RPB-ZB02REMOTE

Operation instructions 1. After matching the key to the car, press 1the unlock key for 2 seconds to open the door and press 3the lock key for 2 seconds to close the door. 2、Press 2key for 3 seconds to open the trunk. Product parameters Rated voltage DC 3V Working current <5mA Operating voltage 1.8V~3.6V Transmit power >-20dbm Key operation force 200±50g Operating temperature -5°C +45°C Stand-by current 5uA transmitting frequency 433.95MHz±75KHz Modulation ASK Battery CR2032 Key durability More than 100,000 times 1 key:Unlock key 3key: Lock key 2key: Trunk key, used to open/close the trunk FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. IC WARNING This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device ADVERTENCIA IC Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS)d'Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis auxdeux conditions suivantes : (1) Cet appareil ne doit pas causer d'interférences. (2) Cet appareil doit accepter toutes les interférences, y compris celles susceptibles deprovoquer un fonctionnement indésirable de l'appareil. Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

DATE : September 7, 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: RPB-ZB02 Product Name: REMOTE Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this September 7, 2020 By: Terry Zhou Signature Printed Title: Engineer On behalf of : SHENZHEN YI CHE TECHNOLOGY CO.,LTD Telephone: +86-755-26738048 SHENZHEN YI CHE TECHNOLOGY CO.,LTD

FCC ID: RPB-ZB02

Label Size: 1.5x1.0cm FCC ID: RPB-ZB02 SHENZHEN YICHE TECHNOLOGY CO., LTD Model Name: REMOTE Model No.: ZB02 Location

FCC ID: RPB-ZB02

FCC ID: RPB-ZB02 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt For Worst case Mode: 433.95MHz Field strength =77.04 dBuV/m @3m Ant gain 0 dBi; so Ant numeric gain=1 So pt= {[10 (77.04/20) /10 6 x3] 2 /30x1} x 1000 mW =0.0152mW So (0.0152mW/5mm) x √0.43395GHz = 0.002<3 Then SAR evaluation is not required

FCC TEST REPORT FCC ID: RPB-ZB02 On Behalf of SHENZHEN YICHE TECHNOLOGY CO., LTD REMOTE Model No.: ZB02 Prepared for : SHENZHEN YICHE TECHNOLOGY CO., LTD Address : Room 201, Building A, 5#, Chuangwei Innovation Valley, Tangtou No.1 Road, Shiyan Subdistrict, Bao’an Shenzhen Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Report Number : A2006125-C01-R03 Date of Receipt : June 17, 2020 Date of Test : June 17, 2020– August 24, 2020 Date of Report : August 24, 2020 Version Number : V0 Page 2 of 29 Report No.: A2006125-C01-R03 Contents 1. General Information ............................................................................................................... 5 1.1. Description of Device (EUT) ...............................................................................5 1.2. Accessories of Device (EUT)...............................................................................6 1.3. Tested Supporting System Details .......................................................................6 1.4. Test Facility ..........................................................................................................6 2. Summary of test ...................................................................................................................... 7 2.1. Summary of test result .........................................................................................7 2.2. Block Diagram .....................................................................................................7 2.3. Test mode .............................................................................................................8 2.4. Test Conditions .....................................................................................................8 2.5. Measurement Uncertainty (95% confidence levels, k=2) ....................................8 2.6. Test Equipment .....................................................................................................9 3. Radiation Emission ............................................................................................................... 10 3.1. Radiation Emission Limits(15.209&231) ..........................................................10 3.2. Test Setup ...........................................................................................................10 3.3. Test Procedure .................................................................................................... 11 3.4. Test Equipment Setting For emission test. .........................................................12 3.5. Test Condition ....................................................................................................12 3.6. Test Result ..........................................................................................................12 4. Power Line Conducted Emission ......................................................................................... 16 4.1. Conducted Emission Limits (15.209) ................................................................16 4.2. Test Setup ...........................................................................................................16 4.3. Test Procedure ....................................................................................................16 4.4. Test Results ........................................................................................................17 5. Occupied bandwidth ............................................................................................................. 18 5.1. Test limit .............................................................................................................18 5.2. Method of measurement .....................................................................................18 5.3. Test Setup ...........................................................................................................18 5.4. Test Results ........................................................................................................18 6. Transmission time ................................................................................................................. 20 6.1. Test limit .............................................................................................................20 6.2. Method of measurement .....................................................................................20 6.3. Test Setup ...........................................................................................................20 6.4. Test Results ........................................................................................................20 7. Antenna Requirement .......................................................................................................... 22 7.1. Standard Requirement ........................................................................................22 7.2. Antenna Connected Construction ......................................................................22 7.3. Result..................................................................................................................22 8. Test setup photo .................................................................................................................... 23 9. Photos of EUT ....................................................................................................................... 24 Page 3 of 29 Report No.: A2006125-C01-R03 TEST REPORT DECLARATION Applicant : SHENZHEN YICHE TECHNOLOGY CO., LTD Address : Room 201, Building A, 5#, Chuangwei Innovation Valley, Tangtou No.1 Road, Shiyan Subdistrict, Bao’an Shenzhen Manufacturer : SHENZHEN YICHE TECHNOLOGY CO., LTD Address : Room 201, Building A, 5#, Chuangwei Innovation Valley, Tangtou No.1 Road, Shiyan Subdistrict, Bao’an Shenzhen EUT Descript…

Text truncated - open the document above for the full version.

FCC ID: RPB-ZB02 Photos of Radiated emission
