SC2 Manual SC2 Charging SC2 Red LED: Charging Blue LED: Fully charged Power On/Off SC2 Press and hold the Multi-function Button for 1 second SC2 Remote Control Tap the Center Button Volume Adjustment (+) Button - Increase the volume (-) Button - Decrease the volume Battery Check Phone, Music Pairing 1. Press the Center Button for 10 seconds. 2. Press the (+) Button to enter into Phone Pairing 3. Search for Bluetooth devices on your mobile phone. Select the SC2 in the list of the devices detected on the mobile phone. 4. Enter 0000 for the PIN. Some mobile phones may not ask for the PIN. Music Operation Play or pause music: Press the Center Button for 1 second. Track back: Press the (-) Button for 1 second. Track forward: Press the (+) Button for 1 second. Mobile Phone Call Making and Answering Answering a call: Tap the Center Button Ending a call: Press the Center Button for 2 seconds. Voice dial: Press the Center Button for 3 seconds. Speed dial: Press the (+) Button for 3 seconds. Rejecting a call: Press the (+) Button for 2 seconds. Intercom Intercom Pairing 1. Press and hold the Center Button of two headsets for 5 seconds until red LEDs of both units start to flash rapidly. 2. The SC2 will automatically pair with a Sena headset Intercom Start/End : Tap the Center Button Mesh Intercom Mesh Intercom On/Off : Tap the Mesh Button Radio On/Off Turn on the FM radio: Press the (-) Button for 1 second. Turn off the FM radio: Press the (-) Button for 1 second. Radio Scan Up FM Band Start scanning: Press (+) Button for 1 second. Stop scanning: Press (+) Button for 1 second. Radio Seek Stations Seek up stations: Double tap the (+) Button. Seek down stations: Double tap the (-) Button. Setting Configuration Menu: Press the Center Button for 10 seconds. Troubleshooting SC2 Factory Reset If you want to restore the SC2 to factory default settings, press and hold the Multi-function Button for 12 seconds. The SC2 automatically restores the default settings and turns off. Certification and Safety Approvals FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antennae -Increase the separation between the equipment and the receiver -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC RF Exposure Statement This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. The antenna used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. When equipped, the distance between antenna and one’s head surface is 40.9mm. FCC Caution Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. Industry Canada(IC) Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1)this device may not cause interference, and (2)this device must accept any interference, including interference that may cause undesired operation of the device. Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisee aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement. IC RF Exposure Statement Cet équipement est conforme aux limites d'exposition aux radiations de la FCC définies pour un environnement non contrôlé. Les utilisateurs finaux doivent suivre les instructions d'utilisation spécifiques pour satisfaire à la conformité d'exposition RF. L'antenne utilisée pour cet émetteur ne doit pas émettre simultanément avec d'autres antennes ou émetteurs, sauf en conformité avec les procédures FCC relatives aux produits multi-émetteurs. Lorsque équipé, la distance entre l’antenne et la surface de la tête est de 40.9mm.

SENA TECHNOLOGIES.Inc Sep 7 th , 2022 Applicant: SENA TECHNOLOGIES.Inc FCC ID: S7A-SP127 / IC: 8154A-SP127 To. Whom it may concern: We, Sena Technologies,Inc. declare that when equipped, the distance between antenna and one’s head surface is 40.9mm. Seunghyun Kim, Research Engineer

SENA TECHNOLOGIES.Inc 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, South Korea Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: S7A-SP127 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description Part List [SP127] BLK [SP127] SCH [SP127] OpDes [SP127] Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name External Photos Internal Photos Test Setup Photos Manual [SP127] EXT Photo [SP127] INT Photo [SP127] Test Setup Photo [SP127] Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, Seunghyun KIM / Research Engineer

SENA TECHNOLOGIES.Inc 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, South Korea Sep 16, 2022 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Letter of Authorization We, the undersigned, hereby authorize Yong-Min, Won of EMC Labs Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: S7A-SP127 / IC: 8154A-SP127 including signing of all documents relating to these matters. Any and all acts carried out by Yong-Min, Won of EMC Labs Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from SENA TECHNOLOGIES.Inc “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Seunghyun KIM / Research Engineer

SENA_SP127_Label & Location Label Location (Rear)

Internal Battery BT Antenna MESH Antenna

Model Name : FCC ID : (mm)(dBm)(dB)(dBm)(mW) 240216.4916.9950.003.00PASS 244116.8017.3053.703.00PASS 248015.7216.2241.883.00PASS 24025.205.703.723.00PASS 24415.355.853.853.00PASS 24803.904.402.753.00PASS 24025.976.474.443.00PASS 24416.166.664.633.00PASS 24804.685.183.303.00PASS 24021.882.381.733.00PASS 24421.411.911.553.00PASS 24800.120.621.153.00PASS 241015.7716.2742.363.00PASS 244515.5016.0039.813.00PASS 247515.3015.8038.023.00PASS S7A-SP127Separation distance : 40.9 mm MPE Calculation KDB 447498 - 4.3.1 a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where - f(GHz) is the RF channel transmit frequency in GHz - Power and distance are rounded to the nearest mW and mm before calculation - The result is rounded to one decimal place for comparison SP127Device Category : Portable device Standalone SAR Test exclusion thresholds for 100MHz to 6GHz at test separation distance ≤ 50 mm LimitResult GFSK 40.90± 0.50 1.8948 2.0514 1.6125 Modulation Frequency (MHz) Min. Test separation distance Measured Maximum Average power Tune-up tolerance Max. Power with tune-up tolerance π/4DQPSK 40.90± 0.50 0.1408 0.1469 0.1060 8DPSK 40.90± 0.50 0.1681 0.1770 0.1269 BT LE 40.90± 0.50 0.0655 0.0593 0.0444 1.6080 1.5220 1.4624 MESH 40.90± 0.50

2018.04.24 RA-N0211-16 APPROVAL SHEET MODEL: SENA_10A Antenna layout ReviewConsentApproval Messrs. SENA Technology Co.,Ltd RadiNa Co. ,Ltd TEL:+82-2-463-0373 FAX:+82-2-463-0374 PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 2 / 11 RADINA. Co., LTD Table of contents 1. Revision History 2. Product Information 2.1 General Features 2.2 Electrical Specifications 3. Pattern Specifications 4. Electrical Characteristics 4.1 VSWR 4.2 Smith Chart 4.3 3D-PLOT 4.4 2D-GAIN 5. Passive Measurement 6. Measurement Process PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 3 / 11 RADINA. Co., LTD 1.Revision History NO.BeforeAfterReasonDate 1 2 3 4 5 6 7 8 9 10 11 12 13 PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 4 / 11 RADINA. Co., LTD 2.Product Information 2.1 General Features PART NUMBERGradiANT ANTENNA TYPEDipole Antenna APPLICATIONSBluetooth 2.2 Electrical Specifications Frequency Range1 (TX)2400MHz~2485MHz Frequency Range1 (RX)2400MHz~2485MHz IMPEDANCE50 V.S.W.R TX 2400MHz2485MHz 5↓5↓ RX 2400MHz2485MHz 5↓5↓ RADIATION PATTERNOmni-directional POLARIZATIONLinear PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 5 / 11 RADINA. Co., LTD 3.Pattern Specifications PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 6 / 11 RADINA. Co., LTD 4.Electrical Characterristics 4.1 VSWR 4.2 SMITH CHART PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 7 / 11 RADINA. Co., LTD 4.3 3D-PLOTs 2400MHZ 2445MHZ 2485MHZ PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 8 / 11 RADINA. Co., LTD 4.4 2D-GAIN 2400MHZ 2445MHZ 2485MHZ PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 9 / 11 RADINA. Co., LTD 5.Passive Measurement 12345678910 Frequency(MHz) 2400240524102415242024252430243524402445 Efficiency(dB) -1.68-1.80-1.94-1.86-1.90-1.74-1.75-1.73-1.75-1.59 Efficiency(%) 67.8966.0964.0165.1264.6466.9466.8267.2166.8569.31 TRG(dB) -1.68-1.80-1.94-1.86-1.90-1.74-1.75-1.73-1.75-1.59 TRG Theta (dB) -7.75-7.86-7.96-7.93-7.94-7.74-7.63-7.59-7.55-7.37 TRG Phi (dB) -2.92-3.04-3.19-3.10-3.14-3.00-3.05-3.03-3.07-2.92 UHRG(dB) -4.25-4.42-4.61-4.57-4.66-4.54-4.56-4.58-4.58-4.40 UHRG/TRG(%) 55.3654.6654.0853.6152.9252.4752.3251.7752.1652.41 H-Plane -16.43-16.82-17.16-16.92-17.80-17.65-17.12-18.21-17.86-18.24 E1-Plane, AVG(dB) -18.08-18.72-18.99-18.12-18.40-17.95-17.92-18.05-17.95-18.26 E2-Plane, AVG(dB) -2.94-3.13-3.04-3.08-3.02-2.80-2.64-2.60-2.69-2.43 Peak Gain(dB) 2.101.821.511.511.471.561.271.131.271.35 Directivity(dB) 3.783.623.443.373.363.303.022.863.022.94 Minimum Gain(dB) -16.63-16.38-17.22-17.64-16.71-17.63-18.36-20.13-19.16-17.51 11121314151617181920 Frequency(MHz) 2450245524602465247024752480248524902497 Efficiency(dB) -1.63-1.53-1.53-1.53-1.56-1.45-1.55-1.57-1.49-1.41 Efficiency(%) 68.7870.3170.3870.3869.7571.5769.9469.6771.0372.22 TRG(dB) -1.63-1.53-1.53-1.53-1.56-1.45-1.55-1.57-1.49-1.41 TRG Theta (dB) -7.31-7.16-7.20-7.11-7.04-6.96-7.15-7.13-6.95-6.87 TRG Phi (dB) -2.99-2.92-2.90-2.93-3.01-2.89-2.95-2.98-2.94-2.87 UHRG(dB) -4.44-4.30-4.33-4.30-4.31-4.18-4.23-4.24-4.12-3.99 UHRG/TRG(%) 52.3152.8552.4252.7853.1253.3853.9554.0954.5155.19 H-Plane -17.93-18.53-17.86-17.91-18.29-17.68-18.03-17.86-18.38-17.21 E1-Plane, AVG(dB) -17.62-17.53-17.37-17.48-17.12-17.14-17.82-17.86-17.59-17.27 E2-Plane, AVG(dB) -2.34-2.18-2.27-2.29-2.24-2.18-2.31-2.44-2.33-2.27 Peak Gain(dB) 1.491.641.611.811.651.861.761.891.992.20 Directivity(dB) 3.123.173.133.333.213.313.323.463.483.62 Minimum Gain(dB) -21.04-20.55-19.59-18.15-18.18-19.91-19.49-17.99-19.05-16.16 Average Efficiency-1.65dBi,68.44% Peak Gain2.10dBi
