RZ3MCON0901

Trapeze Software Group, Inc.

MultiConnect GPRS

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Apr 19, 2004
Application Purpose: Original Equipment
Date of Application: Apr 19, 2004
Equipment Note: MultiConnect GPRS
Frequency Range: 824.20000000 - 848.80000000
Company: Trapeze Software Group, Inc.
Country: Canada

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

Test Setup Photos

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	22H	824.2 MHz - 848.8 MHz	1.82 W	300KGXW	0.055 ppm

Confidentiality

Long Term

Grant Notes

Power Output listed is conducted. The antenna gain, including cable loss, must not exceed 3.18 dBi at 1900 MHz / -0.83 dB at 850 MHz for mobile operating configurations and 7.18 dBi at 1900 MHz / -0.16 dB at 850 MHz for fixed-mounted operations, as defined in 2.1091 and 1.1307 of the rules for satisfying RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End Users and Installers must be provided with antenna installation instructions and transmitter operation conditions for satisfying RF exposure compliance.
