S6Z91505-1433MHz RF Rain Gauge Transmitter

WIRELESS DIGITAL RAIN GAUGE WITH INDOOR / OUTDOOR THERMOMETER Model No. 91505-1 Instruction Manual Rain Collector/Remote SensorBase Unit Size: 12cm x 12cm Total 12pagesP.1 (Cover) FEATURES AND SPECIFICATIONS BASE UNIT: • RF rainfall and temperature measurement • Rainfall history tracking: last hour, last 24 hours, daily, weekly and monthly • Bar chart display for rainfall history • Daily Min. / Max. rainfall tracking with auto daily clearing • Features Decline Principal Rain Measurement Technology* • Indoor / RF outdoor temperature, auto scroll • Indoor temperature range: 32∞F to 122∞F (0∞C to 50∞C) • ∞C/∞F selectable • Memory function to recall Min./Max. temperature readings • Temperature trend arrow indicates rising, falling or constant temperature • Programmable, audible high / low temperature alert • 12 or 24 hour selectable clock • Calendar with day of the week display • Low battery indicator for base station and rain collector • Table top stand or wall mount • Requires 2 AA batteries (not included) RAIN COLLECTOR / REMOTE SENSOR: • Self-emptying, waterproof with oversized collection area • Wide base to minimize tip-over • Transmission range: 100 ft. (range may be shorter based on interference present) • Transmission frequency: 433MHz • Outdoor temperature range: -4∞F to 140∞F (-20∞C to 60∞C) • Includes (2) stainless steel screws and (2) spikes for mounting to solid surface or ground • Requires 2 AA batteries (not included) P.2 Clock Mode ( +) In-Out Temp Max/Min AlertRe-sync Re-sync Reset Reset History Clear ( - ) P.3 BATTERY INSTALLATION AND ACTIVATION Warning: • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon zinc), or rechargeable (nickel cadmium) batteries. • For maximum performance in normal conditions we recommend using good quality alkaline batteries. When temperatures are below 32∞F, alkaline batteries can lose power resulting in a loss of remote transmission. If you reside in an area that experiences frequent temperatures below freezing, we recommend using lithium batteries to minimize the loss of transmission. Battery installation of Base Unit • Open the battery door at the back of the base unit and insert (2) AA batteries according to the polarity markings. Replace the battery door. • Insert the end of a paper clip into the hole in RESET and push the button. • Set the clock and calendar as follows. Setting the Calendar, Clock, ∞C / ∞F: • When either the clock or calendar is being displayed, press and hold the MODE button for 3-4 seconds until the year display is flashing • Press + or – to set the year • Press MODE to display the date • Press + or – to set the month and day • Press MODE to display time • Press + or – to set the time • Press MODE and the display will show 12 hr • Press + or – to set your clock to 12 hr or 24 hr time format • Press MODE and the temperature field will be flashing • Press + or – to select ∞F or ∞C format • Press MODE to lock in the settings P.4 Note: If you set the time and date after initial activation, the accuracy of the rainfall history data may be affected. Reset the unit to clear the history by pressing the RESET button then set your desired time and date. • Press the RE-SYNC button. • Position the Rain Collector/Remote Sensor close to the base unit. Battery installation of Rain collector • Press the hook and open the rain collector unit outer case and remove the inner cover to access RESET/RE-SYNC buttons. • Using a coin, unscrew the battery door at the bottom of the rain collector and insert (2) AA batteries according to the polarity markings. • Press the RESET button. • Replace the battery door. • Remove the tape from the pendulum inside to allow it to move freely. • Close the outer case. Note : Make sure the battery door is closed securely to prevent water leakage. • When the OUT temperature is shown on the display of the base unit, synchronization between the base unit and the remote sensor is complete. POWER UP SYNCHRONIZATION The base unit will search for the RF signal from the rain collector for 6 minutes after reset or after batteries are inserted. When the temperature display on the main unit shows the OUT temperature, synchronization between the base unit and remote unit is complete. P.5 The top, left of the base unit display will show the icon to indicate signal transmission. If the OUT temperature does not show on the display within 6 minutes after reset, press the RE-SYNC button and the main unit will search for the RF signal for another 6 minutes. If the base unit still fails to show the out temperature, refer to the LOSING SYNCHRONIZATION section. Locating the Base Unit and Remote Sensor • Choose a suitable place for the base unit and remote outdoor sensor, within the transmission distance. • Place the base unit near a window, but away from direct sunlight or sources of heat or air conditioning to ensure accurate temperature readings. • The location you choose is critical for maximizing the transmission range. The remote sensor is designed to transmit unimpeded 80 to 100 ft. Transmitting through walls, metal doors and metal framed windows may reduce the transmission range. To optimize the transmission distance, the remote unit should be positioned in a location that minimizes these obstructions. Other interference from electrical sources such as home security systems, wireless doorbells and wireless home entertainment equipment may interrupt the transmission signal temporarily. Notes: • The outdoor rain collector must be placed on a level, horizontal surface for accurate rainfall measurement. • Warning: Ice will affect the accuracy of rainfall readings and will damage the internal mechanism of the rain collector. In temperatures below freezing the collector can remain outdoors for temperature data transmission, but the unit must be placed in a protected area to prevent ice damage. INDOOR AND OUTDOOR TEMPERATURE • The indoor temperature is shown after activation until the first outdoor temperatur…

Text truncated - open the document above for the full version.

Block Diagram of 9 330 ( Tx ) Power System Frequency 433.95 MHz 32.768kHz (i) Raw Data RF Part Base Band (i) The 32.768kHz is the MCU clock frequency for normal operation. Antenna Matching network MCU IC: TM8712 SAW stabilized Colpitts Oscillator Reed switch Key Matrix Moving Magnet Thermometer sensor

Test Setup FCC ID : PEQ933040605 External Photo - Front External Photo - Rear

Test Setup FCC ID : PEQ933040605 Internal Photo - 1 Internal Photo - 2 Test Setup FCC ID : PEQ933040605 Internal Photo - 3 Internal Photo – 4 Test Setup FCC ID : PEQ933040605 Internal Photo - 5 Internal Photo – 6 Test Setup FCC ID : PEQ933040605 Internal Photo – 7

Technical Description of the Circuit: The circuit is a RF rain gauge transmitter, the MCU TM8712 will measure the rain fall by the reel switch accompanied with the moving magnet on the tipping bucket and code the data, also there is a thermometer sensor to measure the temperature and the MCU will code the temperature into digital data. Afterward, the data is transferred to the RF circuit which is a SAW stabilized Colpitts Oscillator ( Constructed by Q1, L1, L2, C1, C2, C3, C4, C5, R1, R3 and X1 ) every 3 minutes, when the Data pin output HIGH level to the oscillator, the oscillator is turned on and output 433.95MHz RF signal, when the Data pin output LOW level to the oscillator, the oscillator is turned off and this ON & OFF process modulate the code data into 433.95MHz with ON OFF KEYING.. Also there is an antenna matching network ( Constructed by C7, C8, L3 and L4 ) after the SAW stabilized Colpitts Oscillator, this network suppress harmonic and spurious and match the Oscillator to the antenna.

X1 : 433.92MHz Q1 : 2SC3356

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2371 0521 Website: www.hk.intertek-etlsemko.com Electronics Tomorrow Ltd. Application For Certification (FCC ID: PEQ933040605) Transmitter 05115581 DL/ Sandy Lee July 18, 2005 INTERTEK TESTING SERVICES FCC ID: PEQ933040605 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: PEQ933040605 ii MEASUREMENT/TECHNICAL REPORT Electronics Tomorrow Ltd. - MODEL: 9330 FCC ID: PEQ933040605 July 18, 2005 This report concerns (check one:) Original Grant X Class II Change Equipment Type: Low Power Transmitter (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [12-08-03 Edition] provision. Report prepared by: Derek Leung Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8539 Fax: 852-2371-0521 INTERTEK TESTING SERVICES FCC ID: PEQ933040605 iii Table of Contents 1.0 General Description..............................................................................................2 1.1 Product Description ..............................................................................................2 1.2 Related Submittal(s) Grants .................................................................................2 1.3 Test Methodology.................................................................................................3 1.4 Test Facility ..........................................................................................................3 2.0 System Test Configuration ...................................................................................5 2.1 Justification ..........................................................................................................5 2.2 EUT Exercising Software .....................................................................................5 2.3 Special Accessories .............................................................................................5 2.4 Equipment Modification ........................................................................................6 2.5 Measurement Uncertainty ....................................................................................6 2.6 Support Equipment List and Description ..............................................................6 3.0 Emission Results ..................................................................................................8 3.1 Field Strength Calculation ....................................................................................9 3.2 Radiated Emission Configuration Photograph ....................................................11 3.3 Radiated Emission Data.....................................................................................12 4.0 Equipment Photographs .....................................................................................15 5.0 Product Labelling ................................................................................................17 6.0 Technical Specifications ....................................................................................19 7.0 Instruction Manual ..............................................................................................21 8.0 Miscellaneous Information .................................................................................23 8.1 Measured Bandwidth .........................................................................................24 8.2 Discussion of Pulse Desensitization ...................................................................25 8.3 Calculation of Average Factor ............................................................................26 8.4 Emissions Test Procedures................................................................................27 INTERTEK TESTING SERVICES FCC ID: PEQ933040605 iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission radiated photos.doc Test Report Bandwidth Plot bw.pdf External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf Test Report Timing Diagram timing.pdf INTERTEK TESTING SERVICES FCC ID: PEQ933040605 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: PEQ933040605 2 1.0 General Description 1.1 Product Description The Equipment Under Test (EUT) is a Transmitter operating at 433.95MHz. The EUT is powered by 3V d.c. (2 x 1.5V “AA” battery). It transmit rainfall and temperature signals to the corresponding receiver. The rainfall and temperature readings will be d…

Text truncated - open the document above for the full version.

Test Setup FCC ID : PEQ933040605 Radiated Photo - Front Radiated Photo - Rear RADIATED Model No.: 9330 Job No.: 05115581 RADIATED Model No.: 9330 Job No.: 05115581
