RG2CL4000Media Master

Copyright © Shenzhen Reach IT Co., Ltd. REACH Media Master CL4000 (Beyonsys™) User Manual V2.1 2012-01 REACH CL4000（Beyonsys™） User Manual Copyright © Shenzhen Reach IT Co., Ltd. Shenzhen Reach IT Co., Ltd provides full technical supports for the customers. If you have any inquiries, please contact the local Reach office or directly contact the headquarters of the company. Shenzhen Reach IT Co., Ltd Address: Unit 601, Block B, Kingdee Software Park, No. 2, Technology Southern No. 12 Rd. South District of Hi-Tech Industrial Park, Nanshan District, Shenzhen Postal code: 518057 Website: http://www.szreach.com Te l . : 0755-86073600 Customer service hotline: 4007-160-868 Customer service fax: 0755-86073689 Copyright © Shenzhen Reach IT Co., Ltd. 2012. All rights reserved. Any part of this document, including the text, image and graph, is the property of Shenzhen Reach IT Co., Ltd. No part of this document shall be copied in any means without the prior written consent of Reach. Reach reserves the right to revise this document without any prior notice. Reach provides warranty of limited liabilities for the software and hardware product. For any loss of the users caused by the design defect of the software and hardware, Reach will compensate the user with the amount up to the price specified in the product purchase contract. Trademark Statement Reach, REACH, , Beyonsys™, Powolive™ and Reach Software are the trademarks of Shenzhen Reach IT Co., Ltd. Windows, Windows 95, Windows 98, Windows NT, Windows 2000, Windows 2003, Windows XP and Windows 7 are the trademarks of Microsoft. Other trademarks are the properties of their respective owners Note: This user manual is compiled to ensure easy installation and configuration of the product. Please read this manual carefully before using the product, so that you can make REACH CL4000（Beyonsys™） User Manual Copyright © Shenzhen Reach IT Co., Ltd. best use of all its functions. This manual is subject to update from time to time without prior notice. If you come across any problem that cannot be solved according to the manual, please contact Reach for solutions. Thank you. REACH CL4000（Beyonsys™） User Manual Copyright © Shenzhen Reach IT Co., Ltd. FCC Notice FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct The interference by one or more of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/TV technician for help z This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note:“Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.” REACH CL4000（Beyonsys™） User Manual Copyright © Shenzhen Reach IT Co., Ltd. Contents CHAPTER 1 OVERVIEW .......................................................................................................... 7 CHAPTER 2 INSTALLATION ................................................................................................... 8 2.1 PRODUCT INTRODUCTION................................................................................................... 8 2.2.1 Product front view ..................................................................................................... 8 2.2.2 Back view of the basic system .................................................................................. 8 2.2.3 Back view of the interface modules .......................................................................... 9 2.2 CONNECTION CABLE.........................................................................................................11 CHAPTER 3 START GUIDE ....................................................................................................11 3.1 STARTUP AND SHUTDOWN.................................................................................................11 3.2 LCD PANEL..................................................................................................................... 12 3.3 BUTTONS ON THE FRONT PANEL........................................................................................ 12 3.4 NETWORK........................................................................................................................ 12 3.5 INSTALL AND DOWNLOAD PLUG-INS................................................................................... 14 CHAPTER 4 LIVE STREAMING.................................................................错误！未定义书签。 4.1 WATCH LIVE STREAMING AS A SUPER ADMINISTRATOR........................................................ 15 4.2 WATCH LIVE STREAMING AS A COMMON USER.................................................................... 15 4.3 INTRODUCTION TO THE LIVE STREAMING PLAYER............................................................... 16 CHAPTER 5 RECORD........................................................................................…

Text truncated - open the document above for the full version.

Letter for Confidentiality Federal Communications Commission Authorization and Evaluation Division Date: Dec.13,2012 Confidentiality Request regarding application for certification of FCC ID: RG2CL4000 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1.Schematic 2.Theory of Operation 3.Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, We do not want these documents to be accessible to the general public. Sincerely, (签名人英文名): weicheng (签名人职称): Engineer SZ Reach Tech Co.,Ltd. Tel: 0755-86073607 Fax: 0755-86073689 E-mail: [email protected]

External Photos

Label and Label location

Internal Photos

FCC PART 15 SUBPART B TEST REPORT FCC PART 15 B Report Reference No. ..................... : TRE12120028 R/C:81138 FCC ID. ............................................. : RG2CL4000 Compiled by ( position+printed name+signature) .. : File administrators Eric Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Tim Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Dec 19, 2012 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................ : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : SZ Reach Tech Co.,Ltd Address ............................................ : 6/F,Block B,Kingdee Software park,#2,Keji 12th South Road.Hi- tech Industrial Park,Nanshan District,Shenzhen,P.R.China Test specification: Standard ........................................... : FCC Part 15 B- Unintentional Radiators TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Media Master Trade Mark ....................................... : / Model/Type reference ....................... : CL4000M Listed Models .................................. : CL4000C,CL4000CM,CL4000T,CL4XXXXXX,CP3000,MO8000, MC8000, MOXXXXXX,MCXXXXXX,CPXXXXXX Result................................................ : Positive Report No.: TRE12120028 Page 2 of 31 Issued:2012-12-19 T E S T R E P O R T Test Report No. : TRE12120028 Dec 19, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : Media Master Model /Type : CL4000M Listed Models : CL4000C,CL4000CM,CL4000T,CL4XXXXXX,CP3000,MO8000, MC8000, MOXXXXXX,MCXXXXXX,CPXXXXXX Applicant : SZ Reach Tech Co.,Ltd Address : 6/F,Block B,Kingdee Software park,#2,Keji 12th South Road.Hi- tech Industrial Park,Nanshan District,Shenzhen,P.R.China Manufacturer SZ Reach Tech Co.,Ltd Address 6/F,Block B,Kingdee Software park,#2,Keji 12th South Road.Hi- tech Industrial Park,Nanshan District,Shenzhen,P.R.China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE12120028 Page 3 of 31 Issued:2012-12-19 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. Configuration of Tested System 5 2.5. EUT configuration 6 2.6. EUT operation mode 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. Modifications 6 3. TEST ENVIRONMENT ............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Statement of the measurement uncertainty 8 3.5. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 13 5. TEST SETUP PHOTOS OF THE EUT .......................................... 19 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 21 Report No.: TRE12120028 Page 4 of 31 Issued:2012-12-19 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15 Subpart B - Unintentional Radiators ANSI C63.4-2009: American National Standard for Methods of Measurement of Radio-Noise Emissions From Low Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz. Report No.: TRE12120028 Page 5 of 31 Issued:2012-12-19 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Dec 13, 2012 Testing commenced on : Dec 13, 2012 Testing concluded on : Dec 19, 2012 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ● 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) AC 120V/60Hz 2.3. Short description of the Equipment under Test (EUT) The EUT is a Media Master,the Sample models are as follow: CL4000C、CL4000CM、CL4000T、CL4000M、CL4XXXXXX、MO8000、MC8000、CP3000、 MOXXXXXX、MCXXXXXX、CPXXXXXX ； Note:X Stands for the characters of 0~9,A~Z,a~z,space or symbols +,-,according to the requirements of customers,these products adopt the same hardware,and the safety and ESD compatibility will not be affected Serial number: Prototype 2.4. Configuration of Tested System Fig. 2-1 Configuration of Tested System 1.0 Meter 1.5 Meter Non-Conducting Table 80 cm above Ground Plane Adapter PC LISN Monitor Mousekeyboard PC EUT camera DVIcable RJ45 cable USB cable VGA cable VGA cable AV cable Report No.: TRE12120028 Page 6 of 31 Issued:2012-12-19 2.5. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ○ - supplied by the manufacturer ● - supplied by the lab Support Equipment List and Details Manufacturer Description Model Serial Number FCC ID DELL Mouse MOC5UO 10R04OPG N/A DELL Keyboard KB522 / N/A Toyoplas LCD Monitor N/A N/A N/A External I/O Cable Cable Description Length (m)From/Po…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
