RP3-3833Tire Pressure Monitor Tool

Tire Pressure Monitor (TPM) System Tester Quick Start Guide EnglishSpanishFrench IMPORTANT NOTICES SAFETY DEFINITIONS All Danger, Warning, Important, and Note messages must be followed for your safety. These safety messages are in the following formats: DANGER: Means you may risk possible loss of life. WARNING: Means you may risk possible bodily harm. CAUTION: Means you risk damage to the vehicle or the tool. NOTE: Provide clarity and helpful tips. These safety messages cover situations SPX is aware of. SPX cannot know, evaluate and advise you as to all of the possible hazards. You must be certain that any conditions or service procedures encountered do not jeopardize your personal safety. COPYRIGHT No part of this manual may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of SPX. DISCLAIMER All information, illustrations, and specifications contained in this technical instruction manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without obligation to notify any person or organization of such revisions or changes. Further, SPX shall not be liable for errors contained herein or for incidental or consequential damages (including lost profits) in connection with the furnishing, performance or use of this material. FCC COMPLIANCE © 2005 SPX Corporation. All rights reserved. OTC Tire Pressure Monitor TesterModel: TPM 3833-1 FCC ID: RP3-3833 IC: 4811A-3833 This device complies with part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. English TPM Tester Quick Start Guidei English CONTENTS IMPORTANT NOTICES . . . . . . . . . . . . . . . . . . . . . . . . . . inside front cover Tester Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii How the TPM Tester Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Component Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Carrying Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 PC Software CD (NEED ACTUAL NAME ON IT??) . . . . . . . . . . . . . . . . .3 Sensor Activation Magnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Batteries (purchased separately) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 RS232 Serial Cable (purchased separately). . . . . . . . . . . . . . . . . . . . . . .3 TPM Tester . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Install the Tester Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Install the PC Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Access the Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Reset Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 SPX Corporation Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . 19 iiTPM Tester Quick Start Guide English Tester Specifications ARE THERE ANY TO INCLUDE HERE?? DIMENSIONS WEIGHT OPERATING TEMP STORAGE TEMP WAVEFORM TYPE AMPLITUDE POWER SOURCE SIGNAL OUTPUT ETC, ETC, ETC TPM Tester Quick Start Guidei English Safety Precautions DANGER: When an engine is operating, keep the service area WELL VENTILATED or attach a building exhaust removal system to the engine exhaust system. Engines produce carbon monoxide, an odor- less, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life. WARNINGS: •When working with hydraulic or fuel lines, liquids under pressure may escape and create a dangerous condition. Use adequate ventilation and make sure there are no sparks or possibility of sparks present that may ignite any vapor. •Wear an American National Standards Institute (ANSI) approved eye shield when testing or repairing vehicles. Objects propelled by whirling engine components or pressurized liquids escaping may cause personal injury. •Set the parking brake and block the wheels before testing or repairing a vehicle. It is especially important to block the wheels on front-wheel drive vehicles because the parking brake does not hold the drive wheels. •Do not drive the vehicle and operate the tester at the same time. Any distractions may cause an accident. Have one person operate the tester as another person drives the vehicle. •Maintain adequate clearance around moving components or belts during testing. Moving components and belts can catch loose clothing, body parts, or test equipment and cause serious damage or personal injury. •Automotive batteries contain sulfuric acid and produce explosive gases that can result in serious injury. To prevent ignition of gases, keep lit cigarettes, sparks, flames, and other ignition sources away from the battery at all times. •Refer to the service manual for the vehicle being serviced and adhere to all diagnostic procedures and precautions. Failure to do so could result in personal injury or otherwise unneeded repairs.…

Text truncated - open the document above for the full version.

315MHz RCVR CLK: 10.178MHz 433MHz RCVR CLK: 13.225MHz 125kHz HP XMTR Microprocessor ATMEGA2561 CLK: 8.00 MHz RS232 Interface 128x64 LCD Power Regulation 3 “C” Batteries Keypad Buzzer 125kHz MOD LP XMTR TPMT Block Diagram SPX Confidential

Tire Pressure Monitor ID Label Label Text: FCC ID# RP3 – 3833 IC ID# IC4811A - 3833

The Tire Pressure Monitor Tool (TPMT) Operation Overview The TPMT transmits and receives RF signals with automotive components. These functions are anticipated to be performed in automotive repair shops and tire changing facilities. Function The TPMT transmits at one frequency: 125kHz. The TPMT can additionally receive two different frequencies: 315MHz and 433MHz. The TPMT also has three different clock sources. 125kHz Transmission The 125kHz transmission can be generated as a pulsed signal or as a continuous wave signal. In other words it can create a 125kHz signal that is turned on and off at a rate of 4kHz with a variable duty cycle. It can also create a higher powered continuous wave signal. 315MHz & 433MHz Receptions The TPMT is capable of receiving these two frequencies in either FSK or ASK styles. Clock Sources The TPMT utilizes a 4MHz ceramic resonator for the microcontroller, which in turn uses a PLL to generate an 8MHz internal use clock signal. The high frequency transmitters and receivers make use of crystals at the following frequencies: 10.178MHz; 13.225MHz. Power Source 3 “C” cell alkaline batteries power the TPMT. Testing The operation of the TPMT during test will be dependent upon suggests provided by ITS on the best way to accurately test the TPMT.

CONTENTS 1.0 GENERAL DESCRIPTION........................................................................................................... 3 1.1 Related Submittals Grants ............................................................................................................... 3 1.2 Product Description ......................................................................................................................... 3 1.3 Test Methodology............................................................................................................................ 3 1.4 Test Facility ..................................................................................................................................... 3 2.0 SYSTEM TEST CONFIGURATION............................................................................................. 4 2.1 Justification...................................................................................................................................... 4 2.2 EUT Setup ....................................................................................................................................... 4 2.3 EUT Exercising Software ................................................................................................................ 4 2.4 Special Accessories ......................................................................................................................... 4 2.5 Equipment Modification .................................................................................................................. 4 2.6 Support Equipment List and Description ........................................................................................ 4 2.7 Test Configuration Block Diagrams ................................................................................................ 5 3.0 TEST RESULTS ............................................................................................................................. 6 3.2 Bandwidth of Emissions, FCC 15.215(c) ........................................................................................ 8 3.3 Radiated Emissions, FCC 15.109, Class A.................................................................................... 10 3.4 Test Procedure ............................................................................................................................... 11 3.5 Field Strength Calculation ............................................................................................................. 12 4.0 TEST EQUIPMENT..................................................................................................................... 13 FCC ID: RP3-3833 December, 2005 Page 3 of 15 1.0 GENERAL DESCRIPTION 1.1 Related Submittals Grants This is a single application of the SPX Service Solutions TPMT Tire Pressure Monitor for Certification under FCC Part 15, Subpart C. There are no other simultaneous applications. 1.2 Product Description TPMT Tire Pressure Monitor is a RF remote control transmitter operating in 125.683 KHz. The intended use of the TPMT Tire Pressure Monitor is to generate and transmit a RF signal to verify tire sensor functionality. The TPMT Tire Pressure Monitor is powered at 4.5Vdc with three “C” cell Alkaline Batteries. Antenna Description: Integrated antenna Sample Submitted: December 1, 2005 Test Work Started: December 1, 2005 Test Work Completed: December 5, 2005 1.3 Test Methodology Emission measurements were performed according to the procedures in ANSI C63.4-2003. All field strength radiated emissions measurements were performed in the semi-anechoic chamber, and for each scan, the procedure for maximizing emissions in Appendices D and E were followed. All field strength radiated tests were performed at an antenna to EUT distance of 3 and 10 meters, unless stated otherwise in the "Justification Section" of this Application. 1.4 Test Facility The test site facility used to collect the radiated and conducted measurement data is located at 7250 Hudson Blvd., Suite 100, Oakdale, Minnesota. This test facility has been fully described in a report dated on December 2005 submitted to FCC. Please reference the site registration number: 90706, dated December 6, 2005. FCC ID: RP3-3833 December, 2005 Page 4 of 15 2.0 SYSTEM TEST CONFIGURATION 2.1 Justification N/A 2.2 EUT Setup For simplicity of testing, the transmitter was enabled to transmit continuously. 2.3 EUT Exercising Software N/A 2.4 Special Accessories There are no special accessories necessary for compliance of these products. 2.5 Equipment Modification No modifications were installed during the testing. 2.6 Support Equipment List and Description N/A FCC ID: RP3-3833 December, 2005 Page 5 of 15 2.7 Test Configuration Block Diagrams The EUT was setup as tabletop equipment. The EUT was powered at 4.5VDC from new alkaline batteries Field Strength Measurements FCC ID: RP3-3833 December, 2005 Page 6 of 15 3.0 TEST RESULTS Data is included for the worst case configuration (the configuration which resulted in the highest emission levels). A sample calculation, configuration photographs, data tables and graphical representations of the emissions are included. The EUT is intended for operation under the requirements of Part 15 Subpart C. Specific test requirements include the following: 47 CFR 15.215(b), 15.209 Field Strength of Fundamental and Spurious Emissions 47 CFR 15.215(c) Bandwidth of Emissions 47 CFR 15.109 Radiated Emissions 47 CFR 15.107 Conducted Emissions (N/A battery operated device) FCC ID: RP3-3833 December, 2005 Page 7 of 15 3.1 Field Strength of Fundamental and Spurious Emissions, FCC 15.215(b), 15.209 Field Strength of Fundamental and Spurious Emissions measurements were made at Fundamental frequency of 125.683 KHz; Spurious Emissions were tested up to 1382.513 KHz (10 th harmonic). The Table 3-1-1 shows the Field Strength of Fundamental Radiation and Spurious Emissions for the TP…
