RUE-RCTRSRXUHF Receiver RC-TRS-RX

RC-TRS Radio Remote Control System TECNORD SERVOCOMANDI E REGOLAZIONE User’s Manual TECNORD RC-TRS User’s Manual Page 2/17 Write the System Number of your Radio Remote Control Equipment here and keep it as a reference for technical support. Using the radio Control is forbidden for anybody who has not read and fully understood this manual. Special attention should be given to the safety instructions herein contained. All reproduction rights, either through photocopies or computer means or supports, are reserved. All texts, illustrations, and drawings are the propriety of TECNORD and their use can only be granted prior to the formal permission of TECNORD. The technical features of the Radio Control as described in this Manual may be subsequentely modified without notice with the sole purpose of improving the equipment to better satisfy the user. Changes or modifications not expressly approved by TECNORD could voice the user's authority to operate the equipment Author: PM Version: 1.0 Date: 12 February 2004 Tecnord Srl Via Decorati al Valor Militare, 3 Baggiovara 41100 Modena – Italy e-mail: [email protected] web: http://www.tecnord.com TECNORD RC-TRS User’s Manual Page 3/17 1 SAFETY......................................................................................................................................................................4 1.1 SAFETY OF THE RADIO CONTROL SYSTEM.............................................................................................................4 1.2 SAFETY INFORMATION.............................................................................................................................................4 1.3 AUTHORIZED OPERATORS.......................................................................................................................................4 1.4 SAFETY MEASURES TO BE TAKEN WITHIN THE WORKING AREA............................................................................4 1.5 PROTECTION DEVICES.............................................................................................................................................5 1.6 HOW TO REACT AND BEHAVE IN CASE OF AN EMERGENCY....................................................................................5 2 RC-TRS SYSTEM’S COMPONENTS....................................................................................................................5 2.1 RC-TRS-TX CONTROL CONFIGURATIONS............................................................................................................6 3 INSTALLATION.......................................................................................................................................................7 3.1 RC-TRS-RX SAMPLE DRAWING..............................................................................................................................7 3.2 RC-TRS-TX SAMPLE DRAWINGS............................................................................................................................8 3.3 POSITIONING THE RECEIVER...................................................................................................................................8 3.4 OUTSIDE ELECTRICAL CONNECTIONS.....................................................................................................................9 4 OPERATION...........................................................................................................................................................10 4.1 THE RADIO TRANSMISSION AND SERVICING SYSTEM............................................................................................10 4.2 USE OF BATTERIES.................................................................................................................................................10 4.3 THE BATTERY CHARGER AND RE-CHARGEABLE BATTERIES................................................................................10 4.4 CONTROL ELEMENTS.............................................................................................................................................11 4.5 VISUAL CHECK.......................................................................................................................................................11 4.6 SAFETY CONTROL AND START-UP OF THE RADIO CONTROL...............................................................................11 4.7 FUNCTIONS OPERATION.........................................................................................................................................12 4.8 DIAGNOSTICS..........................................................................................................................................................12 4.9 OPERATING PROBLEMS..........................................................................................................................................13 4.10 TROUBLESHOOTING TABLE..................................................................................................................................14 5 MAINTENANCE.....................................................................................................................................................15 6 DISPOSAL................................................................................................................................................................15 7 TECHNICAL DATA...............................................................................................................................................16 7.1 TRANSMITTER (RC-TRS-TX)...............................................................................................................................16 7.2 RECEIVER (RC-TRS-RX)......................................................................................................................................16 7.3 COMMUNICATION PROTOCOL.......................................................…

Text truncated - open the document above for the full version.

Response to TCB Findings 1. Please specify the label material The label material is metallized polyester. 2. Please explain why AC line conducted emissions test was not conducted on the device. This device is powered by a pure DC supply (vehicle battery). 3. There seems to be a cable connection between the receiver and the transmitter in the radiated emissions test set-up photo. Please clarify the purpose of this direct connection in terms of functionality. The cable you see is a service cable; it is used for the purpose of recharging the batteries of the transmitter and is not connected during normal operation

T T E E C C N N O O R R D D TECNORD S.r.l. RC-TRS-RX Operational Description.doc via Decorati al Valor Militare, 3 41040 Baggiovara (MO) – ITALY page 1 of 2 Tel. (+39) 059-510-001 Fax. (+39) 059-511-357 Web: http://www.tecnord.com RC-TRS-RX Operational Description RC-TRS receiver (RC-TRS-RX) decodes messages sent by its coupled transmitter unit and actuates the corresponding functions. The functions can be actuated with simple on-off commands or with a proportional regulation. A three-digits 7-segments display provides additional diagnostic information. Several analog and digital inputs are available for monitoring the actuated machine’s status. Figure 1 shows the RC-TRS-RX unit. Figure 1 – RC-TRS receiver unit. SPECIFICATIONS Housing material Stainless steel Weight < 1 kg Antenna external / waterproof connection Temperature range -25°C ÷ +70°C Power supply 8.5 ÷ 30 Vdc Diagnostics three-digits, 7-segments display Analog inputs 3 (8 bit resolution, 0.5 VDC) Power Outputs 14 x 5A or 12x5A and 2x PWM PWM outputs 2 (0-1A) Analog Outputs 6 (0-5V) T T E E C C N N O O R R D D TECNORD S.r.l. RC-TRS-RX Operational Description.doc via Decorati al Valor Militare, 3 41040 Baggiovara (MO) – ITALY page 2 of 2 Tel. (+39) 059-510-001 Fax. (+39) 059-511-357 Web: http://www.tecnord.com OPERATIONAL DESCRIPTION When the power supply is turned on, a short self-diagnosys cycle is performed and then the unit is ready for operation. The RC-TRS-RX decodes only messages coming from its coupled RC-TRS transmitter: a security RF identifier (unique for each tx/rx pair) is stored in a non-volatile memory. A front connector is available for connecting the coupled transmitter unit via a service cable. The service cable is used for charging the transmitter’s batteries as well as to provide a secure backup communication channel (an RS-485 line) in case of highly disturbed environments. First Time Operation Before operating for the first time a receiver with its transmitter unit, the proportional trigger’s acquisition procedure must be performed (see user’s manual for details on the proportional trigger’s acquisition procedure). Normal Operation ÿ The receiver continously waits for messages coming from its coupled transmitter unit. Messages are decoded and the corresponding functions (on-off or proportional) are actuated. ÿ All messages are checked for correspondance of the unique RF identifier. Messages that fail this check are discarded. ÿ All messages have an error control field that is always checked. Errored messages are discarded. ÿ When no valid messages are received, the unit automatically turns all active functions off. ÿ Proportional functions must be activated with their associated on-off switch and then the proportional trigger can be actuated; functions that fail this sequence are not activated. ÿ Depending on customer’s requirements the display can show the receiver’s actual status as well as a variety of diagnostic information (see user’s manual for details on the diagnostic information available). ÿ The function’s parameters are adjustable via a calibration tool (see user’s manual for details on how to set function’s parameters using the calibration tool).

BILL OF MATERIALS24.0102.099 REV.B RX MODULE Designed by: R:BRAGLIA Checked by: P.MALAGOLI Approved by: G:RIGHI Date: Dec. 23, 2003 ItemQuantityReferencePart 52C10,C11100n 111J2MICS8 121J3R113.665.000 131J4MICS12 141L1DO3316P-224 151Q1BC807BLT1 203R5,R6,R72K2 231U2CDPRX02 251U5M24C16 TECNORD Srl Via Decorati al Valor Militare 3 41040 Baggiovara (MO) - Italy Tel. 0039 - 059.51.0001 - Fax 059.51.1357 - e-mail [email protected]

Master: PT15-SubB-15109 Date: October 17, 2001 Test Report: 4W07778.1 Applicant: Tecnord S.r.I Via Decorati al Valor Militare, 3 Baggiovara, MO, Italy 41040 Equipment Under Test: RC-TRS-RX, 458MHz Receiver (EUT) In Accordance With: FCC Part 15, Subpart B, 15.109 Tested By: Nemko Canada Inc. 303 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: Kevin Carr, EMC Specialist Date: 3 February 2004 Total Number of Pages: 10 Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 2 of 10 Table Of Contents Section 1. Summary of Test Results ...................................................................................3 Section 2. General Equipment Specification......................................................................5 Section 3. Radiated Emissions .............................................................................................6 Section 4. Block Diagrams ...................................................................................................9 Section 5. Test Equipment List .........................................................................................10 Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 3 of 10 Section 1. Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15, Subpart B. Measurement procedure ANSI C63.4-1992 was used for all tests. Radiated Emissions were measured on an open area test site. A description of the test facility is on file with the FCC. THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: ______________________________ DATE: 3 February 2004 Glen Westwell, Wireless Technologist Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation. Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 4 of 10 Summary Of Test Data Name Of Test Para. No. Results Antenna Conducted Emissions 15.111 N/A (1) Radiated Emissions 15.109 Complies Powerline Conducted Emissions 15.107 N/A (2) Note: (1) This device does not have access for conducted measurements. (2) This device is DC powered 12-24Vdc. Test Conditions: Indoor Temperature: 24°C Humidity: 2% Outdoor Temperature: 10°C Humidity: 64% 12-24Vdc 458MHz RX (EUT) Battery Charger Cable Radio TX System Control Wiring EUT Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 5 of 10 Section 2. General Equipment Specification Manufacturer: Technord Model No.: RC-TRS-RX, 458MHz Receiver Serial No.: Sample#3 Date Received In Laboratory: 07 Jan. 2004 Nemko Identification No.: #3 Receive Frequency Range: 458.525-458.775MHz Receive Frequency of EUT(s): 458.675MHz (fixed) Supply Voltage: 12-24Vdc. Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 6 of 10 Section 3. Radiated Emissions Para. No.: 15.109(a) Test Performed By: Glen Westwell Date of Test: 19 Jan. 2004 Minimum Standard: Frequency(MHz) Field Strength (dBμV/m @ 3m) 30 - 88 40.0 88 - 216 43.5 216 - 960 46.0 Above 960 54.0 Test Results: Complies. Measurement Data: See attached table. All emissions were searched from 30MHz to5GHz. The EUT was searched on 3 orthogonal axis, worst case data has been presented. The DC supply was varied +/- 15% to verify worst case emissions. Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 7 of 10 Test Date: 19 Jan. 2004 Engineer’s Name: G.W. Tested as per: Table Top Test Distance (meters): 3 Range: A Emissions within 20 dB of the limit have been recorded. Freq. (MHz) Ant. Pol. V/H RCVD Signal (dBμV) Ant. Factor (dB) Amp. Gain (dB) Cable Loss (dB) Field Strength (dBμV/m) Limit (dBμV/m) Margin (dB) Det. Amp 112.4000 BC1 V 19.7 11.4 N/A 1.3 32.4 43.5 11.1 Q-Peak None 112.4000 BC1 H 17.3 10.9 N/A 1.3 29.5 43.5 14.0 Q-Peak None 176.6300 BC1 V 15.0 13.1 N/A 1.7 29.8 43.5 13.7 Q-Peak None 176.6300 BC1 H 12.0 12.4 N/A 1.7 26.1 43.5 17.4 Q-Peak None 437.2770 LP1 V 10.2 16.1 N/A 2.7 29.0 46.4 17.4 Q-Peak None 437.2770 LP1 H 12.1 16.8 N/A 2.7 31.6 46.4 14.8 Q-Peak None Note 1: Antenna Legend: BC = Biconical, BL = Bilog, LP = Log-Periodic, Horn = Horn, ED = EMCO Dipole Note 2: Detector Legend: Q-Peak = 120 kHz RBW, Average = 1.0 MHz RBW Notes: Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 8 of 10 Test Set Up Photos Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 9 of 10 Section 4. Block Diagrams Outdoor Test Site For Radiated Emissions 3 METERS EUT NON-CONDUCTING TURN-TABLE 0.8 METER VARIABLE SEARCH HEIGHT (1 TO 4 m) TO TEST RECEIVER/SPECTRUM ANALYZER SEARCH ANTENNA Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 10 of 10 Section 5. Test Equipment List CAL CYCLE EQUIPMENT MANUFACTURER MODEL SERIAL LAST CAL. NEXT CAL. 1 Year Receiver Rohde & Schwarz ES…

Text truncated - open the document above for the full version.

Nemko Canada Inc. FCC PART 15, SUBPART B, 15.109 PROJECT NO.:4W07778.1 EQUIPMENT: RC-TRS-RX, 458MHz Receiver Page 8 of 10 Test Set Up Photos
