RYQ31PHBM2000A4G Module

UNITED STATES DESIGNATED AGENT LETTER Date: 2024-06-19 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: FIH CO., LTD Company Name: United Consulting Technology Services Co., Ltd. Grantee Code: RYQ FRN 0033495714 Contact Name: Barry Tsai Contact Name: David Wu Address: No.4, Mingsheng St., Tu- Cheng Dist., New Taipei City Address: 17800 CASTLETON ST STE 665 CITY OF INDUSTRY CA 91748 United States City/Province/Zip: Taiwan/23679 City/Province/Zip: Telephone: 886-2-2268-5511Telephone: Fax: 886-2-2269-2922 Fax: Email: [email protected] Email: (626) 217-4022 [email protected] Applicable Equipment: FCC ID: RYQ31PHBM2000A ATTN: Director of Certification: We, FIH CO., LTD and United Consulting Technology Services Co., Ltd. understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, FIH CO., LTD and United Consulting Technology Services Co., Ltd. acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Barry Tsai Name (Printed): David Wu Title: Manager Title: General Manager Signature: Signature:

Applicant Declaration QSF27-14-04 Rev 1.1 Jan 17, 2024 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name FIH Co.,LTD Address No.4, Mingsheng St., Tu-Cheng Dist.,New Taipei City 23679, Taiwan FRN 0022371546 Grantee Code RYQ FCC ID RYQ31PHBM2000A Authorized Contact Name Barry Tsai Contact Email [email protected] Contact Phone +886-2-2268-5511 ext 60780 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List FIH Co., LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. FIH Co., LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to § 1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: Print Name: Barry Tsai Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database 2024/6/18

FIH Co., LTD. Cover Letter-Modular Approval FCC ID: RYQ31PHBM2000A Date: 2024-06-17 Gentlemen: There’s an 4G Module that would like to have your authorization as a modular approval. The specific product as below, 4G Module with its designed features and specified description, meets special requirements for Full modular approval on FCC KDB996369 by cross-reference list below. Company FIH Co., LTD. Model Name 4G Module Model Number 31PHBM2000A FCC ID RYQ31PHBM2000A Requirement of FCC KDB996369 Comply（Y/N） 1. The modular transmitter must have its own RF shielding. Y The EUT provides the RF shielding. See EUT photo. The hole in the shield is smaller than the wavelength of the radiation that is being blocked. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT has its buffered modulation. Please see the Schematic Diagram. 3. The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, please see the Schematic Diagram. 4. The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements; unique antenna connector and photo of antenna are shown in the test report. 5. The modular transmitter must be tested in a stand‐alone configuration, i.e., the Y The EUT was tested with a test board, Please FIH Co., LTD. module must not be inside another device during testing. see test report and setup photo 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: RYQ31PHBM2000A ” or “Contains FCC ID: RYQ31PHBM2000A ” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions give to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequat e instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter w ave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement. FIH Co., LTD. Thank you. Sincerely, Print Name: Barry Tsai Title: Manager Signature: On behalf of Company: FIH Co., LTD. Telephone: +886-2-2268-5511 ext 60780 E-mail: [email protected]

FIH Co., LTD. Date: 17-06-2024 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: RYQ31PHBM2000A To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own.. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with FIH Co., LTD. T his authorization is valid until further written notice from the applicant. Print Name: Barry Tsai Title: Manager Signature: On behalf of Company: FIH Co., LTD. Telephone: +886-2-2268-5511 ext 60780 E-mail: [email protected]

FIH CO., LTD. TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: RYQ31PHBM2000A LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) B lock Diagrams Operational Descriptions BOM List Tune up procedure Software Security Description The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Barry Tsai Title: Manager Signature: On behalf of Company: FIH Co., LTD. Telephone: +886-2-2268-5511 ext 60780 E-mail: [email protected]

Data Code: 240621 M/N: 31PHBM2000A IMEI: 352699370000104 FCC ID: RYQ31PHBM2000A IC : 6989A-31PHBM2000A H/W: 1.0

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR240400147806 Page: 1 of 8 Keny Xu EMC Laboratory Manager RF EXPOSURE EVALUATION REPORT Application No.: SZCR2404001478AT Applicant: FIH Co.,LTD Address of Applicant: No.4, Mingsheng St., Tu-Cheng Dist.,New Taipei City 23679, Taiwan Manufacturer: FIH Co.,LTD Address of Manufacturer: No.4, Mingsheng St., Tu-Cheng Dist.,New Taipei City 23679, Taiwan Factory: Futaijing Precision Electronics (Beijing)co., Ltd. Address of Factory: No.9 JinXiu Street, Beijing Economic & Technological Development Area, Beijing 100176, China Equipment Under Test (EUT): EUT Name: 4G Module Model No.: 31PHBM2000A FCC ID: RYQ31PHBM2000A Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2024-04-23 Date of Evaluation: 2024-05-05 to 2024-05-29 Date of Issue: 2024-06-08 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR240400147806 Page: 2 of 8 Revision Record Version Chapter Date Modifier Remark 01 2024-06-08 Original Authorized for issue by: Calvin Weng/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR240400147806 Page: 3 of 8 2 Contents Page 1 Cover Page ......................................................................................................................................... 1 2 Contents ............................................................................................................................................. 3 3 General Information............................................................................................................................ 4 3.1 General Description of E.U.T. ....................................................................................................... 4 3.2 Details of E.U.T. ........................................................................................................................... 4 3.3 Separation Distance ..................................................................................................................... 5 3.4 Test Location ............................................................................................................................... 6 3.5 Test Facility .................................................................................................................................. 6 3.6 Deviation from Standards ............................................................................................................. 6 3.7 Abnormalities from Standard Conditions ....................................................................................... 6 4 FCC Radiofrequency radiation exposure limits ................................................................................ 7 5 Measurement and Calculation ........................................................................................................... 8 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR240400147806 Page: 4 of 8 3 General Information 3.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Power supply: DC12V For 2.4G WIFI: Cable Loss (for RF conducted test): 0.7dB Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz;802.11n(HT40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11;802.11n(HT40):7 Channel Spacing: 5MHz Antenna Type: Dipole Antenna Antenna Gain: 2.5dBi For 5G WIFI: Cable Loss (for RF conducted test): 1.5dB Operation Frequency/Number of channels (20MHz): U-NII-1: 5180-5240MHz (4 Channels); U-NII-3: 5745-5825MHz (5 Channels) Operation Frequency/Number of channels/(40MHz): U-NII-1: 5190-5230MHz (2 Channels); U-NII-3: 5755-5795MHz (2 Channels) Operation Frequency/Number of channels (80MHz): U-NII-1: 5210MHz (1 Channel); U-NII-3: 5775MHz (1 Channel) Modulation Type: OFDM (64QAM, 16QAM, QPSK, BPSK) 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) Channel Spacing: 802.11a/n/ac 20: 20MHz; 802.11n/ac 40: 40MHz; 802.11ac 80: 80MHz DFS Function: Not support DFS TPC Function: Without TPC function Antenna Type: Dipole Antenna Antenna Gain: U-NII-1:-3.02dBi, U-NII-3:-2.37dBi SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR240400147806 Page: 5 of 8 For 3G: Cable Loss (for RF conducted test): Below 1GHz: 4.5dB, 1GHz~2.4GHz:4.7dB, Above 2.4GHz: 5.2dB Sample Type: Mobile production Support Network: RMC, HSDPA, HSUPA Operation Frequency Band: UMTS FDD Band II/VI/V Modulation Type: QPSK for WCDMA Supported Channel Bandwidth: 5MHz for WCDMA UMTS Power Class: Level 3 Antenna Type: Dipole Antenna Antenna Gain: WCDMA B2:4dBi; B4: 3dBi; B5:1.5dBi For 4G: Cable Loss (for RF conducted test): Below 1GHz: 4.5dB, 1GHz~2.4GHz:4.7dB, Above 2.4GHz: 5.2dB Sample Type: Mobile production LTE Operation Frequency Band: LTE B2/4/5/7/12/13/17/25/26/66/71 Modulation Type: QPSK, 16QAM LTE Power Class: Level 3 Antenna Type: Dipole Antenna Antenna Gain: LTE B2:4dBi; B4: 3dBi; B5:1.5dBi, B7:5.1dBi, B12:0.7dBi, B13:1.1dBi, B17: 1.3dBi, B25: 4dBi; B26:1.5dBi; B66:3.7dBi, B71:0.4dBi Remark:The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. Note: (1)The antenna gain value is provided by the customer. The test lab will not be responsible for wrong test result due to incorrect information about antenna gain values. 3.3 Separation Distance Minimum test separation distance: 20cm Remark: This minimum test separation d…
