RN6STR-6000AMarine DSC VHF Radio Telephone

SAMYUNG ENC Co., Ltd
Marine DSC VHF Radio Telephone - FCC ID RN6STR-6000A - SAMYUNG ENC Co., Ltd
Click to zoom

Application Details

Equipment Class
GVH - Part 80 VHF Transmitter (GMDSS)
Date of Grant
May 02, 2006
Application Purpose
Original Equipment
Date of Application
May 02, 2006
Equipment Note
Marine DSC VHF Radio Telephone
Frequency Range
156.52500000 - 156.52500000
Company
SAMYUNG ENC Co., Ltd
Country
South Korea

Documents & Files

Select a file to view

Users Manual

β†—

Attestation Statements

β†—

Cover Letter(s)

β†—

External Photos

β†—

ID Label/Location Info

β†—

Internal Photos

β†—

Parts List/Tune Up Info

β†—
β†—

Test Report

β†—

Test Setup Photos

β†—

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 MARINE DSC VHF RADIO TELEPHONE FOR GMDSS OPERATING MANUAL STR- 6000A SAMYUNGENC CO.,LTD. 2 INSTRUCTIONS Please read this operating manual with care before turning on power. 1. How to transmit and stop Distress Call Β— In performing Distress Call function, press button and hold it down for 3(three) seconds until DISTRESS MESSAGE is seen. Then the whole display unit will start flashing with a strong alarm. In transmitting Distress Call, the transmission must be made based on the judgment of a person on duty. The test of this function MUST NOT be made at all times because the test may cause heavy damages to near-going vessels and search & rescue authorities concerned. Β— When the Distress Call is performed, the distress message will be automatically transmitted and this transmission will be repeated at the intervals of 3 minutes 30 seconds through 4 minutes 30 seconds. This transmission will be repeated until the DSC (Digital Selective Calling) is received by the authorities of the country to which the call is transmitted or until any operation for ending the call is made. If any transmission is made by accident, press button to bring it to an end. Even though any operation for stop has been made, it is necessary for operator to contact CH16 to inform that the transmission was made by mistake as the message was automatically transmitted more than one time at least. Β— When Distress Call is received, it is necessary to inform a person on duty about this. 2. How to make the initial set-up in installation For the below items, the initial set-up should be made in installation before its actual operation. Please contact SAMYUNG ENC or any agent dealers for the information. 3 2-1 How to check out power supply Input voltage in VHF main unit: Confirm that DC13.6V is supplied. 2-2 How to transmit and receive DSC In order to use DSC function, make sure that any MMSI number available must be input first. 3. Other instructions 3-1 In using Semi-Auto & Auto connection service with DSC, it is necessary to check with the concerned authorities about the formalities of call charge because the billing system has not yet been decided worldwide. 3-2 The paper used in DPU-414 PRINTER is a special one that is chromogenic with thermo-chemistry reaction. Therefore, it is advisable to avoid the below-mentioned cases as the paper tends to change its color or get discolored. Β— Keeping under any places with heat, humidity and light Β— Touching with sweat-wet hands Β— Rubbing with any hard things Β— Pasting with any organic solvents such as glue Β— Applying with any oiled tapes Β— Long time exposure to any vinyl chloride films Β— Contacting diazo immediately after printout Β— Contacting any wet copy Β— Contacting any oiled solvents 4 Chapter 1. Introduction .................................................................................... 6 1.1. Introduction ....................................................................................................... 6 1.2. Features ............................................................................................................ 6 Chapter 2. Configuration ................................................................................. 8 2.1. Standards.......................................................................................................... 8 2.2. Option................................................................................................................ 8 Chapter 3. Specifications................................................................................. 9 3.1. STR-6000A Standards ...................................................................................... 9 3.2. Transmitting Unit ............................................................................................... 9 3.3. Receiving Unit ................................................................................................. 10 3.4. Dedicated Receiving Unit ................................................................................ 10 Chapter 4. How to Operation ......................................................................... 11 4.1. Unit Description............................................................................................... 11 4.1.1. Front Panel ............................................................................................ 11 4.1.2. Microphone ............................................................................................ 14 4.2. LCD Screen Description.................................................................................. 16 4.3. VHF Operation ................................................................................................ 17 4.3.1. Channel Selection ................................................................................. 17 4.3.1.1. Channel 16................................................................................... 17 4.3.1.2. Channel Mode Selection (ITU,USA,CAN).................................... 17 4.3.2. Weather Channel................................................................................... 18 4.3.3 Transmit and Receive............................................................................. 18 4.4. Menu Setup and Construction......................................................................... 20 4.4.1. Menu Construction ................................................................................ 20 4.4.2. Menu Screen Construction and Initialization ......................................... 22 4.4.3. Menu Setup ........................................................................................... 23 4.4.3.1. FRIENDS MMSI LIST .................................................................. 23 4.4.3.2. GROUP MMSI LIST ..................................................................... 23 4.4.3.3. TELEPHONE LIST....................................................................... 24 4.4.3.4. LCD BACKLIGHT...............…

Text truncated - open the document above for the full version.

Cover Letter(s)

1123-17, Dongsam-Dong, Youngdo-gu Busan, 606-083,Korea TEL No : 82-51-601-6600 FAX No : 82-51-412-6616 April 14, 2006 Federal Communications Commision Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : SAMYUNG ENC Co., Ltd. FCC ID : RN6STR-6000A Request for Confidentiality Gentlemen : In accordance with 0.457 and 0.459 of CFR 47, SAMYUNG ENC Co., Ltd. Hereby requests confidentiality of the Schematics, Block diagram and Operational description of the attached test report. These documents contain detailed system and equipment description and related information about the product which SAMYUNG ENC Co., Ltd. Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, SAMYUNG ENC Co., Ltd. Considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, In-Joon, Choi / Managing Director

External Photos

BWS TECH Inc. 1 of 4 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A Appendix 3. External Photos 1. Top 2. Bottom BWS TECH Inc. 2 of 4 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 3. Front 4. Back BWS TECH Inc. 3 of 4 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 5. Left 6. Right BWS TECH Inc. 4 of 4 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 7. Mike - Top 8. Mike - Bottom

ID Label/Location Info

BWS TECH Inc. 1 of 1 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A Appendix 2. FCC ID Label & Location Product Label Sample with FCC ID Label information Following is a sample copy of the label that will be placed on the rear cabinet of the product. The FCC identifier is marked in the product label. The following FCC Warning statement will be described in the user manual. FCC Warning Label Location The label shown above shall be permanently affixed at a conspicuous location(cabinet out side) on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) SAMYUNG ENC Co., Ltd. VHF Transmitter (GMDSS) Model : STR-6000A FCC ID : RN6STR-6000A FCC ID LABEL Caution Device must be restricted to occupation use to safety FCC RF exposure. See Instruction manual for s pecific operating requirement.

Internal Photos

BWS TECH Inc. 1 of 9 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A Appendix 4. Internal Photos 1. Inside BWS TECH Inc. 1 of 9 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 2. SM-6000 Mike / Inside BWS TECH Inc. 1 of 9 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 3. V-896 / Inside BWS TECH Inc. 1 of 9 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 4. V-896 / Top 5. V-896 / Bottom BWS TECH Inc. 1 of 9 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 6. V-894 / Inside BWS TECH Inc. 1 of 9 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 7. V-894 / Top 8. V-894 / Bottom BWS TECH Inc. 1 of 9 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 9. V-895 / Inside BWS TECH Inc. 1 of 9 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 10. V-895 / Top 11. V-895 / Bottom BWS TECH Inc. 1 of 9 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 12. LCD / Top 13. LCD/ Bottom

Test Report

BWS TECH Inc. 2 of 41 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A TABLE OF CONTENTS Pages 1. General Information 3 2. Description of Test Facility 4 3. Product Information 5~7 4. Summary of Test Results 8 5. Test Data 9~35 5.1. RF Power Output (Conducted) 9~10 5.2. RF Power Output (ERP) 11~12 5.3. Modulation Characteristics – Audio Frequency Response 13~14 5.4. Modulation Characteristics – Audio Low-pass Filter Response 15~16 5.5. Modulation Characteristics – Modulation Limiting 17~19 5.6. Occupied Bandwidth 20~24 5.7. Spurious Emissions at Antenna Terminals 25~31 5.8. Field Strength of Spurious Radiation 32~34 5.9. Frequency Stability/Temperature Variation 35~36 5.10 Maximum Usable Sensitivity for the Receiver 37~38 6. RF Exposure Requirement 39~40 7. Test Equipment List 41 Appendix 1. Test Setup Photos Appendix 2. FCC ID Label and location Appendix 3. External Photos of EUT Appendix 4. Internal Photos of EUT Appendix 5. Block Diagram Appendix 6. Schematics Appendix 7. Part-List Appendix 8. Operational Description Appendix 9. User Manual BWS TECH Inc. 3 of 41 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A FCC TEST REPORT Scope – Measurement and determination of electromagnetic emission(EME) of radio frequency devices including intentional radiators and/or unintentional radiators for compliance with the technical rules and regulations of the U.S Federal Communications Commission(FCC) 1. General Information Applicant Manufacturer Company Name : SAMYUNG ENC Co., Ltd. Company Address : 1123-17, Dongsam-Dong, Youngdo-gu, Busan, 606-083, Korea Phone/Fax : Phone : +82-51-601-6600 Fax : +82-51-412-6616 Company Name : SAMYUNG ENC Co., Ltd. Company Address : 1123-17, Dongsam-Dong, Youngdo-gu, Busan, 606-083, Korea Phone/Fax : Phone : +82-51-601-6600 Fax : +82-51-412-6616 z EUT Type : MARINE DSC VHF RADIO TELEPHONE z Model Number : STR-6000A z FCC Identifier : RN6STR-6000A z S/N : Prototype z FCC Rule Part(s) : FCC Part 80 Stations in the Maritime Services z FCC Classification : GVH : Part 80 VHF Transmitter (GMDSS) z Freq. Range : 156.025 MHz ~ 157.425 MHz z Channel : 178 ITU Channel: 55 USA Channel: 53 CANADA Channel: 60 WEATHER Channel: 10 z Modulation Method : FM, FSK z Emission Designator : FM(16K0G3E), DSC(16K0G2B) z RF Power Output : 25W / 1W z Test Procedure : ANSI C63.4-2002 z Dates of Tests : March 30, 2006 z Place of Tests : BWS TECH Inc. #611-1 Maesan-Ri, Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-853, Korea (FCC Registration Number : 553281) TEL: +82 31 333 5997 FAX: +82 31 333 0017 z Test Report No. : BWS-06-RF-0010 BWS TECH Inc. 4 of 41 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 2. Description of Test Facility The measurement for radiated and conducted emission test were conducted at the open area test site of BWS TECH Inc. facility located at #611-1 Maesan-Ri, Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do, 449-853 Korea. The site is constructed in conformance with the requirements of the ANSI C63.4-2002 and CISPR Publication 16. The BWS TECH measurement facility has been filed to the Commission with the FCC for 3 and 10-meter site configurations. Detailed description of test facility was found to be in compliance with the requirements of Section 2.948 FCC Rules according to the ANSI C63.4-2002 and registered to the Federal Communications Commission (Registration Number : 553281 ). The measurement procedure described in American National Standard for Method of Measurement of Radio-Noise Emission from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C.63.4-2002) was used in determining radiated and conducted emissions from the SAMYUNG ENC Co., Ltd. Marine DSC VHF Radio Telephone Model : STR-6000A. BWS TECH Inc. 5 of 41 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 3. Product Information The Equipment Under Test (EUT) is SAMYUNG ENC Co., Ltd. Marine DSC VHF Radio Telephone Model : STR-6000A. (FCC ID: RN6STR-6000A). STR-6000A includes DSC/VHF radio telephone and DSC receiver required by the Global Maritime Distress and Safety System(GMDSS) and is designed to be compact and lightweight for easy installation in any vessels engaged in international voyages and near-going vessels. In addition to the conventional voice communication, STR-6000A is equipped with Digital Selective Calling(DSC) functions for distress calls and routine calls as well. It also incorporates all the necessary units for DSC services such as DSC unit, CH70 DSC receiver. 3.1 DC Voltage abd Currents The DC voltages applied to and DC currents into the several elements of the final radio frequency amplifying stage for normal operation over power range were; Standby : 13.6 Volts, 0.5 Ampare Low Power : 13.6 Volts, 1.5 Ampare High Power : 13.6 Volts, 5.5 Ampare 3.2 Emission Designator Type of Emission : G3E Necessary Bandwidth and Emission Bandwidth : FM : Bn = 16K0G3E DSC : Bn = 16K0G2B Calculation: Maximum Modulation(M) in kHz : 3 Maximum Deviation(D) in kHz : 2.5(NB) and 5(WB) Constant Factor(k) : 1 Bn = 2M + 2DK BWS TECH Inc. 6 of 41 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 3.3 General Specification 3.3.1 STR-6000A Standards TX Frequency 156.025MHz ~ 157.425MHz RX Frequency 156.050MHz ~ 163.275MHz Number of Channels 178 ITU Channel: 55 USA Channel: 53 CANADA Channel: 60 WEATHER Channel: 10 Radio Wave Mode FM(16K0G3E), DSC(16K0G2B) Channel Interval 25kHz Communication Mode Simplex and Semi-Duplex Antenna impedance 50Ω(SO-239) Audio Output Impedance 4Ω Frequency Stability Β±10 PPM(-20 to +60 )Β°CΒ°C Voltage Supply 13.6V DCΒ±10%(Negative Ground) Consumption Currency (13.6V) TX High 5.5A max Maximum Audio 1.5A max Operating Temperatu…

Text truncated - open the document above for the full version.

Test Setup Photos

BWS TECH Inc. 1 of 5 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A Appendix 1. Test Setup Photos 1. Conducted BWS TECH Inc. 2 of 5 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 2. Field Strength of Spurious Emission / Below 1 GHz / Antenna BWS TECH Inc. 3 of 5 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 3. Field Strength of Spurious Emission / Above 1 GHz / Antenna BWS TECH Inc. 4 of 5 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 4. Field Strength of Spurious Emission / Below 1 GHz / Road 5. Field Strength of Spurious Emission / Above 1 GHz / Road BWS TECH Inc. 5 of 5 FCC Part 80 Certification Report No: BWS-06-RF-0010 Issue of Test : April 14, 2006 SAMYUNG ENC Co., Ltd. STR-6000A 6. Environment Test

Contact Information

Applicant

In-Joon Choi(Managing Director)
[email protected]82516016600Fax: 82514126616

Test Firm

BWS TECH INCCheol-Ho Lee
[email protected]82-31-333-5997Fax: 82-31-333-0017

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
380.1101(c)(4)156.525 MHz - 156.525 MHz25 W16K0G2B5 ppm
Confidentiality
Long Term
Grant Notes
Power output listed is conducted. The device must operate with a maximum duty factor not exceeding 50 % in order to satisfy RF exposure compliance requirements. This device must operate with the specific antennas and installation requirements described in this filing. The antennas used for this device must be installed to provide a separation distance of at least 90 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
