S48EN1226CDMA Wireless Modem

Wireless Support -1 DraftVPN and Legacy-to-IP Products Customization and Maintenance Guide 0.1Wireless Support Note: This equipment has been approved for mobile operation, and requires a minimum of 20 cm (7.9 inches) of space between the antenna(s) and each person’s body (excluding extremities of hands, wrists, and feet) during wireless modes of operation. The maximum antenna gain should not exceed 6 dBi. Wireless connections use radiofrequencies through air waves instead of electrical signals through cables. A cellular wireless connection allows free physical movement within the broadcast radius of a cell’s wireless access point (AP)—for example, a cell tower. Each wireless AP provides a direct or indirect cabled connection to the core of the wireless network. The BANDIT chassis can hold an expansion module for connection to a cellular wireless network. The BANDIT’s expansion port can hold a card for access to one of the following wireless networks. (The card installed depends on the wireless carrier and network you wish to use; you order a GSM or CDMA card according to the technology the carrier uses.) • Code Division Multiple Access (CDMA) wireless network • Global System for Mobile Communications (GSM) wireless network A wireless network card supports the BANDIT as a wireless terminal. The card supports a wireless connection to a wireless access point (AP), such as a cell tower. (The BANDIT does not act as a gateway or AP for other wireless devices. That is, it does not provide a connection through which other terminal wireless devices, such as a cellphone or a wireless laptop computer, can reach a wireless network.) You can set the BANDIT up to provide a connection between a cabled network and a wireless network. All features of the BANDIT are available for wireless and wired connections. Figure 0-1 illustrates the BANDIT’s wireless and wired connections. The BANDIT can send a transmission through a wireless carrier or through a wired network. -2: VPN and Legacy-to-IP Products Customization and Maintenance Guide Draft Figure 0-1. BANDIT Connections to Wireless Carrier, to Wired LAN, and to Wired IP Network Note: A remote terminal can be set up to manage the BANDIT, from any location over any network. For example, a wireless laptop can manage the BANDIT remotely, if you configure the BANDIT’s firewall to accept the connection. As in any other remote connection, the wireless laptop’s packets go through the wireless carrier’s network to be routed to the BANDIT (see Figure 0-1). Figure 0-2 shows a BANDIT wireless card’s faceplate with a mini-meg connector port for an antenna. Figure 0-3 shows a wireless module, with antenna, installed in the BANDIT chassis. Wireless Support -3 DraftVPN and Legacy-to-IP Products Customization and Maintenance Guide Note: The standard antenna for the BANDIT’s wireless modules has 0 db (no gain). Contact your Encore Networks sales representative if you would like an optional antenna that has a +3 dB gain. Figure 0-2. Wireless Module Faceplate ?? Picture currently unavailable Figure 0-3. BANDIT Using Wireless Module, with Antenna Connected to Module Warning: It is extremely important to set up security measures, including firewall protection, for each wireless device. Use the BANDIT’s firewall for wireless connections to protect the BANDIT and its connection to the wireless network. See Section 0.1.1, The BANDIT’s Wireless Firewall. The BANDIT uses spoofing to handle legacy protocols that are sensitive to delay. It receives packets from the sender and replies with acknowledgment packets as if it were the remote terminal at the end of the connection; at the -4: VPN and Legacy-to-IP Products Customization and Maintenance Guide Draft same time, the BANDIT sends the received data across the wireless network to the real remote terminal. The same process occurs in reverse when the remote terminal sends reply packets. Note: When you order a CDMA wireless card for the BANDIT, the carrier- specific software is loaded on the wireless card before shipment. A GSM carrier provides a Subscriber Identity Module (SIM) to insert into the GSM wireless card. See the following sections: •Section 0.1.1, The BANDIT’s Wireless Firewall •Section 0.1.2, The CDMA Wireless Card •Section 0.1.3, The GSM Wireless Card 0.1.1The BANDIT’s Wireless Firewall It is extremely important to set up security measures, including firewall protection, for each wireless device. Use the following procedure to configure a firewall to protect the BANDIT and its connection to the wireless network. How to Configure the BANDIT’s [Wireless??] Firewall 1?? To be added. 0.1.2The CDMA Wireless Card CDMA uses spread-spectrum technology. Table 0-1 lists the specifications for the BANDIT’s CDMA wireless expansion module. Table 0-1. Specifications for CDMA Wireless Card (1 of 2) SpecificationCDMA Module Power supply’s maximum voltage 4.2 VDC Wireless Support -5 DraftVPN and Legacy-to-IP Products Customization and Maintenance Guide 0.1.2.1Activating the CDMA Card in the Carrier Network The CDMA module is activated for use before shipment. However, you must activate the module for use in the carrier’s network. Use one of the following procedures, depending on the carrier you have selected. •How to Activate the CDMA Card for the Sprint Network •How to Activate the CDMA Card for the Verizon Network How to Activate the CDMA Card for the Sprint Network Note: Before you activate the module in the network, make sure the module has already been properly provisioned for the Sprint network. (This was done before the BANDIT device was shipped to you.) ?? Procedure to be added. Number of ports One wireless port Wireless interfaceCDMA 2000 (IS-2000) Data rate per portUp to 153 kbps ThroughputUp to 153 kbps Dimensions (L x W x H)2.3 in. x 1.3 in. x 0.2 in. (58 mm x 32.6 mm x 3.9 mm) Weight 0.005 lb. (11 g) Operating temperature -22°F to 140°F (-30°C to 60°C) Storage temperature-40°F to 185°F (-40°C to 85°C) Band of Operating Frequ…

Text truncated - open the document above for the full version.

Encore Networks Inc., 45472 Holiday Dr Dulles, VA 20166 March 14, 2005 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road To Whom It May Concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to this matter. Any and all acts carried out by PCTEST Engineering Laboratory Inc. on our behalf shall have the same effects as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, George Glass Encore Networks Inc., 45472 Holiday Dr Dulles, VA 20166 March 14, 2005 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road To Whom It May Concern: In accordance with 0.459 of CFR 47, Encore Networks Inc., hereby requests confidentiality of Block Diagrams, Circuit Diagrams, Circuit Descriptions, Parts Lists, and Operational Description attachments for the subject application. These documents contain detailed system and equipment description and related information about the product, which Encore Networks Inc., considers proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Encore Networks Inc., considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, George Glass

March 31, 2005 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: ENCORE!NETWORKS FCC ID: S48EN1226 Part 22 Certification Gentlemen: Submitted herewith, on behalf of ENCORE!NETWORKS, is an application for Part 22 Certification of the CDMA Wireless Modem. Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report test data and plots, MPE measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: ENCORE!NETWORKS

ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1

© 2005 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) Sample Label FCC ID: S48EN1226 FCC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept an interference received, including interference that may cause undesired operation. This device complies with Part 68 of FCC Rules. Power Input: +5VDC .75A Made in Canada

ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1

PCTEST MPE REPORT FCC MEASUREMENT REPORT REVIEWED BY: Quality Manager TEST REPORT S/N: 0503030156 TEST DATES: March 3-4, 2005 EUT TYPE: Magnetic Mount Tri-Band Antenna FCC ID: S48EN1226 Page 1 of 2 © 2005 PCTEST Engineering Laboratory, Inc. RF Exposure Evaluation - Maximum Permissible Exposure (MPE) 1. Introduction This document attempts to prove the safety of radiation generated by RF devices to the human body. The limit for Maximum Permissible Exposure (MPE), specified in FCC 1.1210, is listed below. The power generated by this product is measured by a power meter. Through use of the Friis transmission formula and the maximum gain of the antenna, the distance from the product at which compliance with the MPE limit is achieved may be calculated. Alternatively, near field measurements may be performed to demonstrate compliance at a specific measurement distance. Near field probe: Wandel & Goltermann EMR-20. 2. RF Exposure Limit According to FCC 1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures 30-300 61.4 .163 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B) Limits For General Population / Uncontrolled Exposure 30-300 27.5 .073 .2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. Friis Formula Friis transmission formula: Pd = (P out *G) / (4pr 2 ) Where: Pd = power density in mW/cm 2 (MPE limit) P out = output power to antenna in mW G = gain of antenna in linear scale p = 3.1416 r = distance between observation point and center of the radiator in cm Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11.133) PCTEST MPE REPORT FCC MEASUREMENT REPORT REVIEWED BY: Quality Manager TEST REPORT S/N: 0503030156 TEST DATES: March 3-4, 2005 EUT TYPE: Magnetic Mount Tri-Band Antenna FCC ID: S48EN1226 Page 2 of 2 © 2005 PCTEST Engineering Laboratory, Inc. 4. EUT Operating Condition Software provided by the client enabled the EUT to transmit and receive data at lowest, middle, and highest channels individually. 5. Climate Condition The temperature and relative humidity: 22°C and 78% RH 6. Measurement Results 6.1 Output Power into Antenna & RF Exposure Distance: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) 384 836.52 359 0.071 7. Conclusion The device meets the mobile 20cm. separation distance as specified in Section 2.1091 of the FCC Rules and an appropriate RF exposure compliance statement will be placed in the users manual.

PCTEST PT. 22 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0503030156 Test Dates: MARCH 3-4, 2005 EUT Type: CDMA Wireless Modem FCC ID: S48EN1226 Page 1 of 18 © 2005 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 Certification ENCORE ! NETWORKS Dates of Tests: March 3-4, 2005 45472 Holiday Drive, Suite 3 Test Report S/N: 0503030156 Dulles, VA 20166 Test Site: PCTEST Lab, Columbia MD FCC ID S48EN1226 APPLICANT ENCORE!NETWORKS Classification: Licensed Non-Broadcast Transmitter (TNB) FCC Rule Part(s): §22(H) EUT Type: CDMA Wireless Modem Model: MDM100-1 Tx Frequency Range: 824.70 – 848.31MHz (CDMA) Rx Frequency Range: 869.70 – 893.31MHz (CDMA) Max. RF Output Power: 0.358 W (25.533 dBm) Emission Designator(s): 1M25F9W (CDMA) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. This device is electrically identical to the WAVECOM FCC ID: O9EQ2438F. The AMPS and PCS modes have been disabled via software. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST PT. 22 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0503030156 Test Dates: MARCH 3-4, 2005 EUT Type: CDMA Wireless Modem FCC ID: S48EN1226 Page 2 of 18 © 2005 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-8 5.1 FREQUENCY STABILITY 9-14 6.1 PLOTS OF EMISSIONS 15 7.1 LIST OF TEST EQUIPMENT 16 8.1 SAMPLE CALCULATIONS 17 9.1 CONCLUSION 18 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EUT PHOTOGRAPHS ATTACHMENT H: BLOCK DIAGRAM(S) ATTACHMENT I: SCHEMATIC DIAGRAM(S) ATTACHMENT J: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT K: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT L: USER’S MANUAL ATTACHMENT M: MPE REPORT PCTEST PT. 22 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0503030156 Test Dates: MARCH 3-4, 2005 EUT Type: CDMA Wireless Modem FCC ID: S48EN1226 Page 3 of 18 © 2005 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: ENCORE-NETWORKS Address: 45472 Holiday Drive, Suite 3 Dulles, VA 20166 • FCC ID: S48EN1226 • Quantity: Quantity production is planned • Emission Designators: 1M25F9W (CDMA) • Tx Freq. Range: 824.70 – 848.31 MHz (CDMA) • Rx Freq. Range: 869.70 – 893.31 MHz (CDMA) • Max. RF Output Power: 0.358 W (25.533 dBm) • FCC Classification(s): Licensed Non-Broadcast Transmitter (TNB) • Equipment (EUT) Type: CDMA Wireless Modem • Modulation(s): CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): §22H • Dates of Tests: March 3-4, 2005 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 0503030156 PCTEST PT. 22 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0503030156 Test Dates: MARCH 3-4, 2005 EUT Type: CDMA Wireless Modem FCC ID: S48EN1226 Page 4 of 18 © 2005 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Measurement Procedure The radiated and spurious measurements were made outdoors at a 3-meter test range (see Figure2). The equipment under test is placed on a wooden turntable 3-meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. A half- wave dipole was substituted in place of the EUT. This dipole antenna was driven by a signal generator and the level of the signal generator was adjusted to obtain the same receive spectrum analyzer reading. This level is recorded. For readings above 1GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic antenna are taken into consideration. Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Figure 2. Diagram of 3-meter outdoor test range PCTEST PT. 22 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0503030156 Test Dates: MARCH 3-4, 2005 EUT Type: CDMA Wireless Modem FCC ID: S48EN1226 Page 5 of 18 © 2005 PCTEST ENGINEERING LABORATORY, INC. 3.1 INSERTS …

Text truncated - open the document above for the full version.

ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1 ENCORE!NETWORKS FCC ID: S48EN1226 EUT Photographs © 2005 PCTEST Lab. CDMA Wireless Modem Model: MDM100-1
