S7A-SP140S1

Expand Mesh Manual Charging Red LED: Charging Blue LED: Fully charged Power On/Off (+) Button + Center Button for 1 sec Volume Adjustment (+) Button - Increase the volume (-) Button - Decrease the volume Battery Check (-) Button (+) Button Center Button LED Button Status LED DC Power Charging Phone, Music Pairing Initially Pairing the Cast The headset will automatically enter the phone pairing mode when you initially turn on the headset or in the following situation: • Rebooting after executing Factory Reset 1. Press and hold the Center Button and (+) Button for 1 second. 2. Search for Bluetooth devices on your mobile phone. Select the S1 in the list of the devices detected on the mobile phone. 3. Enter 0000 for the PIN. Some mobile phones may not ask for the PIN. Music Operation Play or pause music: Press the Center Button for 1 second. Track back: Press the (-) Button for 1 second. Track forward: Press the (+) Button for 1 second. Mobile Phone Call Making and Answering Answering a call: Tap the Center Button Ending a call: Press the Center Button for 2 seconds. Voice dial: Press the Center Button for 3 seconds. Speed dial: Press the (+) Button for 3 seconds. Rejecting a call: Press the Center Button for 2 seconds. Mesh Intercom On/Off Mesh Intercom On : Tap the M Button. Mesh Intercom Off : Tap the M Button. Setting Configuration Menu: Press the Center Button for 10 seconds. Troubleshooting Factory Reset If you want to restore the headset to factory default settings, use the Factory Reset in the configuration menu. The headset automatically restores the default settings and turns off. Certification and Safety Approvals FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antennae -Increase the separation between the equipment and the receiver -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC RF Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. The antenna used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. When equipped, the distance between antenna and one’s head surface is 23.8mm. FCC Caution Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. Industry Canada(IC) Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1)this device may not cause interference, and (2)this device must accept any interference, including interference that may cause undesired operation of the device. Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisee aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement. IC RF Exposure Statement Cet équipement est conforme aux limites d'exposition aux radiations de la FCC définies pour un environnement non contrôlé. Les utilisateurs finaux doivent suivre les instructions d'utilisation spécifiques pour satisfaire à la conformité d'exposition RF. L'antenne utilisée pour cet émetteur ne doit pas émettre simultanément avec d'autres antennes ou émetteurs, sauf en conformité avec les procédures FCC relatives aux produits multi-émetteurs. Lorsque équipé, la distance entre l’antenne et la surface de la tête est de 23.8mm.

SENA TECHNOLOGIES.Inc January 16, 2023, Applicant: SENA TECHNOLOGIES.Inc FCC ID: S7A-SP140 / IC: 8154A-SP140 To. Whom it may concern: 1. RF connector for MESH antenna is MMCX type. Seunghyun Kim, Research Engineer

SENA TECHNOLOGIES.Inc January 9, 2023, Applicant: SENA TECHNOLOGIES.Inc FCC ID: S7A-SP140 / IC: 8154A-SP140 To. Whom it may concern: We, Sena Technologies,Inc. declare that when equipped, the distance between antenna and one’s head surface is 23.8mm. Seunghyun Kim, Research Engineer

SENA TECHNOLOGIES.Inc 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, South Korea Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: S7A-SP140 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description Part List [SP140] BLK [SP140] SCH [SP140] OpDes [SP140] Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name External Photos Internal Photos Test Setup Photos Manual [SP140] EXT Photo [SP140] INT Photo [SP140] Test Setup Photo [SP140] Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, Seunghyun KIM / Research Engineer

SENA TECHNOLOGIES.Inc 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, South Korea Jan 11, 2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Letter of Authorization We, the undersigned, hereby authorize Yong-Min, Won of EMC Labs Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: S7A-SP140 / IC: 8154A-SP140 including signing of all documents relating to these matters. Any and all acts carried out by Yong-Min, Won of EMC Labs Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from SENA TECHNOLOGIES.Inc “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Seunghyun KIM / Research Engineer

USB Charging Port

SENA_SP140_Label & Location Rear Side Label Location

Internal Battery BT Antenna MESH Antenna 1 MESH Antenna 2

Model Name : FCC ID : (mm)(dBm)(dB)(dBm)(mW) 24026.316.814.803.00PASS 24416.306.804.793.00PASS 24806.196.694.673.00PASS 24026.306.804.793.00PASS 24416.286.784.763.00PASS 24806.166.664.633.00PASS 24026.977.475.583.00PASS 24416.917.415.513.00PASS 24806.837.335.413.00PASS 24022.272.771.893.00PASS 24422.282.781.903.00PASS 24802.182.681.853.00PASS 24109.079.579.063.00PASS 24458.749.248.393.00PASS 24758.088.587.213.00PASS 0.5908 0.5515 0.4767 MESH 23.80± 0.50 BT LE 23.80± 0.50 0.1232 0.1245 0.1226 8DPSK 23.80± 0.50 0.3637 0.3616 0.3578 π/4DQPSK 23.80± 0.50 0.3117 0.3128 0.3067 Standalone SAR Test exclusion thresholds for 100MHz to 6GHz at test separation distance ≤ 50 mm LimitResult GFSK 23.80± 0.50 0.3124 0.3142 0.3088 Modulation Frequency (MHz) Min. Test separation distance Measured Maximum Average power Tune-up tolerance Max. Power with tune-up tolerance S7A-SP140Separation distance : 23.8 mm MPE Calculation KDB 447498 - 4.3.1 a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where - f(GHz) is the RF channel transmit frequency in GHz - Power and distance are rounded to the nearest mW and mm before calculation - The result is rounded to one decimal place for comparison SP140Device Category : Portable device

2018.04.24 RA-N0211-16 APPROVAL SHEET MODEL: SENA_10A Antenna layout ReviewConsentApproval Messrs. SENA Technology Co.,Ltd RadiNa Co. ,Ltd TEL:+82-2-463-0373 FAX:+82-2-463-0374 PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page2 RADINA. Co., LTD Table of contents 1.Revision History 2.Product Information 2.1 General Features 2.2 Electrical Specifications 3. Electrical Characteristics 3.1 VSWR 3.2 Smith Chart 3.3 3D-PLOT 3.4 2D-GAIN 4. Passive Measurement PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page3 RADINA. Co., LTD 1.Revision History NO.BeforeAfterReasonDate 1 2 3 4 5 6 7 8 9 10 11 12 13 PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page4 RADINA. Co., LTD 2.Product Information 2.1 General Features PART NUMBERGradiANT ANTENNA TYPEDipole Antenna APPLICATIONSBluetooth 2.2 Electrical Specifications Frequency Range1 (TX)2400MHz~2485MHz Frequency Range1 (RX)2400MHz~2485MHz IMPEDANCE50 V.S.W.R TX 2400MHz2485MHz 5↓5↓ RX 2400MHz2485MHz 5↓5↓ RADIATION PATTERNOmni-directional POLARIZATIONLinear PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 5 RADINA. Co., LTD 3. Electrical Characterristics 3.1 VSWR 3.2 SMITH CHART PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 6 RADINA. Co., LTD 3.3 3D-PLOTs 2400MHZ 2445MHZ 2485MHZ PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 7 RADINA. Co., LTD 3.4 2D-GAIN 2400MHZ 2445MHZ 2485MHZ PRODUCT APPROVAL SHEET FPSNT004DB7 MODEL NAMEREV.1.0Page 8 RADINA. Co., LTD 4. Passive Measurement 12345678910 Frequency(MHz) 2400240524102415242024252430243524402445 Efficiency(dB) -1.68-1.80-1.94-1.86-1.90-1.74-1.75-1.73-1.75-1.59 Efficiency(%) 67.8966.0964.0165.1264.6466.9466.8267.2166.8569.31 TRG(dB) -1.68-1.80-1.94-1.86-1.90-1.74-1.75-1.73-1.75-1.59 TRG Theta (dB) -7.75-7.86-7.96-7.93-7.94-7.74-7.63-7.59-7.55-7.37 TRG Phi (dB) -2.92-3.04-3.19-3.10-3.14-3.00-3.05-3.03-3.07-2.92 UHRG(dB) -4.25-4.42-4.61-4.57-4.66-4.54-4.56-4.58-4.58-4.40 UHRG/TRG(%) 55.3654.6654.0853.6152.9252.4752.3251.7752.1652.41 H-Plane -16.43-16.82-17.16-16.92-17.80-17.65-17.12-18.21-17.86-18.24 E1-Plane, AVG(dB) -18.08-18.72-18.99-18.12-18.40-17.95-17.92-18.05-17.95-18.26 E2-Plane, AVG(dB) -2.94-3.13-3.04-3.08-3.02-2.80-2.64-2.60-2.69-2.43 Peak Gain(dB) 2.101.821.511.511.471.561.271.131.271.35 Directivity(dB) 3.783.623.443.373.363.303.022.863.022.94 Minimum Gain(dB) -16.63-16.38-17.22-17.64-16.71-17.63-18.36-20.13-19.16-17.51 11121314151617181920 Frequency(MHz) 2450245524602465247024752480248524902497 Efficiency(dB) -1.63-1.53-1.53-1.53-1.56-1.45-1.55-1.57-1.49-1.41 Efficiency(%) 68.7870.3170.3870.3869.7571.5769.9469.6771.0372.22 TRG(dB) -1.63-1.53-1.53-1.53-1.56-1.45-1.55-1.57-1.49-1.41 TRG Theta (dB) -7.31-7.16-7.20-7.11-7.04-6.96-7.15-7.13-6.95-6.87 TRG Phi (dB) -2.99-2.92-2.90-2.93-3.01-2.89-2.95-2.98-2.94-2.87 UHRG(dB) -4.44-4.30-4.33-4.30-4.31-4.18-4.23-4.24-4.12-3.99 UHRG/TRG(%) 52.3152.8552.4252.7853.1253.3853.9554.0954.5155.19 H-Plane -17.93-18.53-17.86-17.91-18.29-17.68-18.03-17.86-18.38-17.21 E1-Plane, AVG(dB) -17.62-17.53-17.37-17.48-17.12-17.14-17.82-17.86-17.59-17.27 E2-Plane, AVG(dB) -2.34-2.18-2.27-2.29-2.24-2.18-2.31-2.44-2.33-2.27 Peak Gain(dB) 1.491.641.611.811.651.861.761.891.992.20 Directivity(dB) 3.123.173.133.333.213.313.323.463.483.62 Minimum Gain(dB) -21.04-20.55-19.59-18.15-18.18-19.91-19.49-17.99-19.05-16.16 Average Efficiency-1.65dBi,68.44% Peak Gain2.10dBi

SPECIFICATION Chip Antenna Manufacturer: Sena Technologies, Inc. Part Number: SENA_009 WRITTEN CHECKED APPROVED Seunghyun Kim Seunghyun Kim September 2, 2020 Sena Technologies, Inc. 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, 06376, South Korea Tel: +82-2-576-7362 Fax: +82-2-573-7710 Website: http://www.sena.com - 2 - CHIP ANTENNA 1. SPECIFICATIONS 1.1. Electrical Specifications ITEM SPEC. Unit Frequency 2400-2485 MHz Bandwidth @ VSWR 2.5:1 100 MHz Gain Max. 0.5 dBi Polarization Linear Azimuth Beam Pattern Omni-directional Impedance 50 Ω ※ These values are measured on the matched reference test board. 1.2. Mechanical Specifications Electrode Silver Dimensions (L x W x H) 9.0 x 3.0 x 1.2 mm Operating Temperature -35 ~ +85 °C 1.3. Appearance and Dimensions - Laminate: FR-4, 1.20mm - Plating Thickness: 1.5oz (54um) - Board Thickness: 1.30mm (typ.) L 9.0 W 3.0 H 1.2 - 3 - CHIP ANTENNA 2. MEASUREMENT 2.1. Electrical Characteristic S 11 (Return Loss) B. (Smith chart) - 4 - CHIP ANTENNA 3. Radiation Data Frequency Efficiency Average Gain Max Gain Max Position Directivity Ver Hor Total Ver Hor Total 2400 MHz37.4 % -6.6 dBi-8.0 dBi-4.3 dBi-1.1 dBi-0.9 dBi0.1 dBiTheta135/Pie255 4.34 dB 2442 MHz43.0 % -6.0 dBi-7.5 dBi-3.7 dBi-0.3 dBi-0.1 dBi0.5 dBiTheta15/Pie240 4.60 dB 2485 MHz37.2 % -6.6 dBi-8.1 dBi-4.3 dBi-0.1 dBi-0.2 dBi0.2 dBiTheta135/Pie255 4.91 dB - 5 - CHIP ANTENNA 4. RELIABILITY TEST No Item Test condition Test Requirements 1 Adhesion strength . Applied force on SMD chip till detached point from PCB 1. No mechanical damage by forces applied on the right 2. Strength (F) > 5 kgf 2 Thermal Shock (Temperature Cycle) 1. 1 cycle / step 1 : -40 ± 3°C, 30 min step 2 : +85 ± 3°C, 30 min 2. Number of cycle : 10 3. Measure after left for 48 hrs min. at room temperature 1. No visual damage 2. VSWR satisfy 3 High Temperature Resistance 1. Temperature: +85 ± 5°C 2. Time : 96 hrs 3. Measure VSWR C after left for 24 hrs min. at room temperature 1. No visual damage 2. VSWR satisfy 4 Low Temperature Resistance 1. Temperature: -40 ± 5°C 2. Time : 96 hrs 3. Measure VSWR C after left for 48 hrs min. at room temperature 1. No visual damage 2. VSWR satisfy 5 Humidity (Steady Condition) 1. Humidity : 85 % RH 1. Temperature: +85 ± 3°C 2. Time : 96 hrs 3. Measure VSWR C after left for 48 hrs min. at room temperature 1. No visual damage 2. VSWR satisfy 6 ESD 1. ESD Level : 8KV 2. Mode : Contact discharge 3. Number of cycle : 100 ※ Used Ref test PCB. 1. No visual damage 2. VSWR satisfy F PCB - 6 - CHIP ANTENNA 5. SOLDERING RECOMMENDATIOS 5.1. Reflow Soldering Profile

R Report No.: KR0140-RF2212-005 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 1 / 41 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. Test Report 1. Client ᆞName : SENA TECHNOLOGIES.Inc ᆞAddress : 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, Korea 2. Use of Report : FCC & IC Approval 3. Sample Description ᆞProduct Name : S1 ᆞModel Name : SP140 4. Date of Receipt : 2022-11-15 5. Date of Test : 2022-11-29 ~ 2022-12-13 6. Test Method : FCC Part 15 Subpart C 15.247 RSS-247 Issue 2(2017-02), RSS-GEN Issue 5(2019-03) 7. Test Results : Refer to the test results This test report must not be reproduced or reproduced in any way. The results shown in this test report are the results of testing the samples provided. This test report is prepared according to the requirements of ISO / IEC 17025. Affirmation Tested by Yong-Min, Won (signature) Technical Manager Jong-Myoung, Shin (signature) Dec 29, 2022 EMC Labs Co., Ltd. (seal) R Report No.: KR0140-RF2212-005 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 2 / 41 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. Contents 1. Applicant & Manufacturer & Test Laboratory Information··································· 4 2. Equipment under Test(EUT) Information······················································· 5 3. Test Summary······················································································· 6 4. Used equipment on test·········································································· 7 5. Antenna Requirement·············································································· 8 6. 6 dB Bandwidth····················································································· 9 7. Maximum Peak Output Power···································································· 13 8. Peak Power Spectral Density····································································· 16 9. TX Radiated Spurious Emission and Conducted Spurious Emission····················· 19 10. Conducted Emission··············································································· 35 APPENDIX APPENDIX I TEST SETUP············································································ 38 APPENDIX II UNCERTAINTY·········································································· 40 R Report No.: KR0140-RF2212-005 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 3 / 41 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. Version TEST REPORT NO. DATE DESCRIPTION KR0140-RF2212-005 Dec 29, 2022 Initial Issue R Report No.: KR0140-RF2212-005 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 4 / 41 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. 1. Applicant & Manufacturer & Test Laboratory Information 1.1 Applicant Information Applicant SENA TECHNOLOGIES.Inc Applicant Address 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, Korea Contact Person Seunghyun Kim Telephone No. +82-2-573-7772 Fax No. +82-2-573-7710 E-mail [email protected] 1.2. Manufacturer Information Manufacturer SENA TECHNOLOGIES.Inc Manufacturer Address 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, Korea 1.3 Test Laboratory Information Laboratory EMC Labs Co., Ltd. Laboratory Address 100, Jangjateo-ro, Hobeop-myeon, Icheon-si, Gyeonggi-do, Republic of Korea Contact Person Yongmin Won Telephone No. +82-31-637-8895 Fax No. +82-505-116-8895 FCC Designation No. KR0140 FCC Registration No. 580000 IC Site Registration No. 28751 R Report No.: KR0140-RF2212-005 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 5 / 41 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. 2. Equipment under Test(EUT) Information 2.1 General Information Product Name S1 Model Name SP140 FCC ID S7A-SP140 IC 8154A-SP140 Rated Voltage DC 3.7 V 2.2 Additional Information Operating Frequency 2 410 MHz ~ 2 475 MHz Number of channel 14 Modulation Type OQPSK Antenna Type PCB Pattern Antenna Antenna Gain 2.1 dBi Firmware Version 1.0 Hardware Version 1.0 Test software CMD v10.0.19044.1889 2.3 Test Frequency Test mode Test Frequency (MHz) Low Frequency Middle Frequency High Frequency MESH 2 410 2 445 2 475 2.4 Used Test Software Setting Value Test Mode Setting Item Power MESH 14 2.5 Mode of operation during the test - The EUT continuous transmission mode during the test with set at Low Channel, Middle Channel, and High Channel. To get a maximum radiated emission levels from the EUT, the EUT was moved throughout the XY, YZ, XZ planes. 2.6 Modifications of EUT - None R Report No.: KR0140-RF2212-005 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 6 / 41 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. 3. Test Summary Applied FCC Rule IC Rule Test Items Test Condition Result 15.203 - Antenna Requirement Conducted C 15.247(a) RSS-247 (5.2) 6 dB Bandwidth C - RSS GEN (6.7) Occupied Bandwidth (99%) C 15.247(b) RSS-247 (5.4) Maximum Peak Output Power C 15.247(e) RSS-247 (5.2) Peak Power Spectral Density C 15.247(d) RSS-247 (5.5) Conducted Spurious Emission C 15.247(d) 15.205 & 15.209 RSS-247 (5.5) RSS-GEN (8.9 & 8.10) Radiated Spurious Emission Radiated C 15.207 RSS-GEN (8.8) Conducted Emissions AC Line Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: ANSI C63.10:2013. Compliance was determined by specification limits of the applicable standard according to customer requirements. R Report No.: KR0140-RF2212-005 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 7 / 41 This test report s…

Text truncated - open the document above for the full version.

R Report No.: KR0140-RF2212-004 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 1 / 39 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. Test Report 1. Client ᆞName : SENA TECHNOLOGIES.Inc ᆞAddress : 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, Korea 2. Use of Report : FCC & IC Approval 3. Sample Description ᆞProduct Name : S1 ᆞModel Name : SP140 4. Date of Receipt : 2022-11-15 5. Date of Test : 2022-11-29 ~ 2022-12-13 6. Test Method : FCC Part 15 Subpart C 15.247 RSS-247 Issue 2(2017-02), RSS-GEN Issue 5(2019-03) 7. Test Results : Refer to the test results This test report must not be reproduced or reproduced in any way. The results shown in this test report are the results of testing the samples provided. This test report is prepared according to the requirements of ISO / IEC 17025. Affirmation Tested by Yong-Min, Won (signature) Technical Manager Jong-Myoung, Shin (signature) Dec 29, 2022 EMC Labs Co., Ltd. (seal) R Report No.: KR0140-RF2212-004 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 2 / 39 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. Contents 1. Applicant & Manufacturer & Test Laboratory Information··································· 4 2. Equipment under Test(EUT) Information······················································· 5 3. Test Summary······················································································· 6 4. Used equipment on test·········································································· 7 5. Antenna Requirement·············································································· 8 6. 6 dB Bandwidth····················································································· 9 7. Maximum Peak Output Power···································································· 13 8. Peak Power Spectral Density····································································· 16 9. TX Radiated Spurious Emission and Conducted Spurious Emission····················· 19 10. Conducted Emission··············································································· 33 APPENDIX APPENDIX I TEST SETUP············································································ 36 APPENDIX II UNCERTAINTY·········································································· 38 R Report No.: KR0140-RF2212-004 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 3 / 39 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. Version TEST REPORT NO. DATE DESCRIPTION KR0140-RF2212-004 Dec 29, 2022 Initial Issue R Report No.: KR0140-RF2212-004 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 4 / 39 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. 1. Applicant & Manufacturer & Test Laboratory Information 1.1 Applicant Information Applicant SENA TECHNOLOGIES.Inc Applicant Address 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, Korea Contact Person Seunghyun Kim Telephone No. +82-2-573-7772 Fax No. +82-2-573-7710 E-mail [email protected] 1.2. Manufacturer Information Manufacturer SENA TECHNOLOGIES.Inc Manufacturer Address 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, Korea 1.3 Test Laboratory Information Laboratory EMC Labs Co., Ltd. Laboratory Address 100, Jangjateo-ro, Hobeop-myeon, Icheon-si, Gyeonggi-do, Republic of Korea Contact Person Yongmin Won Telephone No. +82-31-637-8895 Fax No. +82-505-116-8895 FCC Designation No. KR0140 FCC Registration No. 580000 IC Site Registration No. 28751 R Report No.: KR0140-RF2212-004 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 5 / 39 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. 2. Equipment under Test(EUT) Information 2.1 General Information Product Name S1 Model Name SP140 FCC ID S7A-SP140 IC 8154A-SP140 Rated Voltage DC 3.7 V 2.2 Additional Information Operating Frequency 2 402 MHz ~ 2 480 MHz Number of channel 40 Modulation Type GFSK Antenna Type Chip Antenna Antenna Gain 0.5 dBi Firmware Version 1.0 Hardware Version 1.0 Test software Lab Test Tool V2.9.1 2.3 Test Frequency Test mode Test Frequency (MHz) Low Frequency Middle Frequency High Frequency BLE 2 402 2 442 2 480 2.4 Used Test Software Setting Value Test Mode Setting Item Power BLE 43 2.5 Mode of operation during the test - The EUT continuous transmission mode during the test with set at Low Channel, Middle Channel, and High Channel. To get a maximum radiated emission levels from the EUT, the EUT was moved throughout the XY, YZ, XZ planes. 2.6 Modifications of EUT - None R Report No.: KR0140-RF2212-004 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 6 / 39 This test report shall not be reproduced except in full, Without the written approval. 본 시험성적서는 (주)ABCD의 서면 동의 없이 무단 전제 및 복사를 할 수 없습니다. 3. Test Summary Applied FCC Rule IC Rule Test Items Test Condition Result 15.203 - Antenna Requirement Conducted C 15.247(a) RSS-247 (5.2) 6 dB Bandwidth C - RSS GEN (6.7) Occupied Bandwidth (99%) C 15.247(b) RSS-247 (5.4) Maximum Peak Output Power C 15.247(e) RSS-247 (5.2) Peak Power Spectral Density C 15.247(d) RSS-247 (5.5) Conducted Spurious Emission C 15.247(d) 15.205 & 15.209 RSS-247 (5.5) RSS-GEN (8.9 & 8.10) Radiated Spurious Emission Radiated C 15.207 RSS-GEN (8.8) Conducted Emissions AC Line Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: ANSI C63.10:2013. Compliance was determined by specification limits of the applicable standard according to customer requirements. R Report No.: KR0140-RF2212-004 EMCLabs-QPF-26-25 [Enactment_00 / 2022. 09. 07] Page 7 / 39 This test report shall not b…

Text truncated - open the document above for the full version.

Below 30 MHz Below 1 GHz Above 1 GHz Conducted Emission
