RLVAUDIOPILLARBLUETOOTH SPEAKER

1 AUDIO PILLAR ® QUICK START GUIDE 2 ENG • Power adapter with universal plugs • Aux-in cable • Audio Pillar ® ESP • Adaptador de corriente con enchufes universales • Cable de entrada auxiliar • Audio Pillar ® INSIDE THE BOX EN EL INTERIOR DE LA CAJA 3 ENG LISTEN Play your music wirelessly through any Bluetooth ® -enabled device or connect to your music device via a 3.5mm stereo input cable (included). TALK Utilize the speakerphone capabilities for hands-free conversations. TRAVEL With the Lithium-ion rechargeable battery you don’t need to worry about being connected for 15 hours* and with a universal power adapter (included) you are free to travel the world (100-240V AC, 50+60Hz). *15 hours of continuous play between charges at normal volume. ADORN Find the right Audio Pillar ® to complement your décor. FOR THE TECHIE IN YOU Your new 2.1 stereo system includes proprietary (1.5”) acoustic drivers (stereo pair) and a 3” subwoofer, a universal power supply 100-240V AC, 50-60Hz, built-in microphone for Speakerphone capabilities and a Bluetooth ® wireless range of up to 50 feet. ESP ESCUCHE Escuche su música preferida de forma inalámbrica a través de cualquier dispositivo activado para Bluetooth ® o conéctelo a su equipo de música mediante un cable de entrada para estéreo de 3.5 mm (incluido). HABLE Aproveche la función de altavoz para conversaciones de manos libres. VIAJE Con la batería recargable de litio-ión, durante 15 horas* no tendrá que preocuparse por estar conectado, y con un adaptador de corriente universal (incluido), puede viajar a cualquier lugar del mundo (100-240V c.a., 50-60Hz). *15 horas de reproducción continua entre carga y carga a un volumen normal. ÚSELO COMO OBJETO DECORATIVO Escoja el Audio Pillar ® adecuado para complementar la decoración de su espacio. PARA LOS FANÁTICOS DE NUEVAS TECNOLOGÍAS Su nuevo sistema de estéreo 2.1 incluye controladores acústicos (1.5”) patentados (par por estéreo) y un subwoofer de 3”, un suministro eléctrico universal de 100-240V c.a., 50-60Hz, micrófono integrado para la función de altavoz y un rango inalámbrico para Bluetooth ® de hasta más de 15 m. 4 ENG TOP FEATURES Power Button Pairing Button Conference Call Talk Button Volume Up Volume Down Light in the Center (Orange While Charging, White When Fully Charged) ESP FUNCIONES DE LA PARTE SUPERIOR Botón de encendido/apagado Botón de emparejamiento Botón para llamada en conferencia Subir volumen Bajar volumen Luz en el centro (anaranjada mientras está cargando; blanca cuando se ha cargado por completo) ENG BOTTOM FEATURES DC In USB (*note can charge any smart device) Line In Aux-In Power Button ESP FUNCIONES DE LA PARTE INFERIOR Entrada de CC Puerto USB (*nota: puede cargar cual- quier dispositivo inteligente) Entrada de línea Entrada auxiliar Botón de encendido/apagado BUTTONS & CONTROLS BOTONES Y CONTROLES 5 ENG Plug Audio Pillar ® into an outlet using the included wall charger. The LED will turn orange while charging and will turn white when fully charged. Full charge will take about 4.0 hours. 15 hours between charges at normal volumes. ESP Enchufe el Audio Pillar ® en un tomacor- riente usando el cargador de pared incluido. El indicador LED se verá anaranjado mientras el dispositivo esté cargando y se pondrá blanco cuando se haya cargado por completo. La carga completa demora alrededor de 4 horas. 15 horas entre carga y carga a un volumen normal. CHARGING YOUR PILLAR CÓMO CARGAR SU PILLAR 6 ENG When powered on for the first time, go to Bluetooth® settings on your smartphone, tablet, computer or device. On your Audio Pillar ® ,hold down pairing button for 3 seconds until you hear “pairing” audible voice. Select Stellé Pillar on your device. Once paired you will hear “paired successfully” audible voice. Once your device is paired with the Audio Pillar ® it will automatically pair when device is on and within Bluetooth® range ESP Al encenderlo por primera vez, vaya a la configuración de Bluetooth® de su teléfono inteligente, tableta, ordenador o dispositivo. En su Audio Pillar ® , mantenga presionado el botón de emparejamiento (“pairing”) durante 3 segundos hasta que escuche una voz audible que dirá “pairing” (empareja- miento en proceso). Seleccione Stellé Pillar en su dispositivo. Una vez emparejado, escuchará una voz audible que dirá “paired successfully” (emparejamiento exitoso). Una vez que su dispositivo esté emparejado con el Audio Pillar ® se emparejará automática- mente cuando el dispositivo esté encendido y dentro del rango del Bluetooth®. CONNECT WIRELESSLY CONEXIÓN INALÁMBRICA 7 ENG Use Audio Pillar ® as a portable speak- erphone when connected wirelessly via Bluetooth ® . To answer and/or end a call, press the talk button. ESP Use el Audio Pillar ® como altavoz portátil cuando esté conectado de forma inalámbrica vía Bluetooth ® . Para atender o finalizar una llamada, presione el botón “talk” . SPEAKERPHONE ALTAVOZ 8 ENG Connect Audio Pillar ® to any device with a headphone jack or line out by plugging the included 3.5mm Aux-in cable into Aux-in jack on the bottom of Audio Pillar ® . ESP Conecte el Audio Pillar ® a cualquier dis- positivo con una clavija para auriculares o salida de línea enchufando el cable de entrada auxiliar de 3,5 mm incluido, en la clavija de entrada auxiliar ubicada en la parte inferior del Audio Pillar ® . PLUG & PLAY CONNECT CONEXIÓN ENCHUFAR Y USAR 9 ENG Plug Audio Pillar ® into an outlet using the wall charger. Plug the USB into the Audio Pillar ® and your device to charge. ESP Enchufe el Audio Pillar ® a un tomacor- riente usando el cargador para pared. Conecte el USB en el Audio Pillar ® y el dispositivo que desea cargar. CHARGE YOUR DEVICE CÓMO CARGAR SU DISPOSITIVO 10 SAFETY INFORMATION INFORMACIÓN SOBRE SEGURIDAD ENG WARNING Please read these safety warnings and cautions carefully to ensure your personal safety and prevent property damage. FIRE AND ELECTRIC SHOCK HAZARD Battery/Charger Hazard • Do not dispose of your Stellé Audio Pillar TM Spea…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Stellé Audio couture LLC 2014-11-07 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _Stellé Audio couture LLC_hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): BLUETOOTH SPEAKER, Audio Pillar FCC ID: RLVAUDIOPILLAR Sincerely, signature Wayne Ludlum/ Manager E-mail: [email protected] Phone: 800 896 1012 Fax: 310 775 9766 Address: 419 30th STREET, SUITE A NEWPORT BEACH, California, United States

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Stellé Audio couture LLC 2014-11-07 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: RLVAUDIOPILLAR We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature Wayne Ludlum/ Manager E-mail: [email protected] Phone: 800 896 1012 Fax: 310 775 9766 Address: 419 30th STREET, SUITE A NEWPORT BEACH, California, United States

透明龙贴纸 35x35mm 35x35mm 35x35mm 1色印刷（黑字） 透明龙贴纸 厚度：0.08mm LIHONG 2014-10-11 Pillus A0 Pillus 1:1 Stellé Audio couture LLC - Designed in California Made in P.R.C 35 mm 35 mm 35 mm 15 mm *LABEL MUST BE PROOF-READ, SPROUT IS NOT RESPONSIBLE FOR ERRORS ON THIS LABEL* PILLAR BOTT OM 2200 Model:Audio Pillar 5V 3.5A FCC ID:RLVAUDIOPILLAR IC:10815A-AUDIOPILLAR FCC NOTE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B)/NMB-3(B)

Label Location Proposed Label Location on EUT

Module Antenna

FCC ID: RLVAUDIOPILLAR Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculated. Maximum measured transmitter power: Transmit Frequency (GHz) Mode Measured Power (dBm) Tune-up power (dBm) Max tune-up power(dBm) Result calculation 1-g SAR 2.402 GFSK 4.880 5±1 6 0.9535 3.00 2.441 GFSK 4.797 5±1 6 0.9430 3.00 2.480 GFSK 4.260 5±1 6 0.8400 3.00 2.402 π/4-DQPSK 4.001 3.5±1 4.5 0.7788 3.00 2.441 π/4-DQPSK 3.792 3.5±1 4.5 0.7482 3.00 2.480 π/4-DQPSK 2.945 3.5±1 4.5 0.6205 3.00 2.402 8-DPSK 4.182 4±1 5 0.8119 3.00 2.441 8-DPSK 4.074 4±1 5 0.7984 3.00 2.480 8-DPSK 3.286 4±1 5 0.6712 3.00 Conclusion: For the max result 0.9535≤ 3.0 for 1-g SAR extremity SAR, No SAR is required. Sincerely, Signature Company Name: SHENZHEN EMTEK CO., LTD. Address: Bldg 69, Majialong Industry Zone, NanshanDistrict, Shenzhen, China. David Lee/ Manager

TRF No.:FCC 15.247/A Page 1 of 58 Report No.: ES140928344E Ver.1.0 Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT For BLUETOOTH SPEAKER MODEL No.: Audio Pillar FCC ID: RLVAUDIOPILLAR Trademark: Stellé Audio REPORT NO.: ES140928344E ISSUE DATE: November 11, 2014 Prepared for Stellé Audio couture LLC 419 30th STREET, SUITE A NEWPORT BEACH, California, United States Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.:FCC 15.247/A Page 2 of 58 Report No.: ES140928344E Ver.1.0 Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World Table of Contents 1 TEST RESULT CERTIFICATION .......................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ........................................................................................................................ 4 3 SUMMARY OF TEST RESULT ............................................................................................................................. 5 4 TEST METHODOLOGY ........................................................................................................................................ 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................................... 6 4.2 MEASUREMENT EQUIPMENT USED ..................................................................................................... 6 4.3 DESCRIPTION OF TEST MODES ............................................................................................................. 6 5 FACILITIES AND ACCREDITATIONS ................................................................................................................. 8 5.1 FACILITIES ................................................................................................................................................. 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS .............................................................................. 8 6 TEST SYSTEM UNCERTAINTY ........................................................................................................................... 9 7 SETUP OF EQUIPMENT UNDER TEST ............................................................................................................. 10 7.1 RADIO FREQUENCY TEST SETUP 1 ..................................................................................................... 10 7.2 RADIO FREQUENCY TEST SETUP 2 ..................................................................................................... 10 7.3 CONDUCTED EMISSION TEST SETUP ................................................................................................. 11 7.4 SUPPORT EQUIPMENT ........................................................................................................................... 11 8 TEST REQUIREMENTS ...................................................................................................................................... 12 8.1 20DB BANDWIDTH ................................................................................................................................. 12 8.2 CARRIER FREQUENCY SEPARATION .................................................................................................. 18 8.3 NUMBER OF HOPPING FREQUENCIES ............................................................................................... 24 8.4 AV E R A G E TIME OF OCCUPANCY (DWELL TIME) ............................................................................. 26 8.5 MAXIMUM PEAK CONDUCTED OUTPUT POWER ............................................................................ 29 8.6 CONDUCTED SUPRIOUS EMISSION .................................................................................................... 35 8.7 RADIATED SPURIOUS EMISSION ......................................................................................................... 40 8.8 CONDUCTED EMISSION TEST .............................................................................................................. 55 8.9 ANTENNA APPLICATION ....................................................................................................................... 58 TRF No.:FCC 15.247/A Page 3 of 58 Report No.: ES140928344E Ver.1.0 Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World 1 TEST RESULT CERTIFICATION Applicant: Stellé Audio couture LLC 419 30th STREET, SUITE A NEWPORT BEACH, California, United States Manufacturer: SHENZHEN FENDA TECHNOLOGY CO., LTD. Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City,Guangdong, China Product Description: BLUETOOTH SPEAKER Model Number: Audio Pillar File Number: ES140928344E Date of Test: October 18, 2014 to November 11, 2014 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report Date of Test : October 18, 2014…

Text truncated - open the document above for the full version.

Conducted Measurement Photo Radiated Emission Test
