S59-1214Wireless Remote

Welcome to Device! Device is an easy way to discover and enjoy online digital entertainment instantly in your home. Get started with three easy steps:  Connect Device  Connect to your home network  Register your Device What’s In The Box  Device  Power Adaptor  Remote  2 AAA batteries Getting To Know Device Connecting Device 1. Connect one end of the HDMI cable (not included) into the HDMI port on Device. Connect the other end of the HDMI port on your TV. 2. Plug the included power cable into Device and then into the power outlet. 3. Turn on your TV, and select the appropriate input. 4. Insert the included batteries into the remote. If the remote does not automatically connect, make sure that the batteries are properly installed. Device is now connected to your TV. Simply follow the on-screen guide to complete your set up. TIPS  To route audio and video from Device to your AV receiver, use the HDMI connection.  If your TV does not display the Device welcome screen, please make sure that your TV’s input matches the physical connection used with the Device  Always replace dead batteries with new 1.5 V alkaline or 1.2 NiMH rechargeable batteries. Connecting Device To Your Home Network You can connect Device to your network using one of the methods below: Wired Network 1. Connect one end of an Ethernet cable (not included) to your router. Connect the other end of the Ethernet port on the back of Device. 2. Device will automatically detect your network and continue the setup process. Or Wi-Fi network 1. Using the remote control, select your network from the list displayed on the screen. If your network is hidden, enter your network name. 2. If required, enter your network password using the on-screen keyboard. TIP  For optimal performance, place your Device in an open cabinet or shelf. Registering Your Device [Insert Instructions Here]

Connect Wirelessly [Insert instructions here] Connect a Remote Control & Game Controller [Insert instructions here] Mirror a Device's Display on Your TV [Insert instructions here] Set Up Parental Controls [Insert instructions here] Watch Movies [Insert instructions here] Play Games & Apps [Insert instructions here] View Photos and Screensavers [Insert instructions here] Settings [Insert instructions here] Basics [Insert instructions here] Product Information Safety and Compliance Information [Insert user instructions for safe use of the product.] Using Your Product Around Other Electronic Devices Product generates, uses, and can radiate radio frequency (RF) energy and, if not used in accordance with its instructions, may cause interference to radio communications and electronic equipment. External RF signals may affect improperly installed or inadequately shielded electronic operating systems, entertainment systems, and personal medical devices. While most modern electronic equipment is shielded from external RF signals, if in doubt, check with the manufacturer. For personal medical devices (such as pacemakers and hearing aids), consult with your physician or the manufacturer to determine if they are adequately shielded from external RF signals. There are some places where RF signals could constitute a hazard, such as health care facilities, and construction sites. If you are not sure, look around for signs indicating that two-way radios or mobile phones should be turned off. This device should be installed and operated with at least 20cm between the radiator and your body and is restricted to indoor use when operating in the 5.15 to 5.25 GHz frequency band. FCC Compliance Statement The Product and its related accessories like the remote and the adaptor (the “Products”) comply with part 15 of the FCC Rules. Operation of each Product is subject to the following two conditions: (1) each Product may not cause harmful interference, and (2) each Product must accept any interference received, including interference that may cause undesired operation. Note: The Products have been tested and found to comply with the limits for a Class B digital device or external switching power supply, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. The Products generate, use and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If a Product does cause harmful interference to radio or television reception, which can be determined by unplugging and plugging in the Product, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to a Product by the user that are not expressly approved by the party responsible for compliance could make the Product no longer comply with the FCC Rules. The Product and the remote meet the FCC Radio Frequency Emission Guidelines and are certified with the FCC. Information on these Products is on file with the FCC and can be found by inputting such Product’s FCC ID (which can be found on the back of the Product or in the battery compartment of the remote) into the FCC ID Search form available at transition.fcc.gov/oet/ea/fccid. Information Regarding Exposure to Radio Frequency Energy The output power of the radio technology used in the Products is below the radio frequency exposure limits set by the FCC. Nevertheless, it is advised to use the Products in such a manner that minimizes the potential for human contact during normal operation. Recycling Product Properly In some areas, the disposal of certain electronic devices is regulated. Make sure you dispose of or recycle the Products in accordance with your local laws and regulations. For information about recycling the Products, go to [Insert URL]. Product Specifications Ports: HDMI, Optical Audio, Ethernet, USB Video – [Supported Formats] Audio — [Supported Formats] Power — AC power adaptor Connectivity — Dual Band (2.4/5 GHz) SISO 802.11 a/b/g/n or Ethernet Operating temperature — 0 °C to 40 °C Storage temperature — [TO BE DETERMINED] Legal Terms Please read the terms found at [INSERT URL]. Limited Warranty [Insert warranty terms here]

FCC ID: S59 - 1214 The artwork is in the battery compartment on the back of the device.

Report No. : FA332717-03 Report Version : Rev. 01 Page Number : 1 of 5 RF Exposure Evaluation Report APPLICANT : Ailen LLC EQUIPMENT : Wireless Remote MODEL NAME : DU3560 FCC ID : S59-1214 STANDARD : 47 CFR Part 2.1093 FCC KDB 447498 D01 v05r01 We, SPORTON INTERNATIONAL INC., would like to declare that the device has been evaluated in accordance with 47 CFR Part 2.1093, and pass the limit. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager Report No. : FA332717-03 Report Version : Rev. 01 Page Number : 2 of 5 Table of Contents REVISION HISTORY .......................................................................................................................................... 3 1. ADMINISTRATION DATA ........................................................................................................................... 4 2.1 Testing Laboratory ............................................................................................................................. 4 2.2 Applicant ............................................................................................................................................ 4 2. GENERAL INFORMATION ......................................................................................................................... 4 3.1 Description of Device Under Test (DUT) ........................................................................................... 4 3.2 Maximum RF output power among production units ......................................................................... 5 3. CONDUCTED RF OUTPUT POWER (UNIT: DBM) .................................................................................... 5 4. RF EXPOSURE EVALUATION ................................................................................................................... 5 Report No. : FA332717-03 Report Version : Rev. 01 Page Number : 3 of 5 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA332717-03 Rev. 01 Initial issue of report Aug. 01, 2013 Report No. : FA332717-03 Report Version : Rev. 01 Page Number : 4 of 5 1. Administration Data 2.1 Testing Laboratory Test Site SPORTON INTERNATIONAL INC. Test Site Location No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. TEL: +886-3-327-3456 FAX: +886-3-328-4978 2.2 Applicant Company Name Ailen LLC Address P. O. Box 8125 Wilmington, DE 19803 2. General Information 3.1 Description of Device Under Test (DUT) Product Feature & Specification DUT Type Wireless Remote Model Name DU3560 FCC ID S59-1214 Wireless Technology and Frequency Range Bluetooth: 2402 MHz ~ 2480 MHz Mode Bluetooth 2.1 Antenna Type PIFA Antenna DUT Stage Production Unit Remark: The above DUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. Report No. : FA332717-03 Report Version : Rev. 01 Page Number : 5 of 5 3.2 Maximum RF output power among production units Mode / Band Bluetooth 1Mbps 2Mbps 3Mbps (GFSK) π/4-DQPSK (8-DPSK) 2.4GHz Bluetooth 4 4 4 3. Conducted RF Output Power (Unit: dBm) <Bluetooth Conducted Power> Channel Frequency (MHz) Average power (dBm) Mode GFSK π/4-DQPSK 8-DPSK CH 0 2402 2.36 2.45 2.35 CH 39 2441 2.53 2.59 2.43 CH 78 2480 1.56 1.69 1.58 4. RF Exposure Evaluation Bluetooth Max Power (dBm) mW Test Distance (mm) Frequency (GHz) exclusion thresholds 4 2.51 5 2.48 0.79 Note: 1. Per KDB 447498 D01v05r01, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison Conclusion: According to KDB 447498 D01v05r01 exclusion thresholds is 0.79 < 7.5, RF exposure evaluation is not required.

Report No. : FR332717-03 Report Version : Rev. 01 Page Number : 1 of 63 FCC RF Test Report APPLICANT : Ailen LLC EQUIPMENT : Wireless Remote MODEL NAME : DU3560 FCC ID : S59-1214 STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DSS) Spread Spectrum Transmitter The product was completely tested on Jul. 25, 2013. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown to be compliant with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Report No. : FR332717-03 Report Version : Rev. 01 Page Number : 2 of 63 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Feature of Equipment Under Test ..................................................................................................... 5 1.3 Product Specification of Equipment Under Test ................................................................................ 5 1.4 Modification of EUT ........................................................................................................................... 5 1.5 Testing Site ........................................................................................................................................ 6 1.6 Applied Standards ............................................................................................................................. 6 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1 Descriptions of Test Mode ................................................................................................................. 7 2.2 Test Mode .......................................................................................................................................... 8 2.3 Connection Diagram of Test System ................................................................................................. 8 2.4 Support Unit used in test configuration and system .......................................................................... 9 2.5 EUT Operation Test Setup ................................................................................................................ 9 2.6 Measurement Results Explanation Example ..................................................................................... 9 3 TEST RESULT .......................................................................................................................................... 10 3.1 Number of Channel Measurement .................................................................................................. 10 3.2 Hopping Channel Separation Measurement ................................................................................... 12 3.3 Dwell Time Measurement ................................................................................................................ 19 3.4 20dB Bandwidth Measurement ....................................................................................................... 22 3.5 Peak Output Power Measurement .................................................................................................. 29 3.6 Conducted Band Edges Measurement............................................................................................ 31 3.7 Conducted Spurious Emission Measurement ................................................................................. 38 3.8 Radiated Band Edges and Spurious Emission Measurement ........................................................ 48 3.9 Antenna Requirements .................................................................................................................... 61 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 62 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 63 Report No. : FR332717-03 Report Version : Rev. 01 Page Number : 3 of 63 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR332717-03 Rev. 01 Initial issue of report Aug. 11, 2013 Report No. : FR332717-03 Report Version : Rev. 01 Page Number : 4 of 63 SUMMARY OF TEST RESULT Report Section FCC Rule Description Limit Result Remark 3.1 15.247(a)(1) Number of Channels ≥ 15Chs Pass - 3.2 15.247(a)(1) Hopping Channel Separation ≥ 2/3 of 20dB BW Pass - 3.3 15.247(a)(1) Dwell Time of Each Channel ≤ 0.4sec in 31.6sec period Pass - 3.4 15.247(a)(1) 20dB Bandwidth NA Pass - 3.5 15.247(b)(1) Peak Output Power ≤ 125 mW Pass - 3.6 15.247(d) Conducted Band Edges ≤ 20dBc Pass - 3.7 15.247(d) Conducted Spurious Emission ≤ 20dBc Pass - 3.8 15.247(d) Radiated Band Edges and Radiated Spurious Emission 15.209(a) & 15.247(d) Pass Under limit 12.71 dB at 2483.530 MHz 3.9 15.203 & 15.247(b) Antenna Requirement N/A Pass - Report No. : FR332717-03 Report Version : Rev. 01 Page Number : 5 of 63 1 General Description 1.1 Applicant Ailen LLC P.O. Box 8125 Wilm…

Text truncated - open the document above for the full version.

Report Version : Rev. 01 Page Number : 1 of 1 Setup Photographs <Radiated Emission> LF HF
