GR-250 Hand Held Reader User Manual READING ........... S 07/ 25/ 05 13: 47 Intr oduction ID# 12-3456-789A If a transponder is detected, the green LED will illuminate and a capture tone will sound. The transponder’s ten hexadecimal digit (i.e., 0-9, A-F) ID number will remain on the LCD while the trigger is depressed. Once the trigger is no longer depressed, the ID number will be displayed for about 30 seconds before it disappears from the LCD. The GR-250 Hand Held Reader is desi gned to read Trovan RFID (radio frequency identification) transponders. Prior to first use, you should fully charge the battery. Remove the dust cap from the circular connector at the rear of the reader, attach the battery charger’s connector to the reader, and plug the battery charger into an electrical outlet. The red LED will light to indicate charging is in progress. If the red LED doesn’t light, check your power source and try plugging the battery charger into a different outlet. To initiate another reading, simply depress the trigger button again. The charger has an internal timer that will automatically shut off the charging process after approximately 14 hours and begin trickle charging the battery. At that time, the red LED will also turn off to indicate that the charging cycle is complete and will b link periodically to indicate trickle charging. Once your reader is fully charged, unplug the charger from the outlet, disconnect the reader from the charger, and replace the dust cap. Your reader is now ready for use. R eplacing the Ba tter y Under normal use and recharging, the battery will provide years of service. To replace the battery, remove the battery compartment cover on the bottom of the reader by loosening the two screws (but do not remove the screws from the cover), unsnap the battery connector, and attach it to the new battery. The battery is a 12 volt nickel metal hydride (NiMH) battery. Although the battery connector is the same as a typical 9 volt battery, it is vital that you replace the battery with an authorized 12 volt replacement, NOT a 9 volt battery. A fully charged reader will read approximately 3,000 transponders (average scan time of 1-2 seconds) before the battery needs to be recharged. To ensure maximum reading performance, the reader should be charged once a week, even if 3,000 scans haven’t been performed. If the reader hasn’t been used for about a month, the battery may be low. Therefore, it is recommended the reader be charged at least once a month, even if stored. Advanced R eader Functions The GR-250 Hand Held Reader has additional capabilities which are implemented via its RS- 232 interface. Up to 3,072 transponder ID number readings, automatically stamped with date & time, can be stored in memory. Also, the following parameters can be set via the RS- 232 interface: CAUTION: DO NOT replace the 12 volt battery with a 9 volt battery. The reader will not operate with a 9 volt battery. Note: An optional interface cable must be purchased to connect the reader to a computer via the RS-232 interface. The hole in the rear of the handle can be used to fasten a lanyard or wrist strap to the reader. R eading a T r ansponder To read a transponder, depress the trigger and bring the front face of the reader into close proximity of the transponder to be scanned. The red LED will flash rapidly, indicating that reading is in process. The LCD will display READING...... • Date, time, and day of the week • Communications parameters (BAUD rate, etc.) • Hexadecimal (default) or decimal display mode • Save and Seek modes Length: 11 3/4 inches (30 cm) T r oubleshooting The Reader Doesn’t Read Symptoms: When the trigger is depressed, the red & green LEDs do not illuminate, and the LCD is blank. There is no response from the reader. Response: Recharge or replace battery. The reader will not operate until the battery is recharged or replaced with a fully charged 12 volt battery. The Reader Displays an Error Message on the LCD * Low Battery * Please RECHARGE The battery voltage is below approximately 11.8 volts and must be recharged or replaced immediately. The reader will not function until the battery is either recharged or replaced with a fully charged battery. The reader has experienced a hardware fault and must be returned for repair. * * T ran s m itter* * Fault => SERVICE The real time clock’s lithium battery must be replaced or unpredictable reader operation may occur. The reader must be returned for repair. SERVICE—Replace Lith iu m Battery T e c hnical Specifica t ions Dimensions: Width: 7 1/8 inches (18 cm) Height: 4 1/8 inches (10.5 cm) Weight: 2.85 pounds (1.3 kg) with battery pack Display: LCD (2 lines x 16 characters) Red LED – Flashes to indicate reading in process Green LED – Illuminates when transponder is read Memory Storage Capacity: 3,072 readings with date & time Computer Interface: RS-232, 9600 BAUD (default BAUD rate) Power: 12 volt rechargeable NiMH battery Environmental: Water, salt air, & weather resistant Cau t i on: Change s or modi f i c a ti ons not e x pre ssl y approv e d by the party re sponsi b l e f o r F CC co m p lian ce co uld vo id th e us er’s auth o r ity to o p e rate th is equip m en t. U. S. Pat ent s 5, 012, 236, 5, 095, 309 and 5, 198, 807 032905

GR-250 RFID Reader Top Side Back Front Bottom

FCC Label Location

PRODUCT SERVICE TEST RESULT SUMMARY FCC PART 15 SUBPART C Section 15.209 FCC PART 15 SUBPART C Section 15.207 Conducted Emission Requirements Industry Canada RSS-210: Issue 5: 2001 Section 6.2.1 MANUFACTURER'S NAME Vantro Systems, LLC NAME OF EQUIPMENT Portable, Handheld, Battery Powered RFID Reader MODEL NUMBER GR-250 MANUFACTURER'S ADDRESS 11401 Rupp Drive Burnsville, MN 55337 TEST REPORT NUMBER WC501235 TEST DATE 18 March 2005 According to testing performed at TÜV Product Service Inc, the above-mentioned unit is in compliance with the electromagnetic compatibility requirements defined in FCC Part 15 Subpart C Sections 15.207 and 15.209 and also RSS-210, section 6.2.1. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications necessary for compliance made during testing on the above mentioned date(s) must be implemented in all production units for compliance to be maintained. TÜV Product Service Inc, as an independent testing laboratory, declares that the equipment tested as specified above conforms to the requirements of FCC Part 15 Subpart C Sections 15.207 and 15.209 and also RSS-210, section 6.2.1. Date: 23 March 2005 Location: Taylors Falls MN J. C. Sausen T. K. Swanson USA Tested By Reviewed By Not Transferable File No. WC501235, Page 1 of 32 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE EMC EMISSION - T E S T R E P O R T Test Report File No. : WC501235 Date of issue: 23 March 2005 Model / Serial No. : GR-250 / 42 Product Type : Portable, Handheld, Battery Powered RFID Reader Applicant : Vantro Systems, LLC Manufacturer : Vantro Systems, LLC License holder : Vantro Systems, LLC Address : 11401 Rupp Drive : Burnsville, MN 55337 Test Result : „ Positive † Negative Test Project Number : Reference(s) WC501235 Total pages 32 TÜV Product Service Inc is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO/IEC Guide 25 and EN 45001. TÜV Product Service Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV Product Service Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV Product Service Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. TÜV Product Service Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI File No. WC501235, Page 2 of 32 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE TABLE OF CONTENTS General Information Page(s) Test Regulations 3 Emission Test Results 4 Measurement Protocol 5 - 6 Deviations / Summary 7 Constructional Data Form(s) and/or Product Information Form(s) 8 - 14 Test data FCC Section IC Section General Field Strength Limits .009 – 30 MHz 15.209(a) 6.2.1 16 - 17 Emission Bandwidth N/A 5.9.1 18 - 19 Radiated Emissions 30 – 1000 MHz 15.209(f) 6.2.1 20 - 26 Radiated Emissions 1 – 18 GHz 15.209(f) 6.2.1 27 AC Line Conducted Emissions 15.207 6.6 / CISPR 22 28 - 32 File No. WC501235, Page 3 of 32 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: -------------------------------------------------------------------------------- † - EN 50081-1 / 1991 † - EN 55011 / 1998 † - Group 1 † - Group 2 w/Amendment A1:1999 † - Class A † - Class B † - EN 55013 / 1990 † - EN 55014 / 1987 † - Household appliances and similar † - Portable tools † - Semiconductor devices † - EN 55014 / A2: 1990 † - EN 55014 / 1993 † - Household appliances and similar † - Portable tools † - Semiconductor devices † - EN 55015 / 1987 † - EN 55015 / A1:1990 † - EN 55015 / 1993 † - EN 55022 / 1987 † - Class A † - Class B „ - FCC Part 15 Subpart C Section 15.209 „ - FCC Part 15 Subpart C Section 15.207 Conducted Emission Requirements „ - RSS-210, Issue 5, 2001 – Section 6.2.1 File No. WC501235, Page 4 of 32 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE Emission Test Results: Field Strength [FCC 15.209 (a)], [RSS 210 6.2.1] 9 kHz – 30 MHz The requirements are „ - MET † - NOT MET Minimum limit margin for fundamental 8 dB at 128.0 kHz Minimum limit margin for spurious/harmonics >10 dB at MHz Remarks: The fundamental was measured to be 110 dBuV/m in Average mode at 3 meters, 71 dBuV/m (3548 microvolts/meter) at 10 meters, 53 dBuV/m (446.6 microvolts/meter) at 30 meters. This extrapolates to a level of 17 dBuV/m (7.07 microvolts/meter) at 300 meters using 18 dB/decade as indicated by testing. The limit is 25.46 dBuV/m (18.75 microvolts/meter) at 300 meters. No spurious emissions or other harmonics were detected from 9 kHz to 30 MHz. 99% Bandwidth [RSS-210 5.9.1] The requirements are „ - MET † - NOT MET Remarks: Bandwidth is shown to be 4.04 kHz. Radiated Emissions [FCC 15.209 (f)], [RSS 210 6.2.1] 30 MHz – 1000 MHz The requirements are „ - MET † - NOT MET Minimum margin of compliance 7 dB at 88.4 MHz Maximum margin of non-compliance dB at MHz Remarks: Class B limit. Radiated Emissions [FCC 15.209 (f)], [RSS 210 6.2.1] 1 G…
