1 Helen Zhao Subject:FW: QiaoHua (HongKong) Holding Ltd., FCC ID: RRVQH-919, Assessment NO.: AN05T4652 operational_modifie d.ZIP From: Weili Sent: Tuesday, March 22, 2005 11:19 AM To: Helen Zhao Subject: Re: QiaoHua (HongKong) Holding Ltd., FCC ID: RRVQH-919, Assessment NO.: AN05T4652 Hi, Helen. Here are the anwers. Question #1: Form 731 listed 15.231(e) as the applicable rule part, but the test report shows 15.231(b) limit, please verify which one is correct. Also please recalculate the limit for 315MHz and update the test report. THE APPLICABLE LIMIT IS 15.231(B). SORRY FOR TYPO. PLEASE SEE REVISED TEST REPORT. Question #2: The test report does not show that the radiated spurious emission upto 10th harmonic of the fundamental frequency has been investigated. Please explain. UP TO 10TH HARMONICS ARE INVESTIGATED. NO SIGNIFICANT SIGNALS ARE SHOWN ABOVE 1500MHZ. PLEASE SEE REVISED TEST REPORT. Question #3: The report said the device is powered by DC 12V battery, but the operational description said it is powered by 2 x AA size battery (3V). Please clarify which statement is correct and revise the relevant document to keep consistent. TYPO. SEE REVISED OPERATIONAL DESCRIPTION. Question #4: The user manual said "Shielded cable must be used with the equipement" which is not the case for this application. Please remove this statement from the user manual. PLEASE SEE REVISED USER MANUAL. Thanks a lot. Wei

FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 17 Front View FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 18 Rear View

FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 8 2. PRODUCT LABELING Figure 2.1 FCC ID Label Figure 2.2 Location of Label on Back of the EUT FCC LABEL FCC ID: RRVQH-919 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference. and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 19 Open View FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 20 Component Side FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 21 Foil Side

FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 12 4. SYSTEM SCHEMATICS Figure 4.1 System Schematics

ELECTROMAGNETIC EMISSION COMPLIANCE REPORT of B/O DOORCHIME TRANSMITTER MODEL: QH-919 (QH-918/917/916/915/913/912/727) FCC ID: RRVQH-919 March 14, 2005 This report concerns (check one): Original grant x Class II change Equipment type: TRANSMITTER Deferred grant requested per 47 CF 0.457(d)(1)(ii)? yes no x If yes, defer until: (date) Company agrees to notify the Commission by (date) of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? yes no x If no, assumed Part 15, Subpart B for unintentional radiators - the new 47 CFR [10-1-90 Edition] provision. Report prepared for: QIAOHUA (HONK KONG) HOLDINGLTD. Report prepared by: Advanced Compliance Lab Report number: 0048-050311-01 The test result in this report IS supported and covered by the NVLAP accreditation 6 Randolph Way Hillsborough, NJ 08844 Tel: (908) 927 9288 Fax: (908) 927 0728 Advanced Compliance Laboratory FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 2 Table of Contents Report Cover Page.........................................................................................................1 Table of Contents............................................................................................................2 Figures.............................................................................................................................3 1. GENERAL INFORMATION....................................................................................4 1.1 Verification of Compliance...........................................................................4 1.2 Equipment Modifications..............................................................................5 1.3 Product Information......................................................................................6 1.4 Test Methodology.........................................................................................6 1.5 Test Facility...................................................................................................6 1.6 Test Equipment.............................................................................................6 1.7 Statement of the Document Use..................................................................7 2. PRODUCT LABELING.............................................................................................8 3. SYSTEM TEST CONFIGURATION........................................................................9 3.1 Justification...................................................................................................9 3.2 Special Accessories......................................................................................9 3.3 Configuration of Tested System...................................................................9 4. SYSTEM SCHEMATICS..........................................................................................12 5. RADIATED EMISSION DATA...............................................................................13 5.1 Field Strength Calculation............................................................................13 5.2 Test Methods and Conditions......................................................................13 5.3 Test Data.......................................................................................................14 5.4 Occupied Bandwidth.....................................................................................15 6. PHOTOS OF TESTED EUT......................................................................................16 FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 3 Figures Figure 2.1 FCC ID Label................................................................................................8 Figure 2.2 Location of Label on Back of the EUT........................................................8 Figure 3.1 Radiated Test Setup, Position 1...................................................................10 Figure 3.2 Radiated Test Setup, Position 2...................................................................10 Figure 3.3 Radiated Test Setup, Position 3...................................................................11 Figure 4.1 EUT Schematics............................................................................................12 Figure 5.1 Occupied Bandwidth......................................................................................15 Figure 6.1 Front View.....................................................................................................17 Figure 6.2 Rear View......................................................................................................18 Figure 6.3 Inside View, Cover Opened..........................................................................19 Figure 6.4 Component Side............................................................................................20 Figure 6.5 Foil Side.........................................................................................................21 FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 4 1. GENERAL INFORMATION 1.1 Verification of Compliance EUT: B/O DOORCHIME TRANSMITTER Model: QH-919-TX Applicant: QIAOHUA (HONK KONG) HOLDING LTD. Test Type: FCC Part 15C CERTIFICATION Result: PASS Tested by: ADVANCED COMPLIANCE LAB Test Date: March 14, 2005 Report Number: 0048-050314-01 The above equipment was tested by Advanced Compliance Lab. Compliance Laboratory for compliance with the requirement set forth in the FCC rules and regulations Part 15, subpart C. This said equipment in the configuration de…

Text truncated - open the document above for the full version.

FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 10 Figure 3.1 Radiated Test Setup, Position 1-X Figure 3.2 Radiated Test Setup, Position 2 -Y FCC ID: RRVQH-919 ——————————————————————————————————————————————— Advanced Compliance Lab 6 Randolph Way, Hillsborough, NJ 08844 Tel: (908) 927-9288 Fax: (908) 927-0728 11 Figure 3.3 Radiated Test Setup, Position 3-Z
