RYH-BC13Weather Station LCD Alarm Clock with Outdoor Sensor

English Batteryprecautions 1.Donotuserechargeablebatteries. 2.UseonlyalkalineAA/AAAbatteriesofthesameorequivalenttype. 3.Insertbatterieswiththecorrectpolarity. 4.Keepbatteriesawayfromchildren. 5.Disposeofexhaustedbatteriesaccordingtolocallegalrequirements.Donotdisposethembythrowingawaywithnormalhouseholdrubbish. 6.Avoidshortcircuitingthecontactsinthebatterycompartmentandbatteryterminals. 7.Removebatteriesfromtheunitifitwillnotbeusedforlongperiodoftime. 8.Exhaustedbatteriesshouldberemovedfromthebatterycompartmenttopreventover-discharge,whichcancauseleakageandmaycause damagetotheclock. Gettingstarted 1.Removethebatterydoor. 2.Insert2xAAsizenewbatteriesasindicatedinthemainunitand2xAAAnewbatteriesinthesensorasindicatedinbatterycompartments. 3.Topairthemainunitwiththesensor,presstheRESETkeyatthebackofthemainunitfirst,andthenpresstheRESETkeyinsidethebattery compartmentofthesensor. 4.Insomecasesthemainunitandthesensorwillnotpairimmediately.Youcanresettheunitandthesensoragainasdescribedintheabove section.Duetotheatmosphericdisturbance,thebestreceptionoftenoccursduringnighttime. 5.Closethebatterydoor. Functionkeys TIMESETTING/NEUTRAL/ALARMSETTINGswitch -SlidetheswitchtotheTIMESETTINGposition()tosettheclocktime. -SlidetheswitchtotheALARMSETTINGposition()tosetthealarmtime. -SlidetheswitchtotheNEUTRALpositiontoexitthesettingmodeandreturntonormaldisplay. +Key -WhenthesettingswitchisintheNEUTRALposition,pressthe+keytochangebetween12and24hourdisplayformat. -InTIMESETTINGorALARMSETTINGmodepresstoincreasethesettingvalue.Pressandholdtospeedupthesetting. -Key -WhenthesettingswitchisintheNEUTRALposition,pressthe-keytochangethetemperaturedisplaybetween°Cand°Fformat. -InTIMESETTINGorALARMSETTINGmodepresstodecreasethesettingvalue.Pressandholdtospeedupthesetting. ALARMON/OFFslider -ShifttheALARMON/OFFslideruptoenablethealarmandthealarmtimeshowsonLCDdisplay3seconds. -ShifttheALARMON/OFFsliderdowntodisablethealarm. SNOOZE/LIGHTtouchbutton -Taptoturnonthebacklightfor10seconds. -Taptostopthealarmandactivatethe5minutesnoozefunction. RESETkey -Pressbyusingapintoresetallvaluestodefault.Incaseofamalfunction,theunithastobereset. PAIRbutton -PressPAIRbuttontoreceive433MHzsignalforoutdoorsensorreception. BACKLIGHTON/OFFswitch -SlidetheswitchtoONpositiontoenablethenightlightmode. -SlidetheswitchtoOFFpositiontodisablethenightlightmode. Productdescription(Image1) 1.LCDdisplay 2.SNOOZE/LIGHTtouchbutton 3.ALARMON/OFFslider 4.TIMESETTING/NEUTRAL/ALARMSETTINGswitch 5.+Key 6.-Key 7.Batterycompartment 8.RESETkey 9.PAIRbutton 10.BACKLIGHTON/OFFswitch Displaydetails(Image2) A.Time B.AM/PMindicator(for12hourformat) C.Alarmicon D.Indoortemperature E.Outdoortemperature F.Indoorhumidity G.Outdoorhumidity H.Lowbatteryindicator I.Weatherforecastindicator Settingthetime 1.SlidetheTIMESETTING/NEUTRAL/ALARMSETTINGswitchtotheTIMESETTINGposition(). 2.Pressthe‘+’or‘-’keytosetthedesiredvalue.Pressandholdthe‘+’or‘-’keytospeedupthesetting. 3.SlidetheTIMESETTING/NEUTRAL/ALARMSETTINGswitchtotheNEUTRALpositiontoreturnthenormaldisplayandsavethesettings. Settingthealarm 1.SlidetheTIMESETTING/NEUTRAL/ALARMSETTINGswitchtotheALARMSETTINGposition(). 2.Pressthe‘+’or‘-’keytosetthedesiredvalue.Pressandholdthe‘+’or‘-’keytospeedupthesetting. 3.SlidetheTIMESETTING/NEUTRAL/ALARMSETTINGswitchtotheNEUTRALpositiontoreturnthenormaldisplayandsavethesettings. Usingthealarmandsnoozefunction 1.EnablethealarmbyshiftingtheALARMON/OFFsliderup(sothegreendetailisvisible).Thebellicon()willappearontheLCDdisplay.And thealarmtimewillshowontheLCDdisplay3seconds. 2.TaptheSNOOZE/LIGHTtouchbuttontostopthealarmandactivatethesnoozefunction.Whenthesnoozefunctionisactivated,thebellicon() willflash. 3.Todisablethealarmandsnoozefunction,shifttheALARMON/OFFsliderdown.Thebellicon()willdisappear. Note : Whenthesnoozefunctionisactivated,thealarmwillautomaticallystartagainafter5minutes.ThesnoozefunctionwillnotstopunlesstheALARM ON/OFFSLIDERisshifteddown. Placingthesensoroutside 1.Placethesensoroutsidewithina30metre(98ft)rangeofthemainunit. 2.Thesensorcanbeplacedverticallyonflatsurfaceunderacoveredareawhichcanshielditfromrainoritcanbemountedonawallwithascrew. 3.ThesensorisIPX3waterresistant,howeverextremetemperatures,placingonwetsurfaceandshockshouldbeavoidedtopreventdamage. 4.Itisstronglyadvisedtoplacethesensorunderacoveredareawhichcanshielditfromdirectsunlightorwetconditionsforanaccuratereading. Readingindoor/outdoortemperature&humidity Setthetemperatureto°Cor°Fbypressing°C/°Fkey. Note: 1.Ifnosignalisreceivedorthetransmissionisinterrupted,the“--”symbolwillappearontheLCDdisplay. 2.Ensurethatthemainunitandthesensorareplacedwithina30metre(98ft)rangefromeachother.PressthePAIRbuttontoreceivethesensor signal. 3.Ifthe“--”symbolisstillshowingontheLCDdisplay,pleaseresetthemainunitandthenthesensor. Weatherforecastindicator Thebuilt-inbarometercandetectatmosphericpressurechanges.Basedonthedatacollected.Itcanpredicttheweatherconditioninthe forthcoming12to24hours. Note: Theweatherforecastpredictstheweatherconditionintheforthcoming12to24hours.Itmaynotnecessarilyreflectthecurrentsituation.Wedonot acceptanyliabilityfordamagewhichmayoccurasaresultofanincorrectweatherforecast. Settingthenightlight 1.SlidetheBACKLIGHTswitchtoONpositiontoenablethenightlightmode. 2.SlidetheBACKLIGHTswitchtoOFFpositiontodisablethenightlightmode. Note:Ifthisfeatureisusedcontinuously,thebatterylifewillbegreatlyreduced. Thecontinuousnightlightmodefunctionwilltemporarilybedisabledforperiodofapprox.6minutesatthehoursof2am3amor4am,asduringthis timetheclockisupdatingRadioControlledsignal.Oncethereceptionhasbeensuccessfullyupdatedthecontinuousnightlightmodewill automaticallyberestored.Duringthistime,ifrequired,pressSnooze/Lightbuttontoactivatethebacklightfunctionfor10seconds. Batteryreplacement Whenthe‘Lowbatteryindicator’isvisibleonmainunit,replacewithtwonewAAbatteriesatonce.Whenthe‘Lowbatteryindicator’isvisibleonoutdoor sensor,replacewithtwoAAAbatteriesatonce. Note : Exposuretoanelectrostaticenvironmentmaycausetheclocktoreset.Inthisevent…
