October 22, 2003 American TCB 6731 Whittier Ave Suite C110 McLean, VA. 22101 RE: Lasershield FCC ID RIHK0011500 Tim, Below are my answers for each issue in Blue: 1) Please provide pages 5 & 6 of the R53085-cover letters as a separate exhibit to be uploaded to the FCC site. Corrected and uploaded as separate letters. 2) The FCC ID and Identifier must be located on a single line as given in 2.925(a)(1). The FCC ID shown in the label and test report (1 &4 of 15, 2 of 7), does not match the application 731 form (RIHK0011500 vs.RIHK001150). Please confirm the correct FCC ID and update the label and/or affected exhibits as necessary. Additionally, the drawing showing placement of the label does not look like the device in this application. Please provide an updated photograph or drawing showing the placement of the label. Corrected. FCC ID is RIHK0011500. Uploaded revised label and report. 3) Page 4 of 15 states that the device does have predetermined transmissions, which are not allowed. Please explain. This statement was a typo on our behalf. There are NO predetermined transmissions. Corrected in report and uploaded. Sincerely, Jennifer Sanchez

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 ` October 22, 2003 RE: Lasershield Systems, Inc. FCC ID: RIHK0011500 After a review of the submitted information, I have a few comments on the above referenced Application. General 1) Please provide pages 5 & 6 of the R53085-cover letters as a separate exhibit to be uploaded to the FCC site. 2) The FCC ID and Identifier must be located on a single line as given in 2.925(a)(1). The FCC ID shown in the label and test report (1 &4 of 15, 2 of 7), does not match the application 731 form (RIHK0011500 vs. RIHK001150). Please confirm the correct FCC ID and update the label and/or affected exhibits as necessary. Additionally, the drawing showing placement of the label does not look like the device in this application. Please provide an updated photograph or drawing showing the placement of the label. 3) Page 4 of 15 states that the device does have predetermined transmissions, which are not allowed. Please explain. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Lasershield Systems Inc. 5931 Sea Lion Place, Suite 114 • Carlsbad, CA 92008 Phone (760) 930-1908 • Fax (760) 930-8056 www.lasershield.net American TCB 6731 Whittier Ave Suite C110 McLean, Va. 22101 10/13/2003 Gentlemen: This is your letter of authorization to accept our appointment of Elliott Laboratories, Inc., 5931 Sea Lion Place, Suite 114, Carlsbad, CA. 92008 as Agent for LaserShield Systems, Inc., to sign applications before the Commission and to make representations to you on our behalf. Elliott Laboratories is to receive and exchange data between our company and the Commission. This authorization is made pursuant to Section 2.911(c) of the FCC Rules and expires on {select a date suitable for execution of the application}. I hereby certify on behalf of LaserShield Systems, Inc., 5931 Sea Lion Place, Suite 114, Carlsbad, CA. 92008 ("Applicant") that neither Applicant nor any party to the application (officers, directors, and 5% shareholders) is subject to a denial of Federal benefits that includes FCC benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988. 21 U.S.C. 853a. Sincerely, Dennis Perry VP Engineering

Lasershield Systems Inc. 5931 Sea Lion Place, Suite 114 • Carlsbad, CA 92008 Phone (760) 930-1908 • Fax (760) 930-8056 www.lasershield.net American TCB 6731 Whittier Ave Suite C110 McLean, Va. 22101 10/13/2003 Dear Examiner: I am writing to avoid the possibility of an inadvertent disclosure of proprietary information. The accompanying Form 731 is being filed with the commission on our behalf by Elliott Laboratories, Inc., a consulting and testing laboratory. Included as exhibits with the enclosed application are block diagrams, schematics, and a detailed description of the theory of operation of the device. It is our intention to provide the commission with a full disclosure of our product so that its merits can be evaluated. Indeed, we are pleased to provide any further information that the commission might wish to see. It is not our intention, however, to make our proprietary process a matter of public record. In view of the fact that the block diagrams, schematics, and associated theory of operation disclose the mechanism of our process, we ask that these portions (block diagrams, schematics, and theory of operation) of our application be withheld from public inspection as provided under FCC section 0.459. These documents contain details of the proprietary operation of product. These details are not readily discernible - even to technically sophisticated individuals - from our hardware and constitute trade secrets. We request therefore that these documents and this letter be segregated from the body of our evaluation report and withheld from public inspection. Thank you for your attention. Please let the undersigned know if the Commission disagrees with our position or requires further justification. Sincerely, Dennis Perry VP Engineering

Key chain Remote External Photos

Confidential Information of Lasershield Systems, Inc. Rev. 2 Product label specification October 9, 2003 Text for the KeyFob: 6pt font, Arial, Ink color white LaserShield Systems, inc. FCCID:RIHK0011500 Made in China Label: The label should be 19 mm x 19 mm with rounded corners that is permanently affixed to the battery door recess. Label must have ink that will not easily come off by flaking or scratching. Label material will be determined by the supplier. FCC ID: RIH is the FCC-assigned grantee code; K0011500 is the unique product code for the device, assigned by LaserShield Color configuration: Background- dark gray color (PMS 431U) Text Ink- white color Battery door recess Place Here Label Location

Key chain Remote Internal Photos

File: R53085 Page 1 of 15 Electromagnetic Emissions Test Report and Application for Grant of Equipment Authorization pursuant to FCC Part 15, Subpart C Specifications for an Intentional Radiator, Industry Canada Radio Standards Specification 210 and FCC Part 15, Subpart B Specifications for a Receiver on the Lasershield Systems, Inc. Model: Key Chain Remote (KR) FCC ID: RIHK0011500 GRANTEE: Lasershield Systems, Inc. 5931 Sea Lion Place, Suite114 Carlsbad, CA. 92008 TEST SITE: Elliott Laboratories, Inc. 684 W. Maude Avenue Sunnyvale, CA 94086 REPORT DATE: October 13, 2003 FINAL TEST DATE: September 25, 2003 AUTHORIZED SIGNATORY: ______________________________ Mark Briggs Director of Engineering Elliott Laboratories, Inc. is accredited by the A2LA, certificate number 2016-01, to perform the test(s) listed in this report. This report shall not be reproduced, except in its entirety, without the written approval of Elliott Laboratories, Inc. Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: October 13, 2003 File: R53085 Page 2 of 15 pages TABLE OF CONTENTS COVER PAGE...................................................................................................................................................................................1 TABLE OF CONTENTS..............................................................................................................................................................2 SCOPE............................................................................................................................................................................................3 OBJECTIVE...................................................................................................................................................................................3 STATEMENT OF COMPLIANCE..............................................................................................................................................4 TEST RESULTS SUMMARY......................................................................................................................................................4 MEASUREMENT UNCERTAINTIES....................................................................................................................................5 EQUIPMENT UNDER TEST (EUT) DETAILS..........................................................................................................................6 GENERAL...................................................................................................................................................................................6 ENCLOSURE..............................................................................................................................................................................6 SUPPORT EQUIPMENT...........................................................................................................................................................6 EUT OPERATION.....................................................................................................................................................................6 TEST SITE......................................................................................................................................................................................7 GENERAL INFORMATION.....................................................................................................................................................7 CONDUCTED EMISSIONS CONSIDERATIONS.................................................................................................................7 RADIATED EMISSIONS CONSIDERATIONS....................................................................................................................7 MEASUREMENT INSTRUMENTATION..................................................................................................................................8 RECEIVER SYSTEM..................................................................................................................................................................8 INSTRUMENT CONTROL COMPUTER...............................................................................................................................8 LINE IMPEDANCE STABILIZATION NETWORK (LISN)................................................................................................8 FILTERS/ATTENUATORS......................................................................................................................................................9 ANTENNAS...............................................................................................................................................................................9 ANTENNA MAST AND EQUIPMENT TURNTABLE.......................................................................................................9 INSTRUMENT CALIBRATION..............................................................................................................................................9 TEST PROCEDURES.................................................................................................................................................................10 EUT AND CABLE PLACEMENT.........................................................................................................................................10 CONDUCTED EMISSIONS....................................................................................................................................................10 RADIATED EMISSIONS.......................................................................................................................................................10 SPECIFICATION LIMITS AND SAMPLE CALCULATIONS.......................................................................................…

Text truncated - open the document above for the full version.

Radiated Emissions Test Configuration – EUT Upright Radiated Emissions Test Configuration – EUT On Its Side Radiated Emissions Test Configuration – EUT On Its Back
