RISKAL215MICAMPLIFIER OF ACTIVE SPEAKER BOX

The AC inlet incorporates the voltage selector. Ensure that the main voltage source matches the voltage rating. Extract and place it according to the value. The cselected one will be showed in the correct reading position. 110-120 115-230V AC 50-60Hz 220-240 Device set at 110/120V AC 1. USB HOST 2. SD PLUG 3. Microphone A antena 4. Microphone B antena 5. MICROPHONE VOLUME 12. RCA Line Input/ RCA Line Output Use this control to set the volume level of Microphone 18. ON/OFF POWER SWITCH 19.AC POWER CONNECTOR 20 6. ECHO FOR MICROPHONE 7. Treble 8. Bass 9. Master volume 10/11. 6.35mm Mic input 13. Line in and MP3 Volume 14. Wireless Microphone A Volume 15. Wireless Microphone B Volume 16. Power switch of Wireless Microphone 17. DC 24 V connector 20.Handle Microphone A and Handle Microphone B 5 1 12 4 3 2 6 10 11 14 16 13 7 9 8 18 19 17 15 FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving an tenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 (ROLDY INC) (2015-02-02) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: RISKAL215MIC We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - BOM - Tune up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Victor Levis / Manager Company Name: ROLDY INC Address: 16330 NW 48th Ave, Miami, Florida 33014, United States Email: [email protected]

ROLDY INC Declaration on Model Differences We, ROLDY INC 16330 NW 48th Ave, Miami, Florida 33014, United States Declare that the following product(s): Product Name: AMPLIFIER OF ACTIVE SPEAKER BOX Model Number: KAL-215MIC, KAL-212MIC, SPY-1100MIC, SPY-1300MIC, KAL-2100MIC, SPY-900MIC, KAL1600MIC, SPY-1650MIC FCC ID: RISKAL215MIC Utilize the identical circuit design, PCB layout, shielding and interface with (KAL-215MIC), only the color and model number are difference. Therefore this application can be regarded as identical in performance to the submitted test sample. The manufacturer would take all the responsibilities for the above product(s). For and on behalf of Florida, United States Authorized person Location Name: Victor Levis Position: Manager Date of issue: 2015-02-02 *I hereby declare that I am entitled to sign on behalf of the applicant and that the information supplied is correct and complete.

Figure 1 The EUT-Front View Figure 2 The EUT-Back View Figure 3 The EUT-Top View Figure 4 The EUT-Bottom View Figure 5 The EUT-Left View Figure 6 The EUT-Right View

Product Name: AMPLIFIER OF ACTIVE SPEAKER BOX Model No.: KAL-215MIC FCC ID: RISKAL215MIC

Label Location On EUT

Figure 7 The EUT-Inside View Figure 8 PCB of the EUT-Front View Antenna Figure 9 PCB of the EUT-Back View

RF EXPOSURE EVALUATION FCC ID：RISKAL215MIC According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b): Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. The maximum output power for channel 1(178MHz) is: 3.96dBm= 2.49mW Tune up tolerance is: 3.50±1 dBm The Max. Tune up Power = 4.50dBm= 2.82mW The calculation results= 2.82/5*√0.178 =0.238 ＜3 The maximum output power for channel 1(198MHz) is: 3.70dBm= 2.35mW Tune up tolerance is: 3.50±1 dBm The Max. Tune up Power = 4.50dBm= 2.82mW The calculation results= 2.82/5*√0.198 =0.252 ＜3 Test Results: The product is no need to conduct SAR test.
