RQD-PD800Cordless Phasing Tester

whilesafetyline. The White Rubber Corporation Operating Instructions PD80OW Cordless Phasing Tester Bierer Patent No. 6,617,840 B2 and 6,734,658. Other patents pending. CAUTION The equipment covered in these operating instructions should be used by qualified employees, trained in and familiar with the safety-related work practices, safety rules and other safety requirements associated with the use of this type of equipment. These instructions are not intended as a substitute for adequate training, nor do they cover all details or situations which could be encountered in relation to the operation of this type of equipment. WARNING Use appropriate length live line tool for voltage being worked and maintain minimum approach distances as outlined in OSHA 1910.269,Table R-6. Do not let live line tool fittings become grounded in any way. This may damage the equipment Meter housing shall be considerednon-insulating.Meter should NOT be used as an insulating tool. The high voltage probe assemblies shall be wiped clean prior to each use with a silicone impregnated cloth and kept clean and free of contaminates to prevent tracking on the outside of the probe, which could affectthe accuracy of the meter and/or failure; resulting in personal injury and/or equipment damage. NOTICE Before operating this equipment, read, understand and follow all instructions contained in this manual. Keep instructions with equipment. CONTENTS Design and Function1 Set-Up Testing and Inspection 2 Battery Replacement 2 Phase Angle Measurments Direct Contact from240Vto69kV Including Capaciltive Test Points3 Delta/Wye Measurements3 Phase Angle Measurements Non -Contact from69kVto800kV 4 Testing Phase Sequence5 Voltage Indications URD and Overhead Direct Contact from4kVto69kV 6 Reference Probe as Voltage Detector Direct Contact Non-Contact 7 FCC Compliance Information Statement8 Parts & Accessories9 DESIGN AND FUNCTION The cordless PD80OW is designed to operate similar to a conventional phasing tester, but is easier to use because it does not require an interconnect cable. The unit consists of a Reference Probe (transmitter) and a Meter Probe (receiver) and will operate reliably at distances up to 70 feet. The phasing tester is useable from 240V to 8OOkV. Each unit has a five-position switch for the following functions: • Off– Unit off for storage or transport. • Deg- Phase angle measurement in degrees for use on Secondary, URD and Overhead. Direct contact from 240V to 69kV(including capacitive test points). Non-contact from 69kV to 800kV (without the use of extension resistors). • URD– Phasing Underground Residential Distribution with Voltage Indications. Direct contact from 4kV to 35kV(not for capacitive test points). • OH– Phasing Over-Head conductors with voltage indications Direct contact from 4kV to 69kV. • T– Tests basic meter function and displays the internal 9V battery voltage. Voltage indications and degree readings are supplemented with phase indicator lights on the Meter Probe for dual confirmation of the phase relationship between the Reference Probe and Meter probe. • White - • Blue - • Red indicates an in-phase condition. indicates out-of -phase condition of 120 degrees. indicates an out-of-phase condition of 240 degrees. • Yellow ''DY''-blinking light indicates a Delta/Wye transformation (30 degree phase shift) in conjunction with one of the other three phase indicator lights. Note 1:For best results, always hold the Reference Probe and Meter Probe perpendicular to the conductors being tested and away from all other conductive surfaces such as adjacent phases, neutrals and grounded structures. Maintain a minimum distance of two feet between the body of the probes and all other conductors or grounded surfaces. Maintain a minimum distance of two feet between yourhands and the body of the probe regardless of the voltage being tested. Never hold the tester with rubber gloves when in use. Note 2:When phasing on URD transformer bushings use 8128TBALB Bushing Adapters on both the Reference and the Meter Probe. 1 SET UP- TESTING and INSPECTION Testing the Meter Probe: The Meter Probe completes a self check each time the selector switch is moved from one position to another. It displays the number 510 +/- 5 (full scale) and blinks 0, 120, 240 phase sequence indicator lights followed by a blinking DY (Delta/ Wye Transformation) indicator light. Test: The internal 9V battery voltage may be checked by turning the rotary selector switch to the T position and holding for several seconds until the indicator lights stop blinking. If the battery voltage displayed is less than 8 volts, shown on the meter as 80, the battery should be replaced. A standard 9 volt battery is located behindthe live line tool attachment. Testing the Reference Probe: Turn theMeter Probe selector switchto the URD or OH position. The results of the Reference Probe self checks will be displayed on theMeter Probe.Each time the selector switch on the Reference Probe is moved from one position to another, the number 51 0 will be displayed on theMeter Probefor several seconds. Test: The internal 9V battery is checked by turning the selector switch to the T position and holding for several seconds. The internal battery voltage of the reference will be displayed on the Meter Probe. If the battery voltage displayed on the Meter Probe is less than 8V, shown on meter as 80, the battery should be replaced. A standard 9 volt batteryis located behind the live line tool attachment. Physical Inspection: Both the Reference Probe and Meter Probe should be clean and free of dirt, grease and other contaminants. The unit should not be used if any portion of either the Meter Probe or the Reference Probe is cracked or damaged in any way. Battery Replacement A standard 9 volt battery is located behind the 5/8" x 1 1 " threaded live line tool fitting on the probe housing. Two flat edges are furnished for use with a wrench or slip joint pliers to remove and install the fitting…

Text truncated - open the document above for the full version.

May 1, 2006 Compatible Electronics TCB 114 Olinda Drive Brea, California92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc. as an Agent for Bierer and Associates having principal offices at 11142 Wilson Blvd. Blythewood SC, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the followingBierer and Associatesproduct: PD800W Phasing Tester under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept this letter as an attestation that neitherBierer and Associatesnor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti- Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition,Bierer and Associateswill notify the Federal Communications Commission if, at any time, the situation changes causing Bierer and Associatesto be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at803-786-4839. Sincerely, Jan F. Kennerly Jr. VP Engineering & Operations

Bierer & Associates, Inc.11142 Wilson Blvd., Blythewood, S.C. 29016 Telephone: (803) 786- 4839Mobile: (803) 917-7296Fax: (803) 786-4839 April 27, 2006 Federal Communications Commission 7435 Oakland Mills Road Columbia, Maryland 21046 Gentlemen: In Reference to PD800W: Confidentiality Pursuant to 47 CFR 0.457(d) of the FCC Rules, information that is considered “trade secret” and not routinely available to the public may be withheld from public inspection if a request for non-disclosure issubmitted pursuant to CFR 0.459 Certain material being submitte4d to the FCC in the form of a Block Diagram and Schematic with specific component information and labeled Diagram1 PD800WTransmitter is considered a “Trade Secret” and not available toanyone other than the technical staff at Bierer &Associates, Inc. The design, layout and specific components contained on the Block Diagramwere obtained at considerable expense to Bierer and Associates, Inc. and we request confidentiality pertaining to Block Diagram and Schematic and it be unavailable on the FCC website. Sincerely, Jan F. Kennerly Jr. VP Engineering &Operations

Bierer Model PD800W FCC ID: RQD – PD800 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference and (2)This device must accept any interference received, including interference that may cause undesired operation. SN 10573

Report Number: B60419D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Phasing Tester Model: PD800W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 14 FCC PART 15, SUBPART B and C TEST REPORT for CORDLESS PHASING TESTER MODEL: PD800W Prepared for BIERER & ASSOCIATES, INC. 11142 WILSON BOLUEVARD BLYTHEWOOD, SC 29016 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: MAY 10, 2006 REPORT APPENDICES TOTAL BODY A B C D E PAGES 15 2 2 2 12 10 43 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B60419D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Phasing Tester Model: PD800W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 14 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Radiated Emissions (Spurious and Harmonics) Test 13 8. CONCLUSIONS 15 Report Number: B60419D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Phasing Tester Model: PD800W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 14 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of 3 Meter Radiated Site Report Number: B60419D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Phasing Tester Model: PD800W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 14 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Cordless Phasing Tester Model: PD800W S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Bierer & Associates, Inc. 183 Wilson Boulevard Blythewood, SC 29016 Test Date: April 19, 2006 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209 and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed because the EUT operates on DC power only and cannot be plugged into the AC public mains. 2 Radiated RF Emissions, 10 kHz - 9200 MHz (Transmitter Portion) Complies with the limits of CFR Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.249. 3 Radiated RF Emissions, 30 MHz - 1000 MHz (Digital Portion) Complies with the Class A limits of CFR Title 47, Part 15, Subpart B. Report Number: B60419D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Phasing Tester Model: PD800W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 14 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Cordless Phasing Tester Model: PD800W. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B for the digital portion; and the limits defi…
