 (5)-54.8 143.7120.1-14.014.6+6.160.3 (5)-54.2 158.7521.1-14.015.2+7.143.5-36.4 248.3027.0-14.020.4+13.046.0-33.0 274.3428.0-14.021.7+14.046.0-32.0 325.3421.9-14.015.7+7.946.0-38.1 609.1829.4-14.022.4+15.446.0-30.6 968.0335.6-14.028.3+21.654.0-32.4 Figure 2. Spurious Radiated Emission. Antenna Polarization: VERTICAL. Detector: Peak Note: Margin refers to the test results obtained minus specified requirement; thus a positive number indicates failure, and a negative result indicates that the product passes the test. (1) “Peak Amp.” (dBμV/m) includes the “correction” numbers. (2) “Duty Cycle Factor (D.C.F.)=(See Section 4.2 of this report). (3) “Correction” (dB) = Test Antenna Correction Factor(dB) + Coax Cable. (4) “Final Result” (dBμV/m)=Peak Amp. (dBμV/m)+D.C.F. (dB). (5) Out of restricted band signal: Limit = fundamental limit (80.3dB)-20dB Test Report E51151.01 RACAM - TECH LTD. Page 22 of 39 FCC ACC M Ver 1.1 05Mayl 2000 dB m m 14 sec)(100 sec)(20 log20−= Spurious Radiated Emission Above 1 GHz E.U.T DescriptionTerminal Unit TypeTU Serial Number:00378 Specification: F.C.C., Part 15, Subpart C Antenna Polarization: HorizontalFrequency range: 1 GHz to 2.9 GHz Test Distance: 3 metersDetector: Average FrequencyPeak Amp (1) D.C.F. (2) Correction (3) Final Result (4) Avg. Specification Margin (MHz)(dBμV/m)(dB)(dB)(dBμV/m)(dBμV/m)(dB μV/m) 1253.9249.6-14.034.1+35.660.3 (5)-24.7 1306.2045.6-14.034.5+31.654.0-16.6 1436.7245.5-14.035.8+31.554.0-22.5 1671.9049.2-14.037.7+35.254.0-18.8 1698.0447.8-14.037.9+33.854.0-20.2 2246.5752.2-14.041.6+38.254.0-15.8 Figure 10. Radiated Emission. Antenna Polarization: HORIZONTAL. Detector: Average Note: Margin refers to the test results obtained minus specified requirement; thus a positive number indicates failure, and a negative result indicates that the product passes the test. (1) “Peak Amp.” (dBμV/m) includes the “correction” numbers. (2) “Duty Cycle Factor (D.C.F.)=(See Section 4.2 of this report). (3) “Correction” (dB) = Test Antenna Correction Factor(dB) + Coax Cable. (4) “Final Result” (dBμV/m)=Peak Amp. (dBμV/m)+D.C.F. (dB). (5) Out of restricted band signal: Limit = fundamental limit (80.3dB)-20dB Test Report E51151.01 RACAM - TECH LTD. Page 23 of 39 FCC ACC M Ver 1.1 05Mayl 2000 Spurious Radiated Emission Above 1 GHz E.U.T DescriptionTerminal Unit TypeTU Serial Number:00378 Specification: F.C.C., Part 15, Subpart C Antenna Polarization: HorizontalFrequency range: 1 GHz to 2.9 GHz Test Distance: 3 metersDetector: Peak FrequencyPeak AmpCorrectionSpecificationMargin (MHz)(dBμV/m)(dB)(dBμV/m)(dB μV/m) 1253.9249.634.180.3 (Note*)-30.7 1306.2045.634.574.0-28.4 1436.7245.535.874.0-28.5 1671.9049.237.774.0-24.8 1698.0447.837.974.0-26.2 2246.5752.241.674.0-21.8 Figure 3. Radiated Emission. Antenna Polarization: HORIZONTAL. Detector: Peak Note: Margin refers to the test results obtained minus specified requirement; thus a positive number indicates failure, and a negative result indicates that the product passes the test. Note*Out of restricted band signal: Limit = Average limit + 20dB Test Report E51151.01 RACAM - TECH LTD. Page 24 of 39 FCC ACC M Ver 1.1 05Mayl 2000 Spurious Radiated Emission Above 1 GHz E.U.T DescriptionTerminal Unit TypeTU Serial Number:00378 Specification: F.C.C., Part 15, Subpart C Antenna Polarization: HorizontalFrequency range: 2.9 GHz to 4.2 GHz Test Distance: 3 metersDetector: Peak Correction Factors Freq.Peak Amp Antenna AF Cable CF Low Noise Amp Peak. Specification Peak Final Result FR (P)* Peak. Margin (MHz)(dBμV)(dB)(dB)(dB)(dB μV/m)(dB μV/m) See Note * (dB) 2925.8045.032.61.830.580.3 (Note **)48.9-31.4 3343.804…

Text truncated - open the document above for the full version.

1 Chris Harvey From:Chris Harvey Sent:Tuesday, August 05, 2003 10:44 AM To:'EMC' Cc:Marianne Bosley; TCB INFO Subject:RE: FCC ID Application for RACAM-TECH LTD. MT#14221 David, there are a few questions as we have started reviewing the documentation submitted: 1) There is a conflict between statements on Page 15 of 39, section 7.2, about the use of the Peak Detector with DCF correction, versus the measurement tables on Pages 25, 26, 29. The Duty Cycle Correction should be used for all measurements, including those above 1GHz. 2) ANSI C63.4 requires that hand operated devices be tested in 3 orthogonal axis (re-orient the EUT in 3 planes in addition to rotate 360 degrees) to determine the highest. Additionally, there was no mention of the movement of the EUT antenna (which moveable) to maximize the emissions. Please clarify these issues, or re-test as appropriate. 3) Please review the Radiated Spurious Data for compliance with the Restricted Bands of operation of 15.205. Apply the appropriate limits as necessary. 4) Was the Maximum Duty Cycle used? Just an FYI :The Users manual has an RF exposure statement that indicates that the user should maintain 20cm separation to the antenna. Although this is not a required statement for the field strengths per 15.231. We will continue to review the documentation and may have further questions as we proceed. Please respond to the above issues by e-mail to [email protected]. Best regards, Chris Harvey -----Original Message----- From: EMC [mailto:[email protected]] Sent: Tuesday, August 05, 2003 10:31 AM To: [email protected] Subject: RE: FCC ID Application for RACAM-TECH LTD. MT#14221 Hi Chris, Attached please find the two jpg files. Let me know if you have a problem with them I'll get back to you about the P/O after speaking with Shaike. Regards > David Shidlowsky > Technical Writer > EMC Laboratory > ITL (Product Testing) Ltd. > Kfar Bin Nun 2 > Israel > Tel: +972-8-9797799 > Fax: +972-8-9797702 > Email: [email protected] > http://www.itl.co.il > http://www.i-spec.com > This e-mail message may contain privileged or confidential > information. If you are not the intended recipient, you may not disclose, use, disseminate, distribute, copy or rely upon this message or attachment in any way. If you received this e-mail message in error, please return by forwarding the message and its attachments to the sender. > -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Tuesday, August 05, 2003 2:53 PM To: [email protected] Cc: [email protected] Subject: RE: FCC ID Application for RACAM-TECH LTD. MT#14221 David, I was unable to open the 2 JPG files (Confidentiality and Authorization). Please resend those files separately to my e-mail address. Best regards, Chris -----Original Message----- From: Chris Harvey Sent: Tuesday, August 05, 2003 8:36 AM To: 'EMC' Cc: Marianne Bosley Subject: RE: FCC ID Application for RACAM-TECH LTD. MT#14221 David, I have received this application and will begin the TCB process. I did not see a PO for this project. I know we agreed to $1000 fee, but what PO should we invoice against? We will communicate as we get into the details of the TCB review. Best regards, Chris Harvey -----Original Message----- From: EMC [mailto:[email protected]] 3 Sent: Tuesday, August 05, 2003 8:58 AM To: Chris Harvey (E-mail) Subject: FCC ID Application for RACAM-TECH LTD. Dear Chris, Attached please find the application for RACAM-TECH LTD. <<MetLabs Application.zip>> I have imbedded all the file attachments in MetLab's FCC Certification and application Package for Transmitters file. Please let me know if you have any difficulties opening any of the files. As usual our client is in a hurry so please handle this application A.S.A.P. If you require any additional information, please contact us. Thank you for your assistance Regards > David Shidlowsky > Technical Writer > EMC Laboratory > ITL (Product Testing) Ltd. > Kfar Bin Nun > Israel > Tel: +972-8-9797799 > Fax: +972-8-9797702 > Email: [email protected] > http://www.itl.co.il > http://www.i-spec.com > This e-mail message may contain privileged or confidential > information. If you are not the intended recipient, you may not > disclose, use, disseminate, distribute, copy or rely upon this message > or attachment in any way. If you received this e-mail message in > error, please return by forwarding the message and its attachments to > the sender. > > >

1 Chris Harvey From:EMC [[email protected]] Sent:Wednesday, August 06, 2003 10:46 AM To:Chris Harvey (E-mail) Subject:RE: FCC ID Application for RACAM-TECH LTD. MT#14221 RE: FCC ID Application for RAC... E51151.01.pdf (132 KB) Ref: Your email of 05 August 2003 <<RE: FCC ID Application for RACAM-TECH LTD. MT#14221>> Hi Chris, Thank you for your response of 05 August 2003 In response to your comments please be advised: 1. Attached are the corrected tables for the tests in the report. <<E51151.01.pdf>> 2. Prior to the final radiated emission tests, the E.U.T. was placed in three orthogonal axes for each position of the E.U.T. case. The antenna was also re-oriented. At the selected orientation, the emission was highest relative to the limit. 3. We corrected some of the limits as follows: 3.1. Within Restricted Bands: The table of Section 15.209(a). The final result is based on using peak detector reading minus D.C.F. (14dB). This was used for the whole frequency range (30-4300MHz). 3.2. Out of Restricted Bands up tp 1GHz: Fundamental limit -20dB per table of Section 15.231(b). 3.3. Out of Restricted Bands Above 1GHz: For the Average limit: as in Section 3.2 of this document. For Peak limit: as above (Section 3.2) + 20dB, based on section 15.35(b). 4. The maximum transmission "On" time in a 100msec. window is 20msec. See Section 4.2 of the report (Theory of Operation), therefore the D.C.F. factor is -14dB. I hope that the above helps and again thank you for your prompt response. Regards Shaike Raz EMC Laboratory Manager EMC Laboratory ITL (Product Testing) Ltd. Kfar Bin Nun Israel Tel: +972-8-9797799 Fax: +972-8-9797702 Email: [email protected] http://www.itl.co.il http://www.i-spec.com 2 This e-mail message may contain privileged or confidential information. If you are not the intended recipient, you may not disclose, use, disseminate, distribute, copy or rely upon this message or attachment in any way. If you received this e-mail message in error, please return by forwarding the message and its attachments to the sender.

1. Radiated Measurement Photos Figure 1. Radiated Emission Test. Front Figure 2. Radiated Emission Test. Side
