RSBPBBT2709Portable Boombox

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS

流水号贴纸 FCC铭牌贴纸 58*22mm FCC ID:RSBPBBT2709 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC铭牌+警告贴纸 60*45mm

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Antenna

Page 1 of 29 FCC RADIO TEST REPORT FCC ID:RSBPBBT2709 Product： Portable Boombox Trade Name：AXESS Model Name：PBBT2709,BK-222A, BK-222B, BK-222C, BK-222D, BK-222E, BK-222F, BK-222G, BK-222H, BK-222N Prepared for BK Pride Electronics Co.,Ltd Book Digital Industry Park,Meilin District,Dalingshan Town,Dongguan City,Guangdong Province,China.,P.R.C.523820 Prepared by DongGuan Precise Testing Service Co.,Ltd. Building D, Baoding Technology Park, Guangming Road 2, Guangming Community, Dongcheng District, Dongguan, Guangdong, China Report No.: PT1503058027F Page 2 of 29 TEST RESULT CERTIFICATION Applicant’s name ........ BK Pride Electronics Co.,Ltd Address ................... .... Book Digital Industry Park,Meilin District,Dalingshan Town, Dongguan City,Guangdong Province,China.,P.R.C.523820 Manufacture's Name... BK Pride Electronics Co.,Ltd Address ........................ Book Digital Industry Park,Meilin District,Dalingshan Town, Dongguan City,Guangdong Province,China.,P.R.C.523820 Product description Product name ... ... ........... Portable Boombox Model and/or type reference ..................... PBBT2709,BK-222A, BK-222B, BK-222C, BK-222D, BK-222E, BK-222F, BK-222G, BK-222H, BK-222N In all, the original product and the alternative product are the same. Standards .................... FCC Part15.249 Test procedure ................ ANSI C63.4-2014 This device described above has been tested by PTS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of PTS, this document may be altered or revised by PTS, personal only, and shall be noted in the revision of the document. Date of Test .................... ................ .. Date (s) of performance of test s ....... Mar. 20, 2015 ~ Mar. 31, 2015 Date of Issue ..................................... Apr. 3, 2015 Test Result......................................... Pass Tested by : Authorized Signatory : Maike Huang / Engineer Chris Du / Manager Report No.: PT1503058027F Page 3 of 29 2 Test Summary Test Items Test Requirement Result Spurious Radiated Emissions 15.205(a) 15.209 15.249(d) PASS Band edge Emissions 15.249(d) PASS Conducted Emissions 15.207 PASS 20dB Bandwidth 15.215c 15.249 PASS Report No.: PT1503058027F DongGuan Precise Testing Service Co., Ltd Page 4 of 29 TABLE OF CONTENTS 2 TEST SUMMARY 3 3 GENERAL INFORMATION 5 3.1 GENERAL DESCRIPTION OF E.U.T. 5 3.2 DETAILS OF E.U.T. 5 3.3 CHANNEL LIST 5 3.4 DESCRIPTION OF SUPPORT UNITS 5 3.5 TEST FACILITY 6 4 EQUIPMENT USED DURING TEST 7 4.1 EQUIPMENTS LIST 7 4.2 MEASUREMENT UNCERTAINTY 7 4.3 TEST EQUIPMENT CALIBRATION 8 5 CONDUCTED EMISSION 9 5.1 E.U.T. OPERATION 9 5.2 EUT SETUP 9 5.3 CONDUCTED EMISSION TEST RESULT 10 6 SPURIOUS RADIATED EMISSIONS 12 6.1 EUT OPERATION : 12 6.2 TEST SETUP 13 6.3 SPECTRUM ANALYZER SETUP 14 6.4 TEST PROCEDURE 15 6.5 CORRECTED AMPLITUDE & MARGIN CALCULATION 15 6.6 SUMMARY OF TEST RESULTS 15 7 BAND EDGE MEASUREMENT 20 7.1 TEST PROCEDURE 20 7.2 TEST RESULT: 20 8 20 DB BANDWIDTH MEASUREMENT 22 8.1 TEST PROCEDURE: 22 8.2 TEST RESULT: 22 9 ANTENNA REQUIREMENT 29 Report No.: PT1503058027F DongGuan Precise Testing Service Co., Ltd Page 5 of 29 3 General Information 3.1 General Description of E.U.T. Product Name : Portable Boombox Model No. : PBBT2709,BK-222A, BK-222B, BK-222C, BK-222D, BK-222E, BK-222F, BK-222G, BK-222H, BK-222N Brand Name : AXESS Operation Frequency : 2402MHz ~ 2480MHz,79 channels in total, separated by 1MHz Type of Modulation : GFSK, Pi/4DQPSK, 8DPSK Antenna installation : PCB Printed Antenna Antenna Gain : 0 dBi Bluetooth version : 2.1+EDR hardware version :BKV0.1 software version :V1.0 Serial number :01 3.2 Details of E.U.T. Technical Data : (1)AC 120V/60Hz 3.3 Channel List Channel No. Frequency (MHz) Channel No. Frequency (MHz) Channel No. Frequency (MHz) Channel No. Frequency (MHz) 1 2402 2 2403 3 2404 4 2405 5 2406 6 2407 7 2408 8 2409 9 2410 10 2411 11 2412 12 2413 13 2414 14 2415 15 2416 16 2417 17 2418 18 2419 19 2420 20 2421 21 2422 22 2423 23 2424 24 2425 25 2426 26 2427 27 2428 28 2429 29 2430 30 2431 31 2432 32 2433 33 2434 34 2435 35 2436 36 2437 37 2438 38 2439 39 2440 40 2441 41 2442 42 2443 43 2444 44 2445 45 2446 46 2447 47 2448 48 2449 49 2450 50 2451 51 2452 52 2453 53 2454 54 2455 55 2456 56 2457 57 2458 58 2459 59 2460 60 2461 61 2462 62 2463 63 2464 64 2465 65 2466 66 2467 67 2468 68 2469 69 2470 70 2471 71 2472 72 2473 73 2474 74 2475 75 2476 76 2477 77 2478 78 2479 79 2480 - - 3.4 Description of Support Units No. Equipment Manufacturer Model No. Serial No. 1. N/A N/A N/A N/A Report No.: PT1503058027F DongGuan Precise Testing Service Co., Ltd Page 6 of 29 3.5 Test Facility The test facility has a test site registered with the following organizations: Dongguan Quality Supervision Testing Center Add.: B#, Dongguan Quality Supervision Testing Center, NO.2 South Industry Road, Songshan Lake, Dongguan City, 523808, China. FCC Registration No.: 817095 . Report No.: PT1503058027F DongGuan Precise Testing Service Co., Ltd Page 7 of 29 4 Equipment Used during Test 4.1 Equipments List Mains Terminal Disturbance Voltage (Conducted Emission) Item Equipment Manufacturer Model No. Serial No. Last Cal. Next Due CAL Date 1. EMI Test Receiver R&S ESCI 100229 2014/10/25 2015/10/24 2 LISN SCHWARZBECK NSLK8127 8127437 2014/10/25 2015/10/24 3 LISN R&S ESH3-Z6 100690 2014/10/25 2015/10/24 4 Pulse Limiter R&S ESH3-Z2 101242 2014/10/25 2015/10/24 5 Cable DTB 944 cable 1# 944001 2014/10/25 2015/10/24 3m Semi-anechoic Chamber for Radiation Item Equipment Manufacturer Model No. Serial No. Last Cal. Next Due CAL Date 1 EMI Test Receiver R&S ESCI 100229 2014/10/25 2015/10/24 2 Trilog-Broadband Antenna SCHWARZBECK VULB9163 9613-248 2014/11/01 2015/10/31 3 Horn antenna (1~18GHz) R&S HF906 EC348 2014/11/01 2015/10/31 4 Horn antenna (18~25GHz) SCHWARZBECK BBH…
