S5XALK300-45VictelGlobal KH Digital Transceiver

ALK300 Series Transceiver Operation Manual Guangzhou VictelGlobal Communications Co., Ltd. April, 2013 OUTLINE 1.1 Configuration .............................................................................................................. 3 1.2 Functions ..................................................................................................................... 4 1.3 Working Environment ................................................................................................. 5 1.4 Power Supply Adaptation & Power Consumption ...................................................... 5 2 Operation Instruction ............................................................................................................. 5 2.1 Introduction of Panels & Interfaces ............................................................................ 5 2.1.1 Front Panel of ALK300 Series Transceivers .................................................... 5 2.1.2 Back View of the ALK300 Series Transceiver ................................................. 9 2.2 Wiring Method .......................................................................................................... 11 2.3 Hopping ..................................................................................................................... 11 2.3.1 Coding Switch of the Transceiver .................................................................. 11 2.4 Power On the Equipment .......................................................................................... 13 3 NMS Settings ....................................................................................................................... 13 4 Maintenance ......................................................................................................................... 13 4.1 Installation Environment ........................................................................................... 13 4.2 Report & Solution of Equipment Failures ................................................................. 14 4.3 Equipment Usage ...................................................................................................... 14 4.4 Cleaning of the Equipment Surface .......................................................................... 14 4.5 Equipment Grounding ............................................................................................... 14 5 Transportation ...................................................................................................................... 14 6 Contact: ................................................................................................................................ 16 1. General Introduction The ALK300 series transceiver of VictelGlobal adopts standard 19-inch 2U structure, fully modularized design and optimal design for heat dissipation. The front panel is equipped with high-speed bus line for connection between transceivers, the special wiring hole of which facilitates the installation, test and maintenance and makes the whole unit tidy. VictelGlobal has been granted the patent for structural design. The ALK300 series transceiver adopts dual PA design, greatly reducing the unit temperature, improving the unit stability and prolonging the unit life. The two PAs can work separately as two PAs and work altogether as backup for each other. 1.1 Configuration The digital transceiver is consisted of digital Rx & Tx module, power supply module, PA module, Carrier Control Module (CCM), hub board, satellite module and bus line board etc., which are connected via the bus line board. 1.2 Functions z RF Transmission The RF Tx module shall modulate the digitalized audio and digital/analogue signalling generated by CCM to the RF signal and then transmit it. z RF Reception The RF Rx module shall demodulate the digital/analogue signalling and audio signals after receiving the wireless signal and then send them to CCM for procession. z Rx & Tx Information Display The Rx field intensity and Tx power shall be displayed on the LED in the front panel. Together with the use of management software, the detailed parameters of the receiver and transceiver can be acquired. z Local Audio The local audio signal can be monitored via megaphone. z Channel Cascading Multiple transceivers can form one base station by connecting the interface of each transceiver via high-speed bus line. Usually the 1 st channel shall act as the control channel and all the rest channels shall act as traffic channels, the quantity of which can be increased flexibly by connecting more transceivers. 1.3 Working Environment z Working temperature: -30°C~60°C z Storage temperature: -40°C~85°C 1.4 Power Supply Adaptation & Power Consumption z AC: 90~260V (45~55Hz) z Power consumption: <350W 2 Operation Instruction 2.1 Introduction of Panels & Interfaces 2.1.1 Front Panel of ALK300 Series Transceivers 1— Button of ‘POWER’ and Power Supply LED Press the button ‘POWER’ to power on the transceiver with the power supply LED turned on. Press the button ‘POWER’ when the transceiver is under working status to power off the transceiver with the power supply LED turned off. 2— Button of ‘GATE’ & Rx LED Press the button ‘GATE’ to switch on the megaphone and the user shall be able to monitor the audio information received by the receiver. Press the button ‘GATE’ when the transceiver is under monitoring to switch off the megaphone. The Rx LED shall be turned on when the receiver receives valid signal, or it shall be turned off. 3— Button of ‘PTT’ & Tx LED Press the button ‘PTT’ to activate the PA long Tx. The PA long Tx can also be activated by touching the button ‘PTT’ twice. Touch the button ‘PTT’ once again to stop the PA long Tx. The Tx LED shall be turned on when the PA is under Tx status, or it shall be turned off. 4— Coordination Interface The NMS shall do various operations to the transceivers via the coordination interface, including data monitoring…

Text truncated - open the document above for the full version.

VictelGlobal Communications Corporation Limited FCC ID: S5XALK300-45 DATE: Aug 09 2013 To whom it may concern: We the undersigned, hereby authorize VictelGlobal Communications Corporation Limited. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Shenzhen Huatongwei International Inspection Co., Ltd on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from VictelGlobal Communications Corporation Limited. Sincerely yours, VictelGlobal Communications Corporation Limited. Yan zheng/ Manager Fax: +86-020-87222502 Tel: +86-18038053421 E-mail: [email protected]

VictelGlobal Communications Corporation Limited FCC ID: S5XALK300-45 DATE: Aug 09 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. VictelGlobal Communications Corporation Limited. would like the following documents regarding this submission for FCC ID: S5XALK300-45 to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation 4. Tune-Up Procedure 5． Part List The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, VictelGlobal Communications Corporation Limited. Yan zheng/ Manager Fax: +86-020-87222502 Tel: +86-18038053421 E-mail: [email protected]

Justification Letter DATE: Aug 09, 2013 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: S5XALK300-45 Model: ALK300-45 Dear Sir/Madam, We , VictelGlobal Communications Corporation Limited. acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorised frequencies inside the U.S.A. We , VictelGlobal Communications Corporation Limited. acknowledge this equipment meets the requirements of FCC Rules, Parts 90.203 (e) and (g) as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. Sincerely yours, VictelGlobal Communications Corporation Limited. Yan zheng/ Manager Fax: +86-020-87222502 Tel: +86-18038053421 E-mail: [email protected]

VictelGlobal Communications Corporation Limited Unity Extended Frequency Range – Contiguous Frequency Listing DATE: Aug 09, 2013 FCC ID: S5XALK300-45 Model: ALK300-45 Dear Sir/Madam, We, VictelGlobal Communications Corporation Limited. acknowledge that this device is for use in Part 90, additionally, Federal end users are intended per Part 2.103 (a). The frequency bands are: 40 0 -470 MHz Part 2.106 has been used to construct the following table of frequency range capability intended for end users. VictelGlobal Communications Corporation Limited. acknowledges that operation on unauthorized frequencies is a violation of FCC rules. VictelGlobal Communications Corporation Limited. acknowledges the inclusion of Grant note code “EF”. Freq(MHz) Part 90 Federal 400-406.1 X 406.1-420 X 420-454 X 454-456 X 456-462.5375 X 462.5375-462.7375 X 462.7375-467.5375 X 467.5375-467.7375 X 467.7375-470 X Sincerely yours, VictelGlobal Communications Corporation Limited. Yan zheng/ Manager Fax: +86-020-87222502 Tel: +86-18038053421 E-mail: [email protected]

External photos of the EUT

FCC Label RF Warning Label

Internal photos of the EUT

MPE TEST REPORT FCC Per 47 CFR 2.1091(b) Report Reference No. .................... : FCC ID. ............................................ : TRE1301007602 R/C: 89798 S5XALK300-45 Compiled by ( position+printed name+signature) .. : File administrators Jerome Luo Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Aug 09, 2013 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : VictelGlobal Communications Corporation Limited Address ............................................. : FLAT/RM 803 8/F C C WU BLDG 302-308 HENNESSY RD WANCHAI, Hong Kong, China Test specification: Standard ........................................... : FCC Per 47 CFR 2.1091(b) KDB447498 v05r01 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : VictelGlobal KH Digital Transceiver Trade Mark ....................................... : Manufacturer .................................... : Guangzhou Victel Technology Co., Ltd Model/Type reference ....................... : ALK300-45 Listed Models .................................. : / Ratings .............................................. : AC 120V/60Hz Modulation ....................................... : FM&4FSK Channel Separation ........................... 12.5KHz Rated Power ..................................... 50 Watts(46.98dBm)/15 Watts(41.76dBm) Operation Frequency Range ............. From 400 MHz to 470 MHz Result ................................................ : Positive Report No.: TRE1301007602 Page 2 of 7 Issued:2013-08-09 MPE T E S T R E P O R T Test Report No. : TRE1301007602 Aug 09, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : VictelGlobal KH Digital Transceiver Model /Type : ALK300-45 Listed Models : / Applicant : VictelGlobal Communications Corporation Limited Address : FLAT/RM 803 8/F C C WU BLDG 302-308 HENNESSY RD WANCHAI, Hong Kong, China Manufacturer Guangzhou Victel Technology Co., Ltd Address : 13th Building, No.161 DongGuanZhuang Road, Tianhe District, Guangzhou, China The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1301007602 Page 3 of 7 Issued:2013-08-09 Contents 1. SUMMARY ............................................................................. 4 1.1. EUT configuration 4 1.2. NOTE 4 2. TEST ENVIRONMENT ............................................................... 5 2.1. Address of the test laboratory 5 2.2. Environmental conditions 5 2.3. Statement of the measurement uncertainty 5 3. METHOD OF MEASUREMENT .................................................... 5 3.1. Applicable Standard 5 3.2. Limit 6 3.3. MPE Calculation Method 6 4. CONCLUSION ........................................................................ 7 Report No.: TRE1301007602 Page 4 of 7 Issued:2013-08-09 1. SUMMARY 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab ○ Power Cable Length (m) : / Shield : / Detachable : / ○ Multimeter Manufacturer : / Model No. : / 1.2. NOTE 1. The EUT is a U frequency band (400-470MHz) VictelGlobal KH Digital Transceiver,The functions of the EUT listed as below: Test Standards Reference Report Radio FCC Part 90 TRE1301007601 MPE Oet 65 TRE1301007602 . Report No.: TRE1301007602 Page 5 of 7 Issued:2013-08-09 2. TEST ENVIRONMENT 2.1. Address of the test laboratory Shenzhen Huatongwei International Inspection Co., Ltd Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Phone: 86-755-26715686 Fax: 86-755-26748089 The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 (2009) and CISPR Publication 22. 2.2. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 950-1050mbar 2.3. Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report acc. to TR-100028-01” Electromagnetic compatibility and Radio spectrum Matters (ERM);Uncertainties in the measurement of mobile radio equipment characteristics; Part 1” and TR-100028-02 “Electromagnetic compatibility and Radio spectrum Matters (ERM);Uncertainties in the measurement of mobile radio equipment characteristics; Part 2 “ and is documented in the Shenzhen Huatongwei International Inspection Co., Ltd quality system acc. to DIN EN ISO/IEC 17025. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. The manufacturer has the sole responsibility of continued compliance of the device. Hereafte…

Text truncated - open the document above for the full version.

FCC PART 90 TEST REPORT FCC Part 90 Report Reference No. ..................... : FCC ID. ............................................. : TRE1301007601 R/C: 89798 S5XALK300-45 Compiled by ( position+printed name+signature) .. : File administrators Jerome Luo Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Aug 23, 2013 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : VictelGlobal Communications Corporation Limited Address............................................. : FLAT/RM 803 8/F C C WU BLDG 302-308 HENNESSY RD WANCHAI, Hong Kong, China Test specification: Standard ........................................... : FCC Part 90: PRIVATE LAND MOBILE RADIO SERVICES TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: VictelGlobal KH Digital Transceiver Trade Mark ....................................... : Manufacturer .................................... : Guangzhou Victel Technology Co., Ltd Model/Type reference ....................... : ALK300-45 Listed Models .................................. : / Ratings.............................................. : AC 120V/60Hz Modulation ....................................... : FM&4FSK Channel Separation ........................... 12.5KHz Rated Power ..................................... 50 Watts(46.98dBm)/15 Watts(41.76dBm) Operation Frequency Range ............. From 400 MHz to 470 MHz Result ................................................ : Positive Report No.: TRE1301007601 Page 2 of 101 Issued:2013-08-23 T E S T R E P O R T Test Report No. : TRE1301007601 Aug 23, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : VictelGlobal KH Digital Transceiver Model /Type : ALK300-45 Listed Models : / Applicant : VictelGlobal Communications Corporation Limited Address : FLAT/RM 803 8/F C C WU BLDG 302-308 HENNESSY RD WANCHAI, Hong Kong, China Manufacturer : Guangzhou Victel Technology Co., Ltd Address : 13th Building, No.161 DongGuanZhuang Road, Tianhe District, Guangzhou, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1301007601 Page 3 of 101 Issued:2013-08-23 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 6 2.5. EUT Configuration 6 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 6 2.9. Modifications 6 2.10. Note 7 3. TEST ENVIRONMENT 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 9 3.4. Configuration of Tested System 9 3.5. Discription of Tested Modes 9 3.6. Statement of the measurement uncertainty 9 3.7. Test Description 10 3.8. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS 12 4.1. Conducted Emissions Test 12 4.2. Occupied Bandwidth and Emission Mask Test 17 4.3. Transmitter Radiated Spurious Emssion 35 4.4. Spurious Emssion on Antenna Port 42 4.5. Modulation Charcateristics 74 4.6. Frequency Stability Test 77 4.7. Maximum Transmitter Power 79 4.8. Transmitter Frequency Behavior 90 5. TEST SETUP PHOTOS OF THE EUT 93 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 95 Report No.: TRE1301007601 Page 4 of 101 Issued:2013-08-23 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 90: PRIVATE LAND MOBILE RADIO SERVICES. TIA/EIA 603 D June 2010: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. 47 CFR FCC Part 15 Subpart B: - Unintentional Radiators FCC Part 2: FREQUENCY ALLOCA-TIONS AND RADIO TREATY MAT-TERS; GENERAL RULES AND REG-ULATIONS Report No.: TRE1301007601 Page 5 of 101 Issued:2013-08-23 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Jan 20, 2013 Testing commenced on : Jan 20, 2013 Testing concluded on : Aug 23, 2013 2.2. Product Description The VictelGlobal Communications Corporation Limited.’s Model: ALK300-45 or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT VictelGlobal KH Digital Transceiver Model Number ALK300-45 FCC ID SSXALK300-45 Rated Output Power 50 Watts(46.98dBm)/15 Watts(41.76dBm) Support data rate 9.6kbps Modilation Type FM for Analog Voice 4FSK for Digital Voice/Digital Data 4FSK for Digital Data Analog 11K0F3E for 12.5KHz Channel Separation Digital 7K60FXD for Digital Data only 7K60FXW for Digital Data & Digital Voice Channel Separation Analog 12.5KHz Digital Voice/Data 12.5KHz Digital Data 12.5KHz Antenna Type External Frequency Range From 400 MHz to 470 MHz Maximum Transmitter Power Analog 57.67W for 12.5 KHz Channel Separation Digital 57.15W for 12.5 KHz Channel Separation Note: The product has the same digital wor…

Text truncated - open the document above for the full version.

FCC PART 90 TEST REPORT FCC Part 90 Report Reference No. ..................... : FCC ID. ............................................. : TRE1301007601 R/C: 89798 S5XALK300-45 Compiled by ( position+printed name+signature) .. : File administrators Jerome Luo Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Aug 23, 2013 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : VictelGlobal Communications Corporation Limited Address............................................. : FLAT/RM 803 8/F C C WU BLDG 302-308 HENNESSY RD WANCHAI, Hong Kong, China Test specification: Standard ........................................... : FCC Part 90: PRIVATE LAND MOBILE RADIO SERVICES TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: VictelGlobal KH Digital Transceiver Trade Mark ....................................... : Manufacturer .................................... : Guangzhou Victel Technology Co., Ltd Model/Type reference ....................... : ALK300-45 Listed Models .................................. : / Ratings.............................................. : AC 120V/60Hz Modulation ....................................... : FM&4FSK Channel Separation ........................... 12.5KHz Rated Power ..................................... 50 Watts(46.98dBm)/15 Watts(41.76dBm) Operation Frequency Range ............. From 400 MHz to 470 MHz Result ................................................ : Positive Report No.: TRE1301007601 Page 2 of 102 Issued:2013-08-23 T E S T R E P O R T Test Report No. : TRE1301007601 Aug 23, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : VictelGlobal KH Digital Transceiver Model /Type : ALK300-45 Listed Models : / Applicant : VictelGlobal Communications Corporation Limited Address : FLAT/RM 803 8/F C C WU BLDG 302-308 HENNESSY RD WANCHAI, Hong Kong, China Manufacturer : Guangzhou Victel Technology Co., Ltd Address : 13th Building, No.161 DongGuanZhuang Road, Tianhe District, Guangzhou, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1301007601 Page 3 of 102 Issued:2013-08-23 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 6 2.5. EUT Configuration 6 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 6 2.9. Modifications 6 2.10. Note 7 3. TEST ENVIRONMENT 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 9 3.4. Configuration of Tested System 9 3.5. Discription of Tested Modes 9 3.6. Statement of the measurement uncertainty 9 3.7. Test Description 10 3.8. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS 12 4.1. Conducted Emissions Test 12 4.2. Occupied Bandwidth and Emission Mask Test 17 4.3. Transmitter Radiated Spurious Emssion 35 4.4. Spurious Emssion on Antenna Port 42 4.5. Modulation Charcateristics 74 4.6. Frequency Stability Test 77 4.7. Maximum Transmitter Power 79 4.8. Transmitter Frequency Behavior 90 5. TEST SETUP PHOTOS OF THE EUT 94 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 96 Report No.: TRE1301007601 Page 4 of 102 Issued:2013-08-23 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 90: PRIVATE LAND MOBILE RADIO SERVICES. TIA/EIA 603 D June 2010: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. 47 CFR FCC Part 15 Subpart B: - Unintentional Radiators FCC Part 2: FREQUENCY ALLOCA-TIONS AND RADIO TREATY MAT-TERS; GENERAL RULES AND REG-ULATIONS Report No.: TRE1301007601 Page 5 of 102 Issued:2013-08-23 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Jan 20, 2013 Testing commenced on : Jan 20, 2013 Testing concluded on : Aug 23, 2013 2.2. Product Description The VictelGlobal Communications Corporation Limited.’s Model: ALK300-45 or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT VictelGlobal KH Digital Transceiver Model Number ALK300-45 FCC ID SSXALK300-45 Rated Output Power 50 Watts(46.98dBm)/15 Watts(41.76dBm) Support data rate 9.6kbps Modilation Type FM for Analog Voice 4FSK for Digital Voice/Digital Data 4FSK for Digital Data Analog 11K0F3E for 12.5KHz Channel Separation Digital 7K60FXD for Digital Data only 7K60FXW for Digital Data & Digital Voice Channel Separation Analog 12.5KHz Digital Voice/Data 12.5KHz Digital Data 12.5KHz Antenna Type External Frequency Range From 400 MHz to 470 MHz Maximum Transmitter Power Analog 57.67W for 12.5 KHz Channel Separation Digital 57.15W for 12.5 KHz Channel Separation Note: The product has the same digital wor…

Text truncated - open the document above for the full version.

Test setup photos of the EUT
