RPFMOUSEFUL1Mouseful

1. What is inside? 2. Connect 3. Install 4. Start program 5. Hand and fingers on mouse 6. User Guide Legal The User guide included in the CD is published by Digital Divide Systems (Pty.) Ltd. Improvements and changes to this user guide may be needed and made at any time without notice. Both the hardware and the software of this unique product are the subject of Intellectual Property rights. Any unauthorised reproduction or use of these components will constitute an infringement of these Intellectual Property rights. FCC Notice FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct The interference by one or more of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/TV technician for help This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note:“Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.”

AGENCY AUTHORIZATION LETTER FCC ID: RPFMOUSEFUL1 Date: Feb.25,2013 To whom it may concern: We, the undersigned, hereby authorize Shenzhen Huatongwei International Co.,Ltd of China to act on our behalf, as our agent in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification, Any act carried out by Shenzhen Huatongwei International Co.,Ltd. within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely, (签名人英文名): Diego Canedo (签名人职称): Director DIGITAL DIVIDE SYSTEMS PTY LTD Tel: +27 83 947 1067 Fax: +27 21 4246568 E-mail: [email protected]

Letter for Confidentiality Federal Communications Commission Authorization and Evaluation Division Date: Feb.25,2013 Confidentiality Request regarding application for certification of FCC ID: RPFMOUSEFUL1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1.Schematic 2.Theory of Operation 3.Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, We do not want these documents to be accessible to the general public. Sincerely, (签名人英文名): Diego Canedo (签名人职称): Director DIGITAL DIVIDE SYSTEMS PTY LTD Tel: +27 83 947 1067 Fax: +27 21 4246568 E-mail: [email protected]

External Photos

Label Location

Internal Photos

FCC PART 15 SUBPART B TEST REPORT FCC PART 15 B Report Reference No......................: TRE13010013 R/C:90755 FCC ID..............................................: RPFMOUSEFUL1 Compiled by ( position+printed name+signature)..: File administrators Eric Zhang Supervised by ( position+printed name+signature)..: Test Engineer Tim Zhang Approved by ( position+printed name+signature)..: Manager Wenliang Li Date of issue.....................................: Jan 18, 2013 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: DIGITAL DIVIDE SYSTEMS PTY LTD. Address ............................................: 505 The Studios,112 Buitengragt St.,Cape Town 8001,South Africa Test specification: Standard ...........................................: FCC Part 15 B- Unintentional Radiators TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Mouseful Trade Mark .......................................: / Model/Type reference.......................: Mouseful1 Listed Models ..................................: / Result................................................: Positive Report No.: TRE13010013 Page 2 of 22 Issued:2013-01-18 T E S T R E P O R T Test Report No. : TRE13010013 Jan 18, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mouseful Model /Type : Mouseful1 Listed Models : / Applicant : DIGITAL DIVIDE SYSTEMS PTY LTD. Address : 505 The Studios,112 Buitengragt St.,Cape Town 8001,South Africa Manufacturer Zhuhai Yuehua Electronic Co.,Ltd Address 13, No.4 Pingdong Road, Nanping Technology District, Zhuhai, Guangdong, China 519060 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE13010013 Page 3 of 22 Issued:2013-01-18 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. Configuration of Tested System 5 2.5. EUT configuration 6 2.6. EUT operation mode 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Statement of the measurement uncertainty 8 3.5. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 13 5. TEST SETUP PHOTOS OF THE EUT .......................................... 17 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 18 Report No.: TRE13010013 Page 4 of 22 Issued:2013-01-18 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15 Subpart B - Unintentional Radiators ANSI C63.4-2009: American National Standard for Methods of Measurement of Radio-Noise Emissions From Low Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz. Report No.: TRE13010013 Page 5 of 22 Issued:2013-01-18 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Jan 08, 2013 Testing commenced on : Jan 10, 2013 Testing concluded on : Jan 18, 2013 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 5V for USB Port 2.3. Short description of the Equipment under Test (EUT) The EUT is a Mouseful,the Sample models are as follow: Serial number: Prototype 2.4. Configuration of Tested System Fig. 2-1 Configuration of Tested System 1.0 Meter 1.5 Meter Non-Conducting Table 80 cm above Ground Plane PC Monitor EUT Report No.: TRE13010013 Page 6 of 22 Issued:2013-01-18 2.5. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ○ - supplied by the manufacturer ● - supplied by the lab Support Equipment List and Details Manufacturer Description Model Serial Number FCC ID Toyoplas LCD Monitor N/A N/A N/A Dell PC 380 N/A N/A External I/O Cable Cable Description Length (m)From/Port To Shielded Detachable VGA Cable 0.8 EUT Monitor or PC 2.6. EUT operation mode The EUT has been tested under typical operating condition. 2.7. Related Submittal(s) / Grant (s) This submittal(s) (test report) of FCC ID: RPFMOUSEFUL1 filing to comply with the FCC Part 15, Subpart B Rules. 2.8. Modifications No modifications were implemented to meet testing criteria. Report No.: TRE13010013 Page 7 of 22 Issued:2013-01-18 3. TEST ENVIRONMENT 3.1. Address of the test laboratory Shenzhen Huatongwei International Inspection Co., Ltd Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Phone: 86-755-26715686 Fax: 86-755-26748089 The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 (2009) and CISPR Publicati…
