Model: SP58 Charging Red LED: Charging Blue LED: Fully charged Power On/Off Power On : Rotate while pressing the Jog dial clockwise for 1 second. Power Off : Press and Hold the Phone Button and Jog Dial for 5 sec Volume Adjustment Increase/Decrease the volume : rotate the Jog dial clockwise/counterclockwise. Phone Pairing 1. Rotate while pressing the Jog dial clockwise for 5 seconds when the helmet is turned off. 2. By rotating the Jog dial, you will hear the voice prompt, “Phone pairing” 3. Search for Bluetooth devices on your mobile phone. Select the OUTRUSH in the list of the devices detected on the mobile phone. 4. Enter 0000 for the PIN. Some mobile phones may not ask for the PIN. Music Operation Play or pause music:Press and Hold the Jog Dial for 1 second. Track forward/back: Rotate while pressing the Jog dial clockwise/counterclockwise. Mobile Phone Call Making and Answering Answering/Ending a call: Tap the Jog dial Rejecting a call: Press and Hold the Jog Dial for 1 seconds. Intercom Pairing 1. Rotate while pressing the Jog dial clockwise for 5 seconds when the helmet is turned off. 2. By rotating the Jog dial, you will hear the voice prompt, “Intercom Pairing” 3. Any one of the two headset users must tap the Jog dial. Intercom Start/End Start/End : Tap the Jog dial. Radio On/Off Turn on/Turn off the FM radio: Press and Hold the Jog dial for 3 seconds. Radio Seek Stations Seek up/down stations: Rotate while pressing the Jog dial clockwise/counterclockwise Configuration Rotate while pressing the Jog dial clockwise for 5 seconds. Troubleshooting Factory Reset If you want to restore the OUTRUSH to factory default settings, use the Factory Reset. 1. Rotate while pressing the Jog dial clockwise for 5 seconds. 2. By rotating the Jog dial, you will hear the voice prompt, “Factory Reset” 3. Tap the Jog Dial. Certification and Safety Approvals FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antennae -Increase the separation between the equipment and the receiver -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC RF Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. The antenna used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. When equipped, the distance between antenna and one’s head surface is 36mm. FCC Caution Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. Certification et homologation de sécurité Déclaration de conformité FCC Cet appareil est en conformité avec la partie 15 des règles de la FCC. Son fonctionnement est soumis aux deux conditions suivantes : (1) Cet appareil ne doit pas créer d’interférences préjudiciables et (2) Cet appareil doit accepter toutes les interférences reçues, y compris celles qui pourraient entraver son bon fonctionnement. Cet équipement a été testé et jugé conforme aux limites pour un appareil numérique de classe B, conformément à la partie 15 des règles de la FCC. Ces limites sont conçues pour fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère et utilise de l’énergie radio fréquence et, s’il n’est pas installé et utilisé conformément. aux instructions, il peut occasionner des interférences nuisibles au niveau des communications radios. Cependant, il n’existe aucune garantie que ces interférences ne se produiront pas dans une installation particulière. Si cet équipement génère des interférences nuisibles à la réception de la radio ou de la télévision (ce qu’il est possible de déterminer en mettant l’équipement hors tension, puis sous tension), l’utilisateur est invité à suivre une ou plusieurs des mesures suivantes pour corriger le problème des interférences en prenant l’une des mesures suivantes : -Modifier l’emplacement ou l’orientation de l’antenne de réception. -É loigner l’appareil du récepteur. -Brancher l’appareil sur une prise située sur un circuit différent de celui du récepteur. -Consulter le revendeur ou un technicien expérimenté pour obtenir de l’aide. É noncé FCC sur l’exposition aux radiations RF Cet équipement est conforme aux réglementations FCC d’exposition aux radiations définies pour un environnement non contrôlé. Les utilisateurs doivent respecter les instructions d’exploitation spécifiques pour répondre aux exigences de conformité sur l’exposition aux RF. L’antenne utilisée pour cet appareil ne doit pas fonctionner en même temps qu’une autre antenne ou émetteur, sauf s’il y a conformité av…

Text truncated - open the document above for the full version.

SENA TECHNOLOGIES.Inc Jan 28 th , 2020 Applicant: SENA TECHNOLOGIES.Inc FCC ID: S7A-SP58 / IC: 8154A-SP58 To. Whom it may concern: We, Sena Technologies,Inc. declare that when equipped, the distance between antenna and one’s head surface is 35.8mm. Seunghyun Kim, Research Engineer

SENA TECHNOLOGIES.Inc Feb 04 th , 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370a Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Kenneth Kim of NCT Co.,Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: S7A-SP58 / IC : 8154A-SP58 including signing of all documents relating to these matters. Any and all acts carried out by Kenneth Kim of NCT Co.,Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from SENA TECHNOLOGIES.Inc. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Seunhyun Kim / Reasearch Engineer

SENA TECHNOLOGIES.Inc Rev 11/20/07 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: S7A-SP58 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram [SP58] BLK Part list [SP58] Part List Schematics [SP58] SCH Operational Description [SP58] OpDes The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name Test Set-up Photo [SP58] Test Set-up Photo External Photo [SP58] EXT Photo Internal Photo [SP58] INT Photo User Manual [SP58] Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, Seunhyun Kim / Reasearch Engineer

SENA_SP58_Label & Location

Internal Bluetooth Module Antenna

1. Regulation 580056 mW71 mW85 mW97 mW106 mW Frequency (MHz) 245083 mW123 mW173 mW235 mW309 mW 350086 mW124 mW170 mW225 mW290 mW 83580 mW92 mW105 mW117 mW130 mW 190099 mW153 mW225 mW316 mW431 mW ≤300 223 mW254 mW284 mW315 mW345 mW 450141 mW159 mW177 mW195 mW213 mW 58001 mW6 mW15 mW27 mW41 mW Exemption Limits (mW) At separation distance of 30 mm At separation distance of 35 mm At separation distance of 40 mm At separation distance of 45 mm At separation distance of 50 mm 24504 mW7 mW15 mW30 mW52 mW 35002 mW6 mW16 mW32 mW55 mW 83517 mW30 mW42 mW55 mW67 mW 19007 mW10 mW18 mW34 mW60 mW ≤300 71 mW101 mW132 mW162 mW193 mW 45052 mW70 mW88 mW106 mW123 mW RF EXPOSURE The SAR exclusion table from RSS-102 issue 5 is reproduced below: Table 1: SAR evaluation – Exemption limits for routine evaluation based on frequency and separation distance Frequency (MHz) Exemption Limits (mW) At separation distance of ≤5 mm At separation distance of 10 mm At separation distance of 15 mm At separation distance of 20 mm At separation distance of 25 mm Copyright ⓒ 2020. Lab-T, Inc. Page :1 / 3 RF EXPOSURE KDB447498 was used as the guidance. SAR test exclusion considerations Step.1 For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion threshold are determined by the following : [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Step.2 For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)· (f(MHz)/150)]} mW, for 100 MHz to 1500 MHz {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·10]} mW, for > 1500 MHz and ≤ 6 GHz Step.2-1 Step.2-2 The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below Copyright ⓒ 2020. Lab-T, Inc. Page :2 / 3 ( = 50.12mW f(GHz) : the RF channel transmit frequency in GHz RF Exposure Compliance Issue Therefore, EUT is not required the SAR Evaluation. =2. 19P(mW) : Max tuneup Power (mW) R : Distance to the center of the radiation of the NOTE : f(GHz) was used as worst case is highest frequency.antenna36.00mm ) Estimated SAR at the specific separation - S= [(P(mW) / R)] X [√f(GHz)] - NOTE =[(50.12/36.00)]X[√( 2.48 )]S : Maximum Estimated SAR =33.19mW - PdBm- NOTE =50.12mW =17.00dBm+-1.79dBiP : Max tuneup Power (dBm) =15.21dBmG : Maximum Peak Antenna Gain (dBi) - Maximum Peak Antenna Gain :-1.79dBi - Maximum Output Power for the Calculation :17.00 dBm The EUT will only be used with a separation of 50 millimeters or lesser between the antenna and the body of the SAR Exclusion calculation for this exposure is shown below. - EIRP=P + G- NOTE (Maximum :17.00 dBm&Minimum :15.00 dBm) - Target Power & Tolerance :16.00 dBm&±1.00 dB SAR test exclusion considerations : GFSK 17.00 P : Max tuneup Power (dBm) - Measured RF Maximum Output Power(avg.) :16.00 dBm = - Frequency Range :2 402 MHz~2 480 MHz Copyright ⓒ 2020. Lab-T, Inc. Page :3 / 3
