REZ-CID5000AraTek optical live fingerprint scanner

Aratek the special CID5000 residents ID card fingerprint User manual Product Introduction Aratek, CID5000 fingerprints collector is AraTek Biometrics Technology Co.,Ltd According to the resident id card fingerprint acquisition project research and development production one high-end fingerprint acquisition equipment. The collector fully meet the resident id card fingerprint acquisition equipment requirements. For citizens to fingerprint acquisition, security management, criminal investigation handling and criminal investigation and large public application system provides an important technical support and reliable guarantee. Product Features Excellent image quality The unique optical without distortion fingerprint imaging system Automatic clear fingerprint residue Automatic clear halo effect Unique waterproof technology Durability is good, fast response Image quality automatic detection, and ensure the availability of acquisition Dry, wet or rough fingerprint can make good use of product specification Electrical parameters Power supply voltage/current 5.0V(USBPower supply)/100mA Communication interface USB1.1/2.0 compatible ESD GB/T 17626.2—2006,level4 EMI GB/T 17626.3—2006,level2 Environment parameters Working temperature -10°C - 55°C Storage temperature -40°C - 60°C Work humidity 20%～90% Storage humidity 17%～96% Performance parameters Chip type Optical fingerprint acquisition Acquisition window size 16 *24 mm Effective image size 16 *24 mm Image size 320*480pixel resolution 500dpi Image distortion ≤1% Image defect 0个(R≥3),≤3个(R<3) grayscale 8bit,256 level Grey level dynamic range ≥220 The image background gray not uniformit ≤10% Single frame image acquisition time ≤0.25s Physical parameters Product size 13.8cm(L)*7.4cm(W)*4.3cm(H) Product net weight 250g Packing size 20.5cm(L)*15cm(W)*6.3cm(H) System compatibility Windows 2000, XP, Vista(32bit/64bit),Windows7(32bit/64bit) FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

Report No: CCIS12100022501 China Certification & Inspection Services Co., Ltd. Project No.: CCIS12100025IT 1st Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2311 8282 Fax: +86 (0) 755 2311 6366 Page 16 of 20 9 EUT Constructional Details Report No: CCIS12100022501 China Certification & Inspection Services Co., Ltd. Project No.: CCIS12100025IT 1st Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2311 8282 Fax: +86 (0) 755 2311 6366 Page 17 of 20

Size：75mm X 32mm Resident ID Card Fingerprint Reader Model No.:CID5000 Serial No.:75862851220125000001 FCC ID: REZ-CID5000 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. ShenZhen Aratek Biometrics Technology Co.,LTd. Label location

Report No: CCIS12100022501 China Certification & Inspection Services Co., Ltd. Project No.: CCIS12100025IT 1st Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2311 8282 Fax: +86 (0) 755 2311 6366 Page 18 of 20 Report No: CCIS12100022501 China Certification & Inspection Services Co., Ltd. Project No.: CCIS12100025IT 1st Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2311 8282 Fax: +86 (0) 755 2311 6366 Page 19 of 20 Report No: CCIS12100022501 China Certification & Inspection Services Co., Ltd. Project No.: CCIS12100025IT 1st Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2311 8282 Fax: +86 (0) 755 2311 6366 Page 20 of 20 ------End of report------
