RHX-IA101Shop Floor Signal Station

To Whom It May Concern: The user manual is still under development. Any product shipped prior to the user manual being completed will contain the Information to the User statement. Additionally, as soon as the User Manual is complete, a copy will be provided to Compatible Electronics to post to the FCC. Robert Wilson – Member Industrial Andons LLC

INFORMATION TO THE USER FOR CLASS A DIGITAL DEVICE WARNING: This equipment has been tested and found to comply with the limits for Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction’s manual, may cause interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense. The user is cautioned that changes and modifications made to the equipment without approval of the manufacturer could void the user’s authority to operate this equipment.

Power Supply Modification Certification The power supply manufacturer has been contacted and fully understands the changes made during the testing process. The power supply manufacturer has agreed to supply all power supplies with the added 0.001uf capacitor. This change will be a permanent in the production process. Robert Wilson - Member Industrial Andons LLC

Pursuant to 47 CFR 0.457(d) and 47 CFR 0.459 of the FCC Rules, Industrial Andons LLC requests confidentiality for all schematics, block diagrams and operational descriptions relating to the current model filed for FCC certification. The above-mentioned documents specifically relate to a patent pending product and process. The information in these documents are trade secrets and not available to the general public. The schematics were custom designed specifically for Industrial Andons LLC and not available anywhere else. The block diagram and operational description outlines the whole process behind the patent pending system which may divulge insight into necessary aspects of the circuitry and product. Robert Wilson - Member Industrial Andons LLC

Industrial Andons LLC FCC Label Design. FCC ID: RHX-IA101 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. Actual label is 1” high and approximately 2.5” long. Checklist item: 2) Grantee code has not been procured. a. FCC ID: __ __ __-IA101 3) Label will be on side of box. Label is 1” in total height and approximately 2.5” long. FCC class B Label for Receiver Andon Communication System Model: IA101 Tested to comply With FCC Standards

Report Number: B31001A2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Shop Floor Signal Station Model: IA101 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for SHOP FLOOR SIGNAL STATION MODEL: IA101 Prepared for INDUSTRIAL ANDONS LLC. 3860 SE 52 ND AVENUE OCALA, FL 34480 Prepared by:_____________________ MICHAEL CHRISTENSEN Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: OCTOBER 14, 2003 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 13 23 58 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B31001A2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Shop Floor Signal Station Model: IA101 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 14 7.2 Bandwidth of the Fundamental 15 8. CONCLUSIONS 16 Report Number: B31001A2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Shop Floor Signal Station Model: IA101 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Site Report Number: B31001A2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Shop Floor Signal Station Model: IA101 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Shop Floor Signal Station Model: IA101 S/N: N/A Product Description: See Expository Statement Modifications: The EUT was modified in order to meet the specifications. Please see the list located in Appendix B. Manufacturer: Industrial Andons LLC. 3860 SE 52 nd Avenue Ocala, FL 34480 Test Dates: September 18, 19 and 29, 2003 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.207, 15.209 and 15.231 Test Procedure: ANSI C63.4: 2001 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz Complies with the Class A limits of CFR Title 47, Part 15, Subpart B; and Subpart C, section 15.207. 2 Radiated RF Emissions, 10 kHz - 4180 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. Report Number: B31001A2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Shop Floor Signal Station Model: IA101 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Shop Floor Signal Station Model: IA101. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 2001. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class A (Conducted Emissions) and Class B (Radiated Emissions) specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.231. Report Number: B31001A2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Shop Floor Signal Station Model: IA101 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 16 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 114 Olinda Drive, Brea, California 92823. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST) . 2.3 Cognizant Personnel Industrial Andons LLC. Robert Wilson Owner Compatible Electronics, Inc. Kyle Fujimoto Test Engineer Kirit Ramani Test Engineer Michael Christensen Sr. Test Engineer 2.4 Date Test Sample was Received The test …
